Ltech LT-874 Series User manual

1 2
LT-874-5A
165432
NO PID
NUR XR
M
Function Key
OLED Screen
512
DMX Address DMX Address
DMX -XMDataDemitlaeR -Real time Data
evruCgnimmiDnoituloseRnoituloseR
Main Display Interface
Figure 1 B
Figure 1 A
DMXAddress:001
DMX Setup
Test
SystemExit
DMX Address:001
CH1: 255 CH2: 255
CH3: 255 CH4: 255
RES:8bit Gamma
DMX Address:001
1: 65535 2:
3: 4:
Resolution:16bit
65535
65535 65535
175mm
mm44
170mm
mm03
LT-874-5A4CHCVDMXdecoderwithOLEDdisplay, receivingstandard DMX512protocoldatawirelessly. usewith
our LT-870wirelesstransmitter, supportingpoint to point,point to multi-pointNetworkstructure.Atransmittercan
configuremultiplereceivers as long as theyusethesamefrequency, self-testingfunctionalso available.
Please refer to the OLED display for the detailed information.
1 2 356 4
001002004008016032
Remark
DIP
Value
123456
ON
Dip Switch( : 64 frequency option(2401-2464MHz), Frequency interval: 1MHz (As following table).1st to 6th)
Example, As figure 1, the repeater frequency is 2437M, set the 1st, 3rd , 6th dip switch to “1”, the rest to “0”,
the Value summation from 1-6 is 1+4+32=37, so the repeater frequency is 37+2400=2437M.
(Figure 2)
DIP
LT-874
2.4G Wireless DMX512 transceiver
use relay settings or connect to Booster Antenna to further the communication distance.
Adopt2.4GHZglobalopenISMfrequencychannel, 64 groupswirelessnetworkcanbechosenindependently to
avoidinterference.
1. Technical Specs:
Matched Wirless Transmitter:
Receiving Wireless Signal:
Input Voltage:
Max Load Current:
Max Output Power:
Working Frequency Channel:
Receiver Sensitivity:
LT-870
DMX512
DC5V-DC24V
5A×4CH Max 20A
100W/240W/480W/(5V/12V/24V)
2.4GHz ISM 64 channels
-96dBm
2. Product Size:
Communication Distance:
Working Temperature:
Dimension:
Package Size:
Weight (G.W):
350m
-20 55
L175×W44×H30mm
L178×W48×H33mm
120g
℃～ ℃
3. Configuration Diagram:
3. OLED Screen Interface Diagram:
DIP Switch
DC5V24V~
Running Light
Turns on when
connect to power supply)
(
RX LED indicator light
flashed In data transmission
LED Lamp
Connection Socket
Power Input Socket
PressMkey to enter
the setting interface
" " Press "M" key, switch entries.
∧ ∨Press " " or “ " key, adjust parameters.
Long press "M" key, return to the main
display interface(Figure 1).
Exit Return to the previous menu.:
][ estore the default parameters ： R In the main display interface( Figure 1)，Long press ”M” 3 keys
simultaneously, LT 874 5A willrestore the defaultparameters,andthescreendisplay
/"
- -
∧"/"∨"
( ).
“Devicerestoredefault” for 2s,
thenitwillreturntothemaindisplayinterfaceFigure 1
LT-874-5A will run the test scenes only when you enter "self-test” interface.
Screensaver enable time: undo for2min in the main display interface (Figure 1).
5. Dip Switch Operation:
Frequency value=the total place value amount of 1-6 dip switch+2400,
put the dip switch to ON position, user can get its place value,
put dip switch to OFF position, its place value is 0.

3 4
LT 870-
Transmitting
Terminal
Transmitting
Terminal
Receiving
Terminal
Receiving
Terminal
Receiving Terminal
Receiving Terminal
Relay Point
LEDs
BtnioPycneuqerFAtnioPycneuqerF
LT 870-LT 870-
LT 874-5A-
LT 874-5A-
LEDs
LEDs
LEDs
LT 870-
【 】A Please install the Booster Antenna in high open place.
the communication distance can up to 1000-2000 meter
ttn
generally.
9. Attention:
10. Warranty Agreement:
1. The product shall be installed and serviced byaqualified person.
2. This product is non-waterproof. Please avoid the sun and rain. When installed outdoors please
ensure it is mounted in a water proof enclosure.
3. Good heat dissipation will prolong the working life of the controller. Please ensure good ventilation.
4. Please check if the output voltage of any LED power suppliesusedcomplywith the workingvoltage of the product.
5. Please ensure that adequate sized cable is used from the controller to the LED lights to carry the current. Please
also ensure that the cable is secured tightly in the connector.
6. Ensureallwireconnectionsandpolaritiesarecorrectbeforeapplyingpower to avoid any damages to the LEDlights.
7. Ifafault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
1. We provide lifelong technical assistance with this product:
A 5-year warranty is given from the date of purchase.The warranty is for free repair or replacementand
covers manufacturing faults only.
For faults beyond the 5-year warranty we reserve the right to charge for time and parts.
2. Warranty exclusions below:
Any man-made damages caused from improper operation, or connecting to excess voltage and overloading.
The product appears to have excessive physical damage.
Damage due to natural disasters and force majeure.
Warranty label, fragile label and unique barcode label have been damaged.
The product has been replaced byabrand new product.
3. Repair or replacement as provided under this warranty is the exclusive remedy to the customer. LTECH shall
not be liable for any incidental or consequential damages for breach of any stipulation in this warranty.
4. Any amendment or adjustment to this warranty must be approved in writing by LTECH only.
★This manual only applies to this model. LTECH reserves the right to make changes without prior notice.
Update Time: 2014.06.07
6. Conjunction Diagram:
7. Relay Way to Extend the Communication Distance:
8. Extend the Communication Distance by Boost Antenna:
2.4G Wireless transmission
A sending end can configure
multiple receiving ends
DMX512 Console
DMX512 Console
DMX512 Console
Console signal cable connected
to wireless DMX transceiver
LT-874-5A
LT-870
LT-874-5A
LT-874-5A
LT-874-5A
LT-874-5A
,
Booster Antenna
Booster Antenna
Booster Antenna
