Luvelo Ultra LUPJ1000W User manual

Luvelo Ultra Power Juicer
LUPJ1000W
Congratulations
on the purchase of your new Luvelo Ultra Power Juicer

Sa fety Inst ructions
Safety Instructions
P/3
• Remove all packaging material before using your Luvelo Ultra Power Juicer for
the first time. Wash the food pusher, the feed chute cover,
Juice collector bowl, blade and filtering basket, pulp container and juicer jug
before first use in warm soapy water.
• Do not place your Power Juicer near the edge of a bench or table
during operation. Ensure the surface is level, free of liquids or other substances.
• Do not place your Power Juicer on or near a hot stove or oven.
• Do not put the motor base of the juicer in water or any other liquids.
• Unplug juicer from power outlet when not in use, before putting on or taking
off parts, and before cleaning.
• Do not place utensils into juicer while juicing.
• Never operate damaged appliance (incl. Mains cable).
• Operate appliance only through a professionally installed socket supplying
the correct voltage and do not use extension cables.
• Never remove main cable with wet hands, or lay cable on hot surface, or let
cable come into contact with oil.
• Do not try and perform any maintenance, other than cleaning. For any
maintenance issues please contact Luvelo Australia.
• Never leave your juicer unattended while in operation.
• Do not operate outdoors.
• This appliance is not intended for use by young children or infirm persons
without supervision.
• Use a fire blanket only to extinguish fires on appliance.
• The appliance is not designed for commercial or industrial use, it is for
household use only.
Please be sure to read all instructions before using the Luvelo Ultra Power
Juicer. Keep these instructions for future reference.
Sa fety Inst ructions
Safety Instructions #2
P/4
• Do not put fingers or other objects into the feed chute whilst the juicer is
in operation.
• Do not push fruit or vegetables into the feed chute with your fingers, always
use the food pusher provided.
• If any fruit or vegetables become lodged in the feedchute, use the food pusher
or turn off the juicer, remove the plug from the power outlet and disassemble to
remove the lodged fruit or vegetables.
• Never operate without pulp container.
• Ensure the juicer is correctly and completely assembled before turning the
appliance on ‘0’.
• Ensure the juicer cover is clamped securely and pulp container is in place
before juicer is turned on. Do not unfasten the twin-locking handles while the
juicer is in operation.
• Juicing blades are very sharp; handle juicing filter basket with care when
removing, replacing and cleaning.
• Always operate the juicer on a flat, level surface.

P/5
Know Your Luvelo Ultra Power Juicer
Two Speed Control Switch
Two-speed control maximises juicing results.
Low speed for soft fruit, particularly those
with a high water content including oranges
and watermelon. High speed is ideal for hard
and fibrous fruit and vegetables such as apples,
ginger, celery and carrots.
1.5 liter Juice Jug
catches the juice and
makes it easy to pour
into serving glasses.
Suction Non-slip feet
Heavy-duty non-slip feet
ensure the juicer remains
stable and prevents slipping
on the bench top during use.
2 Litre Pulp Container
Large 1.5 litre capacity pulp
containeris ideal for extracting
large volumes of juice without
stopping. Once full, the pulp
container can be easily
removed without having to
dismantle the juicer.
Twin-Locking Handles
Side arms lock all the parts
in place for total safety.
Unless correctly assembled
and clipped into place, the
juicer will not operate.
Features of your Luvelo Ultra Power Juicer
Stainless Steel Motor Base
Equipped with a powerful
1000 watt motor, to achieve
consistent juicing power
regardless of the load, while
maximising juice extraction.
P/6
Know Your Luvelo Ultra Power Juicer #2
Food Pusher
Feed Chute & Cover
Juicer Collector Bowl
The extra wide 75mm diameter feed chute
takes whole fruit and vegetables reducing the
amount of preparation needed.
To maximise juice extraction, the blade and
ltering basket is constructed and tted
with stainless steel mesh for durability,
performance and cleaning ease.
Stainless Steel Blade and Filtering Basket
Advanced spiral system allows the juice to
ow freely extracting every last drip.
Designed to push food into the spinning
blade for extra safety.
ComplImentary brush for cleaning
the stainless steel blade and lter
basket.

