LS tractor MT784 User manual

LS TRACTOR
OPERATOR'S MANUAL
MT784 MT794 MT7101

CALIFORNIA
Proposition 65 Warning
Diesel engine exhaust and some of its constituents are known
to the State of California to cause cancer, birth defects, and
other reproductive harm.

CONTENTS
1. General Notices for Safety
1-1. Note to the owner – General information ·····················1-1
(1)Beforeusingthetractor···································1-3
(2) Manual scope and required training level · · · ····················1-5
(3)MetricandImperialunitsabbreviations························1-7
(4) Product Identification Number (PIN)·························1-9
(5) Operator's manual storage ·······························1-11
(6)Tractororientation··································1-12
1-2. Safety Precautions (Read this for safety before using)
(1)Noticesbeforeusingthetractor····························1-13
(2)NoticeswhenstartingEngine ······························1-17
(3)Noticeswhileoperating/usingthetractor······················1-18
(4) Notices when connecting Implement ·························1-20
(5)Noticeswhentowingthetractor····························1-21
(6)Noticeswhentransportingthetractor························1-21
(7)Noticeswhenservicingthetractorafterwork ···················1-22
(8) Notices when handling Diesel Fuel ··························1-23
(9)Noticeswhenleavingthetractor····························1-24
(10)NoticesrelatingtoToxicsubstances·······················1-24
(11) Tractor stability · · · ····································1-25
(12)Ecologyandtheenvironment·····························1-28
(13)Symbols············································1-30
(14)SafetyDecals·······································1-31
(15)InstructionalDecals···································1-38
1-3. Long-term storage
(1) Preparation for storage ··································1-43
(2) Check & Maintenance during storage ························1-44
(3)PreparationforReuse···································1-45
2. Instruction for Safe Operation
(1)Thenameofeachpart····································2-1
2-1. Boarding and Exiting the tractor
(1)Boardingthetractor······································2-3
(2)Seatadjustment·········································2-4
(3)Seatbelt··············································2-6
(4)Tiltingsteeringwheel·····································2-7
(5)Ventilation(Cabinonly)·······························2-7
(6)Exitingthetractor········································2-8
2-2. Safety device
(1) Hood (Bonnet)·········································2-10

CONTENTS
3. Instruments and Controls
3-1. Instrument Panel and Front controls
(1) Instrument panel ········································3-2
(2)SCRinducementstrategy–Generalinducementstrategy···········3-17
(3)Keyswitch············································3-22
(4) Throttle pedal · · · ······································3-22
(5) Clutch pedal (MEC models only)·····························3-23
(6) Brake pedals ··········································3-24
(7)Shuttlelever(MECmodelsonly)·····························3-25
(8)Combinationlightswitch··································3-26
(9)Hazardwarninglightswitch································3-29
(10) Grille work light switch (optional)····························3-30
(11)Beaconlampswitch(Cabin)····························3-31
(12)4WDswitch·····································3-32
(13) Differential lock switch (Roll-bar type)·······················3-33
(14) 540E PTO switch (Roll-bar type, If fitted) · · · · · · ···············3-34
(15)DeSOxswitch·······································3-35
3-2. Right-hand controls and Cabin pillar
(1)Throttlelever··········································3-38
(2)Maingearshiftlever(MEC,PSSmodelsonly)····················3-39
(3)Worklightswitch·······································3-40
(4)Windowwiper&wiperswitch(Cabintype) ······················3-41
(5)Electricalpoweroutletsocket(Cabintype) ·····················3-42
(6) Indoor light (Cabin type)··································3-43
(7)Audioplayer(Cabintype)·································3-43
(8)Differentiallockswitch(Cabintype)··························3-44
(9)PTOswitch································ ··········3-45
(10)PTOmodeswitch(iffitted)·······························3-46
(11) 540E PTO switch (Cabin type, if fitted)·······················3-47
(12) Engine Speed Cruise control (ESC) switch ········· ··········3-48
3-3. Left-hand controls and Seat
(1) Range gear shift lever (MEC, PSS models only) · · · · · · · ··········3-50
(2)Creepergearlever(iffitted)·······························3-52
(3)PTOgearlever········································3-52
(4)GSPlever···········································3-53
(5)Parkingbrakelever·····································3-53
(6) Passenger seat (Cabin type, if fitted) · · · · ·····················3-54
(2) Fender··············································2-10
(3)PTOSafetycoverandprotectioncap·························2-10
(4)Roll-OverProtectiveStructure(ROPS)(optional)················2-11

