LuminUltra GeneCount Q-8 User manual

LuminUltra GeneCount®Q-8 Q-16
qPCR Non-Touch Screen Version
For Windows® - based Software
Version 0.16 – for Beta release

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
2
CONTENTS
Introduction................................................................................................................ 3
Safety ....................................................................................................................... 3
Grounding Considerations............................................................................................................ 3
Risk of Electric Shock ................................................................................................................... 4
Power Supply Considerations........................................................................................................ 4
Power cord considerations............................................................................................................ 4
Plugging and unplugging your device ............................................................................................ 4
Placement of instrument ................................................................................................................ 4
Notes during operation ................................................................................................................ 4
Warning Signs............................................................................................................................ 5
Maintenance of Instrument ........................................................................................... 5
Information for the User................................................................................................................ 6
Overview .................................................................................................................. 6
Parts required ............................................................................................................................. 7
Key parameters........................................................................................................................... 8
Set up the instrument.................................................................................................................... 9
Step 1 ............................................................................................................................... 9
Step 2 ............................................................................................................................... 9
Step 3 ............................................................................................................................. 10
Step by step software guide ....................................................................................... 10
Install the software..................................................................................................................... 10
Launching the software .............................................................................................................. 12
The home button ............................................................................................................... 12
Resizing the window.......................................................................................................... 12
The setup page – name setup...................................................................................................... 13
Samples and fluorescence channels set up ............................................................................ 13
Open existing experiment for template file ............................................................................ 13
The setup page – cycler setup ..................................................................................................... 14
Melting curve analysis period ............................................................................................. 14
Hot lid temperature and reaction volume .............................................................................. 15
Saving template ................................................................................................................ 15
Auto Integration Time......................................................................................................... 15
Running the experiment and monitor status ................................................................... 15
Running amplification program ........................................................................................... 15
Running melt analysis ........................................................................................................ 16
Analysis .................................................................................................................. 16
Amplification analysis................................................................................................................ 16
Ct Threshold ..................................................................................................................... 16
Ct Low limit ...................................................................................................................... 16
Normalize........................................................................................................................ 16
Positive vs negative results ......................................................................................... 18
False positive results .......................................................................................................... 18
Standard curve analysis............................................................................................. 19
Steps to perform standard curve analysis: ............................................................................. 19
Save experiment & print report ................................................................................... 20

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
3
Introduction
This manual includes installation instructions, operating instructions, maintenance procedures and
other technical information for the GeneCount® Q-8/Q-16 qPCR Touch Screen device.
Please read and understand this document before operating the unit. Failure to do so could result in
personal injury or damage to equipment. Please consult your local representative if you do not
understand the information in this manual, or if you need additional information.
Care has been used to assemble and describe the information in this manual. LuminUltra
Technologies Ltd. shall not be liable for typographical errors or other mistakes in this manual. All
instructions, pictures and specifications in this manual are based on the latest information that was
available at the time of publication.
Our team strives to improve and update existing information based on user feedback. Newest
versions and information are available for download from the website my.luminultra.com and from
[e-mail].
Note:
Very important information is contained within this manual and it should be carefully read
before first use of the instrument. Failure to operate instrument according to the instruction
could result in damage or abnormal functioning of the instrument.
Warning
The warning messages indicate caution when completing operation of a certain step. If the
instrument is not used in the manner prescribed by the manufacturer, the protection
provided may be compromised.
Safety
During operation, maintenance and repair of this instrument, the following basic notes must be
observed. In case of failure to follow these measures or the warnings or notes indicated herein, the
basic protection provided by the instrument, its safety criteria of design and manufacture, and its
predicted use range would be impaired.
LuminUltra Technologies Ltd. shall not be held responsible for any consequences resulting from the
user's failure to observe the following requirements.
Grounding Considerations

