AIR-CR

This document provides detailed information on the AIR-CR
Controller device structure and steps for installing and, connecting it.
It also includes instructions for preventing or troubleshooting many
common problems.
This guide is for informational purposes only, and in the event of any
discrepancies, the actual product takes precedence.
All instructions, software, and functionality are subject to change
without prior notice.
The latest version of the manual and additional documentation can
be found on our website or by contacting customer support.
The user or installer is responsible for complying with local laws and
privacy regulations when collecting personal data during the use of
the product.
AIR-CR_(serial number)
192.168.4.1
192.168.1.100
none
admin
admin
Enabled
Enabled
Disabled
Disabled
30 minutes
Wiegand
26 bit
34 bit
Introduction
Default Device Settings
3AIR- CR
•Wi-Fi device name when searching
•Access Point (AP) Wi-Fi IP address of the device
• Ethernet IP address of the device
•Wi-Fi password
•Login
•Password
•RFID 125 kHz
•RFID 13.56 MHz
•Copy protection
•Bluetooth
•AP Wi-Fi timer
•Wiegand or Open Supervised Device Protocol
(OSDP) sending method
•Wiegand format 125 kHz
•Wiegand format 13.56 MHZ

Communications
•Wi-Fi
• Ethernet
• Bluetooth
• Wired interfaces
802.11 b/g/n 2.4 GHz
With the RJ-45 adapter (10/100Mbit)
Bluetooth® 5 (LE)
Wiegand/OSDP via RS-485
12 - 24 VDC +/- 10 %
0.5 A (6 W)
0.13 A (1.56 W)
0.5 A (6 W)
Yes
Yes
Electrical characteristics
• Input voltage
• Operation current (MAX) 12 VDC
• Operation current (AVG) 12 VDC
•Switchable output current (MAX) 12 VDC
•Output short-circuit protection
•Power supply reverse polarity protection
Device info
• Model
• Processor
•Over-the-air (OTA) update
•Built-in web server
•Support for 125 kHz identifiers
•Support for 13.56 MHz identifiers
•Support for copy protection for MIFARE
Classic mini/1K/4K identifiers
AIR-CR
ESP32-S3
Yes
Yes
EM Marine
MIFARE DESFire; MIFARE Plus; MIFARE Ultra
Light; MIFARE Classic mini/1K/4K;
MIFARE Classic EV1 1K/4K; NFC Tag
Yes
2
1
Physical connections
• Inputs
• Outputs (open collector) 0.5 A
3280 ft (1000 m)
328 ft (100 m)
33 ft (10 m)
33 ft (10 m)
Work distance
• RS-485 *
• Wiegand
• Wi-Fi 2.4 GHz (open space)
• Bluetooth (open space)
Device Specifications
4AIR- CR
Physical characteristics
•Housing material
•Mounting method
•Dimensions (diameter, height)
•Weight
ABS plastic UL94 V-0
Wall mount
2.36" x 0.67" (60 x 17 mm)
(mounting ring) 2.36" x 0.86" (60 x 22 mm)
1.59 oz (45 g)
Environmental requirements
•Operating temperature
•Ingress Protection rating
-22°F ~ 158°F (-30°C ~ 70°C)
IP65
* See general specifications for RS485 interface.

Device Dimensions
0.67"
3.375"
125, 65535
5AIR-CR
2.125"
2.36"
RFID CARD

Red
Blue
Black
Green
Orange
Purple
Pink
White
Yellow
Brown
Gray
Black
Green
White
Orange
Yellow
+VDC
GND Lock
GND
Green LED
Red LED
DPS
Exit Button
RS-485 A+
RS-485 B-
Data 0
Data 1
GND
TX-
TX+
RX-
RX+
Wire Designation
6AIR-CR
The manufacturer reserves the right to modify the external pin assignment and their placement, as well as the appearance of the device
without prior notice.
These changes may be made to improve functionality, ergonomics, or to comply with technical requirements and standards.
Users are advised to consult the latest versions of technical documentation and instructions before using the device.
Red
Blue
Black
Green
Orange
Purple
Pink
White
Yellow
Brown
Gray
Black
Green
White
Orange
Yellow
+VDC
GND Lock
GND
Green LED
Red LED
DPS
Exit Button
RS-485 A+
RS-485 B-
Data 0
Data 1
GND
TX-
TX+
RX-
RX+
AIR-CR
AIR-R

