Lupo Ultrapanel Full Color 60 Soft User manual

Ultrapanel Full
Color 60 Soft
Cod 816

Technical Data
Photometric data 5600 K6500 K 3200 K
Lux at 1 m - 3.2 ft
Lux at 2 m - 6.5 ft
Lux at 3 m - 9.8 ft
Lux at 4 m - 13.1 ft
Lux at 5 m - 16.4 ft
16600
4280
2080
1290
840
17300
4400
2150
1320
850
15100
4050
1950
1180
800
Distance
Dimensions (cm)
Dimensions (in)
Weight (kg)
Weight (lb)
CRI (Colour Rendering Index)
TLCI (Television Lighting Consistency Index)
Estimated LED lifetime (L80)
Dimmer 0 - 100
Dimming curves mode
DMX module
DMX (bit)
Connection for 14.8 V battery with standard XLR
4 pin connector (pin 1: negative / pin 4: positive)
Standard XLR 5 pin connectors to DMX console
Watt consumption
Watt output (equivalent to tungsten)
Firmware upgrades
Colour temperature
Voltage AC
Voltage DC
Light beam
Frequency (input)
Compliance
Remote control
Ambient temperature
Power factor
673 x 340 x 113 mm
26.4 x 13.5 x 4.4 in
9 kg
19.8 lb
95
96
50,000 hours
included
Linear, Exponential, Logarithmic
included
8 bit / 16 bit
included
included
400 W
8000 W
through USB port
2800 K - 10000 K
90 V - 240 V
14.8 V
120°
50 / 60 Hz
CE
Bluetooth Long Range / DMX / RDM
Max: + 45°C / Min: - 10°C
0.9

Technical Drawing
Lupo srl - Via V. Sassi 28 Collegno (TO) - 10093 - Italy
Phone: [phone] / e-mail: [e-mail]
website: www.lupo.it
673 mm
340 mm
467,9 mm
113 mm
298 mm

Superpanel 30 Full Color
Superpanel 60 Full Color
Actionpanel Full Color
Ultrapanel 30 Full Color
Ultrapanel 60 Full Color
User Manuals
Release 7.xx

WARNING:
When hanging the xture from higher position, please make sure you use safety cable to
attach the barndoors to the yoke of the panel.
Barndoors should always be used to secure the xture and the application when used in this
way.
Another safety cable should be used to secure the xture to the mounting pipe or truss.
Both safety cables must be properly dimensioned for the xture and the application when
the xture is operated in hanging position please ensure that the accessories are installed
correctly with top latch locked.
SAFETY PRECAUTIONS:
Do not operate the equipment before studying
the instruction manual and the accompanying
safety precautions. Make sure that Lupo
Safety Instruction is always included with
the equipment! Lupo products are intended
for professional use. Do not place or use the
equipment where it can be exposed to moisture,
extreme electromagnetic elds or in areas with
ammable gases or dust! Do not expose the
equipment to hasty temperature changes in
humid condition as could lead to condensation
water in the unit. Equipment must only be
serviced, modied or repaired by authorized.
Dealers or the factory.
CAUTION - BURN HAZARD - HOT PARTS
Do not touch hot parts with bare ngers! LED
bulbs and certain metal parts emit strong heat
when used!
Do not point lamps too close to persons. Always
use the xtures with the front part closed.
NOTICE - EQUIPMENT OVERHEATING RISK
Do not obstruct ventilation by placing lters,
diffusing materials, etc. over inlets and outlets of
the equipment ventilation or directly over glass
cover or LED bulbs.
FINAL DISPOSAL
Equipment contains electrical and electronic
components that could be harmful to the
environment.Equipment may be returned to
Lupo distributors free of charge for recycling
according to WEEE. Follow local legal
requirements for separate disposal of waste,
for instance WEEE directive for electrical and
electronic equipment on the European market,
when product life has ended.
MAINTENANCE AND CARE
Please do not forget that the safe operation of
lampheads also includes their maintenance and
care. A visual inspection should be conducted
before every use and an inspection of electrical
safety should be conducted at least once every
12 months.
WARRANTY
The warranty period for Lupo products and those
marketed by Lupo is twelve months from the
date of delivery. Lupo guarantees that the goods
it supplies are well manufactured and of good
quality. The warranty guarantees the repair of
any parts that show acknowledged defects in
materials, construction or workmanship during
the warranty period. The guarantee excludes
any liability for direct or indirect damage of any
kind and for any reason, for which Lupo will
therefore not be required to pay compensation.
The customers shall see to deliver the parts
that need repair or replacement to Lupo’s works
at their own expense and risk. The repaired or
replacement parts shall be delivered by Lupo
ex-works. The customers will be charged for
materials and labor or replacement of the
product after the expiration of the warranty
period.
ATTENTION: Please keep the original package of the
product in a safe place for warranty reasons.
Thanks for having purchased Lupo products. All the products are made in Italy and all the efforts
have been put to keep the quality standards high. We hope this product can help you in your job and
make your life easier as a professional. We also hope you will enjoy its use and we would be happy to
receive your feedback about it.
Superpanel 30 Full Color
Superpanel 60 Full Color
Actionpanel Full Color
Ultrapanel 30 Full Color
Ultrapanel 60 Full Color

