6482R-2-INS-LAB-RevB14 1
6482R-2/6482ER-2: DELUXE TOILET SEAT RISER WITH
ARMRESTS; ASSEMBLY & OPERATION INSTRUCTIONS
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE USE
Info: The most current version of these instructions can be found online at www.grahamfield.com.
Tools required: Phillips or blade screwdriver
WARNING: Important! Read and understand these instructions
before installing or using the Toilet Seat Riser. If you do
not understand any part of these warnings, cautions or
instructions, contact a healthcare professional for direction in
the use of this product. If the toilet seat riser is not properly
assembled and installed, personal injury and damage to the
toilet seat riser could result.
WARNING: If components are damaged or missing, contact
your dealer immediately. DO NOT use substitute parts. Use only
Lumex replacement parts. Non-Lumex replacement parts could
cause personal injury and damage to the toilet seat riser.
WARNING: This product has a weight limit of 300 lb, EVENLY
DISTRIBUTED.
WARNING: Notice for California Customers- California
Proposition 65 WARNING: This product contains a chemical
known to the State of California to cause cancer and
reproductive or developmental harm.
WARNING: GF Health Products, Inc. assumes no responsibility
for any damage or injury caused by improper assembly,
installation or use of this product.
INTENDED USE
The toilet seat riser is intended for use by those who have difculty sitting
down on or standing up from the toilet.
INSTALLATION
1. Remove toilet seat riser, hardware, and armrests from carton and
protective packaging.
2. Install the armrests using the following steps:
a. Identify the right and left armrests by the R (Right) and L (Left) stamped
into armrest ends.
b. Note that each toilet seat riser armrest socket is also stamped with an R
or L, as shown at right. Insert each armrest marked with R or L into the
socket with the corresponding letter.
c. Push each armrest into its sockets until it clicks into place.
d. Ensure locking buttons protrude fully from holes. Pull on armrests
slightly to test proper installation. If loose, repeat step c.
3. At the toilet, lift the cover plates at top rear toilet bowl rim, exposing the
bolts holding the seat and lid to the toilet bowl.
4. Use a Phillips or blade screwdriver, whichever is appropriate, to unscrew
toilet seat bolts by turning counterclockwise.
5. Remove the toilet seat and lid from the toilet bowl and set them aside.
6. Place the toilet seat riser over the toilet bowl rim so that the toilet seat
riser mounting holes align with the toilet rim holes.
7. Place the toilet seat and lid on top of the toilet seat riser so that the seat/lid
holes align with the riser and rim holes.
hardware
bolt
washers
wing
nut
right armrest shown installed
(shown upside down)
“R” on armrest socket
locking button
toilet seat riserarmrest
6482ER-2, one arm attached
(shown upside down)
mounting holes
6482R-2 assembled
6482ER-2 assembled

6482R-2-INS-LAB-RevB14 2
www.grahamfield.com
GF Health Products, Inc. is not responsible for typographical errors. For the most updated and current information on packaging, warranties, products and
specications, including the most current version of these instructions, please visit our website at www.grahameld.com.
Graham-Field and Lumex are registered trademarks of GF Health Products, Inc.
© 2011 GF Health Products, Inc. • 2935 Northeast Parkway, Atlanta, GA 30360 • tel [phone] • fax [phone] • Made in China
8. Install a washer on one of the long bolts included in the box and insert it through the top of the toilet
seat lid, toilet seat riser, and toilet bowl rim.
9. Place a washer and wing nut on the end of the long bolt that protrudes through the bottom of the toilet bowl.
10. Use a Phillips or blade screwdriver, whichever is appropriate, to turn the bolt clockwise until toilet seat
riser and toilet seat lid are snug. Do not overtighten.
11. The toilet seat riser should now be securely installed on the toilet bowl. To ensure that you have a
proper t, intentionally shake the toilet seat riser to ensure proper placement and t. The toilet seat
riser should not move; if it does, re-install.
OPERATION
WARNING: Always ensure the toilet seat riser is securely installed before use.
WARNING: Users with limited physical capabilities should be supervised or assisted
when using toilet seat riser.
MAINTENANCE / CLEANING
WARNING: Check the toilet seat riser weekly for signs of damage or cracking. If
damage is found, DO NOT use the toilet seat riser. Contact your Lumex authorized
distributor immediately.
Loosen, retighten, and check for secure t of toilet seat riser weekly. To clean toilet seat riser, wash with
soap and water or a mild household detergent and rinse with clear water. Ensure the toilet seat riser is
rinsed well before use.
If moisture accumulates inside toilet seat riser, do the following:
1. Remove toilet seat riser from toilet bowl.
2. Turn toilet seat riser upside down and tilt toward drain opening.
3. Rotate until drain opening is facing downward and moisture drains from toilet seat riser.
4. Allow toilet seat riser to air dry for several hours.
s NOTICE: Never use abrasive cleaners or scouring pads on any part of the toilet seat
riser.
LIMITED WARRANTY
GF Health Products, Inc. (“GF”) warrants to the original retail purchaser or lessee (either is the “Customer”) only, that it will replace or repair
components, at GF’s sole discretion, that are defective in material or workmanship under normal use and service. The warranty is for parts only and
does not include labor or costs of shipping. All warranties are conditioned upon the proper use of the product strictly in accordance with applicable
GF instructions. Product provided to users as rentals must be serviced by the provider and inspected prior to delivery. Each user must be properly
trained on the operation and safety of this product prior to use. Within the guidelines set forth in this document, this product is warranted for
six (6) months. The applicable warranty period shall commence from date of shipment to the Customer, unless there is an expiration date on the
component in which case the warranty shall expire on the earlier of the warranty period or the expiration date.
OBTAINING WARRANTY SERVICE
This limited warranty shall only apply to defects that are reported to the Dealer from whom the Customer purchased the product within the
applicable warranty period. If there is not a Dealer, you must contact GF directly by calling 678-291-3207, sending a fax request to 770-368-2386 or by
e-mailing a request to cs@grahameld.com. Specic directions will be provided by the Customer Service Representative.
EXCLUSIONS
The warranty does not cover and GF shall not be liable for the following: 1) Defects, damage, or other conditions caused by misuse, abuse,
negligence, alteration, accident, freight damage, tampering or failure to seek and obtain repair or replacement in a timely manner; 2) Products not
properly installed, used, or cleaned and maintained; and 3) Labor or shipping charges. Other exclusions apply.
ENTIRE WARRANTY, EXCLUSIVE REMEDY AND CONSEQUENTIAL DAMAGES DISCLAIMER
THIS WARRANTY IS GF’S ONLY WARRANTY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED.
For the complete warranty for this product, please visit our website at www.grahameld.com.
