LUX LS250 User manual

OWNER MANUAL
MODEL: LS250
www.luxspachairs.com
www.luxspachair.com

SAFETY & PRECAUTION
Please read the instructions carefully before installing the spa chair. Carefully follow the instructions, your spa
chair will give you years of beauty and service.
This product is to be connected to a branch circuit outlet protected with a Class A GROUND FAULT
CIRCUIT INTERRUPTER (GFCIl). The GFCI shall be tested regularly for continued protection and
correct operation. If a Class A GFCI protected outlet is not available, DO NOT USE THIS
PRODUCT! Please contact a licensed electrician for installation of a Class A GFCI, or equivalent
according to local electric codes.
THIS PRODUCT IS FOR IN DOOR USE ONLY
DISCONNECT POWER SUPPLY CORD BEFORE SERVICING AND CLEANING
Foot-spa must be installed by a licensed plumber and electrician in accordance with local codes. Plumbing
and Electrical Installation instructions must be adhered to in order for the warranty to be in effect and to
insure the utmost in safety. Chair and spa have a maximum seating capacity of 350 pounds.
The foot-spa is not intended to be stood in or used as a step. The portable foot-spa model is movable,
standing in tub or using as a step may cause severe damage to the unit as well as possible serious injury to
the person.
BASIC PRECAUTIONS SHOULD ALWAYS BE OBSERVED, INCLUDING THE FOLLOWING:
Read and follow all instructions.
DANGER. To reduce the risk of injury, do not permit children to use this unit unless they are supervised
at all times.
Use this unit only for its intended use as described in this manual. Do not use attachments that are not
recommended by the manufacturer.
Never drop or insert any object into any opening.
Do not block jets during whirlpool operation.
The unit must be connected to an electrical supply circuit that is protected by a ground fault circuit interrupter.
The clean jet motor is magnetically driven and is insulated twice. Therefore it does not require to be bonded.
Save these instructions.
1.
2.
3.
4.
5.
6.
7.
If a crack occurs in the glass bowl, DO NOT manually handle the bowl unless the proper
attire is worn. Under no circumstances must the bowl be used by your customers as you
can be held accountable for any injury that may occur. We are not liable for any injury
that may occur.
1. Excessive water temperature is dangerous and should be checked BEFORE use.
2. Maximum temperature of the water should never exceed 100 degrees F.
3. Always enter and exit the Foot Spa slowly and carefully.
4. NEVER bring and / or operate any electrical devices into or near the Foot Spa.
www.luxspachairs.com
www.luxspachair.com

COMPLIANCE WITH LOCAL CODES OR
INSPECTIONS IS THE RESPONSIBILITY OF
THE GROUNDING PIN THE PURCHASER
AND/OR INSTALLER
IMPORTANT! At the end of the day, ALWAYS turn the main power OFF!
DANGER: To reduce the risk of injury, do not permit children to use this unit unless they are closely supervised
at all times.
CAUTION: This unit should not be used by persons with open wounds, cuts or sores on their feet or legs, or by
persons with poor circulation, or heart conditions. If in doubt, the client should consult with his or her physician.
Use this unit only for its intended use as described in this manual. Do not use attachments not recommended by
the manufacturer
Do no operate with a damaged cord or plug. If the unit is malfunctions or is damaged in any manner, contact
an authorized service representative for examination or repair.
Never drop or insert any objects into any opening.
Do not block jets during pedicure operation.
Water temperature should be checked before use. Water temperature should never exceed 100 degrees Fahrenheit.
Never bring any electrical devices into the unit or operate electrical devices near it.
The unit must be connected to a supply circuit that is protected by a ground-fault circuit interrupter (GFCI).
Connect the unit only to a properly grounded outlet. See grounding instructions.
Close supervision is necessary when the unit is used by, on or near children or handicapped person.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
SAFETY & PRECAUTION
Because this unit must be connected to a circuit with a ground-fault circuit interrupter (GFCI), DO NOT use a
grounding adapter.
GROUNDING METHODS
OPERATION AND USE INSTRUCTIONS
This appliance must be plugged into an outlet equipped with a ground-fault circuit interrupter. The ground-fault
interrupter can be in the out-let shown in illustration A or in the circuit breaker (fuse) box. If your outlet or circuit
breaker (fuse) box is not equipped with a ground-fault interrupter, you must have your electrician install one.
In the event of an electrical short-circuit, the ground-fault circuit interrupter will turn off the electrical power to the unit
immediately, greatly reducing the likelihood of serious injury. This appliance is for use with a nominal 120-volt circuit
and has a grounding plug that looks like the plug illustrated in the sketch. The outlet must be properly installed and
grounded in compliance with all local codes and ordinances.
If it is necessary to use an extension cord, use only a three-wire extension cord that has a three-blade grounding
plug and a three-blade grounding plug and a three-slot receptacle that will accept the plug on the appliance.
Replace or repair a damaged cord.
GROUNDING INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
www.luxspachairs.com
www.luxspachair.com

