LUNNA LUN-6002 Manual

smart
air purifier
LUN-6002
Instruction Guide

42
disclaimer
product overview
control panel
lter installation instruction
button operation
LUNNA app setup
maintenance
faq
1. Before connecting the power supply, please check whether the voltage of the product is consistent
with the local power supply voltage.
2. If power cord is damaged, in order to avoid danger, it must be replaced by professional staffs.
3. Please stop using if the plug, power cord or product is damaged.
4. Keep the air inlet/outlet free from being blocked.
5. Do not insert foreign things into the machine.
6. Person with physical or mental disability, or without relevant experiences and skills (including
children) should use it under guiding and instructing.
1. To avoid electric shock and re,do not allow water, liquid or any ammable detergent to get into or
to clean the product.
2. Do not spray any ammable materials such as pesticides or perfumes around the product.
Before using, please read this user manual carefully and keep it for future reference.
safety warning
danger warning
4-5
6
7
8
9-10
11
12
13
table of content disclaimer

65
product overview
1. This product cannot replace normal ventilation, daily dust collection or oil pumping when cooking.
2. Ensure the product socket is well connected with plug. If not, the plug will be hot.
3. Do not place any items above the product.
4. Be sure to place and use the product on a rm, at and horizontal surface.
5. Leave at least 30cm of space on the back and sides of the product, and at least 50cm of space above
the product when using.
6. Do not place the product under air conditioner to prevent condensation water dropping into
the product.
7. Ensure both the lter and the back cover are properly installed before connected power.
8. Please use the lter specially designed for this product.
9. Do not take the lter as fuel or similar purposes to avoid irreversible harm.
10. Do not use hard objects to strike the products, especially the air outlet and air inlet.
11. Do not insert nger or other things into the air outlet/inlet to prevent physical damage or trouble.
12. Do not use this product when you are using an indoor spray repellent, or in a place lled with grease,
ammable gas or chemical fumes.
13. Ensure the product is unplugged before moving, cleaning, maintaining and replacing lter.
14. Unplug the power connecting before moving the machine. Do not pull the wire to move the machine.
usage warning
control panel
body
air inlet
air outlet
light ring
air quality sensor
HEPA lter back cover

87
control panel filter installation instruction
Before using, please remove the package of the lter. Ensure the machine is unplugged before removing
or installing the lter.
Press the red circle switch to
take out the back cover.
Put the lter into
the machine
Remove the lter from
the machine.
Press the red circle switch button
to close the back cover.
Remove the plastic
cover of the new lter.
Wind Speed /
Filter Button
Power Button
UV / Light Button
Timer / Wi-Fi Button
specifications
Model No. LUN-6002
Size 10.7in. x 11.9in. x 22.1in.
Net Weight 4.8kg
Power Supply Input: AC 100-240V 50/60Hz
Power 50W
Noise <56dB
Coverage Area ≤45-50m2
1
4
2
5
3

109
button operation
Connect the power all indicators will be on 1 second and then off. When Power Button Wind Speed
Button, Light Button and Timer Button are on again it means the machine is in standby mode
Power Button
Press the power button,the machine turns on auto default Mode the corresponding
indicator will be on after 30s of pre-working the light ring will display the relevant colors
according the air quality.
Wind Speed Button
1. In the condition of working,press the Wind Speed Button to adjust the wind speed among
the circulation of S-H-Auto grade,and the corresponding indicators will be on. Every time
you press the button the buzzer rings for one time
2. When the machine work in auto mode, the wind speed will be adjusted according
the air quality.
3. When the machine works in sleep mode, if no operation for 5 seconds, the machine will
enter sleep mode.
Reminder of lter replacement
In the condition of working, when the machine detects the lter is saturated after running
for 2200 hours, the lter mark will keep ashing in red. Long press the Wind Speed Button
for 7s to stop ashing light and to reset after installing a new lter.
UV/Light Button
1. In the condition of working,long press the UV/Light Button for 3S to start the UV
function Long press it again, the UV function will be off. Every time you long press the
UV/Light button, the buzzer rings for one time.
2. In the condition of working, press the UV/Light Button, the light will be changed among
the circulation of off-soft-standard.
Timer/Wi-Fi Button
1. In the condition of working, press the Timer Button to set timer among the circulation
of 2H, 4H and 8H. Every time you press the button, the buzzer rings one time and the
corresponding indicator will be on.
2. Long press the Timer/Wi-Fi Button for 5 seconds to start Wi-Fi function, and the
indicator will be on. If you turn off the machine, the Wi-Fi function need to be reset
when you turn on the machine again.

