Lumantek ez Liveshow ez-CGER User manual

ez-CGER All-in-One Video Switcher with Live CG / Manual v 1.0.3
Updated Jan. 2016
manual
ez-CGER All-in-One Video Switcher with Live CG

ez-CGER : All-in-One Video Switcher with Live CG / Manual
ez-CGER All-in-One Video Switcher with Live CG Manual
Revision Number: 1.0.3
Distribution Date: Jan. 2016
Copy Rights
Copyright © 2006~2015 LUMANTEK Co., Ltd.
All Rights Reserved
This document contains information that is proprietary to LUMANTEK.CO., LTD. The information in this
document is believed to be accurate and reliable; however, LUMANTEK assumes no responsibility or liability
for any errors or inaccuracies that may appear in this document, nor for any infringements of patents or other
rights to third parties resulting from its use.
This publication may contain technical issues, inaccurate information or typos. These will be revised in revised
edition, if there is any. No part of this publication is subject to be reproduced, stored in retrieval system, or
transmitted in any forms, or any means without the prior consent by Lumantek.
Trademarks
HD ENCODULATOR TM, SD ENCODULATOR TM LUMANTEK Logo, Mega CruiserTM, ORIXTM, X-CruiserTM, DTA-
PlusTM, Media BlasterTM, are Trademarks of Lumantek. Co., Ltd.
Any other trademarks than stated above in this document belongs to its pertinent corporation.
Warranty Period
Lumantek’s products comes with One(1) year limited warranty.Please contact below if you need more
information.
LUMANTEK CUSTOMER SERVICES
[e-mail] / TEL:[phone] / FAX:[phone]
2

ez-CGER : All-in-One Video Switcher with Live CG / Manual
Installation Precautions
This page states the safety measures the users must take to avoid circumstances where the system may
occur physical damages or injuries. Please THOROUGHLY go over this page before the system
installation/operation.
-Maintain dust FREE condition during and after System Installation/Operation.
-Please place the system cover in a safe location when opened.
-Securely stow tools and cables away from the passages.
-Avoid wearing loosened clothes or accessories during installation/Operation.
-Avoid any unnecessary actions that may damage/harm system or personnel.
-Do NOT open the system unless advised by Lumantek representative. Lumantek takes no responsibility
on units with broken RMA seals.
General Precautions
Power Precautions
-Please check cable overload before connecting the system to the power supply.
-Avoid wearing metal accessories (Rings, Earrings) connecting system to the power source.
-Avoid operating on wet floors. Make sure power extension cables, floors, and instruments are
grounded and in a safe operating condition.
-Please discharge static electricity by touching grounding metals before starting hardware installation.
-The grounding parts must be disassembled last.
-Manufacture takes no responsibilities on Direct/Indirect losses or damages due to use of
inappropriate parts or services by unauthorized service provider
-Supplying power during the system installation may cause damages to the system and personnel.
AC Power Precautions
-This unit utilizes AC power, the cord comes with a grounding function.
-Please connect the system to the power socket with groundings.
-Use Green/Yellow 0.75mm2 (18AWG) or higher grade grounding cables.
-Do NOT block power sockets with tools or boxes. Please keep it clear at all times.
3

ez-CGER : All-in-One Video Switcher with Live CG / Manual
Contents
1. Introduction ---------------------------------
2. Software Installation & Uninstallation -------
3 Hardware Device Connection -----------------
4 Software ----------------------------------------
5Software Interface ----------------------------
6Software Manual -------------------------------
05
07
16
17
18
19
4

ez-CGER : All-in-One Video Switcher with Live CG / Manual
Video Switcher & Graphic Mixer, ez-CGER
4 HD-SDI, 2 HDMI Input / 1 HD-SDI, 1 HDMI, 1 VGA Output , USB3.0 data input/output
ez-CGER is a hybrid system comprised of CG software and Video switcher.
The system is easily connected to the PC through USB 3.0, it communicates with the CG
software for system control. ez-CGER is a hardware based product providing stable and
reliable implementation to your broadcasting environment. Total Six(6) Media input
sources supported via 4 HD-SDI and 2 HDMIs, CG is mixed with the input sources by
software via USB 3.0, transmitted through HD-SDI/HDMI/VGA Outputs.
One SDI output as well as HDMI and VGA with built-in scaler enables to transmit signals
with various resolutions. Plus, the Multi-view output for four live inputs enabling users to
monitor input sources as well as PIP sources. ez-CGER supports HDMI/SDI embedded
audio or (XRL) external audio. SDI or HDMI input audio inputs are synchronized with the
video, switches seamlessly without generating any noise.
•Features
①Input : SDI 4EA , HDMI 2EA (For ports 1 & 2 ONLY)
②File play input: : 1EA ( CG Software)
③CG input: Fill and Key 1 (USB 3.0)
④Program Output : SDI 1EA, HDMI 1EA (scaler) and VGA 1EA (scaler)
⑤Multi-view Output: 1EA (USB 3.0), 2x2 format with 4EA live Input sources
⑥HD level input and output resolution support
⑦Various HDMI/VGA Output Resolution support with the Scaler
1. Introduction
5