Installation
It is best to avoid installing the device on metal surfaces, as this may
reduce the card reading distance, WI-Fi connection quality, and
Bluetooth connectivity.
If installing on a metal surface is necessary, use the reinforced plastic
mounting base that is supplied with the device.
Wiegand connection
The length of the communication line through the Wiegand interface
must not exceed 328 ft (100 m).
This interface is susceptible to external sources of interference. We do
not recommend running it directly parallel to power cables or near
electric lights.
It is recommended that the Wiegand communication line be routed
at least than 1.64 ft (0.5 m) away from any power cables.
If the communication line is longer than 16.4 ft (5 m), UTP 5E cable is
recommended.
Connecting OSDP
The OSDP uses an RS-485 interface that is designed for long-distance
communications. It operates at ranges up to 3,280 ft (1,000 m) with
good resistance to noise interference.
The OSDP communication line should be laid as far away as possible
from power cables and electric lights. A UTP 5E or FTP 5 twisted pair
cable should be used as the OSDP communication line (if possible,
ground the shield at one end). To ensure reliable system operations, it
is best to use one power source for the controllers and a separate one
for the actuators.
The power supply line wires for the reader should be kept as short as
possible to avoid a significant voltage drop across them.
After cabling, ensure that the power supply voltage to the reader is at
least 12 VDC with the locks switched on.
Installation Recommendations
7AIR-CR

Ethernet Network
8AIR-CR
Cable length up to 325 feet
Warning
Make sure that the power supply voltage
meets the recommended requirements.
1
2
3
4
5
6
7
8
Connection Diagram
+VDC
GND
TX-
TX+
RX-
RX+
+VDC
GND
G
W.G
O
W.O
W.O
O
W.G
4
5
G
7
8
W.O
O
W.G
B
W.B
G
W.Br
Br
white-orange
orange
white-green
blue
white-blue
green
white-brown
broun
Red
Blue
Black
Green
Orange
Purple
Pink
White
Yellow
Brown
Gray
Black
Green
White
Orange
Yellow
AIR-CR
RJ-45 Adapter
Warning
The voltage level at the power supply and at the Controller may differ depending on the cable length and the resistance of the conductor.
Use a separate power supply to connect the reader if the cable is longer than 165 feet or the voltage at the end of the line is less than 10
volts.
BE SURE TO CONNECT THE GND OF THE CABLE FROM THE CONTROLLER TO THE GND OF THE AUXILIARY POWER SUPPLY!
DO NOT USE POWER SUPPLIES WITH DIFFERENT VOLTAGE LEVELS!
Use a multimeter in the VDC measurement mode to verify that the power supply voltage meets the recommended requirements.

9AIR-CR
Warning
The voltage level at the power supply and at the Controller may differ depending on the cable length and the resistance of the conductor.
Use a separate power supply to connect the Controller if the cable is longer than 165 feet or the voltage at the end of the line is less than
10 volts.
BE SURE TO CONNECT THE GND OF THE CABLE FROM THE CONTROLLER TO THE GND OF THE AUXILIATY POWER SUPPLY !
DO NOT USE POWER SUPPLIES WITH DIFFERENT VOLTAGE LEVELS !
Use a multimeter in the VDC measurement mode to verify that the power supply voltage meets the recommended requirements.
Wiegand Reader
Connection Diagram
+VDC
GND
G LED
R LED
Data 0
Data 1
Red
Blue
Black
Green
Orange
Purple
Pink
White
Yellow
Brown
Gray
Black
Green
White
Orange
Yellow
Red
Black
Green
Orange
Brown
Gray
White
Black
Yellow
W. + BR BR
W. + W.GO
W.B
B
O
G
AIR-R
AIR-CR

10AIR-CR
Warning
OSDP Reader
Connection Diagram
+VDC
GND
OSDP+
OSDP-
GND
Red
Blue
Black
Green
Orange
Purple
Pink
White
Yellow
Brown
Gray
Black
Green
White
Orange
Yellow
Red
Black
White
Black
Yellow
W. + BR BR
W. + B B
G
W. W.G+ O
O
AIR-R
AIR-CR
The voltage level at the power supply and at the Controller may differ depending on the cable length and the resistance of the conductor.
Use a separate power supply to connect the reader if the cable is longer than 165 feet or the voltage at the end of the line is less than 10
volts.
BE SURE TO CONNECT THE GND OF THE CABLE FROM THE CONTROLLER TO THE GND OF THE AUXILIARY POWER SUPPLY!
DO NOT USE POWER SUPPLIES WITH DIFFERENT VOLTAGE LEVELS!
Use a multimeter in the VDC measurement mode to verify that the power supply voltage meets the recommended requirements.

11AIR-CR
Warning
Exit Button
Connection Diagram
+VDC
GND
G LED
Button
Red
Blue
Black
Green
Orange
Purple
Pink
White
Yellow
Brown
Gray
Black
Green
White
Orange
Yellow
Red
Black
Blue
Green
W. + BR BR
W. + B B
G
W.G
AIR-B
AIR-CR
WAVE
TO OPEN
The voltage level at the power supply and at the Controller may differ depending on the cable length and the resistance of the conductor.
Use a separate power supply to connect the reader if the cable is longer than 165 feet or the voltage at the end of the line is less than 10
volts.
BE SURE TO CONNECT THE GND OF THE CABLE FROM THE CONTROLLER TO THE GND OF THE AUXILIARY POWER SUPPLY!
DO NOT USE POWER SUPPLIES WITH DIFFERENT VOLTAGE LEVELS!
Use a multimeter in the VDC measurement mode to verify that the power supply voltage meets the recommended requirements.

