Ls Xcode-iu9011 User manual

XCODE-IU9011

UHF USB Reader

●Read the safety precautions for an accurate use of

the product.

●After reading the User Manual, place it in a

location for other product users to easily read it.

Safety Precautions

XCODE-IU9011 UHF USB Reader

User Manual

UHF USB Reader

2

Thank you for purchasing the XCODE Reader of the LS Industrial Systems Co., Ltd.

Safety Precautions



The safety precautions are to prevent any accidents or dangers by using the product

safely, so do comply with them.



The safety precautions are classified into 2 types –“Caution”and “Warning”–and

the respective details are as the following:



The symbols in the product and the user manual have the following meanings.

It is a symbol for you to be cautious of any dangers.

It is a symbol for you to be cautious of any electric shock that may occur.



After reading the user manual, place it in a location for other product users to easily

read it.



Before using the product, please fully read the user manual.

Caution

Do not deliver in an overload.

It may cause physical or product damages.

Input power in accordance to the conditions set in the product power rating standards.

It may cause electric shock, fire, malfunctioning and damages or deterioration to the

product.

Any cases in which severe injuries or death may occur if the instruction is

not kept

Any cases in which minor injuries or damages to the product may occur, if the

instruction is not kept.

Caution

Warning

3

Only the experts are allowed to perform the maintenance works.

It may cause physical damages and malfunctioning.

Unplug the power cord and the charger when there is a severe lightning.

It may cause lightning strike or fire.

Do not use the device near the hazardous location with potential of explosion.

It may impact the high-frequency device.

Do not disassemble or impact the product.

It may cause electric leakage or fire.

Do not use chemical substances or detergents to cleanse the reader.

It may damage the product, so wipe off using a soft cloth.

Do not place the product in fire, heat or disassemble it.

It may cause fire or explosion.

Warning

Make sure that the product is not exposed to rain or snow during the delivery.

It may degrade the product performance.

Do not store the product in a place that may wet or moist it.

It may cause dielectric breakdown or degrade the product performance.

Do not use it under high temperature or at highly wet areas.

It may damage the product or degrade the product performance.

Do not place the reader near magnetic objects including a credit card, a phone card, a

bankbook or a ticket.

The information may be damaged due to the reader magnetism.

4

Critical data must be archived or stored separately.

When repairing the product, the critical information stored in the reader may be deleted,

so make sure to perform back up. The manufacturer is not liable for any damages arising

from the data loss, so please take extra care on it.

Be careful not to drop the device.

Although the product passed the standard drop performance test, it may influence the

device life.

Do not use or store it under extreme setting.

It may impact the device performance.

Precautions for Use

(1) Delivery & Installation



Use an appropriate method to deliver the product in accordance to the weight.



Do not pile up multiple devices without conforming to the set standards.



Install in accordance to the rules set in the user manual.



Do not open the cover when delivering the product.



Do not place a heavy object on top of the product.



Use ONLY the charger with a suitable power rating.



Do not disassemble on your own, but consult with the expert.

Use the product under the following conditions.

Conditions

Description

Operating Temperature

- 10 ~ 50 ℃

Humidity

90% RH or under (No dew formation)

Storage Temperature

- 20 ~ 60 ℃

Environmental Setting

No corrosive gas, combustible gas, oil residue or dust

Altitude· Vibration

Altitude of 1000m or under · 5.9m/sec²(=0.6g) or under

Air Pressure

70 ~ 106 kPa

5

(2) Control under Test Run (Operation)



Check various program settings before operating the product.



Do not input voltage that exceeds the voltage range specified in the user manual.

(3) How to Use



Do not remodel the interior of the product.



Use the provided program and the user-convenient program.



Be careful of losing the set program and the saved data when resetting the H/W.

(4) Preventing the Malfunctioning



If the reader is damaged and cannot be controlled, there are cases in which the

device is left without caution. In such a circumstance, unplug the power and have it stored

via A/S.

(5) Disposal



Make sure that it is discarded as an industrial waste.

(6) General



The figures presented in the user manual for an accurate description may not

correspond exactly to the actual product.

