LVS CEPS-A Manual

LVS, Inc. 2555 Nicholson Street, San Leandro, CA 94577-4216
Phone: [phone] Fax: [phone]
www.lvscontrols.com
Model CEPS-A
Installation Instructions
& User Manual
500W-6000W
Emergency
Lighting Inverter
U
L
®
UL924 LISTED
EMERGENCY LIGHTING
EQUIPMENT
73PK
IMPORTANT SAFEGUARDS:
When using electrical equipment, basic safety precautions
should always be followed, including the following:
1. Do not install outdoors.
2. Do not install near gas or electric heaters.
3. Mount CEPS-A securely and in locations and at heights where it will not be readily subjected
to tampering by unauthorized personnel.
4. Do not use this equipment for other than its intended use.
5. All installation and servicing of this equpiment must be performed by qualified personnel.
6. The use of accessory equipment not specified or recommended by LVS, Inc. may cause
unsafe conditions and may void the warranty.
7. Use caution when servicing batteries. Battery acid can cause burns to skin and eyes. If acid is
spilled on skin or in the eyes, flush with fresh water and seek medical attention immediately.
8. Make sure all connections are in accordance with NEC and local regulations.
9. Check AC Voltage rating on equipment label. Do not connect to any other voltage.
10. An unswitched AC power source is required (120 VAC or 277 VAC).
11. Do not use this product for other than intended use.
12. To reduce risk of electric shock, disconnect dedicated input breaker and all fuses before servicing.
13. Do not attempt to service sealed components with the exception of standard battery replacements.
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS

2
3 Year Warranty
6 Year Pro-Rata Battery Warranty
LVS Inc., warrants to the original purchaser/user for the published warranty period from the date of shipment that should LVS
instruments or equipment prove defective by reason of improper workmanship or material, LVS will repair or replace the same
equipment without charge. This warranty does not cover defects or malfunctions arising from improper installation, operation or
repair, or neglect, accident or abuse. LVS will honor its warranty provided the equipment has not been physically damaged or
improperly installed or connected. To obtain warranty/repair, the defective product should be shipped freight prepaid within the
warranty period to the address below. To the extent permitted by applicable law, all warranties extending beyond repair or
replacement as described above are disclaimed, including the implied warranties of merchantability and fitness for a particular
purpose. Where applicable law prohibits disclaimers or the implied warranties of merchantability and fitness; those warranties
are limited to 12 months from date of shipment. LVS does provide a 90 day money back guarantee if equipment does not
perform in accordance with LVS published specifications. The liability of LVS and its agents under all warranties is limited to
repair and replacement as described herein, and under no circumstances shall there be liability for any other kind of loss,
damage, or labor, either consequential or for injury to person or property or otherwise.
Batteries are supplied on a pro-rata basis for six years, provided that the product
has been properly installed in the correct surroundings.
TEMPORARY STORAGE INSTRUCTIONS:
For temporary storage of CEPS-A system and batteries prior to installation select a clean, cool, dry location with
normal ventilation suitible for human habitation and level floors. DO NOT store system or batteries in a sealed room
or container. Ensure that floor is cabable of bearing load.
Do not store batteries for more than 60 days without charging. Doing so will cause irreversible damage to battery
cells and void battery warranty. Ensure batteries are stored at temperatures within the following range: 40ºF to 100ºF.
Panel Location
1. Panel should be installed in a ventilated indoor location and not subjected to temperatures above 100 °F
(37.8 °C) nor below 40 °F (4.5 °C) and at an altitude of less than 10,000 feet for optimum performance.
2. When the panel is installed on the wall, the wall must have sufficient strength to support the weight of the
panel. A minimum of 4 screws (#10) should be securely fastened in wood or concrete with plastic
inserts to secure the panel. 500W: 160 lbs (4+ screws recommended)
1000W: 240 lbs (4+ screws recommended)
1500W: 350 lbs (6+ screws recommended)
2000W: 440 lbs (8+ screws recommended)
3. Remove 2 or 3 knockouts from the top of the panel.
4. Install utility input conduit and wire from a dedicated circuit breaker, 120VAC 60 Hz or 277VAC 60 Hz, such
as provided for a fire alarm or security system.
Note: 20A breaker recommended, except for 2000W, 120V system: 25A recommended.
5. Install emergency output conduit and wire to load.
6. When you receive the panel, there may be cardboard or foam protection on front panel to protect test
switch. This should be removed after the panel has been securely mounted.

