lubluelu Mate40 User manual

Instruction Manual
Handy Cordless Vacuum
Cleaner Manual
Make Your Daily Cleaning Easy
Model Number: Mate40

Contents
Important Safety Instructions--------------------------- 01
Product Instructions------------------------------------- 05
Accessory Instructions---------------------------------- 06
On-Screen Display------------------------------------- 07
Assembly----------------------------------------------- 08
Product Operation-------------------------------------- 10
Maintenance-------------------------------------------- 12
DE------------------------------------------------------ 20
FR------------------------------------------------------- 39
IT------------------------------------------------------- 58
ES------------------------------------------------------ 77

Important Safety Instructions
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE.
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
Personal Safety:
1. Store indoors in a dry place out reach of children;
2. The device CANNOT be used by children, physically and mentally
fragile people and people lack of related experience and knowledge,
unless they are supervised by others and they fully understand the
possible potential hazards.
3. Keep children away from the device. Otherwise, children must be
supervised when using or maintaining the appliance.
4. Use the manufacturer’s recommended attachments and accessories
only. Using other accessories may have a risk of safety hazard.
5. Take extra care when cleaning stairs;
6. Keep the appliance and accessories away from hot surface;
7. Do not block the outlet of the appliance or hinder the airflow. Keep
dust, lint, clothing or fingers away from the outlet.
8. Do not block the outlet and attachments of the device.
Do not use the device or leave it outdoors when it’s raining.
Basic safety precautions should always be observed when
using an electrical appliance, including the following to reduce the risk
of fire, electrical shock, or injury.
WARNING:
1

Electrical Safety:
1. Only use batteries and chargers supplied by the manufacturer;
2. Never modify the charger in any way;
3. The charger has been designed at a specific voltage. Always make
sure the main voltage is the same as the specific voltage.
4. There is a risk of fire when a charger that is designed for a specific
battery type is used with another type of batteries.
5. Check if there is damage or tear and wear on the charging cable.
A damaged or entangled charging cable may increase the risk of fire
and electric shock.
6. Do not abuse the charger;
7. Never carry the charger by the cord;
8. Do not pull the charging cable when the charge is plugged into an
outlet.
9. Do not wrap the charger with the charging cable when you store the
charger.
10. Keep the charger away from hot surfaces and sharp edges;
11. TThe included charging cable is not replaceable. If the charging cable
is damaged, please change another charger directly.
12. Do not operate the charger or the appliance with wet hands;
13. Do not store or charge the appliance outdoors;
14. The charger must be removed from the socket before removing
the battery, cleaning or maintaining the appliance.
Battery Safety:
1. his appliance included Li-ion batteries. Please do not expose the
appliance to high-temperature environments as the batteries may
explode.
2. Liquid from the battery may cause irritation or burns;
2

3. For any emergency, please contact professional staff for help
immediately.
4. Li-ion batteries may leak corrosive fluid under extreme conditions.
Do no touch the liquid. If the liquid splashes on your skin, wash your
skin immediately with soap and water. If the liquid splashes in the eye,
flush your eye with clean water for at least 10 minutes and seek medical
attention. Wear gloves to handle and dispose of the battery based on
local regulations.
5. A short circuit may cause a fire.
6. When the battery is not in use, keep it away from clips, coins, keys, nails,
screws or other small metal objects;
7. When you dispose of the appliance, remove the battery and dispose
of the battery safely in accordance with local regulations.
Attention:
1. If the appliance hits an object, please check if there is any damage.
2. Do not use the appliance if any part is damaged or defective;
3. Repairs should be carried out by a service agent or a suitably
qualified person in accordance with relevant safety regulations;
Repairs by unqualified persons may have a risk of damaging the
appliance;
4. Never modify the appliance in any way as this may increase the
risk of personal injury;
5. Only use replacement parts or accessories provided or
recommended by the manufacturer.
3

Intended Use:
1. The appliance is designed for use in dry environments for vacuum
cleaning only;
2. Do not use the appliance on any wet surface or to clean any liquid;
3. Do not use the appliance to clean flammable or burning objects;
4. Use the appliance properly based on this user manual;
5. Don’t use the appliance on concrete, tarmacadam or other rough
surfaces.
WARNING:
1. Do not use water, solvents, or polishes to clean the outside of the
appliance; Clean it with a dry cloth;
2. Never immerse the unit in water and do not clean it in a dish washer.
4

5
PRODUCT INSTRUCTIONS
Product Introduction：
HEPA Outlet
Battery Release Button
Switch Button
Main Screen
Conductor Tube
Floor Brush Release Button
Floor Brush
Aluminum Tube
Of Rack And Pinion
Dust Pan Release Button
Pipe
Extend-Retract Tube Button
Rack Base
Charging Cradle
Battery Pack
Charging Port
Soft Dusting Brush Power Adapter HEPA FilterCleaning ToolLong Suction Nozzle