•Device for indoor use only.
•Maximum ambient temperature: 40 °C.
•Make sure power supply plug is suitable to power required.
•As prescribed by international regulations, a safety cable must be used when the xture is
suspended from ceiling.
•To switch on the light push the on/off button.
•Superpanel models are equipped with new generation high quality powerleds.
Instructions
Getting Started with the Actionpanel
Turning on the Actionpanel
Place the AC Adapter in
the mounting bracket
via the 2 captive screws
to the bottom of the
ACTIONPANEL xture.
1Insert the power cord
cable into the AC adapter
and connect the xture to
the power plug.
2Insert the DC connector
into the input jack on the
ACTIONPANEL and power
on the xture.
3
5
4
1
6
3
Screw hole for V-Mount
battery bracket
Screw hole for
adapter bracket and
barndoors/diffuser
Silent FAN
ON/OFF
Intensity knob
Tilt lock knob
UP button
Display
DMX THROUGH*
(Female 5 PIN XLR connector)
DMX INPUT*
(Male 5 PIN XLR connector)
Tilt lock knob
DOWN button
Stirrup
CCT knob
GN/SAT/COLOR knob
Power IN connector
Locking knob

Getting Started with the Superpanel 30 and the Ultrapanel 30
Turning on the Superpanel 30 and the Ultrapanel 30
Place the AC Adapter in
the mounting bracket via
the 2 captive screws to the
bottom of the SUPERPANEL
30 xture.
1Insert the power cord
cable into the AC adapter
and connect the xture to
the power plug.
2Insert the DC XLR 4 pin
connector into the input
jack on the SUPERPANEL
30 and power on the xture.
3
1
3
2
5
4
Screw hole for barndoors/diffuser
Display
Power ON indicator LED light
INTENSITY knob
UP buttonDOWN button
CCT knob
DMX THROUGH
(Female 5 PIN XLR connector)
DMX INPUT
(Male 5 PIN XLR connector)
Tilt lock knobTilt lock knob
Power IN connector
(Male 4 PIN XLR connector)
Screw hole for V-Mount
battery bracket
Screw hole for adapter bracket
Screw hole for barndoors/diffuser
Locking knob
Silent FAN
ON/OFF
GN/SAT/COLOR knob
Stirrup
USB port

Getting Started with the Superpanel 60 and the Ultrapanel 60
Place the two AC Adapters
in the mounting brackets via
the 2 captive screws of the
SUPERPANEL 60 xture.
1Insert the two power
cord cables into the AC
adapters and connect the
xture to the power plug.
2Insert the two DC XLR 4 pin
connectors into the input
jacks on the SUPERPANEL
60 and power on the xture.
3
Turning on the Superpanel 60 and the Ultrapanel 60
CONTROL PANEL
-In current mode press the 5 push button to enter the main MENU.
-In the sub-menus press the 5 push button to conrm a selection.
-Rotate the 5 knob to navigate in the main MENU and sub-menus.
-Use the « INTENSITY » 4 knob to adjust the light intensity from 0 to 100%.
-Use the knobs 5 and 6 to adjust the light mode parameters.
-Display 7 .
DOWN/+ button
Display
Power ON indicator
LED light
INTENSITY knob
UP/+ button
CCT knob
DMX THROUGH
(Female 5 PIN XLR)
DMX INPUT
(Male 5 PIN XLR)
Tilt lock knob
Tilt lock knob
Screw hole for
adapter bracket Screw hole for
adapter bracket
Screw hole for
adapter bracket
Screw hole for
adapter bracket
Locking knob
Silent FAN
Power IN connector
(Male 4 PIN XLR)
Power IN connector
(Male 4 PIN XLR)
ON/OFF
GN/SAT/RGBW knob
Stirrup
Hook for safety cable