12AIR-CR
Warning
Door Sensor & Magnetic Lock
Connection Diagram
+VDC
Lock
GND
Sensor
Red
Blue
Black
Green
Orange
Purple
Pink
White
Yellow
Brown
Gray
Black
Green
White
Orange
Yellow
AIR-CR
MAX 500 mA
The voltage level at the power supply and at the Controller may differ depending on the cable length and the resistance of the conductor.
Use a separate power supply to connect the reader if the cable is longer than 165 feet or the voltage at the end of the line is less than 10
volts.
BE SURE TO CONNECT THE GND OF THE CABLE FROM THE CONTROLLER TO THE GND OF THE AUXILIARY POWER SUPPLY!
DO NOT USE POWER SUPPLIES WITH DIFFERENT VOLTAGE LEVELS!
Use a multimeter in the VDC measurement mode to verify that the power supply voltage meets the recommended requirements.

Connecting to the built-in Wi-Fi access point.
Step 1. Connect the device to a power source.
Step 2. Search for Wi-Fi and connect to the AIR-CR_xxxxxxxxx network.
Step 3. Enter the IP address of the device 192.168.4.1 in the address bar of
your browser and press Enter.
Step 4. After the page loads, enter your login and password.
After login, the browser will redirect you to the Quick Start page.
Connection via Ethernet.
Reminder: you must first change the network settings of the controller if they are different
from those of the network you are connecting to. The controller and the mobile device from
which you are configuring must be on the same network.
Step 1. Connect the Ethernet cable to the device using an adapter or by
connecting the wires as shown in the diagram below.
Step 2. Connect the device to a power source.
Step 3. In the address bar of your browser, enter the device IP address
192.168.1.100 and press enter.
Step 4. After the page loads, enter your login and password. After login, the
browser will redirect you to the Quick Start page.
Connecting to Device
Login
13AIR-CR

Quick Start
The device's interface allows you to use the Quick Start feature to quickly
set up your device to connect to the Internet and add it to a cloud service.
14AIR-CR
Network Connection:
Select the connection method: Wi-Fi or
Ethernet.
•A. Wi-Fi:
◦Click on the empty service set identifier
◦(SSID) field to scan and choose a
network.
◦Enter the network password and
submit to establish the connection.
•B. Ethernet:
◦Choose “DHCP” for automatic settings
or “Manual” for manual configuration.
◦Submit the entered information to
confirm the settings.
Cloud:
Select which type of connection you are
using:
◦Wi-Fi or Ethernet.
◦Enter your account ID and submit.
Security:
◦Checkbox: Use the same password for
two purposes.
◦The entered SSID will be displayed
during Wi-Fi scanning.
◦Choose a strong and unique password,
◦and keep it secured at all times.

System
This section displays information about the current settings and status of
the device.
15
•The Current Status subsection displays
the:
◦Current time and date. These upload to
the device automatically when the
device is connected to the Internet.
◦Status of the device's connection to the
Ethernet router.
◦Status of the device's connection to the
Wi-Fi router.
◦Status of the device's connection to the
◦cloud server.
◦Level and quality of the device's
connection to the Wi-Fi router.
◦Power supply voltage value.
•Network Information subsection displays
the:
◦Device’s current network settings.
◦Device’s network address.
◦Network mode - Manual or DHCP.
◦The network mask.
◦Domain Name Service (DNS).
◦Network port of the device.
•In the Hardware Information subsection,
you can see the:
◦Device model name.
◦Device type.
◦Device serial number.
◦Current firmware version.
◦Current hardware version of the device.
◦Web version used by the device.
◦Application Programming Interface
(API) version used by the device.
AIR-CR