CONTENTS
(7)Beaconlampswitch(Roll-bartype,iffitted)···················3-54
3-4. Power Shuttle System (PSS) (optional)
(1)Powershuttlelever(PSS)·································3-55
(2) Clutch pedal (PSS) · · · · · · · · · · · · · · · · · · · · · · · · · · ············3-57
(3)Clutchbutton(PSS)······································3-58
(4)HI-LOselectswitch(PSS)·································3-59
(5)Shiftmodeadjustmentdial(PSS)·························3-60
(6) Error Diagnosis code (PSS) ·······························3-61
3-5. Power Shift Transmission (PST) (optional)
(1)Powershuttlelever(PST)·································3-62
(2)Maingearshiftlever(PST)·································3-64
(3) Range gear shift lever (PST) · · ·····························3-65
(4) Clutch pedal (PST)······································3-66
(5)Shiftmodeadjustmentdial(PST)·························3-67
(6) Error Diagnosis code (PST) · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-68
3-6. Hydraulic System
(1)Safetyprecautions ·····································3-70
(2) Steering system · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-71
(3)Hydraulicliftcontrol(MHL)(iffitted)··························3-72
(4)RemotecontrolleverandQuickcoupler(optional) ···············3-75
(5)Joysticklever(optional) ··································3-77
(6)Autoliftcontrol(MHL)····································3-78
(7)HydraulicSystemDiagram ································3-79
4. Operation and Work
4-1. How to handle new tractor
(1)Checkpoints··········································4-1
(2) Notices in handling new tractor (Engine brake-in procedure) · ········4-1
4-2. Engine start and stop
(1)Enginestart············································4-2
(2)Startincoldweather·····································4-3
(3)Enginestop············································4-4
4-3. How to drive and stop
(1) Transmission Warm-up in cold weather · · ······················ 4-5
(2)Howtodrive·········································· 4-6
(3) Changing speed · · ······································4-8
(4)EmergencyStop········································4-9
(5)Stoppingtractor·········································4-10
(6)Parking·········································4-11
(7)HandlingTurbocharger(iffitted)····························4-11

CONTENTS
5. Lubrication and Maintenance
5-1. General information ·····································5-1
(1)TighteningTorquefornormalassembly···················· 5-2
(2) Standard torque data for hydraulics · · · · · ······················5-4
(3)Generalspecification-Dieselfuel····························5-7
(4)Biodieselfuel···········································5-8
(5)Refuelingthetractor·····································5-10
(6) Change engine coolant to Organic Acid Technology (OAT) coolant ····5-11
(7) Access for maintenance ··································5-12
5-2. Maintenance Chart ·····································5-13
5-3. Lubricants and Capacity ································5-15
5-4. First 50 hour check ····································5-16
5-5 When the warning indicator lights
(1)Fuelfilterwarningindicator································5-17
(2)Engineoilpressureindicator······························5-18
(3)Batterychargingindicator································5-18
5-6. Checking before Starting (Daily check)
(1)Engineoil············································5-19
(2)Fueltank&DEF/ureatank································5-20
4-4. Transport on public roads
(1)Safetyruleswhendrivingtractorontheroads ·················· 4-12
(2)Lightoperation········································ 4-13
(3) 7-Pole connector (optional)································4-15
(4)Noticeswhentowingthetractor·····························4-16
(5)Noticeswhentransportingthetractor·························4-18
4-5. Field Operations
(1)Rear3-pointlinkage·····································4-19
(2)Powertake-off(PTO)operation·····························4-23
(3)HitchandDrawbar(optional)·······························4-27
(4)Technicallymaximumpermissiblemass······················4-28
(5) Tires and Load capacity ··································4-29
(6)AdjustingWheeltracksandtirereplacement···················4-30
(7) Using Front-end loader (if fitted)···························4-34
(8)AdjustingSteeringangle·································4-37
(9) Recommended Maximum Specification of Implements · · · · · · · · · · · 4-38
(10)BallastingWeights(optional)······························4-39
(11)Workinginhazardousarea·······························4-42
4-6. Driving Speed········································4-43

