LSS OCTO User manual

PROFESSIONAL AUDIO SYSTEM
OCTO21
OPERATING MANUAL
Ver. OCTO21-EN-1.0
LSS Advanced Speaker Systems
Via On. Longo 53-89024 Polistena (RC) ITALY Tel [phone] – Fax [phone] Email: [email protected] - Internet: www.lss.it

OCTO21_______________________________________________________________________________
2| Operating Manual ver. OCTO21-EN-1.0
NOTICE:
LSS products are manufactured for use according to proper procedures by a
qualified operator and only for the purposes described in this manual.
The following conventions are used to indicate and classify precautions in
this manual. Always heed the information provided with them. Failure to
heed precautions can result in injury to people or damage to property.
© LSS, 2014
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in
any form, or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior
written permission of LSS.
No patent liability is assumed with respect to the use of the information contained herein. Moreover, because
LSS is constantly
striving to improve its high-quality products, the information contained in this manual is subject to change
without notice. Every precaution has been taken in the preparation of this manual. Nevertheless, LSS assumes
no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of
the information contained in this publication.

______________________________________________________________________________
Operating Manual ver. OCTO21-EN-1.0 |3
SUMMARY
INTRODUCTION ............................................................................................................................................ 4
SAFETY AND WARNING .............................................................................................................................. 5
APPLICATION ................................................................................................................................................. 6
PHYSICAL DESCRIPTION ........................................................................................................................... 6
TECHNICAL SPECIFICATIONS .................................................................................................................. 7
INSTALLATION AND WIRING ..................................................................................................................... 8
WEEE DIRECTIVE ....................................................................................................................................... 10
TROUBLESHOOTING ................................................................................................................................. 11
DIMENSIONS ................................................................................................................................................ 12
NOTES ........................................................................................................................................................... 13

OCTO21_______________________________________________________________________________
4| Operating Manual ver. OCTO21-EN-1.0
INTRODUCTION
Congratulation on the purchase of your new LSS loudspeaker.
Quality innovation and versatility, this is a summary of the new system
developed by LSS for professional sound users.
LSS produces professional audio products – the result of exceptional
engineering and meticulous craftsmanship.
This manual is intended for use with LSS loudspeaker. This includes: safety
precautions; installation, set-up and operating instruction.
Please read this manual plus any accompanying manual and follow all
relevant precautions and instructions. This should allow you to obtain the
maximum performance from your new loudspeaker.
Where there are conflicts or overlaps, the information in any accompanying
manual supersedes the information in this manual.

______________________________________________________________________________
Operating Manual ver. OCTO21-EN-1.0 |5
SAFETY AND WARNING
IMPORTANT! SAFETY WARNING!
In the interest of their own and others' safety and to prevent voiding the
warranty, we recommend a careful reading of this section before using the
product.
- This product was designed and manufactured to be used as a speaker system in
the context of a typical sound reinforcement system.
The use for any purpose other than these is not provided by the manufacturer and is
therefore under the direct responsibility of the user / installer.
- This device complies with class I (must be connected to the outlet with a protective
earthing connection).
TO AVOID THE RISK OF FIRE AND / OR ELECTRIC SHOCK*:
- Do not expose this system to rain or moisture. Do not expose the apparatus to
dripping or splashing water. Do not place objects filled with liquids, such as drinks, on
the apparatus.
- Before connecting the system, be sure the mains voltage corresponds to that stated
on the product.
- Connect this appliance to a power outlet with earth contact, according to national
security force, via a power cable of adequate section ends with a plug or connector
that meets the applicable safety regulations.
- The unit is connected to the network even when the power switch is in position '0'
(OFF). Before any maintenance, disconnect the power cable from the outlet.
*Risk of electric shock only for self-powered system.
IMPORTANT! SAFETY PRECAUTIONS!
Read This First.
Read and heed all warnings and safety instructions in this Manual before using the
product.
Failure to follow all precautions can result in equipment damage and / or personal
injury.
1. Read these instructions.
2. Keep these instructions
3. Heed all warnings and follow all instructions.
4. Use only attachments/accessories specified by the manufacturer.
5. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-over.
6. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
7. LSS loudspeakers can produce sound levels capable of causing permanent
hearing damage from prolonged exposure. The higher the sound level, the less
exposure needed to cause such damage
CAUTION: This product is energized as long as it is connected to the AC.
CAUTION: Allow at least six inches of free space all around the amplifier for sufficient
ventilation.