MANUAL OPERATION
ATTENTION: The light intensity level is adjustable from 0 - 50% if the FAN is OFF. The
value on the display ashes.
1. Press the 5 push button to enter the main MENU.
2. Select MANUAL by pressing the 5 push button.
3. Select the light mode between CCT / HSI / RGBW / PRESET / EFFECT / SAVE PRESET with
the 5 knob and press the 5 push button to conrm selection.
4. See LIGHT MODES.
MODE
CCT
RGBW
HSI
PRESET
EFFECT
CCT/HUE 5
CT 2800K to 10000K
-
HUE 0º to 100º
-
"See EFFECT table"
GN/SAT/COLOR 6« » 1 « » 3
GN -1.00 to +1.00 -
Select function R/G/B/W/CT/GN Change values of the function
SAT 0 to 100% -
-
"See EFFECT table"
Change Preset
Change Effect
INTENSITY 4
Light Intensity
from 0 to 100%
In CCT, HSI, RGBW and PRESET Mode, the « » key selects the STROBE page and the « »
key exits the STROBE PAGE.
In the STROBE PAGE it is possible to set DIMMER value and the STROBE frequency by rotating
the 5 button.
ATTENTION: STROBE frequency = 0 means STROBE effect OFF.
*
*
*
*
*
LIGHT MODES
A. CCT MODE: Warm and cold white control mode. It allows you to adjust colour temperature
(CCT), green/magenta compensation (GN) and light intensity. This is the default setting.
B. HSI MODE: Colour composition mode. It allows you to adjust hue of colour (HUE), colour
saturation (SAT) and light intensity.
C. RGBW MODE: RGBW colour control mode allows to individually set the R, G, B, W, Color
Temperature (CT), green/magenta compensation (GN) values and to adjust light intensity
D. FRGBW MODE: Available only in DMX operation. Same as RGBW but with white color
power unlimited. See DMX PROTOCOL MANUAL.
E. PRESET MODE: Mode with 53 PRESET colors, 48 factory preset and 5 user-dened preset.
1. In MANUAL OPTIONS or DMX MODE menu select PRESET MODE.
2. Select the PRESET to be activated rotate the 5 button, conrm the selection by pressing
the 5 push button.
3. Use the « INTENSITY » 4 knob to adjust the light intensity from 0 to 100%.
SAVING THE SET VALUES AS A PRESET
You can store up to 5 PRESETS.
1. In MANUAL select SAVE PRESET by pressing the 5 push button.
2. Save the set values in one of the available presets between USER PRESET 1 / 2 / 3 / 4

/ 5 rotate the 5 knob to select the PRESET number and press the 5 push button to
conrm the selection. THE SET COLOR IS SAVED AS PRESET.
"BUSY" indicates that in the user preset there are parameters memorized if you select it,
the parameters is replaced by the new ones. "EMPTY" indicates that the user preset is free.
E. SPECIAL EFFECT MODE: Mode with 11 SPECIAL EFFECTS. PARTY / COPCAR / DISCO 1
/ DISCO 2 / TELEVISION BW / TELEVISION CO / PAPARAZZI / LIGHTNING / EXPLOSION /
FIREWORKS / FIRE.
1. In MANUAL OPTIONS or DMX MODE menu select EFFECT MODE.
2. Select the EFFECT to be activated with rotate the 5 button, conrm the selection by
pressing the 5 push button.
3. In current mode, use the « » 1 o « » 3 button to change the EFFECT in ascending or
descending order. THE EFFECT ON THE DISPLAY IS THE SELECTED EFFECT.
4. Use the knobs 5 and 6 to adjust the effect setting values. See table below.
EFFECT
DISCO 2
COPCAR
PARTY
DISCO 1
5CCT/HUE knob
Flash Color - B / R / R+B / B+W / R+B+W
Speed - 0 to 100%
Speed - 0 to 100%
Speed - 0 to 100%
6GN/SAT/COLOR knob
Nº ashes for cycle - 1 to 4
-
-
-
4INTENSITY knob
Light Intensity
from 0 to 100%
TELEVISION BW
LIGHTNING
FIREWORKS
PAPARAZZI
TELEVISION CO
EXPLOSION
FIRE
White range - 1 / 2 / 3 / 4
White range - 1 / 2 / 3 / 4
Color Temperature
Speed - 1 to 60
Flashing Interval - 1 to 10
Speed - 1 to 60
Speed - 1 to 3
Frequency - 4 to 24 Hz
Frequency - 4 to 24 Hz
Lightnings Interval - 1 to 20
-
Bulb type - 0 / 1 / 2
-
-
Light Intensity
from 0 to 100%
DMX OPERATION
1. Press the 5 push button to enter the main MENU.
2. Select DMX with the 5 knob and press the 5 push button to conrm selection.
3. Select the light mode between CCT / HSI / RGBW / FRGBW / PRESET / EFFECT with the 5
knob and press the 5 push button to conrm selection.
4. Select the DMX channel, rotating the 5 knob to change DMX ADDRESS in ascending or
descending order between 1 and 512. The number shown on the display 7 is the selected
channel to communicate with the control desk.
5. See DMX PROTOCOL MANUAL to DMX channel specication.
NOTE: The symbol - ! - on the display indicates that there is no DMX signal.
BLUETOOTH
Enable / Disable BLE App interface