3
AC Input/Output Wiring Instructions
NOTE: The CEPS-A can be field-wired in 3 distinct modes of operation. See “WIRING MODES” insert
sheet for further details.
#1) (FACTORY DEFAULT) NORMALLY-ON: The emergency lights connected to the CEPS-A will be ON at all
times, during both normal condition and power interruptions. This mode is set by connecting the #1 wire on the
red transfer switch to the utility input hot.
#2) NORMALLY-OFF: The emergency lights connected to the CEPS-A will be OFF until a power interruption, at
which time they will turn ON. This mode is set by capping off the #1 wire on the red transfer switch.
#3) NORMALLY-SWITCHED: The emergency lights connected to the CEPS-A can be switched ON/OFF
normally, until a power interruption, at which time they will turn ON regardless of switch position. This mode is
set by connecting the load side of a switch, time clock, or relay panel to the #1 wire on the red transfer switch.
Please note: Only one switch can be used per inverter. If multiple switches are needed, wire inverter as
NORMALLY-ON, and use LVS EPC relays. With EPC relays an unlimited number of switch legs may be used.
Contact tech support for further details 1-800-982-4587.
The CEPS must be installed by a qualified electrician in accordance with local, state, and NEC codes. AC & DC
Voltages are hazardous and care should be taken to follow all instructions. Prior to wiring AC connections, discon-
nect AC Input feed at relevant branch circuit breaker(s) and verify using proper voltage meter.
Always wear appropriate clothing when handling batteries and equipment, and use insulated tools.
1) Check that all input breakers are disconnected. Trip all output breakers using a flat screwdriver.
2) Check that knockouts on top of panel have been removed and conduits have been installed.
3) Bring AC Input conductors and AC Output Conductors through the appropriate conduits. Per
NEC, emergency output circuit should be installed in a dedicated conduit.
4) Connect AC Input conductors to wires labelled “120VAC Input” or “277VAC Input”
5) Connect AC Output conductors to wires labelled “120VAC Output” or “277VAC Output”
(277V MODELS 1000W & Larger ONLY): Take ACME XFR out of box and mount per instructions. Confirm
that it has been properly configured: X1 should be connected with X3. X2 should be connected with X4.
Connect one of XFR A wires in panel to X1&X3 in transformer (also labeled XFR A).
Connect other XFR A wire in panel to X2&X4 in transformer (also labeled XFR A).
Connect one XFR B wire in panel to H1 wire in transformer (also labeled XFR B).
Connect other XFR B wire in panel to H5 wire in transformer (also labeled XFR B).
NOTE: For 277V systems 1000W & Larger ONLY, the XFR B wire in the transformer which is connected to
the White with Blue Stripe (#4) XFR B wire in panel should be grounded, because it is the neutral output of an
isolation transformer. See transformer grounding instruction sheet provided.
6) Connect grounds for AC Input & AC Output to grounding wires provided. For systems larger than
1000W, NEC requires a grounding electrode conductor be installed from panel to grounding electrode.
7) Refer to battery wiring instructions.
8) Ensure that cabinet is securely fastened to wall and that no wires are loose or disconnected.
9) Ensure all connections & grounding have been made in workman-like & code compliant manner.

4
If output does not match specifications or test is not successful, consult
troubleshooting guide or call 1-800-982-4587 for technical support.
#1) While input breaker is de-energized, close the output breaker(s) mounted on front or side of panel.
#2) Turn rocker switch on blue inverter (located near receptacle) to REMOTE position
(REMOTE is the downward position of the 3 position rocker switch).
#3) Check that red LED on red transfer switch box is illuminated. Green LED should be OFF.
#4) Check that emergency lighting loads are illuminated.
#5) Wait 1 minute and ensure emergency lighting loads are still illuminated.
#6) Energize input breaker and verify that green LED on red transfer switch box is illuminated.
Red LED should turn off after ~1-2 seconds.
#7) Press and hold test button on red transfer switch box. Green LED should turn off and Red LED
and emergency lights should turn on after ~1-2 seconds.
#8) Release test button, green LED should turn on, red LED should turn off.
Allow 96 hours for batteries to fully charge before performing full discharge (90 minutes) test.
Battery Installation
1. Remove batteries from shipping boxes and check for enclosure and terminal damage.
2. Batteries should have labels and jumper wires installed.
CAllaekaM:ETON.srepmujyrettabotetamotsrotcennochtiwdedivorpsissenrahgniriwnuremoH.3
connections prior to battery connections.
5. Follow “BATTERY INSTALLATION” label on inside of panel door for instructions on wiring batteries.
NOTE: All connections should be made between the same colors.
(Black to Black, Red to Red, Yellow to Yellow).
6. Complete the following battery voltage tests after all batteries are installed.
Measure DC voltage between the following terminals (- is left/black terminal, + is right/red terminal):
[ALL MODELS] Battery A (-) to Battery B(+) should measure ±22 V-28V
7. Ensure that all connections have been made in a workman-like manner, and that panel door can close. It
is suggested to keep the removable battery ropes/handles either inside or near the panel, for future use.
Start-Up Instructions
Note: Blue LED function depends on WIRING mode from page 3.
For the purpose of startup test, ignore it.
4. Check all batteries for proper color connectors:
[IMPORTANT]
TYPE “A” Batteries have BLACK jumper on LEFT terminal
YELLOW jumper on RIGHT terminal
TYPE “B” Batteries have YELLOW jumper on LEFT terminal
RED jumper on RIGHT terminal