OCTO21_______________________________________________________________________________
6| Operating Manual ver. OCTO21-EN-1.0
APPLICATION
LSS's OCTO21 loudspeaker system is a reflex subwoofer system that
provides high output, low distortion sound reinforcement. OCTO21 was
designed for a wide range of professional applications.
This system enclosure uses one woofers of 547 mm (21") very high
excursion cone with 150 mm (6") voice coil and Neodymium magnet
structure. This driver is ideal to reproduce very low frequencies. High
performance and very high peak output for concert sound. The OCTO21
powering mode is only passive amplified operation with external digital
processor. High output, bass response and low distortion make the OCTO21
surprising in terms of performance. The OCT021 is the ideal product to be
paired with speakers such as, SP530, SP640, PSAT1, PSAT2, ST17,
HDA24, AR210, AR208 or similar.
LSS OCTO21 is a subwoofer of high peak low frequency response in the
range 30-150Hz.
PHYSICAL DESCRIPTION
FRONT
TOP
BOTTOM
SIDE REAR
[A]
[B] [D] [E]
[F]
[G] [I]
[H]
[J]
[K]
[C]
[A] Wheels [G] Connection Panel
[B] Handles [H] Recesses for Plastic Skids
[C] Reflex [I] Plastic Skids
[D] Steel Protection Grid [J] Handles
[E] Enclosure Cabinet [K] Handles
[F] Woofer
Materials and construction meet the highest professional standards to ensure maximum reliability

______________________________________________________________________________
Operating Manual ver. OCTO21-EN-1.0 |7
TECHNICAL SPECIFICATIONS
PHYSICAL
Dimensions mm (±1 mm)
[Inches]
Height 600 [23.62"]
Front Width 700 [27.56"]
Depth 800 [31.50"]
Weight Kilograms Net Weight 70
Shipping Weight 76
SYSTEM PERFORMANCE
Frequency Response ±5 dB 30 Hz ~ 150 Hz
-10 dB 25 Hz
Sensitivity (1 Watt @ 1 m) LF Range Passive 96 dB
Max SPL Calculated 129 dB
Nominal Input Impedance (Ω) LF Range Passive 8 Ω
Power Handling (Watt cont.
AES) LF Range Passive 2000
Peak Power (W) 8000
Nominal Dispersion (@ -6 dB) 360°, varies with number of units
and configuration
MECHANYCAL
Enclosure material Birch Plywood of 18 mm [0.71
inches]
Finish Texture poliuretanic black paint
Grille Powder coated perforated steel
with anti-dust foam
Connectors 2 Neutrik NL4 Speakon
Accessories Wheels (Included)

OCTO21_______________________________________________________________________________
8| Operating Manual ver. OCTO21-EN-1.0
INSTALLATION AND WIRING
OCTO21 must be installed on the floor.
It is possible to install more OCTO21 in stack configuration making fit Top
Sub’s plastic skids in bottom sub’s recesses.
To transport the speaker, use the wheels installed in the rear of the case.

______________________________________________________________________________
Operating Manual ver. OCTO21-EN-1.0 |9
Choose a safe mounting location, so as to prevent the cables can be
stepped on or create tripping hazards.
Before making connections between mixer and speakers, make sure the
mixer volume is turned down.
In the connection panel there are two Speakon NL4 connectors referred as
‘IN’ and ‘OUT’.
IN is the input connector and must be connected to the amplifier, ‘OUT’ is a
LINK OUT and can be connected to other systems.
Recommended configuration using multiple speakers is represented below:
You can now use the system
Amplifier
Output A
Output B
Input A
Input B
Amplifier Load (per Output Channel)
# of Speakers Nominal Minimum
1 8 Ohms 7 Ohms
2 4 Ohms 3.5 Ohms
3 2.7 Ohms 2.3 Ohms
4 2 Ohms 1.8 Ohms
Caution: Do not exceed the
maximum load rating of
the amplifier.
NL4 Pin Configuration
Pins 1+ and 1- Used
Pins 2+ and 2- Not Used
Mixer

