Luxier KTS17-TB User manual

1KTS17 SG Rev.3 08/2021
Luxier USA
Model Number:
KTS17-TB (Brushed Nickel)
KTS17-TC (Chrome)
KTS17-TG (Brushed Gold)
KTS17-TM (Matte Black)
KTS17-TO (Oil Rubbed Bronze)
Features:
- Drip Free 1/4 Turn Ceramic Cartridge
- Maximum Flow Rate 4.0 gpm at 60 psi
- 1/2” NPT Connection
- For Cold Water Only
- Complies with:
NSF 61-9
ASME A112.18.1
IAPMO / UPC / cUPC
CSA B125-1
CA AB-1953
Wall Mounted Pot Filler
12.85”
13.95”
1.91”
4.24”
7.97”
1.75”
2.56”
2.54”
2.26”
2.97”
* Drawing not to scale. All measurements are approximate.
1/2” NPT

2KTS17 SG Rev.3 08/2021
Luxier USA
Thank you for purchasing Luxier products. Please read the information below and keep this
installation guide for future reference. If you require assistance, please contact our customer service
department at 1-877-711-8828, Monday - Friday 9AM - 5PM Paci c Time or by email at
[email protected].
Limited Lifetime Warranty (For USA Only)
The manufacturer warrants this product to be leak and drip free during daily normal household use
for as long as it is owned by the original purchaser of this product. Please keep a copy of the original
invoice as proof of purchase.
Should a malfunction occur within the warranty period, Luxier USA will, as its option, (1) repair or
replace the defective part(s) or product at no charge; (2) issue a refund of the purchase price paid
for the product (Valid within 30 days from the date of purchase); or (3) issue a credit to be applied
against the purchase of a new Luxier product. Shipping/delivery charges may apply and are in Luxier
USA’s sole discretion.
This limited warranty shall not apply to goods which have been subject to accident, negligence,
improper installation, product abuse, product misuse, or use of cleaners containing abrasives, alcohol
or other organic solvents, whether performed by a contractor, service company, or yourself, are
excluded from this warranty.
Our responsibility under this warranty is limited to only to replacement parts and no other costs.
Luxier USA will not be responsible for labor charges and/or damage incurred by installation, repair or
replacement, nor for any indirect incidental or consequential damages, losses, injury or costs of any
nature relating to this faucet. Except as provided by law, this warranty is in lieu of and excludes all
other warranties, conditions, and guarantees, whether expressed or implied, statutory or otherwise,
including without restriction those merchantability of  tness for use.
This limited warranty is non-transferable. This limited warranty only applies to products purchased
and installed in the United States. This limited warranty covers the original consumer purchase only
and does not include business, commercial or industrial use of this product. To obtain service under
the Limited Warranty, please contact Luxier USA at [email protected]. The Luxier USA Customer
Care Department will determine whether to repair or replace your product, issue a refund, or issue a
credit.

3KTS17 SG Rev.3 08/2021
Luxier USA
Important Points
• This installation guide is subject to change without notice, please contact us to request the most
updated version of this installation guide.
• This is a general installation guideline, actual installation may vary. Consult a professional if
necessary.
• Read and understand this instructions completely before installation.
• Please follow all local building and plumbing codes.
• Product drawings in this installation guide is for illustration purpose only. Actual product may vary
depends on model.
• Always take extra precautions and wear appropriate safety equipment when installing this
product.
• Wrap all threaded connections, except the aerator in the spout, with Te on (PTFE) tape. Always
wrap in a counterclockwise direction.
• When installing your new faucet,  rst hand tighten the water supply hoses then use a wrench to
give the compression nuts an additional (1/4) turn. Do not overtighten the compression nuts as it
will reduce the integrity of the sealed connection.
You may also need the following tools
1. Safety Glasses 5. Adjustable Wrench
2. Teon (PTFE) Tape 6. Screwdriver
3. Plumber’s Putty and Caulking
4. Basin Wrench
Maintenance Guide
Please follow the cleaning material manufacturer’s instructions. Damage caused by improper
treatment will not be covered by product warranty. In addition, pay attention to the following points:
• Regular cleaning can prevent mineral build up on faucet spout.
• Carefully read the cleaner product label to ensure the cleaner is safe for use on the material.
• Test the cleaner on a small area before using on the entire surface.
• Use a mild detergent such as liquid dishwashing soap and warm water for cleaning.
• Do not use abrasive / harsh chemical when cleaning the  xture as they will damage and dull the
 nish.
• When using spray cleaners, spray  rst onto a soft cloth or sponge. Never spray directly onto the
faucet as droplets can enter openings and gaps and cause damage.
• After cleaning, rinse thoroughly with clean water to remove any cleaner residue.

4KTS17 SG Rev.3 08/2021
Luxier USA
Installation
A. Shut o the main water supply before
installation. The faucet requires an 1/2”
NPT threaded male nipple extending
1/2” from the nished wall. For ease of
future maintenance, it is recommended
to install a shut o valve for the water
supply line at an easily accessible
location.
B. Place mounting base on the wall as
shown in the gure with setscrew holes
set at 12 and 3 o’clock positions. Mark
the placement for the 3 screws with
marker.
C. Drill the holes and insert wall anchors
into the holes. Apply PTFE tape onto the
nipple in counter-clockwise direction.
Secure the mounting base with the
supplied screws.
(IMPORTANT: Make sure there are no
pipes or electrical wires behind the mounting
surface.)
D. Slide the ange trim onto the body
and attache the pot ller onto the pipe
by turning the entire pot ller clockwise.
(IMPORTANT: DO NOT overtighten the pot
ller)
E. Tighten the 2 small setscrews with
the hex wrench to secure the pot ller.
Slide the ange to cover the mounting
base after the pot ller is secured.
1/2” NPT Male
1/2”
A
F
F. Remove aerator from the spout and
turn on the water to ush out any
debris in the plumbing system. Also
check for leaks at all connections.
Install the aerator when done. The
installation is now complete.
(NOTE: This faucet is equipped with
two on/o handles, the handle on the
wall side should be closed (handle
in vertical position) when faucet is
not in use. If the pot ller is to be
left unattended, please ensure both
handles are in closed position.)
setscrew holes
BC
DE
1
2
3
4
5
6
7
8
92
10
11
12
13
14
16
17
15
18 19
01. Cap
02. Screw
03. Handle
04. Cartridge
05. Upper Arm
06. Aerator
07. Aerator Wrench
08. Lower Arm
09. Cap
10. Handle
11. Cartridge
12. Body
13. Flange
14. Mounting Base
15. Rubber Washer
16. Setscrew
17. Hex Wrench
18. Screws (x3)
19. Wall Anchors (x3)