6

The User Manual:

Contains information on the specification, operation, functions, maintenance and repair

of the XCODE Series Reader and this is for users with basic understanding of readers.

Carefully read the user manual for a safe, accurate use of the XCODE Reader.

7

XCODE-IU9011 UHF USB Reader?

Section 1 Basic Specifications

Product Features



Lightweight, Compact-Sized Innovative Design

XCODE-IU9011 is a 900MHZ bandwidth, micro reader module that supports the EPC Class1

GEN2. It has an excellent RFID Reader function.

Certified, Stable Performance

It obtained the KCC (Wireless Approval & Electromagnetic Wave Conformity) certificate,

prioritizing the customer‟s safety.

Outstanding Durability & Environmental-Resistance

It is designed in consideration of the RFID performance, drop and environmental resistance

properties.

1.1 Detailed RFID Specifications

Classification

Description

Material

Poly Carbonate

Weight

100g

Dimensions

95mm L x 50mm W x 12mm H

Supported tags

EPC global Gen2(ISO 1800-6C) with Anti-Collision

Host interface

USB mini-B connector, with cable terminated in A type plug

Frequency

917.3 ~ 920.3MHz

Modulation

ASK

Signals

2 color LED

Power supply

DC Voltage: 5VDC(Powered by USB Interface)

Operating

temperature:

-10C to +50C

Tag Read distance

Up to 50mm dependent on type/size of tag

Built in antenna:

Ceramic patch Antenna

8

1.2 Certification of the Telecommunication Device

Classification

Description

Device Name (Model Name)

Wireless Device for RFID/USN (XCODE-IU9011)

Certified Trade Name

LS Industrial Systems Co., Ltd

Date of Manufacture

2011.

Manufacturer/Country

LS Industrial Systems Co., Ltd/Korea

Certified ID Code

LSR-XCODE-IU9011A

1.3 Operating Frequency

No

FREQ [MHz]

0

865.0

1

865.5

2

866.0

3

866.5

4

867.0

5

867.5

6

868.0

1.4

Output Power Level

DAC

POWER LEVEL

DAC

POWER LEVEL

10

2

80

20

7

90

21

30

11

100

22

40

13

110

23

50

15

120

23

60

18

130

23

70

19

140

23

9

1.5

Product Components & Names

XCODE-IU9011_Reader Body

XCODE-IU9011_Accessory

CD Manual USB Cable

XCODE-IU9011 [90mm*50mm*11.5mm]

10

1.6

Part Names & Dimensions

Name

Functions

①Antenna

Antenna is built in to recognize the Tag.

②LED

It displays the power and Tag operations.

Green: Power, Blue: Tag Recognition

③USB

Power is supplied and the program is started through the USB

communication.

④Name Plate

It displays the basic product specification.

(Certificate No., Date of Manufacture and etc))

11

Section 2 How to Use the Product

2.1

How to Use the Product

2.1.1

USB Driver Installation

Install the USB Driver in accordance to the procedure described below.

Refer to the CD Manual for further details.

■USB Driver Installation

1. Double click on the „Device Manager General Serial Bus Controller UsbHarve.sys for

Intel RFID MAC‟.

Check „Install from a list or a specific location (Advanced)‟and then click on Next.

2. As shown above, perform a search to designate a folder that contains ‟UsbHarve.sys‟.

Then click on Next.

12

3. A search window pops up as shown above.

4. Click on Continue.

13

5. Installation is in progress as shown above.

6. When this screen is shown, the installation is completed. It completes the drive

installation.

■Test Device Connection

14

2.1.2

How to Use the XCODE-IU9011 Program

Buttons

Description

Open

Communication Port Open

Close

Communication Port Close

Select Country

Select Korea, China or Iran

Start

Tag Read Start

Stop

Tag Read Stop

Memory Bank

Select Memory Bank

Access Password

Insert Access Password

Read

Memory Bank Selection Area Read

Length

Set Memory Bank Selection Area Data Length

Write

Memory Bank Selection Area Write

Lock

Tag Lock Execution

Kill

Tag Kill Execution

Clear

Tag Data Delete

Output Level

Output Power Setting (Refer to ‘1.4 Output Power Level’)

15

Section 3 Others

3.1

Before You Think the Device is Out of Order

Trouble

Diagnosis

No USB

Recognition

Check whether the Driver in the CD is installed.