6
Multi-Task Roller Brush with LED
The roller brush increases the cleaning efficiency, ideal for removing
stubborn dirt in the carpets, dust and debris on hard floors.
Long Suction Nozzle
The crevice tool is used for corners, niches and other hard-to-reach
places, such as car seat and mat, picture frame, etc.
Soft Dusting Brush
Angled bristles on slender and the oval shape provide anti-static
cushioned contact, suitable for cleaning dust on sofa, curtain or other
fabric furniture or delicate surfaces, electronics and more.
Cleaning Tool
Use the end with small blade to remove the hair and debris wrapped
around the roller brush. Use the end with little brush to clean the the
dustbin and the HEPA filter.
Power Adapter
Charge the battery of the vacuum cleaner with the power adapter.
HEPA Filter
TThe HEPA filter increases the cleaning efficiency and removes up to
99.8% of ultrafine dust particles down to 0.3 microns.
Accessory Instructions

On Screen Display
7
Battery Display Battery Indicator
Air Duct Clog Reminder
Speed Up
Roller Brush Clog
Reminder
Speed Down
Automatic Mode
1. Suction mode selection:
Automatic mode:
( 1 ). Automatically adjust the suction power according to the degree of
dirt on the floor (The default suction mode is automatic mode).
( 2 ). Click on automatic mode again to deactivate automatic mode.
Speed down: The level of dirt on the floor is low, click on speed down to
reduce noise and extend the operating time.
Speed up: The level of dirt on the floor is high, click the speed up to
increase the suction and improve the cleaning efficiency.
2. Fault indication:
When the roller brush is clogged, the red light of the roller brush clog
indicator will flash, and then the floor brush will stop working. After
cleaning the dust or dirt, restart the machine and it will work normally.
When the machine is blocked, the red light on the air duct clog indicator
will flash. After cleaning the dust or dirt, restart the machine and it will
function normally.
Note:

8
Assemble and Disassemble the Telescope Pipe
Insert the telescope pipe into
the main motor. Press the release button and then remove the telescope pipe.
Assembly
Assemble and Disassemble the Motorized Floor Brush
Insert the floor brush to the
telescope pipe. Press the release button and then remove the floor brush.
Assemble and Disassemble the Roller Brush
On one side of the floor brush,
there is a release button. Push
the button.
The roller brush handle will bounce
and now you can remove the roller
brush.

9
Disassemble the Dustbin
Install the Rack
1.Turn off the device. Press the dustbin release button to release the garbage.
2. Separate the dustbin from the main motor by rotating the dustbin.
3.Rotate the filter component clockwise.
Assemble the rack against the wall and place the machine on the rack.
Place the accessories in the charging station slot.

Assemble and Disassemble the Battery
Press the battery release button and
remove the battery.
Slide the battery into place.
PRODUCT OPERATION
How to Operate the Vacuum
Press the switch button and then
the vacuum will start to work. Press the switch button again and then the vacuum will stop working.
1
10

11
Press the extend-retract tube button with one hand, extending or retracting to
choose the suitable vacuum cleaner height for more comfortable cleaning
with the other hand;
Four ways to charge your vacuum cleaner :
2.Charge the vacuum cleaner head by the power adapter;
1. Place the machine on the base and start charging;
3.Remove the battery from the vacuum cleaner and charge it separately
by the power adapter;
4. Charge the whole vacuum cleaner by the power adapter.
Charging mode : directly insert into the charging socket of the battery
to charge.
2
Battery Charging:
1. When the battery power is below 10%, the battery indicator light will flash,
indicating that the machine's battery power is low.
2. When the battery power reaches 100%, it means the machine is fully charged.
Battery Indicator Light:
3
1
2
3

Press the Dustbin Release Button
1. Please clean the dustbin when the dust reaches the MAX level;
2. Please clean the dustbin every 3-5 days even the dust doesn't
reach the MAX level.
Note:
Note:
How to Empty the Dustbin
Disassemble the filter system as above, then clean it.
1. Cleaning the dust pan: wipe with a brush or dry cloth.
2. Cleaning the stainless steel filter: wipe with a brush or dry cloth.
If it is too dirty, wash it and dry it in the sun.
3. HEPA cleaning: clean the HEPA once a week, if it is too dirty, please replace
the HEPA in time.
It is recommended to clean the HEPA filter once a week for better cleaning efficiency.
Please make sure dry the filter completely before use. Otherwise, it will affect the life
of the machine.
Clean the Filter Components
Maintenance
12