CONTENTS
(3) Instrument panel & Indicators · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 5-23
(4)Turnsignallights,LightsandHorn··························5-24
(5)Enginecoolant········································5-24
(6) Air cleaner··································5-25
(7)CleaningRadiatorandRadiatorscreen····················5-26
(8)Tireairpressureanddamage······························5-26
(9)TighteningstateofBoltsandNutsofeachpart ·················5-27
(10) Adjustment of Clutch pedal play ····························5-28
(11) Adjustment of Brake pedal play ····························5-29
5-7. Every 50 hour check
(1)Lubricatinggreasenipple·································5-30
(2)CleaningRadiatorandRadiatorscreen·······················5-30
(3)CheckingTransmissionoil·································5-31
(4)CheckingFrontaxleoil···································5-31
(5)Batterycheck··········································5-32
(6) Air cleaner (Dry type)····································5-32
(7)HydraulichosesandLeakage······························5-32
(8)CleaningCabinairfilter···································5-32
5-8. Every 300 hour check
(1)ReplacingHydraulicOilFilter······························5-33
(2)ReplacingPowershuttleoilfilter(PSSmodelsonly)···············5-33
(3)ReplacingPowershiftoilfilter(PSTmodelsonly)···············5-34
(4)CheckingBrakeoil······································5-34
(5)TensionofFanbelt······································5-35
(6)Toe-in···············································5-35
(7)In-linepressurefilter(optional)······························5-35
5-9. Every 600 hour check
(1)ReplacingEngineoilandFilter······························5-36
(2) Changing Front axle oil ···································5-37
(3) Changing Transmission oil ································5-38
(4)ReplacingFuelfiltercartridge······························5-38
(5)CheckingNozzleinjectionpressure··························5-39
(6)ReplacingCabinairfilters·································5-39
5-10. Every 1200 hour or 1 year check
(1) Replacing Air cleaner element (Dry type) · · · · ··················5-40
5-11. Every 1800 hour check
(1)ReplacingBlow-byfilterelement····························5-41
5-12. Every 3000 hour or 2 year check
(1)ReplacementofEngineCoolant····························5-42
(2)ReplacingEnginefanbelt····························5-45
(3)ReplacingDEFfilterelement·······························5-46

CONTENTS
6. Air Conditioning System (Cabin type)
6-1. The name of each part of cooling and heating system ···········6-1
6-2. How to use air conditioner and heater
(1) How to operate air conditioner and heater······················ 6-2
(2)Airdirectioncontrol········ ······························6-2
6-3. Every 6 month check
(1)CheckingRefrigerantamount·······························6-3
(2) Cleaning Condenser and Radiator screen ······················6-3
(3) Checking Leakage · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 6-3
(4)Belttensionadjustment···································6-4
(5)Cleaningandreplacingcabinairfilters························6-4
6-4. Every year check
(1)Compressorcheck·······································6-5
(2)Controlswitchcheck ·····································6-5
6-5. Troubleshooting ·······································6-6
6-6. System Diagram ········································6-8
5-13. General maintenance (When required)
(1)Air-bleedingfromFuelsystem······························5-49
(2)Air-bleedingfromBrakeline·······························5-51
(3)Air-bleedingfromClutchline(MECmodelsonly)··················5-51
(4)Fuse&Mainfuse·······································5-52
(5) Battery handling and Notices ······························5-56
(6)Alternatoranddrivebelt-Check····························5-60
(7) Tail/brake light and Turn signal light bulb - Replace (Bulb type)······5-61
(8)Headlightbulb-Replace································5-63
(9)Touch-uppaintcolor ··································5-64
5-14. Troubleshooting ······································5-65
5-15. Engine manufacturer’s warranty ·························5-70
7. Pneumatic System (optional)
7-1. Cleaning Air-Gun (optional)
(1)Air-gunsystemconfiguration····························7-1
(2) How to use Air-gun system · · ··························7-2
(3)CheckingandrepairingAir-gunsystem·····················7-3
8. Dimension and Specification ······················ 8-1