Transfer Switch
(red box)
#3 (blue)
#4 (white
with blue stripe)
U
L
®
UL924 LISTED
EMERGENCY LIGHTING
EQUIPMENT
73PK
LVS, Inc. 2555 Nicholson Street, San Leandro, CA 94577-4216
Phone: [phone] Fax: [phone]
www.lvscontrols.com
CEPS 277V Output Transformer Grounding
NOTE:
Because the provided output transformer is isolation type, it is recommended to ground the #4 Wire (277V
Neutral) (white wire with blue stripe) on the transfer switch.
ACME
TRANSFORMER
XFR B Leads
XFR B Leads
Ground Stud
black
white
XFR A Leads
XFR A Leads
TS-1000

UTILITY
EMERGENCY
SET
TEST
LOAD
1
56



2
The wiring of the #1 wire on the transfer switch (red plastic box)
normal condition.
#1) (DEFAULT) NORMALLY-ON:
CONNECT #1 TO INPUT HOT
The emergency lights connected to the CEPS-A will be
ON at all times, during normal condition (24/7) and power
interruptions.
#2) NORMALLY-OFF:
CAP OFF #1
The emergency lights connected to the CEPS-A will be
OFF until a power interruption, at which time they will turn
ON.
#3) NORMALLY-SWITCHED:
CONNECT #1 to the load side of your wall switch, time
clock or occupancy sensor. DO NOT connect the light
itself to the switch or sensor or you will damage the invert-
er. The lights should be connected to “120V OUTPUT” or
“277V OUTPUT” Leads.
The emergency lights connected to the CEPS-A can then
be switched ON/OFF normally, until a power interruption,
at which time they will turn ON regardless of switch posi-
tion. Please note: Only one switch leg can be used per
inverter. If multiple switches are needed, wire the legs
inverter as NORMALLY-ON, and use LVS EPC relays.
HOT
INPUT
20A
HotNeutral
NEUTRAL
INPUT
TRANSFERSWITCH


CEPS-A GFCI Troubleshooting
If the GFCI on the blue inverter is tripping, there are two things that can
cause this: a crossed neutral (dangerous) or inrush current (not
dangerous). This simple test will help you to determine which it is.
#1) Get an amp/current meter
#2) Measure the red OUTPUT wire coming out of the inverter. Write
down how many amps________
Measure the white/red stripe OUTPUT wire coming out of the inverter.
Write down how many amps_________
#3) The two amp readings should be equal (within 0.1A preferred). If it
is equal and GFCI still strips, proceed to step #4. If it is not equal, there
is a problem with your output neutral wiring. It needs to be a
dedicated neutral wire going out to your lights and cannot touch the
building neutral anywhere. Usually one of the emergency fixtures in
the field has been incorrectly connected to a normal building neutral
wire. As a result, some of your neutral current is returning to your
building neutral instead of your inverter neutral. This is a code issue
and if the imbalance is large enough it can also damage the inverter.
#4) If the currents are balanced please call tech support at 1-800-982-
4587 and reference this troubleshooting guide, they will assist with
next steps.

Note: The reset switch for the blue inverter is on the back right
side of the inverter. It is a 3 position rocker switch. You can
reach it by reaching around the black cord through the opening
in the metal side bracket and pressing the switch to the
middle(OFF) position, wait 5 seconds, then turn it back down
(ON).
You only need to use the reset when the three LED’s shown in
the left side of the picture are flashing or red. Normally they
should all be green.
If first light and last light are RED, indicates low battery.
Measure DC voltage on battery, it should be between 12.5-
13.8VDC.
RESET
Middle position is OFF
Bottom position is ON
Top position is not used