DMX OPERATION - Advanced Settings
1. Press the 5 push button to enter the main MENU.
2. Navigate through the main MENU with the 5 knob and press the 5 push button to
conrm selection.
3. Rotate the 5 knob to select DMX ADVANCED, press the 5 push button to conrm
selection.
4. Select one of the options among the DMX BIT, DMX SIGNAL LOSS and RDM ENABLE,
press 5 push button to conrm the selection.
DMX BIT:
Resolution of the DMX control. 8bit 1 channel per function and 16 bit 2 channels per
function.
1. Select the DMX BIT item by pressing the 5 push button.
2. Rotate the 5 knob to choose between 8bit / 16bit, press the 5 push button to
conrm the selected setting. See DMX PROTOCOL MANUAL.
DMX SIGNAL LOSS:
This feature allows to choose the device’s behaviour in case of a DMX signal loss.
1. Select the LOSS DMX SIGNAL item with the 5 push button
2. Rotate the 5 knob to select the device’s behaviour between BLACK OUT /SETTINGS
LAST / SETTINGS 1min, press the 5 push button to conrm the setting.
Black out: The device switches off.
Settings Last: The values of the last selected setting are maintained over time until the
device is switched off.
Settings 1min: The values of the last selected settings is maintained for one minute and
then the device is switch off.
RDM Enable: ON/OFF, enable/disable RDM Protocol
INV CCT: ON/FF: enable/disable reversal CCT console control
DMX Protocol
Introduction
The Actionpanel Full Color, the Superpanel 30 Full Color and the Superpanel 60 Full color can be used with 8 bit or
16 bit DMX control.
(See DMX OPERATION - advanced settings in the user's manual).
When used in 8 bit mode the panels uses one channel for each function. DMX values for each channel are in the
range of 0 to 255.
When used in 16 bit mode the panels uses two channels for each function. The increased resolution offers a
smooth dimming and a more accurate color adjustment. DMX values for the rst channel (byte 1) are in the range
of 256 to 65535 while for the second channel (byte 2) they are in the range of 0 to 255.
The xture use the number of channels required based on the light mode selected CCT / HSI / RGBW /PRESET /
PARTY / COPCAR / DISCO 1 / DISCO2 / TELEVISION 1 / TELEVISION 2 / PAPARAZZI / LIGHTNING /EXPLOSION /
FIREWORKS / FIRE.
ATTENTION: The symbol - ! - on the display indicates that there is no DMX signal.

DMX Channel Protocol - 8 bit
CCT
1. DIMMER 0 - 255 0 ÷ 100 %
2. COLOR TEMPERATURE 0 - 255 6500 - 2700
3. GN COMPENSATION
7. GN COMPENSATION
0 ÷ 5
0 ÷ 5
0 ÷ 5
6 ÷ 255
6 ÷ 255
6 ÷ 255
Ø
Ø
Ø
-1,00 ÷ + 1,00
-1,00 ÷ + 1,00
-1,00 ÷ + 1,00
4. STROBE 0 ÷ 10
11 ÷ 255
strobe off
freq. strobe 1 ÷ 24
4. STROBE
8. STROBE
8. STROBE
HSI
1. DIMMER 0 - 255 0 ÷ 100 %
2. HUE 0 ÷ 253 0 ÷ 360
3. SATURATION 0 ÷ 255 0 ÷ 100 %
RGBW
FRGBW
1. DIMMER 0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
1 ÷ 10 %
0 ÷ 2
0 ÷ 100 %
4 ÷ 24
4 ÷ 24
0 ÷ 100 %
1 ÷ 5
1 ÷ 4
1 ÷ 4
1 ÷ 4
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
1. DIMMER
2. RED 0 ÷ 255
0 ÷ 255
0 ÷ 100 %
0 ÷ 100 %
2. RED
3. GREEN 0 ÷ 255
0 ÷ 255
0 ÷ 100 %
0 ÷ 100 %
3. GREEN
4. BLUE 0 ÷ 255
0 ÷ 255
0 ÷ 100 %
0 ÷ 100 %
4. BLUE
5. WHITE 0 ÷ 255
0 ÷ 255
0 ÷ 100 %
0 ÷ 100 %
5. WHITE
1. DIMMER
2. PRESET
3. PRESET FREEZE
PARTY 1. DIMMER
2. SPEED
COPCAR
1. DIMMER
2. NUMBER OF COLORS
3. NUMBER OF FLASH
DISCO 1 1. DIMMER
2. SPEED
4
4
8
8
2
3
2
MODE CHANNELS DMX CHANNEL POSITION DMX VALUE VALUE
6. COLOR TEMPERATURE 0 - 255
0 - 255
6500 - 2700
6500 - 2700
6. COLOR TEMPERATURE
8. STROBE
7. GN COMPENSATION
PRESET 4
DISCO 2 1. DIMMER
2. SPEED
2
LIGHTNING
1. DIMMER
2. COLOR TEMPERATURE
3. INTERVAL
EXPLOSION
FIREWORKS
FIRE
1. DIMMER
1. DIMMER
1. DIMMER
2. SPEED
2. SPEED
2. SPEED
3
2
2
2
TELEVISION 1
TELEVISION 2
PAPARAZZI
1. DIMMER
1. DIMMER
1. DIMMER
2. WHITE RANGE
2. WHITE RANGE
2. INTERVAL
3. FREQUENCY
3. FREQUENCY
3. BULB TYPE
3
3
3
0 ÷ 10
0 ÷ 10
0 ÷ 10
0 ÷ 10
11 ÷ 255
11 ÷ 255
11 ÷ 255
11 ÷ 255
strobe off
strobe off
strobe off
strobe off
freq. strobe 1 ÷ 24
freq. strobe 1 ÷ 24
freq. strobe 1 ÷ 24
freq. strobe 1 ÷ 24
0 - 255
0 ÷ 255
0 - 50
200 ÷ 255
0 ÷ 100 %
0 ÷ N PRESET
no freeze
freeze
0 - 255
0 ÷ 255
0 ÷ 255
0 ÷ 255
0 - 255
6500 - 2700
1 ÷ 20
1 ÷ 60
1 ÷ 3
1 ÷ 60

