Lupus LE808+ User manual

LE808+ / 816+
User Manual

1
ENGLISH
This symbol is intended to alert the user to the presence of unprotected “Dangerous voltage"
within the product's enclosure that may be strong enough to cause a risk of electric shock.
This symbol is intended to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
NOTE: This equipment has been tested and found to comply with the limits for a class digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at ones own expense.
Disposal of Old Electrical & Electronic Equipment (Applicable in the European
Union and other European countries with separate collection systems)
This symbol on the product or on its packaging indicates that this product shall not be treated as household
waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The recycling of materials will help to conserve natural resources.
For more detailed information about recycling of this product, please contact your local city office, your
household waste disposal service or the shop where you purchased the product.

2
ENGLISH
All the safety and operating instructions must be read before the unit is operated.
•Make sure to switch the power off before you install the DVR.
•There is the danger of an electric shock if the DVR is opened by an unqualified service
engineer or installer.
•Avoid using the DVR outside of the reference temperature and humidity indicated in the
specification.
•Avoid exposing the DVR to violent movement or vibration.
•Do not use or store the DVR in direct sunlight or near to any source of heat.
•Do not place any object into the holes used for air circulation.
•Always use the DVR in a well ventilated location to prevent overheating.
•Risk of explosion if battery is replaced by an incorrect type.
•Dispose of used batteries according to the instructions.

3
ENGLISH
TABLE OF CONTENTS
Chapter 1 FEATURES ....................................................................................................................4
Chapter 2 PACKING DETAIL..........................................................................................................5
Chapter 3 LOCATION AND CONTROL...........................................................................................6
3.1 Front Panel Controls ..............................................................................................................6
3.2 Real Panel Connectors...........................................................................................................7
3.3 Remote Controller..................................................................................................................8
3.4 Mouse Control......................................................................................................................11
3.4.1 Network Control ...............................................................................................................14
3.5 Playback Mode.....................................................................................................................15
3.6 PTZ Mode............................................................................................................................16
Chapter 4 INSTALLATION ............................................................................................................19
4.1 System Configuration – 16ch...............................................................................................19
4.1 System Configuration – 8ch.................................................................................................19
4.2 Hard Disk Installation..........................................................................................................20
4.2.1 Switch display resolution..................................................................................................23
Chapter 5 BASIC OPERATION and MENU SETUP......................................................................24
5.1 Main Menu Setup.................................................................................................................24
5.2 Record Setup........................................................................................................................26
5.3 Event Setup..........................................................................................................................28
5.4 Schedule Setup.....................................................................................................................32
5.5 Camera Setup.......................................................................................................................34
5.6 Account Setup ......................................................................................................................35
5.7 Network Setup......................................................................................................................36
5.8 PTZ & RS-485 Setup...........................................................................................................40
5.9 System Setup........................................................................................................................40
5.10 Utility Setup.......................................................................................................................47
5.11 Diagnostic ..........................................................................................................................48
Chapter 6 SEARCH & BACKUP ...................................................................................................49
6.1 Search Setup.........................................................................................................................49
6.2 Backup Setup .......................................................................................................................53
Chapter 7 SPECIFICATION..........................................................................................................55
Chapter 8 NETWORK SURVEILLANCE .......................................................................................57
8.1 AP Software Installation and Setup......................................................................................57
8.2 AP Software Operation ........................................................................................................59
Chapter 9 Mobile Connection........................................................................................................63
Mobile Application ....................................................................................................................63
1 Mobile Application, Installation and Operation for Symbian System....................................63
2 Mobile Application Installation and Operation for Windows Mobile System........................69
Chapter 10 Internet Connection....................................................................................................73
APPENDIX I - DB 26 DIFINITION.................................................................................................79
APPENDIX II - COMPATIBILITY LIST...........................................................................................80

4
ENGLISH
Chapter 1 FEATURES
Realtime recording
Two USB ports (for mouse usage and backup).
H.264 compression ideal for saving HDD space
Real time live display
Up to 400FPS @ 360x288 recording (PAL)
VGA output resolution up to 1920x1200 Pixel.
Live display, record, backup, playback and network access at the same time
Control methods: front panel, USB mouse, IR remote controller, and client viewer
Intuitive GUI for easy configuration and menu driven operation
4 channel audio recording and playback
Supports SATA HDDs
Pan / Tilt / Zoom camera control
Data backup: USB devices and network
Event triggered with email notification: motion detection, alarm, and video loss
Support AP on your PC end for remote operation
Multi-language OSD