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
4
To avoid an electric shock, the input power cable of the instrument must be properly grounded. This
instrument uses a 10A 3-pin grounded plug. It is for use with a grounded power receptable and is a
safety feature. If the plug cannot be inserted into the receptable the receptable must be fixed by a
qualified electrician to maintain the safety function of the plug and the protection it provides.
Risk of Electric Shock
Operators are not allowed to disassemble instrument protection, replace components, or make
internal adjustment without authorization. If necessary, it must be completed by certified professional
maintenance personnel. In the event work is required to be performed the device must be
disconnected from all power sources.
Power Supply Considerations
Before connecting to the mains and switching the instrument on, make sure the voltage is
consistent
with the instrument’s requirements 110-240V at 16V and 9A. The rated load for the
power socket must not be less
than the instruments maximum load of 144W.
Power cord considerations
The instrument is supplied with a power cable, always use the supplied cable when operating the
instrument. If the power cable is damaged it should be replaced with a new one of the same
specifications. The power supply wire should be treated with care; do not place objects on the wire
and do not place the wire in high traffic areas. If the power cord near a hot surface, add protection
to prevent the insulation from being damaged.
Plugging and unplugging your device
At insertion and withdrawal of power cable, the back of the plug shall be firmly held with the hand.
The plug must be completely and tightly inserted into the socket and must not be removed by pulling
the cable.
Placement of instrument
This instrument should not be positioned in a place where it is difficult to cut off the power supply.
When not in use, the power should be switched off. If the instrument is not going to be used for a
long time, the power should be switched off, the power plug withdrawn and the instrument covered
with soft cloth or plastic film to prevent dust or foreign bodies entering the machine.
Notes during operation
During test, cares shall be taken to prevent liquid from dropping onto the instrument. The castoff used
in
tests, such as consumables, reagent, and so on, should be treated as required, and should not
be thrown
away or poured down the drain.
During test, if there are hazardous substances, user must be trained before using. Hazardous
substances, which has been used, should be handled, and stored according to direction for

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
5
use. Please consult and follow all regulations as required by the local authority having
jurisdiction. User who operate the instrument, must be trained, and has relevant quantification.
Warning
If any of the following should occur, you should immediately switch off the power supply,
withdraw the power plug from the power socket, and contact the supplier to effect a repair:
Repairs can only be carried out by suitably qualified engineers.
• Liquid gets inside the instrument.
• The instrument is rained upon or water is spilled over it.
• The instrument works abnormally, generates an abnormal sound, or generates a strange
odour.
• The instrument is dropped, or its casing is damaged.
• There is an obvious change in the function of the instrument.
Warning
When operating or performing work on the device, all relevant PPE guidelines should be
followed taking special care to protect oneself and others from potentially contagious material.
Warning Signs
• Hot Surface warning Label
Warning
When “HOT SURFACE!” is pasted in the instrument, it means that the metal part (module)
near this sign shall not be touched with any part of the body during the operation of the
instrument or a period of time immediately after the operation of the program to avoid burns!
Maintenance of Instrument
If there is any stain on the surface of the instrument, it can be cleaned with a lint-free cloth and low
strength bleach solution.
Heat conducting oil medium is not allowed in the module hole of this
instrument.

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
6
The drawer should be closed in time after the normal storage and use of the instrument to prevent
dust
accumulation.
Warning
• When cleaning the instrument, the power should be turned off.
• The instrument surface should not be cleaned with corrosive cleaning agents.
• The instrument module includes precise optics. Dust, foreign matter and residue should be
avoided.
Information to the User
This equipment has been tested and found to comply with the limits for a class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures
1. Reorient or relocate the receiving antenna
2. Increase the separation between the equipment and receiver
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
4. Consult the dealer or an experienced radio/TV technician for help
This equipment has been verified to comply with the limits for a class B computing device, pursuant
to FCC Rules. In order to maintain compliance with FCC regulations, shielded cables must be used
with this equipment. Operation with non-approved equipment or unshielded cables is likely to result
in interference to radio and TV reception. The user is cautioned that changes and modifications
made to the equipment without the approval of manufacturer could void the user’s authority to
operate this equipment.

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
7
Overview
This is a user’s guide for using LuminUltra GeneCount qPCR with Windows®-based software.
Parts required
•GeneCount qPCR instrument unit
•AC adapter and power cord
•USB cable
•A Windows®1- based PC

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
8
Key parameters
Capacity (# of wells) 4, 8, 16
Channels (# of Fluorophores per well)
4
(1. FAM/SYBR Green;
2. JOE/HEX/VIC/TET;
3. ROX/Texas Red;
4. CY5/LIZ/Cy5.5)
Multiplex capability Up to 4 targets per well
Minimum detection threshold 4 copies
Dynamic range >1.0E9
Signal Interface USB 2.0, Wi-Fi
Excitation source High endurance LED
Detector Ultra–low- light CMOS Bio-imaging chip
Thermal system Solid-state, Peltier-based
Tube/plate formats 0.2mL, 4 or 8-tube strip
Reaction volume 10uL – 60uL
Filters: 4 sets exchangeable*, **
Excitation Range: 460nm – 670nm
Emission Range 510nm – 720nm
DNA probes supported:
DNA binding dyes (e.g. SybrGreen),
hydrolysis probes (e.g. TaqMan probe) and
hybridization probes (e.g. FRET probes).
Temperature Uniformity < +-0.2°C
Temperature control resolution +-0.1 °C
Temperature Ramp Rate 6.5°C/s heating; 4°C/s cooling