0 - 65535
0 - 65535
0 ÷ 100 %
0 ÷ 100 %
0 - 65535 6500 - 2700
DMX VALUE VALUE
PARTY 4
1. DIMMER - byte 1
2. DIMMER - byte 2
1. DIMMER - byte 1
3. SPEED - byte 1
2. DIMMER - byte 2
4. SPEED - byte 2
4. PRESET - byte 2
3. PRESET - byte 1
7. STROBE - byte 1
8. STROBE - byte 2
5. PRESET FREEZE - byte 1
6. PRESET FREEZE - byte 2
PRESET 8
9. WHITE - byte 1
10. WHITE - byte 2
11. COLOR TEMPERATURE - byte 1
12. COLOR TEMPERATURE - byte 2
13. GN COMPENSATION - byte 1
15. STROBE - byte 1
14. GN COMPENSATION - byte 2
16. STROBE- byte 2
DMX Channel Protocol - 16 bit
CCT
1. DIMMER - byte 1
2. DIMMER - byte 2
3. COLOR TEMPERATURE - byte 1
HSI
1. DIMMER - byte 1
2. DIMMER - byte 2
3. HUE - byte 1
RGBW
1. DIMMER - byte 1
2. DIMMER - byte 2
3. RED - byte 1
4. RED - byte 2
5. GREEN - byte 1
8
8
16
MODE CHANNELS DMX CHANNEL POSITION
4. COLOR TEMPERATURE - byte 2
5. GN COMPRENSATION - byte 1
6. GN COMPENSATION - byte 2
7. STROBE - byte 1
7. STROBE - byte 1
8. STROBE - byte 2
8. STROBE - byte 2
4. HUE - byte 2
5. SATURATION - byte 1
6. SATURATION - byte 2
6. GREEN - byte 2
7. BLUE - byte 1
8. BLUE - byte 2
9. WHITE - byte 1
10. WHITE - byte 2
11. COLOR TEMPERATURE - byte 1
12. COLOR TEMPERATURE - byte 2
13. GN COMPENSATION - byte 1
15. STROBE - byte 1
14. GN COMPENSATION - byte 2
16. STROBE - byte 2
FRGBW
1. DIMMER - byte 1
2. DIMMER - byte 2
3. RED - byte 1
4. RED - byte 2
5. GREEN - byte 1
16
6. GREEN - byte 2
7. BLUE - byte 1
8. BLUE - byte 2
0 ÷ 2620
2621 ÷ 65535
0 ÷ 500
501 ÷ 65535
0 ÷ 2620
2621 ÷ 65535
strobe off
-1,00 ÷ + 1,00
Ø
-1,00 ÷ + 1,00
strobe off
-1,00 ÷ + 1,00
0 ÷ 65535 0 ÷ 360
0 ÷ 65535 0 ÷ 100 %
0 - 65535
0 - 65535
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 65535 0 ÷ 100 %
0 ÷ 65535 0 ÷ 100 %
0 ÷ 65535 0 ÷ 100 %
0 - 65535 6500 - 2700
0 - 65535 0 ÷ 100 %
0 ÷ 65535 0 ÷ 100 %
0 ÷ 65535 0 ÷ 100 %
0 ÷ 65535 0 ÷ 100 %
0 ÷ 65535 0 ÷ 100 %
0 - 65535 6500 - 2700
0 - 12800 > no freeze 51200 ÷ 65535 freeze
0 - 65535
0 ÷ 2620
2621 ÷ 65535
0 ÷ 65535
0 ÷ 100 %
strobe off
-1,00 ÷ + 1,00
0 ÷ N PRESET
0 - 65535
0 - 65535
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 2620
2621 ÷ 65535
strobe off
-1,00 ÷ + 1,00
0 ÷ 500
501 ÷ 65535
Ø
-1,00 ÷ + 1,00
0 ÷ 500
501 ÷ 65535
Ø
-1,00 ÷ + 1,00
0 ÷ 2620
2621 ÷ 65535
strobe off
-1,00 ÷ + 1,00

