LW MEASUREMENTS TREE LDS Series User manual

LDS/SDS Series Weight Scale
Large drum scale/small drum scale
Operation Manual
NOTE: THIS PRODUCT HAS BEEN
CALIBRATED IN THE FACTORY.
PLEASE REFER TO THE MANUAL
BEFORE RE-CALIBRATING
PRODUCT!
Professional Weighing Equipment

2
Table of Contents
Section Page
Declaration of Conformity
Customer Service
Safety
Specifications
Parts Description
Features
Getting Started
Delivery
Program Options
Function Settings
Calibration
Interface
Hold Function
Maintenance & Service
Transportation & Storage
Warranty
Rev.2 01.30.2023
3
4
5
6
6
7
8
8
9
9
10
11
11
12
12
13

Rev.2 01.30.2023 3
Declaration of Conformity
Declaration of conformity for apparatus with CE mark
We hereby declare that the product to which this declaration refers conforms to the
following standards.
Electronic Scale: LDS Series / SDS Series
Signature:
Boon Lim, R & D Manager
Date: 1.21.2016
LW Measurements LLC, 620 Carlson Court, Rohnert Park, CA 94928
Mark applied
EU Directive
Standards
2004/108/EC
EN 61326-1: 2006

Rev.2 01.30.2023 4
Customer Service
USA
LW Measurements LLC,
620 Carlson Court
Rohnert Park, CA 94928
USA
Tel: [phone]
Fax: [phone]
http://lwmeasurements.com
Introduction
What you should know about this Operation Manual:
Tree® Professional Weighing Equipment products are simple to operate.
Nevertheless, you should read through these operating instructions in their entirety, so
that you can make optimum use of the full potential of the weighing scale in your daily
work activities.
These operating instructions contain guidance in the form of pictograms and keyboard
diagrams, which should help in finding the required information:
For the labeling of potential hazards, please refer to the Safety proportion of this
operation manual.

Rev.2 01.30.2023 5
Safety
Representations & Symbols
Note: Important instructions, which involve safety, are highlighted with the appropriate
mark:
Safety recommendations
When using the weighing equipment in surroundings with increased safety
requirements, the corresponding regulations must be observed.
The weighing scale may only be used with the power adapter supplied.
Before connecting the power adapter to the scale, the user must ensure that the
operating voltage stated on the power adapter is compliant with the mains voltage.
If not, please contact Customer Service at the address above.
If the power adapter or its cable is damaged, the weighing scale must immediately be
disconnected from the electricity supply (pull out the power adapter).
If there should be any reason to believe that it is no longer safe to operate the scale, it
should be immediately unplugged from the electricity supply (pull out power adapter)
and secured against inadvertent operation.
In carrying out maintenance work, it is essential to follow the recommendations set out
in maintenance and servicing.
The weighing scale must not be operated in an area subject to explosion risks.
Care must be taken when weighing liquids to ensure that no liquid is spilled into the
inside of the scale or into connections on the rear of the equipment or the power
adapter. If liquid is spilled on the scale, it must immediately be unplugged from the main
electricity supply (pull out power adapter).
The weighing scale may be operated after it has first been inspected by a service
technician.
These operating instructions must be read by each user and should be easily
accessible at the workplace at all times.

Rev.2 01.30.2023 6
Specifications
Model Capacity Division
LDS 2000 lbs. 0.5 lb.
Platter 39.4 x 37 inches
Net/gross weight 121 lb./143 lb.
Package Standard Capacity: 45 x 39 x 5.1 inches
Operating temperature 0-40°C (32-104°F)
Power Source 6xx AA battery or AC/DC
Adapter 9V/400mA
Model Capacity Division
SDS
1000lb. 0.2 lb.
Platter 31 x 32.4 inches
Net/gross weight 110 lb.
Package
Operating temperature 0-40°C (32-104°F)
Power Source
Adapter 9V/400mA
Parts Description
ON/OFF: Turn the scale power on/off.
HOLD: Press this key to store weight value.
UNIT：Select weighing units：kg or lb.
ZERO： (for TARE) Set the display to zero or subtract the weight of container.
PRINT: Press once and send weight information once.
LDS specifications:
SDS specifications:
6xx AA battery or AC/DC
Standard Capacity: 42 x 32.4 x 4.5 inches
RS232 socket
AC Adapter Socket

