Luxier BSH03-SB User manual

1BSH03S Rev. SG1 08/2019Luxier
Single Handle Bathroom Lavatory Faucet
Model Number:
BSH03-SB (Brushed Nickel)
BSH03-SC (Chome)
BSH03-SM (Matte Black)
BSH03-SO (Oil Rubbed Bronze)
Features:
- Brass Construction
- Single Hole Installation
- Drip Free Ceramic Cartridge
- NEOPERL®aerator 1.2 gpm maximum
at 60 psi
- Complies with:
NSF 61-9
ASME A112.18.1 / CSA B125.1
IAPMO / UPC / cUPC
CA AB-1953
ADA
Max. Deck Thickness 1.5”
*Drawings Not To Scale. All Measurements are Approximate*
2”
2.2”
6.53”
3.6”
4.75”
3.35”
7.4”
2”
Approx. 27” long water supply hose with 3/8”compression tting
1 3/8” Hole Size

2BSH03S Rev. SG1 08/2019Luxier
Thank you for purchasing Luxier products. Please read the information below and keep this installation
guide for future reference. If you require assistance, please contact our customer service department at
1-877-711-8828, Monday - Friday 9AM - 5PM Pacic Time or by email at
suppor[email protected].
Limited Lifetime Warranty (For USA Only)
The manufacturer warrants this product to be leak and drip free during daily normal household use for as long as it is owned by
the original purchaser of this product. Please keep a copy of the original invoice as proof of purchase.
Should a malfunction occur within the warranty period, Luxier USA will, as its option, (1) repair or replace the defective part(s) or
product at no charge; (2) issue a refund of the purchase price paid for the product (Valid within 30 days from the date of purchase);
or (3) issue a credit to be applied against the purchase of a new Luxier product. Shipping/delivery charges may apply and are in
Luxier USA’s sole discretion.
This limited warranty shall not apply to goods which have been subject to accident, negligence, improper installation, product
abuse, product misuse, or use of cleaners containing abrasives, alcohol or other organic solvents, whether performed by a
contractor, service company, or yourself, are excluded from this warranty.
Our responsibility under this warranty is limited to only to replacement parts and no other costs. Luxier USA will not be
responsible for labor charges and/or damage incurred by installation, repair or replacement, nor for any indirect incidental or
consequential damages, losses, injury or costs of any nature relating to this faucet. Except as provided by law, this warranty is
in lieu of and excludes all other warranties, conditions, and guarantees, whether expressed or implied, statutory or otherwise,
including without restriction those merchantability of tness for use.
This limited warranty is non-transferable. This limited warranty only applies to products purchased and installed in the United
States. This limited warranty covers the original consumer purchase only and does not include business, commercial or industrial
use of this product. To obtain service under the Limited Warranty, please contact Luxier USA at
[email protected]. The Luxier USA Customer Care Department will determine whether to repair or replace your product,
issue a refund, or issue a credit.

3BSH03S Rev. SG1 08/2019Luxier
Maintenance Guide
Please follow the cleaning material manufacturer’s instructions. Damage caused by improper treatment will
not be covered by product warranty. In addition, pay attention to the following points:
• Regular cleaning can prevent mineral build up on faucet spout.
• Carefully read the cleaner product label to ensure the cleaner is safe for use on the material.
• Test the cleaner on a small area before using on the entire surface.
• Use a mild detergent such as liquid dishwashing soap and warm water for cleaning.
• Do not use abrasive / harsh chemical when cleaning the xture as they will damage and dull the nish.
• When using spray cleaners, spray rst onto a soft cloth or sponge. Never spray directly onto the faucet as
droplets can enter openings and gaps and cause damage.
• After cleaning, rinse thoroughly with clean water to remove any cleaner residue.
Important Points
• This installation guide is subject to change without notice, please contact us to request the most
updated version of this installation guide.
• This is a general installation guideline, actual installation may vary. Consult a professional installer
if necessary.
• Read and understand this instructions completely before installation.
• Please follow all local building and plumbing codes.
• Product drawings in this installation guide is for illustration purpose only. Actual product may vary
depends on model.
• Always take extra precautions and wear appropriate safety equipment when installing this
product.
• Wrap all threaded connections, except the aerator in the spout, with Te on (TPFE) tape. Always
wrap in a counterclockwise direction.
• When installing your new faucet, fi rst hand tighten the water supply hoses then use a wrench to
give the compression nuts an additional (1/4) turn. Do not over tighten the compression nuts as it
will reduce the integrity of the sealed connection.
You may also need the following tools
1. Safety Glasses 5. Screwdriver
2. Teon (PTFE) Tape
3. Plumber’s Putty and Caulking
4. Adjustable Wrench

4BSH03S Rev. SG1 08/2019Luxier
Installation
B
A. Shut o water supply at the valves.
Remove old faucet and clean the
mounting surface for installation of new
faucet.
D1. Apply Teon (PTFE) tape on the
shut o valves. Thread the tape in
counter-clockwise direction.
F. Remove aerator from the spout and
let the water run for about 1 minute to
clear any debris in the plumbing system.
Attach the aerator.
D2. Use a wrench to tighten the
hoses, please do not overtighten the
connections.
E. Turn on the water supply to check for
leaks at all connections.
B. First place the new faucet through
ange on the mounting surface. The
faucet hole should be 1 3/8” in diameter
on the mounting surface.
D1
Flexible water supply line
D2 E
F
A
15
14
12
13
C
C. Remove the 2 screws (15) from
locking nut (14). From under the sink,
install the rubber washer (12), steel
washer (13) and locking nut (14) onto
the shank (11) Tighten the locking nut
with a basin wrench or the socket tool
and install the 2 screws (15) to secure
the faucet in place.
02
03
01
04
05
06
07
09
10
11
12 13
14
15
16
08
01. Handle
02. Setscrew
03. Handle Cap
04. Cap
05. Bonnet
06. Cartridge
07. Faucet Body
08. Aerator
09. Flange (non-removable)
10. EVA Washer (non-removable)
11. Shank
12. Rubber Washer
13. Steel Washer
14. Locking Nut
15. Screws (x2)
16. Water Supply Hoses