** Only available if enabled in DMX ADVANCED.
RDM
Protocol Specication
COMMAND
Manufacturer ID
PID
0x0622
DESCRIPTION
Manufacturer identication number
(LUPO Lighting).
DISCO 1
DISCO 2
EXPLOSION
FIREWORKS
FIRE
4
4
4
4
4
1. DIMMER - byte 1
1. DIMMER - byte 1
1. DIMMER - byte 1
1. DIMMER - byte 1
1. DIMMER - byte 1
2. DIMMER - byte 2
2. DIMMER - byte 2
2. DIMMER - byte 2
2. DIMMER - byte 2
2. DIMMER - byte 2
1. DIMMER - byte 1
1. DIMMER - byte 1
1. DIMMER - byte 1
1. DIMMER - byte 1
3. SPEED - byte 1
3. SPEED - byte 1
3. SPEED - byte 1
3. SPEED - byte 1
3. SPEED - byte 1
2. DIMMER - byte 2
2. DIMMER - byte 2
2. DIMMER - byte 2
2. DIMMER - byte 2
4. SPEED - byte 2
4. SPEED - byte 2
4. SPEED - byte 2
4. SPEED - byte 2
4. SPEED - byte 2
6. NUMBER OF FLASH - byte 2
6. FREQUENCY - byte 2
6. FREQUENCY - byte 2
6. BULB TYPE - byte 2
6. INTERVAL - byte 2
5. FREQUENCY - byte 1
5. FREQUENCY - byte 1
5. BULB TYPE - byte 1
5. INTERVAL - byte 1
3. WHITE RANGE - byte 1
3. WHITE RANGE - byte 1
3. INTERVAL - byte 1
3. COLOR TEMPERATURE - byte 1
4. WHITE RANGE - byte 2
4. WHITE RANGE - byte 2
4. INTERVAL - byte 2
4. COLOR TEMPERATURE - byte 2
TELEVISION
2
TELEVISION
1
PAPARAZZI
LIGHTNING
6
6
6
6
1. DIMMER - byte 1
2. DIMMER - byte 2
5. NUMBER OF FLASH - byte 1
3. NUMBER OF COLORS - byte 1
4. NUMBER OF COLORS - byte 2
COPCAR 6
0 - 65535
0 - 65535
0 - 65535
0 ÷ 100 %
1 ÷ 5
1 ÷ 4
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
0 ÷ 100 %
1 ÷ 10 %
0 ÷ 2
0 ÷ 100 %
4 ÷ 24
4 ÷ 24
1 ÷ 4
1 ÷ 4
0 ÷ 100 %
0 ÷ 100 %
0 - 65535
0 ÷ 65535
0 ÷ 65535
0 ÷ 65535
0 - 65535
6500 - 2700
1 ÷ 20
1 ÷ 60
1 ÷ 3
1 ÷ 60

Device Identication
Model ID Model identication number
Personality DMX Personality
CCT
HSI
0x01
0x02
Dayled 650 mono color
Dayled 650 dual color
Dayled 1000 mono color
Superpanel 30 dual color soft
Dayled 2000 mono color
Superpanel 30 full color soft
Superpanel 60 dual color soft
Dayled 1000 dual color
Superpanel 30 dual color lens
Dayled 2000 dual color
Superpanel 30 full color lens
Superpanel 60 dual color lens
0x0001
0x0002
0x0003
0x0007
0x0005
0x0009
0x0011
0x0004
0x0008
0x0006
0x0010
0x0012
Superpanel 60 full color soft
Movielight monocolor
Superpanel 60 full color lens
Movielight dual color
Actionpanel dual color soft
Ultrapanel 30 dual color soft
Kickasspanel dual color
Ultrapanel 30 full color soft
Actionpanel full color soft
Ultrapanel 60 dual color soft
Lupoled monocolor
Ultrapanel 60 full color soft
Actionpanel dual color lens
Ultrapanel 30 dual color lens
Kickasspanel full color
Ultrapanel 30 full color lens
Actionpanel full color lens
Ultrapanel 60 dual color lens
Lupoled dualcolor
Ultrapanel 60 full color lens
0x0013
0x0023
0x0014
0x0024
0x0015
0x0025
0x0019
0x0029
0x0017
0x0027
0x0021
0x0031
0x0016
0x0026
0x0020
0x0030
0x0018
0x0028
0x0022
0x0032
RGBW
DISCO 1
PRESET
PARTY
TELEVISION BW
FRGBW
DISCO 2
COPCAR
0x06
0x04
0x0A
0x08
0x03
0x07
0x05
0x09