1 -1
◆Safety Mark Description
- In the places where the cautions in usage are required, the marks such as “DANGER”,
“WARNING”, “CAUTION” are found.
- You should comply with the description marked on the decals attached on the product or the contents
marked with safety mark in this Operator's Manual.
Warning - This indicates a potential dangerous situation that may cause a serious
injury or death if not avoided.
Caution - This indicates a potential dangerous situation that may cause a light
injury or damage to the properties if not avoided.
Notice - This indicates the instructions for right use for the safety of persons or
products.
Danger - This indicates a fatal dangerous situation that may cause a serious injury
or death if not avoided.
1-1. Note to the owner – General information
▶Illustrations in this manual may show protective shielding open or removed
to better illustrate a particular feature or adjustment.
Replace all shields before operating the tractor.
Failure to comply could result in death or serious injury.
Warning
Operator’s manual
Please have all operators read this manual carefully and keep this manual available for ready
reference. Read this manual to make sure that you have a complete understanding of how to
operate this tractor safely, correctly, and for the most effective performance of the tractor.
NOTE: This operator’s manual may be available in other languages; see your authorized local
dealer for ordering.
This manual contains important information concerning the adjustment and maintenance of your
new equipment.
NOTE: Some images of the tractor in this manual may differ slightly in some detail. Any variations
will be similar enough for you to understand the information or instructions.
Throughout this operator’s manual, references to the right-hand and left-hand sides of the tractor
are determined by facing the forward operating direction of travel.
This is the safety alert symbol. The safety alert symbol alerts you to potential
personal injury hazards. Obey all safety messages that follow this symbol to avoid
possible death or injury.
1. General Notices for Safety
Notice
Caution
Warning
Danger

1 -2
Your authorized local dealer and service
Your authorized local dealer has performed a pre-delivery setup, inspection, and testing to make
sure that your tractor operates at its best performance level.
Your authorized local dealer will instruct you in the general operation of your new equipment. Your
dealer's staff of factory-trained service technicians will be glad to answer any questions that may
arise regarding the operation of your tractor.
Your authorized local dealer carries a complete line of genuine service parts. These parts are
manufactured and carefully inspected to ensure high quality and accurate fitting of any necessary
replacement parts. Be prepared to give your dealer the model and product identification number of
your new equipment when ordering parts. Locate these numbers now and record them below.
Refer to the 'General Information' section of this manual for the location of the model and product
identification numbers of your tractor.
ATTENTION: The engine and fuel system on your tractor is designed and built to government
emission standards. Tampering by dealer, customers, operators, and end users is strictly prohibited
by law. Failure to comply could result in government fines, rework charges, invalid warranty, legal
action, and possible confiscation of the tractor until rework to original condition is completed.
Engine service and/or repairs must be done by a certified technician only!
Improvements
We are continually striving to improve its products. We reserve the right to make improvements or
changes when improvements or changes become practical and possible to do so, without incurring
any obligation to make changes or additions to the equipment sold previously.

1 -3
(1) Before using the tractor
※Must read and understand this operator’s manual carefully and
always refer to information and prescriptions outlined in this manual
to prevent all potential health and safety risks.
◆General information for intended use
Your tractor is designed and manufactured to pull, to carry, to supply the power a variety of mounted
or towed equipment for agriculture. Do not use the product for other purposes than intended by the
manufacturer and outlined in this manual. Do not use this tractor for light/heavy forestry applications.
Do not use the product beyond its limits of terrain gradient and stability than outlined in this manual.
Using the tractor beyond these limits may cause a overturning accident.
Do not use the tractor on higher speeds than allowed by the load of the tractor and road condition.
Always choose a suitable driving speed to maintain the stability of the tractor.
Do not use the tractor near or on soft verges of canals and brooks or banks and verges that are
undermined by rodents. The tractor may sink sideways and roll-over.
Do not use the tractor on brittle bridge heads and poor bridge floors. These constructions may
collapse and cause overturning of the tractor. Always check out the condition and carrying
capacity of bridges and ramps prior to engage.
Do not use the tractor without wearing the seat belt and Roll-Over Protective Structure (ROPS)
during operations where roll-over or tip-over hazards exist. The ROPS will only be fully effective when
the driver remains attached to his/her seat.
Do not use equipment mounted on the tractor which is not correctly matching and firmly fixed.
Such equipment may increase the risk for roll-over and hit the tractor when coming loose.
Do not use the tractor in combination with equipment arbitrary, without having consulted the
specific operator’s manual provided with the equipment. This manual alone cannot provide you
with all the information about safety operation of the combination.
Do not use the tractor beyond its limits of dynamic stability. High speed, abrupt maneuvers, and
fast and short cornering will increase the risk of roll-over.
Do not use the tractor for overloaded pulling work, in cases where you don’t know if the load will
yield, for instance when pulling stumps. The tractor may flip over when the stump is not yielding.
Be extremely cautious when working with the tractor on forage silos without lateral concrete
walls. A wide track setting may improve the lateral stability of the tractor.
Be cautious that the center of gravity of the tractor may increase when the front-end loader is
loaded or the three-point linkage are raised. In these conditions, the tractor may roll-over earlier than
expected.
Do not step down from the tractor without shutting down the PTO, shifting the transmission
to neutral and applying the parking brake.

