1. FEATURES
* Design meet IEC 1010 safety requirement.
* 4 1/2 digits DMM, high precision.
* Large LCD display with annunciators.
* LCD display, easy read-out.
* True RMS measuring reading for ACV & ACA function.
* With data hold function
* Compact & strong housing case.
* Optional Holster case.
* Full range optional adapters for Temperature, Light,
DC/AC CLAMP current, Humidity, RPM, Pressure
measurement.
2. SPECIFICATIONS
2-1 General Specifications
Display 15 mm(0.5") LCD, w/ annunciators,
4 1/2 digits Max. reading 19999
Measurement 28 ranges, DCV, ACV, DCA, ACA,
ohms, hFE, DIODE, Continuity
Beeper.
Polarity Automatic Switching,
'-' indicates negative polarity.
Zero Adjustment Automatic adjustment.
Over-input Indicator "1 " mark indication.
Sampling Time Approx. 0.4 second.
Operating Temp. 0 蚓to 50 蚓(32 蚌to 122 蚌).
Operating Humidity Less than 80% RH.
Power Supply 006 P DC 9V battery.
Power Consumption Approx. DC 1.6 mA.
Dimensions 185 x 87 x 39 mm
(6.7 X 3.5 X 1.4 inch)
Weight 320 g/0.71 LB
1

Fuse The meter build in one fuse for
current range(200u/2m/20m/200mA)
protection, its spec. :
Rating - 500 mA
Size - 5 mm dia. x 20 mm
Accessories Red and Black Test Leads ..... 1 pair.
Included Instruction Manual ................. 1 PC.
Optional Please refer page 9, 10, 11.
Accessories
2-2 Electrical Specifications (23 #5 C)
DC Voltage
Range 200 mV / 2 V/ 20 V/ 200 V / 600 V
Resolution 0.01 mV / 0.1 mV /1 mV /10 mV / 0.1 V
Accuracy #(0.1%+2d) -200mV.
3(0.2%+2d) -2V,20V,200V,600V.
Input Impedance 10 M ohm.
Over Load DCV, 350 ACV - 200mV range.
Protection DCV, 600 ACV - others.
AC Voltage (True RMS)
Range 200 mV/2/20/200/600 V
Resolution 0.01 mV/0.1 m/1 m/10 m/0.1 V
Accuracy #(0.8%+10d) -200mV,2V,20V,200V,600V
* spec. are tested under 50/60 Hz.
Input Impedance 10 M ohm.
Over Load DCV, 350 ACV - 200mV range.
Protection DCV, 600 ACV - others.
2

DC Current
Range 200u/2m/20m/200m/10A
Resolution 10n/100n/1u/10u/1mA
Accuracy #(0.5%+5d) -200uA,2mA,20mA
#(0.8%+10d) -200mA
#(2%+5d) -10A
Over Load 200u/2m/20m/200mA range :
Protection 0.5A fuse protection
10 A range :
Max. 10A ( no fuse ).
AC Current(True RMS)
Range 200u/2m/20m/200m/10A
Resolution 10n/100n/1u/10u/1mA
Accuracy #(0.8%+10d) -200uA,2mA,20mA,200mA
#(2%+10d) -10A
* spec. are tested under 50/60 Hz.
Over Load 200u/2m/20m/200mA range :
Protection 0.5A fuse protection
10 A range :
Max. 10A ( no fuse ).
OHMS
Range 200/2k/20k/200k/2M/20M ohm
Resolution 0.01/0.1/1/10/100/1k ohm
Accuracy #(0.5%+5d) -200 ohm
#(0.3%+5d) -2k,20k,200k,2 M ohm
#(0.8%+3d) -20 M ohm.
Over Load DCV, 350 ACV.
Protection
Remark : The above DCV, ACV, DCA, ACA, ohm spec. are tested under the
environment RF Field Stren
g
th less than 3 V/M & frequency less
less than 30 MHz only.
3

Diode Check
Range Approx. forward voltage(VF),
good/defect test.
Resolution 0.1 mV.
Transistor hFE
0-1000 hFE, NPN/PNP.
Data hold
To freeze the display values.
Continuity
Sound beeper for continuity check.
Beeper will sound if the measuring resistance < 250 ohm
approximately.
4

3. FRONT PANEL DESCRIPTION
Fig. 1
3-1 Display 3-a Volt/OHM/Diode Input
3-2 Power On/Off Switch 3-b 200 mA Current Input
3-3 Data Hold Switch 3-c 10 A Current Input
3-4 Function Rotary Switch 3-d Transistor hFE Input
3-5 DCV Rotary Switch
3-6 ACV Rotary Switch
3-7 ACA Rotary Switch
3-8 DCA Rotary Switch
3-9 OHM Rotary Switch
3-10 hFE Rotary Switch
3-11 Battery Compartment/Cover
5