ez-CGER : All-in-One Video Switcher with Live CG / Manual
•ez-CGER - Main Frame (Front/Rear)
Power
•ez-CGER Package
Status LED
RJ45 port
Console
USB 3.0
CG IN & Control
SDI Output
HDMI / SDI input 1/2/3/4
Scaler Output
VGA / HDMI
Audio Input
(Left/Right)
ez-CGER Main Frame
Console
(Optional)
GND
Air Vent Input Indicator
1/2/3/4/CG Power switch
Status LED
Green: Normal
Blue: processing or booting
Red : processing error
IN1/IN2/IN3/IN4 LED
Off: No input signal
Green : Normal Input signal
Red: Unstable Input signal
CG IN LED
Off: USB3.0 NOT connected
Orange: USB3.0 connected w/o the Data
Green: USB3.0 connected with Data
* HDMI input 1/2 and SDI input 1/2 shares the same input channels
** Scaled output supports either system format as it is or the other formats
*** Most of the monitors do NOT support interlace mode with VGA input
6

ez-CGER : All-in-One Video Switcher with Live CG / Manual
2. Software Installation & Uninstallation
Minimum requirements for Software Installation
•Recommend Specification
①OS : Windows7 or higher Ver.
②CPU : 4th Generation intel i7 or above
③RAM : 8GB or above
④VGA : GeForce GTX 750 or above
⑤Monitor Resolution: 1920 x 1080 or above
⑥MUST HAVE USB3.0 PORT
⑦You may install the CG Software on your PC without connecting to the main hardware
device. However, ez-CGER-VM4 device is necessary in order to transmit the CG properly
from the S/W.
7

ez-CGER : All-in-One Video Switcher with Live CG / Manual
•Software Installation
1. Run ‘ez-CGER VM4’ setup file.
2. Press ‘Next’ when screen below is shown.
3. Select the path you want to install the software, then click ‘Next’.
8

ez-CGER : All-in-One Video Switcher with Live CG / Manual
4. Select the program folder name and user, then click ‘Next’.
5. Click ‘Next’ when below ready message is shown.
9

ez-CGER : All-in-One Video Switcher with Live CG / Manual
6. Installing the software.
7. When the device driver installation screen appears, press ‘Install’.
10

ez-CGER : All-in-One Video Switcher with Live CG / Manual
8. Press ‘Next’ to install the USB-Serial Driver.
9. Select destination folder then click ‘Install’.
11

ez-CGER : All-in-One Video Switcher with Live CG / Manual
10. Click ‘Finish’ to complete the Driver installation.
11. Click ‘Finish’ to complete the S/W installation.
12. Please restart the system for proper operation of S/W and driver.
You may restart the system later by unchecking the box.
12

ez-CGER : All-in-One Video Switcher with Live CG / Manual
•Software Uninstall
1. Go to ‘Start’ on Windows then click ‘All Programs’.
2. Select ‘ez-CGER VM4’
3. Select ‘Uninstall ez-CGER VM4’.
4. Click ‘Yes’ to uninstall.
13

ez-CGER : All-in-One Video Switcher with Live CG / Manual
5. Click ‘Next’ to remove the driver.
6. Click ‘Uninstall’ to remove all drivers
14

ez-CGER : All-in-One Video Switcher with Live CG / Manual
7. Click ‘Finish’ to complete driver uninstallation.
8. S/W is completely removed. Click ‘Finish’.
15

ez-CGER : All-in-One Video Switcher with Live CG / Manual
•VM4 Device Connection
1. VM4 device connection
Please use a USB 3.0 cable to connect VM4 system with your PC/laptop.
3. Hardware Device Connection
16

ez-CGER : All-in-One Video Switcher with Live CG / Manual
•Run ez-CGER VM4 S/W from the windows ‘Start’ menu
1. Go to ‘Start’, click ‘All Programs’.
2. Select ‘ez-CGER VM4’ Folder
3. Click ‘ez-CGER VM4’ Icon either 32Bit or 64 bit
based on your Operating System
•Run ez-CGER VM4 S/W from the desktop.
1. Double click ‘ez-CGER VM4’ icon on Windows desktop screen.
4. Software
17

ez-CGER : All-in-One Video Switcher with Live CG / Manual
1. Conti list management area
2. Conti page management area
3. Edit menu area
4. Edit area
5. Edit tool area
6. Transmission control area
5. Software interface
1
2
3
4
5
6
18

ez-CGER : All-in-One Video Switcher with Live CG / Manual
1. Conti File Management
•Create a new conti
1. New conti is created automatically when program is opened.
2. Click ‘New conti’ to add conti to the ‘conti files list’
•Load a conti file
1. Click ’Open’ to load saved conti file.
•Save the conti file
1. Click ‘Save’ to store current conti page.
2. Click ‘Save all’ to store all conti pages on the list.
•Delete conti from the list
1. Click ‘Delete’ to remove selected Conti from the list
2. ‘Delete’ only removes selected conti from the list. The actual data file still exists in the
storage which can be retrieved again.
6. Software manual
19

ez-CGER : All-in-One Video Switcher with Live CG / Manual
2. Conti Page Management
•Add page
- Click ‘Add’ to add a new page.
•Select page
- Click on the desired page from the page list.
The selected page appears in the content
layer in the edit area.
•Delete page
- Click ‘Delete’ to remove(delete) selected
page.
•Copy page
- Click ‘Copy’ to copy a selected page.
•Change page sequence
- Select a page from the list, then drag it with
left mouse to change its sequence.