Network
16
In this section, you can configure the connection to the Wi-Fi router for
remote administration or to update the firmware of the device. You can also
change the connection settings for the built-in Wi-Fi AP and set the activity
time.
The Wi-Fi Network subsection provides the
following functions:
•Enabled check: enables or disables the
ability to use the Wi-Fi router connection.
•Choose Wi-Fi network field: displays the
name of the Wi-Fi network you want to
connect to. Clicking on this field displays
all available wireless networks as a list.
After selecting the desired network, enter
the password to connect.
•Connection mode: Select DHCP for
automatic network settings or Manual to
enter all network settings manually in the
available fields below.
In the Wi-Fi AP Settings subsection, you can
select the operation option of the built-in
Wi-Fi AP access point which provides the
connection to the device:
•Check Always On: makes the AP of the
device searchable all the time.
•Unchecked: makes the device’s AP of the
device available for only 3 minutes
following moment of active connection.
•Wi-Fi Timer field: specifies the availability
time in minutes.
•Enabled timed mode check: enables the
option to specify the availability time.
•Local Wi-Fi AP Name field: The user can
change the password for connecting to
the AP.
•Password field: change the password for
connecting to the AP.
•Enable Hidden Mode checkbox: hides the
name of the built-in AP network when
searching. To connect to the device later,
•you will need to know its name and enter
•it manually when connecting.
AIR-CR

Network
17
The Cloud settings subsection allows you to
connect the controller to a cloud server for
later use.
In the Server form, you can select one of the
available servers to connect to, or select a
custom connection option if a private server
is used.
Next you need to select the connection
method, which depends on which type of
connection is used to access the Internet. If
you have connected the device to the
Internet via Ethernet cable, then specify the
connection method ”Ethernet.” If you
connected the device to the Internet using
a Wi-Fi connection, specify the connection
method as “Wi-Fi.”
The Account ID form is used for adding to
the cloud system. You only need to specify
the ID to connect.
When connecting to other cloud systems,
you may need to enter server address, login
password, and invite key.
When using a private server, the
parameters required for connection must
be filled in. The parameters are determined
by the properties of the server and its
security level.
AIR-CR

Main
18
The main section allows you to configure the functionality of the device and
determine the modes of operation.
•Selecting RFID Readers makes the 125 kHz
and 13.56 MHz built-in reader antenna
modules active and configurable.
•Uncheck the Enabled checkbox in the
RFID Reader 125 kHz settings section to
disable the ability to read identifiers of this
format.
•Check the Reverse Byte Order checkbox to
change the code reading order for 125 kHz
identifiers.
•Uncheck the Enabled checkbox in the
RFID Reader 13.56 MHz settings section to
disable the ability to read identifiers of this
format.
•Select the desired Output Format from
the list of supported Wiegand formats.
Note: It is recommended to use the same format on all
readers within an access control system. The default
format for 13.56 MHz identifiers is Wiegand 34 bit.
•Check the Reverse Byte Order checkbox to
change the code reading order for 13.56
MHz identifiers.
•Check the Copy Protection checkbox to
use the 13.56 MHz format ID verification
mode for authenticity.
•Enter the ID encryption password.
Note: The Copy Protection feature uses a unique
password encryption method to encrypt private
identifier memory areas. If the encryption password of
the identifier and the reader match, then the reader will
recognize the identifier. If there is no password or it is
different, the identifier is ignored. Thus, all identifiers
other than encrypted ones will be ignored. Copying an
encrypted identifier means that only part of its code
from open areas can be copied. At the same time, closed
areas are difficult or impossible to copy.
AIR-CR

Main
19
•Selecting the No-Touch Button activates the built-in proximity sensor, which acts as an exit
button.
•Using the Distance slider, you can select the required distance at which the configured
output will be activated.
•Check the Enabled checkbox to enable the built-in Bluetooth Low Energy (BLE) module. In
the Name field, you can give the device a name that will be visible when scanning
available Bluetooth connections.
•Check the Reverse Byte Order checkbox to change the order in which the identifier code is
read from the reader connected to the controller.
Note: Byte order will be reversed for all identifier types.
The main section allows you to configure the functionality of the device and
determine the modes of operation.
AIR-CR

OSDP
20
The Open Supervised Device Protocol
(OSDP) port subsection allows you to
configure the connection of external
devices and shows the interaction method
on the diagram. In the baud rate form,
select the required baud rate for all
connected devices.
The Search for Devices subsection allows
you to automatically detect the presence of
a connected device. Automatic detection is
performed if the device is able to publish
data about itself. It is necessary to perform
a search and subsequent addition by
connecting devices one by one. This means
that there cannot be more than one
unknown device on the line.
After a device is detected by autosearch,
information about it is displayed in the
information field and you can assign a
name and physical address to the found
device.
Pressing the button will add the device to
the list on the left. In the list, you can make
additional settings for each device
individually.
You can edit its name and address, remove
it from the list, and also choose the option
to use the OSDP version.
Selecting version 2 of the OSDP allows the
use of a secure channel. Check the
appropriate box and enter the encryption
key that the connected device uses. After
clicking on the "Link" button, the result of
establishing a secure connection is
displayed - Secure or Not Secure.
Note: To determine the device to be added
by OSDP, the "Installation Mode" function
must be enabled in it. If this condition is not
met, the device being added may not be
detected or may not be configured.
After finishing the process of adding and
configuring, disable "Installation Mode" on
the device being added.
AIR-CR