No Tag

Recognition

Check the Program Setting conditions. (National, DAC Level)

Check the Cable connection status.

Check the program Open status.

3.2

Disposal

1. The non-metal (liquid or liquefied substances) elements should be separated from the

RFID Reader conforming to the ISO 14000, and the materials that are harmful to the

environment and the materials that can be reused should be classified before disposing

them to the designated locations.

2. If there are any materials to be reused, please contact us.

3. Any materials that emit toxic gas during the incineration process may cause respiratory

diseases, so they must be discarded in the authorized location.

16

3.3

Purchase Information

Model Name

Date of Purchase

Serial No

Memo

_________________________________________________________________________

17

3.4

Quality Assurance Service Standards

3.4.1

Introduction to the Quality Assurance Service Standards

QA Related Claims

Within the

Warranty

Period

After the

Warranty

Period

Performance/Function

Troubles under a

normal operation

Repair

Possible

In case of a Defect

Free Repair

Recurring troubles

for the same defect

repaired (4th time)

Exchange the

product

Charged Repair

Repair

Impossible

Although there are

repair parts, it is not

possible to perform

the repair.

Exchange the

product

-

When the critical part must be

repaired right after the purchase

Exchange the

product

-

Performance/Function

Troubles due to the

Customer‟s

intentional negligence

Repair Possible

Charged Repair

Repair

Impossible

An abnormal

appearance cannot

be repaired; only

the performance

troubles can be

fixed

Exchange the

product after

collecting the

amount

equivalent to the

charged repair

-

3.4.2

A/S Tips

■If any abnormalities occur as using the product, reread the user manual and then contact

our customer service team by 1544-2080. We will promptly take appropriate actions.

3.4.3

Warranty Terms & Conditions

■Free A/S Service

We will repair the product free-of-charge, if the product is malfunctioning under a normal

status from the date of purchase to the warranty termination.

■Charged A/S Service

Under the following situations, we will repair the product by charging a suitable service fee

(repair cost, parts cost and etc):

18

1. The warranty period has terminated;

2. If within the warranty period;

Troubles owing to the natural disasters (fire, salt damage, gas damage, earthquake,

damage from storm and flood, lightning strike, abnormal power input and etc);

Troubles due to the careless handling and use (drop, impact and damage)

Troubles because a person other than the service center engineer repaired the

product;

If the product is disassembled or the name plate is not attached;

Troubles due to the abnormal power input;

If it is used for other purposes;

If an user remodeled the interior part;

Unexpected problems occurred which were impossible to be anticipated at the time

the product was manufactured;

■We are not responsible for any safety accidents that occur due to the customer‟s

negligence.

19

LS Industrial Systems prioritizes the

environmental preservation in

managing the company, and all

executives and staff members do

their best to achieve a more

pleasant environment for all to

share.

Product Name

LS Industrial Systems XCODE

Date of Purchase

Model Name

XCODE-IU9011

Warranty Period

Customer

Name

Address

Phone No

Sales Store

Name

Address

Phone No.

This product is manufactured under a strict quality control and inspection processes

by the LS Industrial Systems Technical Team.

The warranty period is generally 12 months from the date of purchase. If the date of

purchase is not filled in, 12 months from the date of manufacture will be applied.

However, this can be changed in accordance to the contract terms and conditions.

No.

Issued Date

Revision

Version No.

Remarks

1

2011.10

First Version

1.00

Warranty

LS Industrial Systems Reader is

designed to protect the

environment. When discarding the

product it can be classified into

iron, aluminum and synthetic resin

(cover) parts to be recycled.

Environmental Management

How to Dispose the Product

User Manual Version

LS XCODE-IU9011 User manual

Popular Card Reader manuals by other brands