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
9
Size and weight 165mm (L) x 115mm (W) x 75mm (H).
Weight 950g
Power supply
DC 16V, 144W
(Adapter provided that accepts
110V/240V AC)
*: Wavelength characteristics can be modified by changing filter modules.
**: We support 1 – 4 channels in different configurations.
Set up the instrument
Step 1
After installing the software (see appendix at end
of the document about how to download,
decompress and install software from LuminUltra’s
web site). Connect instrument with Windows® -
based PC via included USB cable. Power up the
instrument using the included AC adapter. In
some models, there is a main power switch in the
back. Please flip it to the on position.
Figure 1. PDx 16 USB and power connections
Step 2
Start the software, by launching Anitoa.exe. The software should recognize the instrument HW
automatically. There is no need to install a driver as Windows® should already have the driver
necessary to connect to GeneCount device.2

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
10
Step 3
Open the instrument lid and place the
test tubes filled with sample and
reagent mix. We support 0.2ml
standard qPCR tubes. Make sure the
top lid of the tube is transparent and
flat. Close the instrument lid when
done. For more information about the
reaction tubes selection for GeneCount
qPCR instrument, please see Appendix
A.
1We required Windows® 10 with Office 2010 or later installed to support print report function.
2We use the USB HID device interface for GeneCount. This is the same USB HID for keyboard and
mouse
Step by step software guide
Install the software
The Beta version of the software is delivered as either a folder or one compressed file, with the
name “Anitoa-Eng” for the English version.
If the file is one compressed file, please decompress it first. If you do not have a
compress/decompress utility installed on your computer, go get one at: http://www.7-zip.org . It
is free.
Once the file is decompressed, just copy the folder to any directory in your PC. The folder should
look like this, see below, when opened. The executable file is the file “Anitoa.exe”.

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
11

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
12
Launching the software
When the GeneCount PC software is launched, after a brief delay for device initialization, the
front page will display as shown in Figure 1.
Figure 1 GeneCount software front page
Several notable features are marked in Figure 1. Marker (1) is an indicator of whether the
GeneCount USB device is found. If found, a message “HID Device Connected” is shown along
with a green dot. We call it HID, because the GeneCount instrument uses USB HID device class.
The home button
Marker (2) is the home button. At any time of running this software, click this button to return to this
front page.
Resizing the window
Marker (3) is the place to drag to resize the GeneCount software windows.

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
13
The setup page – name setup
Click on the “Setup” button will take us to the setup page (Figure 2). Here we can set up the
experiment. Here we can name the experiment and all the samples in the wells. We can also
name and select the fluorescence channels for qPCR fluorescence reading.
A default date-coded experiment name is given on this page when we first enter. Feel free to
change it to something you choose.
Samples and fluorescence channels set up
The software automatically detects the number of reaction wells the connected instrument can
support. Each reaction well can be associated with a sample. In this page, the user can enter a
name for each sample. It a sample well name field is left empty (white spaces), it is considered that
the sample does not exist for that well.
It is important to select the fluorescence channels (Marker (2)) we need to use for the experiment.
The selection of the channels depends on the type of fluorescence dyes used in the assay design.
We can also give a name for each selected channel
Figure 2 The setup page – name setup
Open existing experiment for template file
We can also load an existing experiment file or template file by clicking on the “Open experiment
file” button (Marker (1)).
When this step is done, we can click on the “Next step” button to continue setting the thermal
cycling program

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
14
The setup page – cycler setup
Here we can setup the thermal cycler program. We could choose the type and number of thermal
periods and steps, assign time period and temperatures. We could have up to two Pre-Denature
periods. The main thermal cycling period can have 2, 3, or 4 steps. We can also define at which
step the fluorescence capture is done. Lastly, we have a hold period whose temperature and time
period are configurable.
A cycler program can have several periods; and each period can have one or more steps. For
example, we could have pre-denature period, cycle period and hold period. In the cycle period,
we can have many repeated cycles consists of denature, annealing, and extension steps.
Figure 3 Cycler setup
qPCR amplification thermal cycling program starts when the user clicks on the “Start” button.
Melting curve analysis period
We can also add a Melt Curve (Marker (1)) analysis period at the end of the main thermal cycling
program. The Melt curve analysis can be triggered either manually by clicking the start melt
analysis button, or automatically by checking “” check box (not done yet).

