Lumagen Radiance Series Quick start guide

© 2013 Lumagen, Inc. Radiance Tech Tip 19, Rev 1.01
Radiance Tech Tip 19
Radiance Installation Notes
Introduction
This is a practical guide to installing the Lumagen Radiance video processor. This guide has
installation tips for of all models of the Radiance video processor.
How to connect the Radiance outputs
For correct operation, it is important to connect your receiver and display to the correct
outputs on the Radiance. This will allow the Radiance to pass-back the correct audio and
video E I to the video sources.
1. Connect the Radiance Output 1 to your receiver and Output 2 to your display. By default
the Radiance passes back the audio EDID from Output 1 and the video EDID from
Output 2.
Note: The RadianceMini only has one H MI output.
2. If you are only using one output on the Radiance, connect Output 2 to the display.
3. If you have a receiver connected to the HDMI Output 1 of the Radiance, you can turn off
video on Output 1. The Radiance will output audio with 1080i blank 2D video on Output 1.
To turn off video on HDMI Output 1, press “Menu 0985” (added in SW Rev 090412).
Then save the new setting by pressing “Menu, Save, Ok, Ok, Ok”. See Figure 1.
Figure 1: Shows a receiver connected to HDMI Output 1 and video turned off.
How to reset the Radiance to factory default settings
Please follow these instructions when you install a used Radiance or if you want to reset your
unit to the factory default settings.
1. Go to the Lumagen website and download the latest software for your unit.
http://www.lumagen.com/testindex.php?module=updates
2. See "Tech Tip 6 – Updating the Radiance" for instructions on installing new software.
http://www.lumagen.com/testindex.php?module=manuals
3. Do a factory reset by pressing "Menu 0999".

© 2013 Lumagen, Inc. Radiance Tech Tip 19, Rev 1.02
4. Save the new factory default settings by pressing "Menu, Save, Ok, Ok, Ok"..
5. You can download the latest manual and technical tips from the Lumagen website.
http://www.lumagen.com/testindex.php?module=manuals
Output settings
The Radiance output is set, by default, so that it will produce an image on all digital displays that
have a VI or a H MI input. There are two settings that you can change, if you have a display
with a H MI input.
1. We recommend that you change the output of the Radiance from “RGB” to “YCbCr 422”.
Press “Menu, Output, Styles, stylex, H MI Format, Type, Ok, YcbCr 422, Ok”. Save the
new setting by pressing “Menu, Save, Ok, Ok, Ok”.
2. Most displays can display video signals that are an even 24.0Hz, 30.0Hz, and 60.0Hz
instead of the normal 24.97Hz, 29.97Hz, and 59.96Hz.
You can change the Radiance “Ratematch” setting to “On” which allows the Radiance to
match the rate of the input to the output for an occasional video that might have an
even rate. Press “Menu, Output,
Use the right HDMI cables
H MI cables continue to be the source of many problems, such as a snowy image due to the loss
of the H CP connection to the display.
Short H MI cables that are 1 meter (3 feet) long can cause problems. Most H MI transmitter
chips have a built in equalizer circuit that boosts the signal level to compensate for losses in the
cable. A cable that is too short, can deliver a signal that is too strong, and overwhelm the input
of the H MI receiver chip. If you have short H MI cables and are experiencing intermittent
problems, a longer cable can make a more reliable connection. It’s a good practice to use good
quality generic H MI cables that are a minimum length of 2 meters (6 foot) long.
For H MI cables that are 12 meter (40 foot) to 30 meters (100 foot) a Lumagen VidExt (Video
Extender) might be required to clean up the signal going to the display. The Lumagen VidExt
buffers all the signals, including the control signals, to provide a better signal to the display.
There is also a rotary switch to set the optimum cable equalization length. Most other H MI
cable extenders lack this useful feature.
For instillations than require a video cable up to 60 meter (200 feet), a Lumagen CatExt (CAT6
Extender) can be used to transmit the H MI signal. The Lumagen CatExt uses two Cat6 wires to
transmit a H MI signal up to 60 meter (200 feet).
Note: It is a good idea to install two spare Cat5 or Cat6 cables when you install a H MI cable
to a projector. This gives you an alternate method of providing video, to the projector, if the
H MI cable doesn’t provide a good signal.
HDMI to D I Adapters

© 2013 Lumagen, Inc. Radiance Tech Tip 19, Rev 1.03
Some HDMI to DVI Adaptors degrade the video signal. Price is no guarantee of quality.
Sometimes the most expensive HDMI to DVI Adaptors degrade the signal the most. We
recommend using a good quality generic HDMI to DVI Cable for better signal integrity.
HDMI Splitters
We have received reports that some HDMI Splitters, advertised to support 3D, don’t work
correctly in real world 3D installations. When a HDMI splitter is required for the installation, we
recommend doing a system test before taking the components to the installation site to insure
proper functionality.
Receivers and ideo Artifacts
Lumagen recommends using the Radiance for video switching to avoid having to pass video
through an Audio Video Receiver (AVR). The issue to be aware of with an AVR, in the video path,
is that it can cause artifacts, even if the AVR is in “bypass” mode. Many receivers add
“enhancements” to the video signal, which can add artifacts to the video.
If your are using an AVR to switch video to a RadianceMini-3D, when possible, turn off “scaling”
and all video “enhancements” in the AVR.
Eliminate Possible Ground Loops
Lumagen recommends if possible that the Radiance, projector, and all equipment be plugged into
the same AC power circuit. This will reduce the possibility of introducing a ground loop.
Ground loops are a common problem, but much less apparent when you use digital signals for
audio and video. In the past, ground loops were apparent because they would cause an audible
50Hz/60Hz hum on the audio system or visible “hum bars” on the analog display.
Note: Power conditioners don’t eliminate ground loops, because the electrical safety
regulations require the AC power ground to be connected through the power conditioner.
4K ideo Signals
The Radiance 2041 and 2042 offer support for 4K video signals on HDMI Output 2. The
Geometry and Lines test patterns have been updated to display single pixel wide 4K patterns.
The latest 4K video requires more bandwidth than a similar 1080p signal. You might find that a
HDMI cable that worked for 1080p, no longer works when you use it for a 4K video signal. A
Lumagen VidExt (Video Extender) can help a marginal HDMI cable transmit a 4K signal.
It is recommended that you test all HDMI cables and equipment to verify that they support a 4K
video signal.
Lumagen Support
Please call or email Lumagen if you have any questions about our products or need help with
your installation.
Phone: [phone] x104
Email: [e-mail]