13
Remove the roller brush and clean the hair and other dirt tangled on the roller
brush with the cleaning tool. If the roller brush is too dirty, please wash it and
dry it completely in a well-ventilated place under the sun.
Clean the Roller Brush
Assemble the rack against the wall and place the machine on the rack. Place
the accessories in the charging station slot.
Product Storage

14
• Do not carry out any maintenance or repair work beyond this user manual.
• Store the machine indoors. Do not use or store it below 37.4°F (3°C).
Ensure the machine is at room temperature before operating.
• Clean the machine only with a dry cloth. Do not use any lubricants, cleaning
agents, polishes or air fresheners on any part of the machine.
Maintenance
When using the Lubluelu vacuum cleaner, basic precautions should always
be followed. Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
1. Please use the original parts for the machine. Do not use non-original parts
without the permission of the manufacturer. If there is any malfunction due
to using non-original parts, the warranty will be automatically void. The
manufacturer is not responsible for any loss of life or property.
2. Please check if the product is damaged or the accessories are completely
received after you have received the package.
3. Do not use the vacuum with any damaged cord or plug. If the appliance
has been dropped, damaged, left outdoors, dropped into water, or is not
working, return it to the manufacturer.
4. Children below 15 years old and incapacitated persons should use this
machine under the supervision of their guardians.
5. When a fault occurs, the power adapter should be pulled out immediately
and the defective product should not be in working status.
6. Please do not disassemble and repair all the electric parts including but not
limited to motors, battery and power adapter, which is easy to damage the
machine and cause other hazards.
Any content with the logo means being prohibited.
Otherwise, it may cause damage to the product or
endanger the personal safety of the user.
Prohibited sign
WARNING：

15
All contents with the logo mean it must be handled in
strict accordance with the requirements. Otherwise, it
may cause damage to the product or endanger
personal safety of the user.
This product is for household use
only. Do not use this product
outdoors.
Children below 15 years old are not
allowed to use the device alone to
avoid dangers like electric shock.
Please do not let the vacuum cleaner
too close to the heat source and
other high temperature objects, lest
plastic deformation. It will affect the
use of the vacuum cleaner.
When using the vacuum cleaner,
please pay attention to the installation
of various filter parts. Do not use the
vacuum cleaner when there are no
filter accessories.
Please don't use the vacuum cleaner
to suck up burning cigarette butts,
so as to avoid danger. Please do not
suck up detergent, kerosene, gasoline,
paint, sewage and other liquids, in
case the liquid enters the motor and
causes motor failure.
Warning sign
When cleaning the vacuum cleaner,
please use the wet cloth with water
or neutral detergent. Do not use
gasoline, banana oil, etc., or it will
cause shell crack and fade.

16
Troubleshooting
Problem Possible Cause Solution
Please do not suck up hair group,
paper group and other objects that
are easy to block the suction port
and air duct.
Please do not place heavy objects
on the machine or tread on the
machine.
After charging the vacuum cleaner
or 5-6 hours, please unplug the
power adapter from the socket
and keep it properly. Keep the
power adapter out of reach of
children.
Please do not use the vacuum cleaner
to suck up cement, gypsum powder,
wall powder, starch and other small
particles. Otherwise, it will cause
vacuum cleaner filter part blockage,
motor burnout and other faults. If the
vacuum cleaner sucks up the above
small particles, please clean all filter
parts in time.
1. Low battery
2. Pipe is blocked
Product stops
working
1. Use the device after it is fully
charged
2. Clean the pipe and restart
the device
1. Low battery
2. Run with MAX mode
all the time
Working time is too
short 1. Use the device after it is fully charged
2. Select the appropriate
suction speed according to
different floor conditions

17
Problem Possible cause Solution
1. The dust fills the
dustbin up to the MAX
line
2. The roller brush is
blocked by objects such
as hair
3. HEPA is dirty or
missing
The suction power
of the product is
reduced
1. Clean the dustbin on time
2. Clean the roller brush on
time
3. Clean HEPA in time or use it
after HEPA installation
1. The power outlet is
damaged
2. The power adapt-
er/charging port is not
properly inserted into
the charging port of
the socket/rack
3. The original power
adapter is not used
4. Overheating
protection
Battery is not
charging
1. Replace the power outlet
2. Insert the power adapt-
er/charging port into the
charging port of the
socket/rack correctly
3. Use the original power
adapter to charge the appli-
ance
4. Wait for a few minutes until
the appliance cools down
before charging/usingbefore
Roller brush is blocked
by objects such as hair
Roller brush does
not turn/floor
brush light does
not turn on/roller
brush blockage
light is on
Clean roller brush in time and
restart the machine
Pipe is blocked
Abnormal motor
noise Clean the pipe in time
Insufficient battery
power
Battery indicator is
flashing Charge the appliance in time
Dust detection sensor
is clogged/dirty
Automatic mode
does not work Clean the trash/dirt from the dustbin port in time
