Luxier BSH06-S User manual

1BSH06S Rev. A 02/2017Luxier USA
Single Handle Bathroom Lavatory Faucet
Model Number:
BSH06-SB
BSH06-SC
Features:
- Brass Construction
- Single Hole Installation
- Drip Free Ceramic Cartridge
- NEOPERL®aerator 1.2 gpm max at 60 psi
- Complies with:
NSF 61-9
ASME A112.18.1 / CSA B125.1
IAPMO / UPC / cUPC
CA AB-1953
WaterSense
CALGreen
Max. Deck Thickness 2”
3/8” compression tting
1 3/8” Hole Size
*Drawing not to Scale. All Measurements are Approximate
Approx. 24” water supply hose
7.25”
5.56”
3.56”
7”
2.56”
3”
2.3”

2BSH06S Rev. A 02/2017Luxier USA
Thank you for purchasing Luxier products. Please read the information below and keep this
installation guide for future reference. If you require assistance, please contact our customer service
departmentat1-877-711-8828,Monday-Friday9AM-5PMPacificTimeorbyemailat
[email protected].
Limited Lifetime Warranty (For USA Only)
The manufacturer warrants this product to be leak and drip free during daily normal household use for as long as it is
owned by the original purchaser of this product. Please keep a copy of the original invoice as proof of purchase.
Should a malfunction occur within the warranty period, Luxier USA will, as its option, (1) repair or replace the defective
part(s) or product at no charge; (2) issue a refund of the purchase price paid for the product (Valid within 30 days from
the date of purchase); or (3) issue a credit to be applied against the purchase of a new Luxier product. Shipping/delivery
charges may apply and are in Luxier USA’s sole discretion.
This limited warranty shall not apply to goods which have been subject to accident, negligence, improper installation,
product abuse, product misuse, or use of cleaners containing abrasives, alcohol or other organic solvents, whether per-
formed by a contractor, service company, or yourself, are excluded from this warranty.
Our responsibility under this warranty is limited to only to replacement parts and no other costs. Luxier USA will not be
responsible for labor charges and/or damage incurred by installation, repair or replacement, nor for any indirect inciden-
tal or consequential damages, losses, injury or costs of any nature relating to this faucet. Except as provided by law, this
warranty is in lieu of and excludes all other warranties, conditions, and guarantees, whether expressed or implied, statu-
toryorotherwise,includingwithoutrestrictionthosemerchantabilityoffitnessforuse.
This limited warranty is non-transferable. This limited warranty only applies to products purchased and installed in the
United States. This limited warranty covers the original consumer purchase only and does not include business, commer-
cial or industrial use of this product. To obtain service under the Limited Warranty, please contact Luxier USA at
[email protected]. The Luxier USA Customer Care Department will determine whether to repair or replace your
product, issue a refund, or issue a credit.

3BSH06S Rev. A 02/2017Luxier USA
Maintenance Guide
Please follow the cleaning material manufacturer’s instructions. Damage caused by improper
treatment will not be covered by product warranty. In addition, pay attention to the following points:
• Regular cleaning can prevent mineral build up on faucet spout.
• Carefully read the cleaner product label to ensure the cleaner is safe for use on the material.
• Test the cleaner on a small area before using on the entire surface.
• Use a mild detergent such as liquid dishwashing soap and warm water for cleaning.
• Donotuseabrasive/harshchemicalwhencleaningthefixtureastheywilldamageanddullthe
finish.
• Whenusingspraycleaners,sprayfirstontoasoftclothorsponge.Neverspraydirectlyontothe
faucet as droplets can enter openings and gaps and cause damage.
• After cleaning, rinse thoroughly with clean water to remove any cleaner residue.
You may also need the following tools
Adjustable Wrench Teon (PTFE) Tape
Plumber’s Putty Screwdriver
Silicone Sealant
Safety Glasses
Attention
• This installation guide is subject to change without notice, please contact us to request the most
updated version of this installation guide.
• This is a general installation guideline, actual installation may vary. Consult a professional if neces-
sary.
• Please read all of these instructions carefully before installing your new faucet.
• Product drawings in this installation guide is for illustration purpose only. Actual product may vary
depends on model.
• Always take extra precautions and wear appropriate safety equipment when installing this prod-
uct.

4BSH06S Rev. A 02/2017Luxier USA
Installation
BC
A.Shutowatersupplyatthevalves.
Remove old faucet and clean the
mounting surface for installation of new
faucet.
D1.ApplyTeon(TPFE)tapeonthe
shutovalves.Threadthetapein
counter-clockwise direction.
F. Remove aerator from the spout and
let the water run for about 1 minute to
clear any debris in the plumbing system.
Attach the aerator.
D2. Use a wrench to tighten the hoses,
please do not overtighten the connec-
tions.
E. Turn on the water supply to check for
leaks at all connections.
B. First place the new faucet through
angeonthemountingsurface.The
faucet hole should be 1 3/8” in diameter
on the mounting surface.
C. Insert the rubber washer, metal
washer, and secure the faucet with the
mounting nut.
D1
Flexible water supply line
D2 E
F
A
01. Plug
02. Setscrew
03. Screw
04. Cap
05. Bonnet
06. Cartridge
07. Body
08. Gasket
09. Aerator
10. Aerator Housing
11. Base
12. O-ring
13. Rubber Gasket
14. Metal Washer
15. Mounting Bolt
16. Locking Nut
17. Water Supply Hoses
18. Cap
19. Setscrew
01
02
03
18 19
04
05
06
07
08
11
12
13
14
15
16
17
09
10