IDENTIFY YOUR FOOT-SPA
9.
10.
11.
12.
13.
1.
2.
3.
4.
5.
6.
7.
8.
Resin Bowl
7-colors LED light crossing the side
Armrest
Folding Manicure Tray
Backrest & Massage
Seat Cushion
Adjustable Footrest
Footrest
Faucet
Magnet Jet
Second remote for technician
Airvent
Built-in remte control
1
6
7
11
12
9
10
2
8
313
4
5
Armest can be raised up/down
Maincure tray can be folded up/down
SEAT OPERATION
www.luxspachairs.com
www.luxspachair.com

To turn off the Auto Fill System, touch and hold the POWER button for 3 seconds. The system is OFF
when all button lights are off.
Note: The Auto Fill System will be in temporary lock mode every 30 seconds, indicated by POWER
button blinking. To unlock the system, simply touch and hold the POWER button for 3 seconds.
Preparation:
Pedicure bowl must empty and water stopper is plugged before
using the Auto Fill System.
To begin simply touch the POWER button to turn on the AutoFill System.
Press the AUTO FILL button to begin filling the bowl. Adjust the water temperature by turning
the temperature knob accordingly. Once it fills 4.2 gallonsof water, it will automatically shut off and
the blue AUTO FILL button will blink and be on lock mode. Simultaneously, the LED light and
jet pump automatically turn on. After 30 seconds, the POWER button will be flashing indicating
temporary lock mode.
To add more water, touch the FILL button. Each time the water will run for 8 seconds and automatically
shut off to prevent overflow. Simply touch the FILL button again to manually stop water flow.
Touch the JET button to turn jet pump on and off.
LUX AUTO FILL SYSTEM USER MANUAL
AUTO FILL Panel
www.luxspachairs.com
www.luxspachair.com

IDENTIFY YOUR FOOT-SPA
SPA DIMENSION
3
3
”
52”
58”
www.luxspachairs.com
www.luxspachair.com

FOOT-SPA CLEARANCE
28”
60”
60”
WALL CLEARANCE
TYPICAL FOOT-SPAS
Center
Foot-spa #1 Foot-spa #2
Center
www.luxspachairs.com
www.luxspachair.com

INSTALLATIONS
Plumbing Connections
3/8 " Hot & Cold Fitting
1” Fitting
Electrical Service
110v, 60Hz, 15 Amp, GFCI protected grounded circuitsmust be usedto supply power to each individual
pedicure spa, and the main circuit breaker must be at 25Amp. Maximum of two units per each electrical outlet.
Spa Chair Rate : 120VAC, 60HZ, 10A
FAILURE TO ANCHOR THE BASE MAY RESULT IN PERSONAL INJURY OR DAMAGE TO THE UNIT.
DAMAGE AS A RESULT WILL VOID THE WARRANTY.
Discharge pump may be connected to an existing sink floor drain. It can also pump up to 7 ft high, but this will
increase the length of the drain time. The drain connection is at the rear of the unit by a 3/4” fitting. Gravity drain
uses a standard gravity drain. Afloor drain is recommended. Connection via a P-Trap is supplied. Hot and cold
water supply connections are located at the rear of the unit (4” fittings).
Please be advised that the hot and cold water supply lines are not fitted with optional back flow preventers
unless ordered at initial sale.
Have a qualified licensed electrician install the wiring according to local codes.
The Cleanjets are 1/10 hp, 120V, 1.2 AMP 60OHZ. A 15 amp. GFI protected circuit must be used to supply
power to the unit. The roller back massage chair uses a 115V supply.
Spa chair base should be anchored securely to the floor. The base may be anchored through the opening in the
back of the base wherever access is convenient for the installer.
1.
2.
3.
4.
5.
www.luxspachairs.com
www.luxspachair.com