1211
works with LUNNA smart app
1. Use your mobile phone to search for LUNNA smart app in the App Store
or Google Play to install LUNNA smart app.
2. Open the LUNNA smart app, click “register”, use your phone number or
email to register the LUNNA smart app account, and then log in to the
LUNNA smart app.
1. Connect the mobile phone to the home wireless network, and turn on the mobile phone Bluetooth
(please select 2.4GHz Wi-Fi network).
2. Open the LUNNA smart app.
3. Enter the homepage of the LUNNA smart app. Click “+” to select to add a device, the app will display
manual addition and automatic discovery.
4. AUTOMATIC DISCOVERY: When the corresponding authority is turned on, the device can be
automatically discovered, and the device needs to be in the network conguration state and
turned on.
MANUALLY ADD: Select the name corresponding to the product, Wi-Fi + Bluetooth mode.
download and registration:
add device:
When conrming that the WIFI indicator of the device is ashing quickly, click OK, and then wait for the
connection. RECOMMENDED: When “Successfully add 1 device” appears, it means the connection has
been completed and your device will be listed in your APP list.
1. Click on the Wi-Fi quick connection in the upper right corner to select the hotspot distribution
network (compatibility mode), conrm that the Wi-Fi indicator of the device ashes slowly, click
OK, and enter your home Wi-Fi and Wi-Fi password.
2. Next, click to connect to go to the WLAN setting interface of the phone, and then select the Wi-Fi
network “LUNNAsmart_XXXX” to connect it.
Your device will be listed in your APP list. Now, you can control your smart device through the mobile
APP anytime and anywhere (make sure your mobile phone and smart device are connected to the
network, make sure your router name is changed to LUNNAsmart_XXXX).
bluetooth conguration:
hotspot conguration:

1413
faq
NOTICE: If the above FAQ cannot solve your problems and need maintenance, please contact the supplier or after sales service center.
Please do not disassemble the machine to maintain by yourself.
SITUATION REASON
Not working
• Is it plugged into a power socket? Is there a power outage?
• Is the home leakage switch or fuse cut off?
• Is the lter replacing indicator keep ashing?
Poor performance • Is there any dust in the surface of primary lter?
• Is there any obstacle blocking the air inlet/outlet.
Signicant noise
• Is there anything stuck on the fan in the air outlet?
• Is the machine tilted?
• Please set a lower grade of wind speed if the noise is too loud , or set low grade of wind speed
when using in bedroom at night.
Coming out
nasty smell
• It is the normal phenomenon that the machine emits the smell of plastic for the rst time.
• The machine will emit nasty smell if the lter is dusty, so in this situation, please clean or
replace the lter.
• If the burning smell emits from the machine, please unplug the power socket and contact with
buyer or customer service.
The reminder of
replacing lter is still
ashing after user have
replaced a new one
• Please press the Wind Speed/Filter Button for 7 seconds to reset the machine and the
life counter of the lter will restart.
maintenance
• Ensure the machine is unplugged before maintenance.
• Do not immerse the air purier into water or any liquid.
• Do not use abrasive, corrosive or ammable cleansers (such as bleach or alcohol) to clean any
part of the unit.
• Clean the lter regularly. Do not wash or reuse the lter.
• Ensure the machine is unplugged before replacing the lter.
• Please sterilize the lter under sunlight regularly.
• Do not use a vacuum cleaner to clean the lter or wash it directly.
1. Ensure the machine is power-off and unplugged.
2. Take out the lter to clean any dust from the surface of it.
3. Use a soft cloth with neutral cleanser to clean away any dust or debris from the surface of the
machine.
4. After the lter is dried, install it into the air purier to restart.
5. If you do not use the machine for a long time, ensure the machine is dry out, put on the dust cover
bag and place it in a cool and well-ventilated place.
6. To ensure a good performance of the machine, please turn on the machine for a few minutes from
time to time.
NOTICE: Please don’t drop any water into the machine when clean the air outlet.
read before cleaning and storing
cleaning & storage