4. MEASURING PROCEDURE
4-1 DCV, ACV, DCA, ACA, OHM,
Continuity beeper, Diode, hF
E
When operate the MULTIMETER, first push on
the "POWER SW."(3-2, Fig. 1). Then rotate the
"Range Selector" to the right position. & plug in
the test lead to the right "Input Terminal"
according the following instruction & ref. Fig. 1.
Function Ran
g
e Selector Input Terminal
DCV 3-5 DCV 3-a
ACV 3-6 ACV 3-a
DCA ( < 200 mA) 3-7 DC
A
3-b
DCA ( 200 mA) 3-7 DC
A
3-c
ACA ( < 200 mA) 3-8 AC
A
3-b
ACA ( 200 mA) 3-8 AC
A
3-c
OHM 3-9 ohm 3-a
Continuity beeper 3-9 ohm(beeper) 3-a
Diode 3-9 ohm(Diode) 3-a
hFE 3-10 hFE 3-d
4-2 Data hold
When make any measurement, if select the "Hold Switch"
(3-3, Fig.1) to the "Hold" position will keep the data
on the display. It will release the data hold function if select
the "Hold Switch" to the "Off" position(left side) again.
6

5. MEASURING CONSIDERATIONS
Caution :
* Do not apply the overload
voltage, current to the input
terminal !
(1) Ensure that the battery(006 P DC 9V) is connected to
its snap terminal correctly and placed in the battery
compartment.
(2) Before operating this instrument, familiarize yourself
with all instructions that mentioned in this manual.
(3) Always check to make sure that the function switch is
set to the proper position.
(4) Place the RED Test Lead into the proper input terminal
before making measurements.
(5) Remove either of the test leads from the circuit under
test when changing the measurement range.
(6) Do not exceed the maximum rated signal of each range
to the input terminal.
(7) The "Power On/Off Switch" always to the "OFF" position
when the instrument does not use. Remove the battery if
the instrument is not to be used for a long period of
time.
(8) Be sure to slide the "Data Hold Switch" to the off position
(left side) if the data function is not be executed.
7

6. MAINTENANCE
Caution :
Remove test leads before
open the battery cover !
Caution :
* Risk of electric shock !
6-1 Replacement of Battery
(1) When the left corner of the LCD display shows
" " , it indicates the battery output less than
6.1 V - 7.7 V. Replacement of the battery is then
needed. However measurement could still be
taken for another few hours before the tester
becomes inaccurate.
(2) Open the "Battery Cover"(3-11, Fig. 1) on rear cabinet
by loose the screw on the battery cover and remove the
battery.
(3) Replace with a 9V battery and reinstate the rear cabinet.
6-2 Replacement of Fuse
Fuse :
Rating : 500 mA, Size : 5 mm dia. x 20 mm
(1) This instrument is provided with one 5 x 20 mm
500 mA fuse for 200mA, 20mA, 2mA, 200uA
current range overload protection purpose.
When the current range function (2 A range)
can not operate, please check if the fuse is broken ?
8

(2) When replace the fuse, please open the Battery Cover
and remove the battery, refer Fig.2
(3) Replace the fuse according the spec. and reinstate the
battery cover again.
6-3 Cleaning
Caution :
Cleaning - Only use
the dry cloth to clean
the plastic case !
7. OPTIONAL ACCESSORIES & ADAPTERS
7-1 Holster, HS-01
High quality rubber protective holster.
Fig. 2
9

7-2 Other optional accessories & adapters
Carrying Case Vinyl soft carrying case, high quality.
CA-03 185 x 90 x 60 mm.
Temperature Match DMM to be used as the
Adapter thermometer.
DH-802C, DH-802C : CENTIGRADE MODEL
DH-802F DH-802F : FAHRENHEIT MODEL
Sensor : Type k thermocouple probe,
TP-01, included.
Output : 0.1 mV DC / 0.1 蚓or 0.1 蚌.
Test Lead, High quality and better performance
TL-02A test lead with silicon rubber wire
& separate alligator clip sets.
LIGHT Match DMM to be used as the
ADAPTER Light meter.
LX-02 3 ranges, 2000/20000/50000 LUX.
ANEMOMETER Match DMM to be used as the
ADAPTER Anemometer.
AM-402 Measurements : m/s, km/h, ft/min.,
knots.
HUMIDITY Match DMM be used as the humidity
ADAPTER meter.
HA-701 Range : 10 % to 95 % RH.
TACHOMETER Match DMM to be used as the
ADAPTER Tachometer.
TA-601 Photo type : 2 ranges.
100 - 20,000 RPM.
10

400 A AC/DCA Match DMM to be used as the DCA &
CURRENT ACA clamp meter.
ADAPTER Range : 200A, 400A.
CA-501 Output :1 ACmV/1 ACA,
1 DCmV/1 DCA.
2000 A AC/DCA Match DMM to be used as the DCA &
CURRENT ACA clamp meter.
ADAPTER Range : 200A, 2000A.
CA-202 Output :1 ACmV/1 ACA,
1 DCmV/1 DCA.
MINI ACA Match DMM to be used as the ACA
CURRENT clamp meter.
ADAPTER clamp meter. Range : 20A, 200A.
CA-201 Output : 1 ACmV/1 ACA(200A),
10 ACmV/1 ACA(20A).
50 A CURRENT 50 A DCA/ACA resistance shunt.
SHUNT, ST-50 Match DMM to measure the current
up to 50 A precisely.
11