Network management
Status collection
RDM Information
Product Information
Search RDM devices
Retrieves queued messages or status
message if no message is in queue
Retrieves a list of all supported RDM
commands
Retrieves a variety of information about the
device that is normally required by a controller.
Mute RDM device, no response message
Retrieves current Warning/Error messages
Retrieves a list of all RDM commands
Text description of up to 32 characters for the
device model type.
Activate RDM device fo response message
DISC UNIQUE BRANCH
QUEUED MESAGES
SUPPORTED
PARAMETERS
DEVICE INFO
DISC MUTE
STATUS MESSAGES
PARAMETER
DESCRIPTION
DEVICE MODEL
DESCRIPTION
DISC UN MUTE
0x0001
0x0020
0x0050
0x0060
0x0002
0x0030
0x0051
0x0080
0x0003
EXPLOSION
FIRE
FIREWORKS
0x0E
0x0F
0x10
This parameter provides an ASCII text
response with the Manufacturer name for the
device. “LUPO” is the default name.
DMX mode
The identify ag (ashes the light)
0: Off 1: On
0: 30 sec 1: 1 min 2: always on
0: black out 1: last settings on 2: last settings
1 min
0: 8 bit 1: 16 bit
0: 2800-10000 1: 3200-5600
0: linear 1: exponential 2: logarithmic
0: full speed 1: normal speed 2: high speed 3:
low speed
0: 18 KHz 1: 25 KHz
0: not inverted 1: inverted
Set the device to its factory defaults. Get:
Check if settings still in default state -> 1 if
default
Shows a description of a DMX-Mode, max 32
characters
Retrieves software version string of main
software
DMX address
MANUFACTURER
LABEL
DMX PERSONALITY
IDENTIFY DEVICE
FAN MODE
DISPLAY TIMEOUT
DMX SIGNAL LOST
MODE
DMX BITS
CCT LIMIT
LINEARIZATION
FILTER
FREQUENCY
INV - CCT
FACTORY DEFAULTS
DMX PERSONALITY
DESCRIPTION
SOFTWARE VERSION
LABEL
DMX START ADDRESS
0x0081
0x00E0
0x1000
0x8001
0x8002
0x8003
0x8004
0x8005
0x8006
0x8007
0x8008
0x8009
0x0090
0x00E1
0x00C0
0x00F0
DMX512 Setup
Control
Manufacturer Commands
PAPARAZZI
LIGHTNING
0x0C
0x0D
TELEVISION CO
0x0B

FULL SPEED / NORMAL SPEED / HIGH SPEED / LOW SPEED.
Linearization: Linearization is the compensation curve for the human eye's perception
of the luminous intensity emitted as a function of the required power. Required power =
dimmer value on the display. LINEAR / EXPONENTIAL / LOGARITHMIC.
Linear: No compensation, the intensity of the light is directly proportional to requested
power.
Exponential: The light intensity increases from 0 to 100 exponentially.
Logarithmic: The light intensity increases from 0 to 100 logarithmically.
CCT Limit: The colour temperature is limited. 3200K - 5600K / 2800K - 10000K.
RESET DEVICE
1. Press the « OK » 2 button to enter the main MENU.
2. Select RESET DEVICE rotating the 5 button, press the 5 push button to conrm the
selection.
3. Select YES rotating the 5 button, press the 5 push button to conrm the selection.
4. The device ask for further conrmation, select YES by pressing the press the 5 push
button.THE DEVICE RETURN TO FACTORY DEFAULT SETTINGS.
DEVICE SETTINGS
FAN: ON
DISPLAY: 1 min
MENU VIEW : Manual/DMX
FILTER : Normal speed
LINEARIZATION: Linear
CCT LIMIT: 2800K - 10000K
FREQUENCY: 18 KHz
BLUETOOTH
Bluetooth Active: OFF
MANUAL OPERATION
MODE: CCT
DMX OPERATION
MODE: CCT
BIT: 8 BIT
DMX SIGNAL LOSS: Settings 1 MIN
RDM ENABLE: OFF
INV-CCT: OFF
FACTORY DEFAULT SETTING
DEVICE SETTINGS
1. Press the 5 push button to enter the main MENU.
2. Navigate through the MENU rotating the 5 button, select DEVICE SETTINGS, press the 5
push button to conrm the selection.
3. Navigate through the FAN / DISPLAY / MENU VIEW / FREQUENCY / FILTER /
LINEARIZATION / CCT LIMIT functions, rotating the 5 button to select the desired function
and press the 5 push button to conrm the selection.
4. Within each function select the option to be activated and rotate the 5 button.
Fan: Fan operation. ON / OFF.
When the fan is OFF the light intensity is adjustable between 0 and 50%.
Display: Time during which the display backlight stays on. 30sec / 1min / ALWAYS ON.
Menu View: Type the main MENU, sub-menus and functions to show. ONLY MANUAL /
ONLY DMX / MANUAL/DMX.
Frequency: Dimmer frequency 18 KHz - 25 KHz
Filter: It is the speed response of the system (smooth factor).