Assembling your Luvelo Ultra Power Juicer
P/7
Before using your Juicer
After unpacking your juicer, wash all parts except the motor base in hot soapy water. Rinse and dry
thoroughly.
Important: Always ensure your juicer is unplugged from the power outlet when not in use, during
assembling or whilst removing parts.
1. Set the motor base on a dry, level surface. For convenience when juicing, have the control
switch facing you.
2. Place the pulp container onto the specifically designed pulp container foot rest.
(When you have clipped the juicer collector bowl into place the pulp container will
be secure).
Tip: To reduce cleaning we recommend that you line the pulp container with a plastic bag
to collect the pulp.
3. Place the juicer collector bowl onto the top of the motor base. It will clip securely into
position.
4. Position the stainless steel blade and filtering basket onto the motor drive shaft and push
down until firmly in place. (You may need to rotate to get into correct position).
5. Place the feed chute and cover onto the juicer collector bowl, with the feed chute positioned
over the stainless steel blade and filtering basket and push into position.
6. Secure the juicer cover by raising the twinlocking handles and clip the tops to the juicer
cover. Press firmly on the lower part of the twin-locking handles to lock into place.
Please note: The juicer will not power on until the twin-locks have been clipped into place.
When twin-locks are clipped into place and the juicer is switched on at the power point, then
the red LED light will come on around the control switch.
7. Take the food pusher, align the groove on the food pusher with the notch on the inside of
the feed chute and slide the food pusher down into the feed chute.
You are now ready to switch the juicer on and begin juicing.
Operating your Luvelo Ultra Power Juicer
P/8
Please note: The juicer should be completely assembled before use.
1. Ensure the control switch on the juicer is in the off ‘0’ position and insert the power cord into a
230-240V AC power outlet and turn the power ‘On’.
2. Clean fruit and vegetables thoroughly, ready for juicing.
Note: The extra large feed chute allows whole fruit and vegetables to be juiced, however
some fruit and vegetables may require other preparation before juicing, such as peeling
and removing stones. See page 9 for tips and techniques.
3. Ensure that the juicer has been assembled completely and correctly, making sure that the
stainless steel blade and filtering basket revolves properly before placing fruit and vegetables
in the juicer.
4. Place the 1.5 litre jug under the juice spout.
5. Select 1 or 2 speed with the control dial. For optimum juicing results speed 1 is used primarily
for soft fruit and vegetables, particularly those with a high water content and speed 2 is ideal for
hard and fibrous fruit and vegetables.
Please note: When speed 1 or 2 is selected, the control switch LED light will change
from red to blue to indicate the juicer in now ready for operation
6. With the juicer in operation, place the fruit and vegetables into the feed chute. Using the food
pusher, guide the fruit and vegetables down the feed chute and onto the stainless steel blade.
Tip: For maximum juice extraction, guide the food pusher down the feed chute in a slow
downward motion.
Important: Do not push fruit or vegetables into the feed chute with your fingers, always
use the food pusher provided.
7. The juice from the fruit and vegetables will flow directly into the jug.
Important: When juicing be aware of the level of pulp in the pulp collection container,
because if the container is overfilled this can cause damage to the appliance and
prevent the juicer from operating correctly.
8. When juicing is complete, ensure that the juicer is switched ‘Off’ and unplugged from the
power outlet.

P/9
Wash all fruit and vegetables thoroughly before juicing. There is no need to peel
vegetables that have a thin skin but a light scrub with a clean sponge can help remove any
dirt that may be stuck on, as well as any waxy coatings. Peel fruit and vegetables that have
a thick skin such as melons, pineapple and citrus fruit.
Juice only the freshest of fruit and vegetables to get the best nutritional benefits and
flavours. Cut large pieces of fruit, such as melons into large wedges. Some seeds from
citrus fruits can be bitter so you may want to remove the seeds if desired.
Remove seeds and stones from fruit such as mangoes, papaya and stone fruit.
This will prevent the blade from getting damaged.
When juicing different fruit and vegetables, it may help to juice in different combinations.
For example, when juicing apples and oranges, juice the soft fruit (oranges) first, then
follow with the hard fruit (apples) second. This will help you to achieve the maximum
juice extraction from the fruit and vegetables.
When juicing fresh herbs such as mint or parsley, add the herbs in between the fruit and
vegetables to get the most out of the herb or if only using a small quantity, add the herb
at the same time as a piece of fruit and vegetable.
Bananas can be hard to juice but the taste goes a long way. When juicing a blend of fruit
with bananas, add the banana as either the first or second piece of fruit. The nectar of
the banana will sit inside the filtering basket and as the remaining fruits are added into the
juice extractor they will release the banana nectar throughout the rest of the juice
resulting in frothy flavoursome juice.
When juicing small fruit such as grapes or strawberries, add the fruit in handfuls rather
than one at a time, this will maximise the amount of juice extracted. Be aware that beetroot
stains all other fruit and vegetables.
Tips for Juicing & Techniques
Troubleshooting
P/10
Question: Fibres are coming out from the pulp container during operation?
Sometimes when juicing fibrous fruits and vegetable, small specks of fibres can come out of the
pulp container. This is because there is a small gap design between the pulp container and the juicer
cover to allow for air-flow when juicing. Without this gap the motor would not work correctly.
Solution: If juicing a lot of fibrous fruits and vegetables, we recommend that you line the pulp
container with a plastic bag to assist with clean up.
Question: The juicer will not start when speed is selected.
Solution: The juicer has not been assembled correctly. Please see page 7 ‘Assembling
your Luvelo Ultra Power Juicer’
Question: The stainless steel blade and filtering basket is blocked with excess pulp
After extended juicing of fibrous fruits and vegetables, the mesh on the filtering basket
may need to be cleaned.
Solution: Stop juicing, disassemble the juicer and follow the cleaning and care instructions
on page 11.

Cleaning & Care
P/11
Please note: Ensure that the juicer is unplugged from the power outlet prior
to cleaning.
Important: Do not place any part of your juicer in the dishwasher.
Cleaning
For easy fast cleaning, ensure that immediately after use the juicer is disassembled
and that each removable part cleaned. Rinse the juicer collector, feed tube & juicer
cover, pulp container and food pusher under running water and then wash with warm,
soapy water, making sure all wet pulp is removed. Rinse well, then allow to air dry.
To clean the stainless steel blade and filtering basket
Using the brush provided, hold the stainless steel blade and filtering basket under running
water and brush the outside of the basket first. Then with the basket still under running
water, brush the inside of the basket in an anticlockwise direction, removing all pulp. To
ensure the stainless steel blade and filtering basket is free of all remaining pulp, hold it
up to light and ensure that the holes in the filtering basket are not blocked.
Important: Juicing blades are very sharp, handle the filtering basket with care when
removing, replacing and cleaning.
To clean the motor base
Clean the motor base of the juicer using a damp soft sponge with mild detergent and
wipe over the appliance.
Important: Never immerse the motor base in water or any other liquid.
For recipes, tips and the latest information on the Luvelo Ultra Power Juicer
please visit our website.
www.luvelo.com
