Lumex 89333 User manual

Reclining PVC Shower Chair
Items: 89333, 89337, 89339
Assembly Instructions:
Step 1
Remove partially assembled shower chair from shipping
container/box.
Step 2
Insert the 4 casters into the opening of the fittings. Secure the
casters by inserting and tightening ½" screws into the pre-
drilled pilot holes on the fittings with a Phillips screwdriver.
Step 3
The sliding footrest goes directly under the commode seat on the horizontal bars. Snap the sliding footrest
onto each side and secure the vinyl strap onto each fitting. Once the straps are secure, the sliding footrest
should be able to function and a household furniture polish can help the footrest slide easier.
Step 4
Insert each arm into the fittings located directly on each side of the toilet commode seat. Secure each
section of the arm with ½" stainless steel screws (2 per side).
Step 5
Insert the PVC high-back with mesh sling into the opening of the fittings. Secure with ½" screws.
Step 6
Insert the push/pull handle into the rear top section of the reclining chair. The push/pull handle also serves
as the safety catch for the reclining back.
NOTE: ALL ATTACHED SECTIONS SHOULD BE DOUBLE CHECKED FOR PROPER INSTALLMENT.
GF0600016RevA06
Contents:
Partially assembled (reclined) shower chair
Four (4) caster wheels (2 braking & 2 non-braking)
PVC high-back with mesh sling
PVC push/pull handle
Twelve (12) ½" stainless steel screws