1 -4
Never remove or modify or change the driver’s protection device or safety device arbitrary.
Any unauthorized modifications made to this tractor can have serious consequences. Consult an
authorized dealer on changes, additions, or modifications that may be required for this tractor. Do not
make any unauthorized modifications.
You must take the necessary precautions to always be aware of the possible presence of
bystanders, certainly when maneuvering in confined areas. Keep people away from the tractor
during work. Pay the necessary attention while operating next to public roads or footpaths. Thrown
objects can get projected outside the field and hit unprotected people like bikers or pedestrians. Wait
until it is clear of bystanders.
Do not violate the local traffic rules related to public roads and highways.
Do not allow riders on the tractor; do not allow people standing on the access way or step to the
cab when the tractor is moving. Your view to the left will be obstructed and a rider risks to fall from the
tractor during unforeseen or abrupt movements.
This tractor has only one operator station and is a one man operated vehicle. Other people on or
around the tractor during normal operation are not allowed.
Always stay clear from implements operating area and especially do not stand between tractor
and trailed vehicle either three-point linkage when operating lift controls; ensure no bystanders
are near these operating areas.
This tractor may be equipped with a number of sensors to control safety functions. Do not attempt
to bypass any function on the tractor. You will be exposed to serious hazards, and moreover, the
behavior of the tractor may become unpredictable.
The manufacturer will not be responsible for the damage or safety problems caused by maintenance
or repair with non-genuine parts. It must be requested to use the genuine parts.
When cleaning the tractor by using high pressurized water, do not inject water directly to the
electronic parts, wiring, air intake pipe, hot engine or muffler inside the bonnet.
Maintenance and repair of the tractor is performed by skilled technical experts with the proper
tools authorized by the manufacturer.
Pay attention to overhead power lines and hanging obstacles. High voltage lines may require
significant clearance for safety.
Do not operate the tractor during an electrical storm. (Lightening strikes)
For damage or accidents caused by misuse or operation in violation of these rules, the manufacturer
and its distributors will not have any responsibility and warranty.
Keep this operator’s manual for future reference at hand (on the tractor).

1 -5
(2) Manual scope and required training level
Introduction to this manual
This manual gives information about the use of
your tractor as intended and under the
conditions foreseen by manufacturer during
normal operation, routine service, and
maintenance.
This manual does not contain all the
information that relates to periodic service,
conversions, and repairs that only trained
service personnel can perform. Some of these
activities may require appropriate facilities,
technical skills, and/or tools that manufacturer
does not supply with the tractor.
The manual contains the chapters as shown on
the Contents pages.
Normal operation
Normal operation consists of the use of this
tractor for the purpose manufacturer intends by
an operator that:
• Is familiar with the tractor and any mounted
equipment or towed equipment.
• Complies with the information on operation
and safe practices as specified by
manufacturer in this manual and by the signs
on the tractor.
Normal operation includes:
• Preparation and storage of the tractor.
• Addition and removal of ballast.
• Connection and disconnection of mounted
equipment and/or towed equipment.
• Adjustment and configuration of the tractor
and equipment for the specific conditions of
the job site, field, and/or crop.
• Movement of components into and out of
working positions.
Routine service and maintenance
Routine service and maintenance consists of
the daily activities necessary to maintain the
proper tractor function. The operator must:
• Be familiar with the tractor characteristics.
• Comply with the information on routine
service and safe practices as specified by
manufacturer in this manual and by the signs
on the tractor.
Routine service can include:
• Fueling
• Cleaning
• Washing
• Topping up fluid levels
• Greasing
• Replacing consumable items such as light
bulbs
Periodic service, conversions, and
repairs
Periodic service consists of activities that are
necessary to maintain the expected life of your
tractor. These activities have defined intervals.
Trained service personnel familiar with the
tractor characteristics must perform these
activities at the defined intervals. Trained
service personnel must comply with the
information on periodic service and safe
practices as partly specified by manufacturer in
this manual and/or other company literature.
Periodic service includes:
• Oil change service for the engine, hydraulic
circuits, or transmission.
• Periodic exchange of other substances or
components as required.

