Luxul X-wav xwk1-24-fp14 User manual

For use with the EOC1650 WAP

X-WAV™ OUTDOOR WI-FI

RANGE EXTENDER ANTENNA KIT

QUICK INSTALL GUIDE

Results may vary depending on building layout, type of construction and other environmental factors

including Wi-Fi trafﬁ c, Microwaves Ovens, Cordless Phones, etc.

FCC NOTICE: The use of all radio equipment is subject to regulations in each country. To comply with FCC part 15

rules in the United States, radio equipment must only be used in systems that have been FCC certiﬁ ed. It is the

responsibility of the user/professional installer/operator to ensure that only approved equipment/systems are

deployed. To ensure FCC part 15 compliance, Luxul ampliﬁ er products should only be installed in certiﬁ ed systems by

licensed professionals.

FCC Certiﬁ cation Support for OEMs: Luxul Wireless offers FCC certiﬁ cation assistance and engineering support for

qualiﬁ ed OEM’s interested in certifying complete ampliﬁ ed WLAN systems. Please contact us for details.

LUXUL WIRELESS | 357 South 670 West, Lindon, UT, 84042

p: 801-822-5450 f: 801-822-5460

www.luxulwireless.com

Congratulations on your purchase of a Luxul Wireless X-WAV™ Outdoor Wi-Fi Range

Extender Antenna Kit. X-WAV kits are simple to install. In just a few short steps, you will

be able to enjoy the beneﬁ ts of a farther reaching, clearer wireless signal.

LUXUL WIRELESS PRODUCTS COVERED BY THIS GUIDE

XWK1-24-FP14 - X-WAV 2.4GHz Outdoor Wi-Fi Range Extender Antenna Kit

TROUBLESHOOTING

Weak or non-existent coverage.

1. Make sure the cables are properly connected and that there is power to the

X-WAV Antenna and the EnGenius EOC1650.

2. Ensure that the X-WAV antenna is properly positioned. The antenna should be facing

the direction of the area to be covered with a minimum of 2 feet (.6 meters) with no

obstructions in front of the antenna. Luxul wireless signals are superior for penetrating

wood, concrete, and stucco, but all wireless signals can be disrupted by certain

obstructions, including large metal objects. Try orienting the antenna where more

line-of-sight access to the desired coverage area is available.

If after checking the above items, your X-WAV™ Outdoor Wi-Fi Range Extender Antenna

Kit still does not seem to be functioning properly, please contact: Luxul Wireless Technical

Support at: support@luxulwireless.com regarding Antenna.

Luxul Wireless products include a Limited One Year Warranty

diagram 3

X-WAV™ KIT QUICK INSTALL GUIDE

THE X-WAV™ OUTDOOR WI-FI RANGE EXTENDER ANTENNA KIT

INCLUDES THE FOLLOWING:

• X-WAV XW-24-FP14 14dBi High Gain 2.4GHz Flat Panel CPAntenna

• 36” Coax cable (N-Male to RP-SMA)

• HDW-AM-UOD outdoor mounting bracket

• Quick Install Guide

GETTING STARTED: ADDITIONAL ITEM REQUIRED

• EnGenius EOC1650 Wireless Access Point (WAP)

Included with the EOC1650: 802.11b/g Long range AP/CB (EOC1650), POE injector (EPE-

1212), Power Adaptor, CD with User’s Manual, Quick Installation Guide(QIG), Metal strap,

Special screwset.

• External Ethernet cable from your data source/network (Max. length 329’ or 100

meters).

NOTE: Disconnect all power before connecting or disconnecting any cables, coax or

antennas to or from this device. Failure to do so will void your warranty.

SETTING UP YOUR X-WAV™ OUTDOOR

WI-FI RANGE EXTENDER ANTENNA KIT

Connecting the EnGenius EOC1650 to the Antenna

(diagram 1)

1. Remove the connector cover on the back of

the EOC1650 to access the antenna switch

labeled INT - EXT

2. Set the switch to EXT to use the External

Antenna port

3. Connect the RP-SMA end of the coax cable

to the external antenna connector on the

top of the EOC1650

4. Connect the N-Male connector of the coax

cable to the antenna.

diagram 1

INT EXT

SET UP YOUR ENGENIUS EOC1650

See the EnGenius EOC1650 Wireless Access Point (WAP) and POE injector (EPE-1212) manual for

set up instructions. Contact EnGenius directly for additional support or warranty information

POSITIONING YOUR X-WAV™ OUTDOOR RANGE EXTENDER KIT

The X-WAV™ Outdoor Wi-Fi Range Extender Antenna Kit features a high gain directional

antenna. Remember to consider the direction of the signal when positioning the X-WAV™

Antenna. The signal extends outward, away from the front of the antenna. Use diagram 2

below for suggestions on positioning your X-WAV™ Outdoor Antenna Kit for maximum Wi-Fi

coverage.

MOUNTING YOUR X-WAV™ OUTDOOR RANGE EXTENDER KIT

The X-WAV™ Outdoor Wi-Fi Range Extender Antenna Kit may be mounted to a pole using

the included HDW-AM-UOD outdoor mounting bracket. See diagram 3 (Next page) for an

example of the antenna mount set up. see the EnGenius EOC1650 Wireless Access Point

(WAP) for mounting instructions.

diagram 2