Ventilation
VENTILATION
1”
Discharge
Pump
Exhaust fan
actuation air
switch
50”
28”
Wall
Wall
Gravity Sink
2” - 3” drain pipe
to sewer line
28”
TYPICAL Gravity Sink (Direct Drain) Installation
www.luxspachairs.com
www.luxspachair.com

DISCHARGE PUMP
Wall
Gravity Sink
2” - 3” drain pipe
to sewer line
28”
Wall
28”
Sewer line parallel with floor
Wall
28”
Discharge Pump
www.luxspachairs.com
www.luxspachair.com

OPERATIONS & USE
Air Vent
Mixing Valve
Drain Knob
Hand Spray
POWER Panel
Control Panel
1. To fill water:
The foot-spa is provided with a single hot and cold mixing valve located on the front of your spa as shown. This is
a pressure balance valve that requires you to lift the handle to start the water flow and to adjust to the temperature
that is desired. The clean jet motor must be completely submerged in water.
CAUTION: DO NOT USE FOAMING, SUDSING OR MINERAL OIL BASED ADDITIVES IN THE WATER.
2. To Auto Fill (Optional)
- With drain open. Turn on water with mixer valve handle.
- Press auto fill air switch (brown & chrome).
- Adjust mixer for desired water temperature.
- Close drain valve, bowl will fill to set water level and shut off.
- Mixer valve is now set open and at temperature setting for the rest of the day.
*Mixer valve must be turned off at the end of the day.
3. To start whirlpool:
Press the jet button as shown. This will start your Jet motor. You may stop the whirlpool function at any time by
pressing the button again. The jet button is not labeled in the installation.
4. To use water spray:
The foot-spa is equipped with a hand held sprayer. To activate the hand shower, pull the hand shower from the
receptacle and depress the thumb control on the sprayer handle. This will turn on the water. When you release
pressure on the thumb control this will turn the water off.
5. To drain whirlpool tub:
Open the drain plug by turning the control knob as shown.
BASIC PRECAUTIONS SHOULD ALWAYS BE OBSERVED, INCLUDING THE FOLLOWING:
Read and follow all instructions
DANGER. To reduce the risk of injury, do not permit children to use this unit unless they are supervised
at all times
Use this unit only for its intended use as described in this manual. Do not use attachments that are not
recommended by the manufacturer.
Never drop or insert any object into any opening.
Do not block jets during whirlpool operation.
The unit must be connected to an electrical supply circuit that is protected by a ground fault circuit interrupter.
The clean jet motor is magnetically driven and is insulated twice. Therefore it does not require to be bonded.
Save these instructions.
1.
2.
3.
4.
5.
6.
7.
www.luxspachairs.com
www.luxspachair.com

CLEANING & MAINTENANCE
Please refer to the diagrams to remove jet unit components for cleaning
We highly recommend the following cleaning regimen. You should always contact your local governing agency for
their specific cleaning and disinfecting requirements and regulations for pedicure spas. For your clients safety,
always use the regulations as a minimum standard for cleaning and disinfecting. Combining your states standards
with the regimen listed below will provide your clients with a safe and healthy pedicure spa environment experience.
Routine maintenance:
Powdered cleansers or abrasives are NOT RECOMMENDED. A clean towel or sponge, are all that are usually
needed. A soft bristled brush may be used when excessive residue is present. Use a mild soap and water solution
to clean the upholstery, but do not over wet. Wipe dry with a clean towel. No internal maintenance of the spa
components is necessary. Remove clean jet caps and spray with disinfectant after each use. For extra protection,
our recommendation is that the system be flushed daily or weekly depending on use. To flush the clean jet system
fill spa with hot water to just above the jets. Add disinfectant. Run whirlpool for 15 minutes, drain and then wipe dry
with clean soft cloth.
The use of oil based products can build up in the whirlpool system causing clogging in the jets. Adherence to the
above cleaning will minimize build up. We do not recommend the use of mineral oil based products.
TESTING/FLUSHING FOOT SPA
After the foot spa has been installed, fill the tub with water just above the jets. Carefully check for leaks at the
drain and over flow. After checking the underside for leaks,turn on the system by pushing the whirlpool button
and watch for leaks as water circulates. Let the unit run a full cycle. Open drain plug for water discharge.
NOTE:
According to the Centers For Disease Control and Prevention (CDC), and the US Environmental Protection
Agency (EPA), disinfecting occurs only when there is a reduction of pathogenic microbes at 99.999%.
Sanitizing is only a reduction of 99.9%. Cleaning of whirlpool pedicure spas requires surfactant and
chelating detergents that are low-foaming and have the ability to remove body oils, organic oil additives,
mineral oil, skin cells, nail clippings etc that can accumulate both in the basin and the jets,which may
become a fertile area for micro organisms to grow.
www.luxspachairs.com
www.luxspachair.com