1 -6
Conversion activities rebuild your tractor in a
configuration that is appropriate for a specific
job site, crop, and/or soil conditions (e.g.,
installation of dual wheels). Conversion
activities must be done:
• By trained service personnel familiar with the
tractor characteristics.
• By trained service personnel that comply with
the information on conversion as partly
specified by manufacturer in this manual,
assembly instructions, and/or other company
literature.
Repair activities restore proper function to your
tractor after a failure or degradation of
performance. Dismantling activities occur
during the scrapping and/or dismantling of the
tractor.
Trained service personnel familiar with the
tractor characteristics must perform these
activities. Trained service personnel must
comply with the information for repair as
specified by manufacturer in the service
manual.
Before you operate
Read this manual before you start the engine or
operate this tractor. Contact your authorized
local dealer if:
• You do not understand any information in this
manual.
• You need more information.
• You need assistance.
All persons training to operate, or who will
operate this tractor should be old enough to
possess a valid local vehicle operating permit
(or meet other applicable local age
requirements). These persons must
demonstrate the ability to operate and service
the tractor in a correct and safe manner.

1 -7
(3) Metric and Imperial units abbreviations
Metric unit Imperial unit
Name Symbol Name Symbol
Area
Square meter m2Square foot ft2
Square centimeter cm2Square inch in2
Square millimeter mm2Square inch in2
Electricity ampere A ampere A
voltVvoltV
Force kilonewton kN pound lb
newton N pound lb
Frequency
megahertz MHz megahertz MHz
Kilohertz kHz Kilohertz kHz
hertz Hz hertz Hz
Rotational
frequency Revolution per minute rpm Revolution per minute rpm
Length
kilometer Km mile mi
meter m foot ft
centimeter cm inch in
millimeter mm inch in
Mass kilogram kg pound lb
gram g ounce oz
Power kilowatt kW horsepower Hp or ps
watt W Btu per hour
Btu per minute Btu/hr Btu/min
Pressure or stress
(Force per area)
kilopascal kPa Pound per square
inch psi
megapascal MPa Pound per square
inch psi
bar bar Pound per square
inch psi
Kilogram per
square centimeter Kg/cm2Pound per square
inch psi
Temperature Degrees Celsius °CDegrees
Fahrenheit °F

1 -8
Metric unit Imperial unit
Name Symbol Name Symbol
Time
hour hr hour hr
minute min minute min
second s second s
Torque Newton meter N.m Pound foot lb.ft
Kilogram meter Kg.m Pound foot lb.ft
Velocity kilometer per hour km/h mile per hour mph
meter per second m/s foot per second ft/s
Volume
Cubic meter m3Cubic yard yd3
liter L Cubic inch in3
liter L US gallon US gal
cc cc Cubic inch in3
Volume per time
(flow rate) Liter per minute L/min US gallon per minute US gal/min
Sound pressure
level decibel dB decibel dB
Acronym Definition
MEC Synchro shuttle transmission
HST Hydrostatic transmission
PSS Power shuttle system
PST Power shift transmission
MHL Mechanical Hydraulic Lift
EHL Electro-Hydraulic Lift
DEF Diesel Exhaust Fluid
DPF Diesel Particle Filter
ISO International Organization for Standardization
MSDS Material Safety Data Sheet
NOx Nitrogen Oxide
PPE Personal Protective Equipment
SCR Selective Catalytic Reduction
< Less than
> Greater than
Glossary

1 -9
(4) Product Identification Number (PIN)
The tractor and major components are identified with Product Identification Number (PIN) plates.
You should supply the PIN plate data to your authorized local dealer when requesting parts or
service, and also to identify the tractor in case of theft.
1
②Engine Product Identification
Number (PIN) plate
The engine PIN plate②is located on the right-
hand side of the engine block.
2
①Product Identification Number (PIN)
plate
The tractor PIN Plate①is located on the left-
hand side of the engine frame.
This may vary depending on the market.

1 -10
③Roll Over Protective Structure
(ROPS) Product Identification
Number (PIN)
The Roll Over Protective Structure (ROPS) PIN
plate③is located on the left-hand side of the
cabin rear steel plate for cabin models, and on
the right-hand side of the ROPS cross bracket
behind the driver’s station for roll-bar models.
This may vary depending on the market.
5
④TM number and Running hours
In case of requesting service or parts from your
dealer, the dealer may need TM number④
and/or running hours⑤displayed on the
instrument panel.
3
3
4
Roll-bar
Cabin
5
MEC or PSSPST