OCTO21_______________________________________________________________________________
10| Operating Manual ver. OCTO21-EN-1.0
WEEE DIRECTIVE
WEEE Directive
Warning!
The product is marked with this symbol which indicates not to discard
electrical and electronic equipment via the normal procedure for disposal of
household waste. For these products there is a diverse collection system in
accordance with legislation that requires proper treatment, recovery and
recycling of used products. For more information please contact the
appropriate local authority.
The black bar underneath indicates that the product was placed on the
market after 13 August 2005.
INFORMATION FOR PROPER DISPOSAL
For home users
In the European Union
Warning: To dispose of this equipment, do not use the ordinary dust bin!
The electrical and electronic equipment must be treated separately and in
accordance with legislation that requires proper treatment, recovery and
recycling of used products. Following the implementation by member states,
private households within the EU can give free electrical and electronic
equipment to designated collection facilities *.
In some countries (*), your local retailer may withdraw the old product for
free if you purchase a new one of similar type.
* For more information please contact the appropriate local authority.
In countries outside the EU: please contact your local authorities and ask
for the correct method of disposal.
In Switzerland: Used electrical or electronic equipment can be returned free
of charge to the dealer, even if you do not purchase a new product.
Further collection facilities are listed on the homepage or www.swico.ch.
www.sens.ch.
For professional users
In the European Union
Warning: If the product is used for business purposes, the following steps to
delete it:
contact your LSS dealer for information about the product recall.
Might be charged for the costs of collection and recycling. Small products
(and amounts) might be taken back by your local collection facilities.
In Spain: contact the established collection system or the local authority for
collection of used products.
In countries outside the EU: please contact your local authorities and ask
for the correct method of disposal.

______________________________________________________________________________
Operating Manual ver. OCTO21-EN-1.0 |11
TROUBLESHOOTING
Problem Possible cause (s) Action
1. No Sound
Amplifier
Connect a known working test speaker to the amplifier outputs. If
there is no sound, check that all the electronics are on, the signal
routing is correct, the source is active, the volume is turned up,
and so on. Correct/repair/replace as necessary. If there is sound,
the problem is in the wiring.
Wiring
Verify that you have connected the correct wire pairs to the
amplifier. Play something at low level through the amplifier (for
example, from a CD player or tuner). Connect the test speaker in
parallel with the malfunctioning line. If the sound level has gone
or is very weak, the line has a short in it (possibly a severe
scrape, pinch, or staple puncture). If the sound level is normal,
the wire is open (possibly a cut wire or a missed connection).
Using the test speaker, move down the line and test each
connection/junction until you find the problem and correct it.
Observe proper polarity.
2. Poor Low
Frequency
Response
Speakers wired out-
of-polarity
When two speakers are connected out of polarity, the low
frequencies will cancel each other acoustically. Carefully observe
the wire markings or tracers on your speaker wires. Verify that
the amplifier (+) terminal is connected to pin 1+ of the NL4
connector and the amplifier (-) terminal is connected to pin 1- of
the NL4 connector.
3. Intermittent
output such as
crackling or
distortion
Faulty Connection Check all connections at amplifier and speakers to ensure they are all clean and tight. If the problem persists, it may be in the
amplifier or wiring. See Problem 1 above.
4. Constant
noise such as
buzzing,
hissing,
humming
Defective amplifier or
other electronic
Devices
If the noise is present but no program material is playing, the
likely cause is the signal chain in the electronics. Evaluate each
component as necessary to isolate the problem.
Poor system
grounding or ground
loop Check and correct the system grounding, as required.
If these suggestions do not solve your problem, contact your nearest LSS dealer or LSS distributor.

OCTO21_______________________________________________________________________________
12| Operating Manual ver. OCTO21-EN-1.0
DIMENSIONS
FRONT
TOP
BOTTOM
SIDE
60cm80cm
7
0
c
m
REAR
60cm

______________________________________________________________________________
Operating Manual ver. OCTO21-EN-1.0 |13
NOTES

OCTO21_______________________________________________________________________________
14| Operating Manual ver. OCTO21-EN-1.0
CONTACT INFORMATION:
LSS Advanced Speaker Systems
Via On. Longo 53
89024 Polistena (RC) ITALY
Tel [phone] – Fax [phone]
Email: [e-mail] - Internet: www.lss.it