CLEANING & MAINTENANCE
1. Pull Magnet Jet off from the pedicure bowl.
2. Turn the Top Plate of the Magnet Jet counter-clockwise.
3. Separate the three components of the Magnet Jet: Top Plate, Magnet, Back Plate.
4. Wash each component of the Magnet Jet in a recommended or high quality solution or cleaning agent
5. Reassemble the Magnet Jet using the following directions:
‣Turn the Top Plate clockwise until you hear a “click-sound”
6. Remount the Magnet Jet onto the pedicure bowl by aligning the pegs so that the tab is at the top of the Magnet
Jet.
Do not place two wet ends in the same bowl when cleaning. The jets' strong magnets
could cause injury (pins your fingers).
Do not attach two wet ends to each other. Doing so will cause breakage to wet ends and
will void the warranty.
Do not run magnet jets without water. This will void your warranty.
CLEANING THE MAGNET JET (Step by Step)
THREE MAGNET JET COMPONENTS
Top Plate Back Plate BottomBack Plate TopMagnet
www.luxspachairs.com
www.luxspachair.com

WARRANTY & SERVICE
Lux Spa warrants to the original purchaser that the new pedicure spa will be free from defect during the Standard
Warranty Period (listed below). The shipping date and the uniquely-coded Serial Number on the back of each spa
chair will justify the start of the warranty period for the product. The warranty is null and void if the pedicure spa is
taken from its initial place of installation, or it is not installed in accordance with federal, state or local codes and
ordinances. Also, this warranty does not apply if the pedicure spa has beer subject to misapplication, improper
installation or maintenance, negligence, improper cleaning or other circumstances.
WARRANTY
Limited One (1) Year warranty on the Discharge/Drain Pump.
Limited One (1) Year warranty on the Clean Jet (Dry End).
Limited Three (3) Years Part-Only warranty which covers the Hydraulic System, upper massage
mechanism system.
Lux Spa will pay standard shipping charges on all replacement part during the first 90 days of the stated
Warranty Period.
After 90 days the consumer is responsible for all labor and shipping costs occurred.
EXCLUSIONS
Damage to pump parts and/or motor parts due to obstruction in plumbing lines etc.
Staining, fading or discoloration of plastic surfaces due to exposure and/or the use of harmful cleaning
agents or chemicals.
Staining, fading or discoloration caused by improper or poor water additives not related to the
maintenance of proper water are not covered by this warranty.
Staining, fading or discoloration of the seat, armrests or footrests.
Freight damage, misuse, neglect, accident, natural disaster and abuse.
Unauthorized repairs.
1.
2.
3.
4.
1.
2.
3.
4.
5.
6.
SERVICE
The Customer shall forward all warranty-related matters to our Customer Service Department.
Original Invoice must accompany all warranty claims.
Customers are responsible for shipping defective parts back to Lux Spa. These parts must be packaged
correctly in order to protect against any further damage.
All parts are to be shipped by UPS Ground or USPS Service.
All defective parts must be shipped back to Lux spa within 30 days of receiving the new replacement parts
or warranty will be void.
The customer must send photos and original invoice directly to Lux Spa for warranty claims that
cannot be determined over the phone before any repairs can be performed.
Any service performed on the product without Lux Spa authorization will also void the Warranty.
1.
2.
3.
4.
5.
6.
7.
www.luxspachairs.com
www.luxspachair.com
Table of contents
Other LUX Massager manuals
Popular Massager manuals by other brands

Prospera
Prospera PL009 operating manual

Hotronic
Hotronic m4 power plus operating instructions

Panasonic
Panasonic Real Pro Ultra EP30005 Instrucciones de Uso

iRest
iRest ICOMFORT PLUS Operation instructions

HoMedics
HoMedics Back Revitalizer VC-150 Instruction manual and warranty

Therabody
Therabody Recovery Air PRO manual