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
15
Hot lid temperature and reaction volume
In this page, we can also set the desired hot lid temperature and reaction volume. The latter (reaction volume
setting) is used for data analysis only. It will not affect how the experiment is run.
Saving template
At this step, we can also save the settings to a template file (Marker (2)). So next time when we perform a
similar experiment, we can just load the template file instead of manually entering all the information again.
Auto Integration Time
This is an option to let the instrument automatically choose the optical sensor integration time (i.e. Exposure
time of the fluorescence camera) according to the fluorescence strength of the assay (Marker (3)). The goal is
to adjust the sensitivity of the fluorescence camera so that the signals from the chemistry fall into the
appropriate dynamic range of the sensors and yield the best signal to noise ratio (signal quality). We
recommend leaving this check box checked.
Running the experiment and monitor status
In the setup page – cycler setup, when we are satisfied with all the settings and loaded the
samples, we can start running the experiment by click the “Start…” button.
Before the instrument starts to execute thermal cycling program, it will automatically check to
ensure the lid is closed and the main power is applied. If either of these conditions is not met, the
software will show popup windows with warnings. We could correct these programs and start
again by simply press the “Start…” button again.
When the qPCR cycler starts to run, the software will automatically switch to Run pages. The first
Run page will allow us to monitor hot lid and reaction well temperature. We can easily see if the
temperature is going through the cycling programs or not.
Running amplification program
When running normal qPCR amplification program, the amplification window will real time
monitor the fluorescence signal from the samples. In addition, the Run-Amplification Curve page
will also show the current run status and estimated remaining run time

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
16
Running melt analysis
When running Melt analysis, the “Run-Melt
curve” will show the fluorescence change rate
as function of temperature.
Figure 4. Melt analysis
Analysis
There are two analysis pages: Amplification analysis and Standard curve analysis. The latter is
used for determining the quantity of the DNA targets using standard curve analysis method.
Amplification analysis
This will show the amplification curves for all
samples. We can select the samples and
study, set several parameters to this analysis.
Ct Threshold
The threshold for determining Ct is expressed
as the percentage of the saturating level of the
amplification levels after normalization. The
default Ct threshold is 10%. The bigger this
percentage, the more delayed the Ct values
are.
Ct Low limit
The minimum value of Ct is set through this parameter. This setting is helpful in determining the
base fluorescence value for amplification curve analysis. In most qPCR experiments, the
concentration of the analytes prior to amplification is low, such that the Ct value cannot be less
than 13 or so.
Normalize
When displaying amplification curve, we usually normalize the fluorescence values. This will allow
us to visualize Ct threshold value. This choice will not affect the result of the analysis.
Figure 5. Amplification analysis

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
17

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
18
Positive vs negative results
For each sample’s DNA target, we get a positive vs negative result. Generally, the negative result
will be shown as “Neg” and the positive result will be shown with a Ct value between Ct low limit
and maximum cycle number. If we mouse over the Ct value in the data table, we will see some
additional parameters that justifies the positive/negative test. These parameters include the
saturation fluorescence level, amplification efficiency and fluorescence reading signal to noise
ratio.
False positive results
Sometimes a negative result is the result of a “false positive” result. If we mouse over the result, we
see that the “Confidence” level of positive is below a threshold, for example, 10%. The confidence
threshold is adjusted through advanced setting window.
Further discussion of how to judge positive vs. negative results is given in Appendix B.
Figure 6. Positive vs Negative analysis

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
19
Standard curve analysis
Standard curve analysis is used to determine the absolute concentration of a sample by comparing
to other samples with known amount of analyte concentration. We called the samples with known
concentration “standards” and the ones with concentration that needs to be determined
“unknowns”.
For such analysis, the “standards” and “unknowns” should be in the same fluorescence channel to
ensure they are comparable. Thus standard curve analysis is always performed on one specific
channel.3We have to first the select the specific channel and perform such analysis.
Figure 7. Standard curve analysis page
Steps to perform standard curve analysis:
Step 1: Select the fluorescence channel for such analysis
Step 2: Add standard samples – we can select the samples that are standard and click “Add the
standard” button (Marker 1) to add to standard table. We can then assign the concentration
numerical values to these standard samples by typing into the table.
Step 3: Draw the curve by clicking “Draw Std Curve” - Marker (2)
Step 4: Add unknown samples to unknown table - Marker (3)
Step 5: Calculate concentration for unknown samples - Marker (4)
3We usually also make sure no other competing DNA targets and primer/probe sets are present in
standard curve analysis samples, unless in very low concentration.

LuminUltra GeneCount®Q-8 Q-16 qPCR
Quick Guide For Windows® - based Software
20
Save experiment & print report
Open report page to print report and save experiment.
The experiment file will contain all the settings and experiment results.
Two report formats will be used for report generation. The excel file report is hand editable. The
PDF report is easier to store and use on different platforms.
Figure 8. Save and export page
In this page, we can also enter the operator’s name and some comments. These will be saved with
the experiment file.