USB port
Use USB port for rmware updates.
Update the Firmware
1. Copy the le on an USB Pendrive (FAT32 formatted) in the main root;
2. Switch off the equipment and insert the USB Pendrive;
3. Switch on the equipment;
4. Wait until display backlight ashes (it takes several minutes and red led must toggle for
all time long);
5. Switch off the equipment;
6. Extract the Pendrive and switch on the equipment: the rmware is updated.
MENU e submenus
Select “EXIT” to return to
the current mode.
Select "BACK" to return
to the previous menu.
After 1 minute of
inactivity in the menu,
the device automatically
exits and returns to the
last selected mode.
MANUAL DEVICE SETTINGS DMX BLUETOOTH
CCT LIMIT 3200K - 5600K
2800K - 10000K
BACK
DISPLAY
OPTIONS
30 SEC
1 MIN
ALWAYS ON
BACK
FILTER
FULL SPEED
NORMAL SPEED
HIGH SPEED
LINEARIZATION
MENU VIEW
EXIT
EXIT
LINEAR
ONLY MANUAL
BACK
BACK
LOGARITHMIC
MANUAL/DMX
EXPONENTIAL
ONLY DMX
FAN POWER
BLE
RGBW MODE
CCT MODE
HSI MODE
EFFECT
MODE
SAVE
PRESET
PRESET
MODE
RED
...
SOFT PINK
BLUE
DMX SIGNAL
LOSS
BACK
ON/OFF
DMX
ADVANCED
BIT
LOW SPEED
1
PARTY
2
COPCAR
3
DISCO 1
4
DISCO 2
5
TELEVISION W
TELEVISION C
PAPARAZZI
LIGHTNING
EXPLOSION
FIREWORKS
FIRE
BACK
EXIT
EXIT
GREEN
USER PRE3
USER PRE4
USER PRE5
BACK
RGBW MODE
FRGBW MODE
CCT MODE
HSI MODE
EFFECT
MODE
PRESET
MODE
RED
...
SOFT PINK
BLUE
PARTY
COPCAR
DISCO 1
DISCO 2
TELEVISION W
TELEVISION C
PAPARAZZI
LIGHTNING
EXPLOSION
FIREWORKS
FIRE
BACK
GREEN
USER PRE3
USER PRE4
USER PRE5
BACK
8 BIT
ON
BLACK OUT
BACK
BACK
SETTINGS 1 MIN
16 BIT
OFF
SETTINGS LAST
BACK
RESET DEVICE
EXIT
INFO
YES
BACK
FW
BACK
FREQUENCY 18 KHz
25 KHz
RDM ADDRESS
RDM ENABLE
BACK
STROBE ENABLE
INV - CCT
ON
ON
ON
OFF
OFF
OFF

Package Contents for Superpanel 30 and Ultrapanel 30
Superpanel 30
Ultrapanel 30
AC Adapter
AC input: 100 V - 240 V
DC output: 24 V
AC Adapter
Mounting Bracket
AC Power
Cord Cable
ATTENTION: Please keep the original package of the
product in a safe place for warranty reasons.
ATTENTION: Please keep the original package of the
product in a safe place for warranty reasons.
Package Contents for Actionpanel
Actionpanel
ATTENTION: Please keep the original package of the
product in a safe place for warranty reasons.
AC Power
Cord Cable
AC Adapter *
AC input: 100 V - 240 V
DC output: 24 V
AC Adapter
Mounting
Bracket
Package Contents for Superpanel 60 and Ultrapanel 60
Superpanel 60
Ultrapanel 60
2x AC Adapter
AC input: 100 V - 240 V
DC output: 24 V
2x AC Adapter
Mounting Bracket
AC Power Cord with
AC Power Cord Splitter