LUN-6002
Guía de instrucciones
purificador
inteligente
de aire

1817
descargo de responsabilidad
descripción del producto
panel de control / especicaciones
instrucciones de instalación del ltro
operación de botón
conguración de la aplicación LUNNA
mantenimiento
preguntas más frecuentes
1. Antes de conectar a la fuente de alimentación, verique si el voltaje del producto es consistente con
el voltaje de la fuente de alimentación local.
2. Si el cable de alimentación está dañado debe ser reemplazado por personal profesional para evitar
peligros.
3. Deje de usarlo si el enchufe, el cable de alimentación o el producto están dañados.
4. Mantenga la entrada/salida de aire libres de obstrucciones.
5. No inserte objetos extraños en el aparato.
6. Las personas con discapacidad física o mental, o sin experiencia y habilidades relevantes (incluidos
los niños) deben usarlo bajo guía e instrucción.
1. Para evitar descargas eléctricas e incendios, no permita que agua, líquido inamable o cualquier
detergente penetre o limpie el producto.
2. No rocíe materiales inamables como pesticidas o perfumes alrededor del producto.
Antes de usar, lea atentamente este manual de usuario y guárdelo para futuras consultas.
advertencia de seguridad
advertencia de peligro
18-19
20
21
22
23-24
25-26
27
28
tabla de contenidos descargo de responsabilidad

2019
descripción del producto
1. Este producto no puede reemplazar la ventilación normal, la recolección diaria de polvo o la
campana extractora al cocinar.
2. Asegúrese de que la clavija del producto esté bien conectada a la alimentación. Si no, el enchufe
estará caliente.
3. No coloque ningún elemento encima del producto.
4. Asegúrese de colocar y utilizar el producto sobre una supercie rme, plana y horizontal.
5. Deje al menos 30 cm de espacio en la parte posterior y los lados del producto, y al menos 50 cm de
espacio por encima del producto cuando lo use.
6. No coloque el producto debajo del aire acondicionado para evitar que el agua de condensación caiga
en el producto.
7. Asegúrese de que tanto el ltro como la cubierta posterior estén correctamente instalados antes de
conectar a la alimentación.
8. Utilice el ltro especialmente diseñado para este producto.
9. No tome el ltro como combustible o propósitos similares para evitar daños irreversibles.
10. No use objetos duros para golpear los productos, especialmente la salida y la entrada de aire.
11. No inserte los dedos u otras cosas en la salida/entrada de aire para evitar daños físicos o desgracias.
12. No use este producto cuando esté usando un repelente en aerosol para interiores o en un lugar lleno
de grasa, gas inamable o vapores químicos.
13. Asegúrese de que el producto esté desconectado antes de mover, limpiar, mantener y reemplazar el
ltro.
14. Desconecte de la fuente de alimentación antes de mover el aparato. No tire del cable para mover el
aparato.
advertencia de uso
panel de control
cuerpo
entrada de aire
salida de aire
anillo de luz
sensor de calidad del aire
Filtro de alta eciencia
(HEPA)
contraportada