Rev.2 01.30.2023 7
Features
Display options：5 digital LCD
Power：AC adapter 9V/400mA
Auto back light (optional)
Auto shut off (optional)
Operating Temperature：5～35℃
Operating Humidity：25％～95％RH
Zero Range (0 to 4% of full capacity)
Tare Range (4% to full capacity)
Error Message indication：
Err-O Overload
Err-Z Exceed zero track range when power is on
Err-S Unstable when power is on
Err-C Calibration code is not enough or operation error.
Low battery indication
Two calibration weight units: kg, lb.
Open calibration capacity
Power on zero-setting range: + 10%
Zero range: + 4% of full capacity
Three modes: Normal mode / Setting mode /Internal Auto Calibration mode
RS232 function

Rev.2 01.30.2023 8
The scale is packaged in an environmentally-friendly carton, which provides optimum
protection for the balance during transportation.
We suggest that you keep the original packaging in order to avoid damage if you are
shipping or transporting the scale to a different location. It is also the best way to keep it
in the best conditions if it will not be used for an extended period of time.
In order to avoid damage, please follow the instructions provided below, when
unpacking the scale:
Unpack the scale carefully.
When outside temperatures are very low, the scale should be stored for a couple
hours and kept in its box in a dry room at normal temperature, so that no
condensation settles on the unit when opening the box.
Check the scale immediately after unpacking for any external visual damage. If
there is any damage on scale, contact customer service immediately.
If the scale is not to be used immediately after purchase, it should be stored in a
dry place where fluctuations in temperature are low. (Reference pg.).
Read through these operating instruction, before you work with the unit and pay
attention to the Safety recommendations
Delivery
Inspect delivery for completeness immediately upon unpacking all components.
Checklist for complete delivery
Component delivered present yes / no
Weighing unit body
Weighing pan
Power adapter
Operating manual
Getting Started

Rev.2 01.30.2023 9
Work mode setting of the indicator:
Press and hold [UNIT] key and [HOLD] key, then press [ON/OFF] key to turn on
the scale, the display will show Ani.Sw, press [UNIT] key to enter function setting
menu press [ZERO] key to select ON or OFF ( ON means animal mode, OFF
means normal weighing mode),press [HOLD] key to confirm the selection.
Press [HOLD] key again to enter the next menu, the display will show Ani.Kd, press
[UNIT] key to enter function setting menu, press [ZERO] key to select animal scale
anti-shock range among 50, 100, 200, 400, press [HOLD] key to confirm the
selection.
Press [HOLD] key again to enter the next menu, the display will show Ani.fd, press
[UNIT] key to enter function setting menu, press [ZERO] key to select animal scale
filter range among 0.5, 3, 5, 10, press [HOLD] key to confirm the selection.
Press [HOLD] key again to enter the next menu, the display will show Ani.Ft, press
[UNIT] key to enter function setting menu, press [ZERO] key to select animal scale
filter time among 1,2,3,4, press [HOLD] key to confirm the selection
FUNCTION SETTINGS
Press and hold [HOLD] key then press [ON/OFF] key to turn on the sclae, the
display will show A-ON or A-OFF, press [ZERO] key to select on or off (ON
means auto power off function activate, off means auto power off function
inactivate). Press [UNIT] key, the display will show L-ON or L-OFF, press [ZERO]
key to select on or off (ON means auto backlight function activate, OFF means
auto backlight function inactivate).
Press [UNIT] key, the display will show P-XXX. Press [ZERO] key to select OFF,
key, con and Stb. (OFF means RS232 function inactivate, KEY means that
output the data by pressing [PRINT] key. Con means that output the data
continually. Stb means that output the data when reading is stable)
Press [UNIT] key, the display will show J-ON or J-OFF, press [ZERO] key to
select ON or OFF. (ON means showing zero when turn on the power, OFF
means showing weight placed when turn on the power.)
Program Options

Rev.2 01.30.2023 10
Press [UNIT] key to enter setting full capacity, press [UNIT] key to move the flash
digit to right, press [ZERO] key to increase the flash digit, press [HOLD] key to
confirm the selection.
Press [HOLD] key again to enter the next menu, the display will show CALU=,
press [UNIT] key to select calibration unit kg or lb, press [HOLD] key to confirm
the selection.
Press [HOLD] key again to enter the next menu, the display will show CAL, press
[UNIT] key to enter setting calibration weight ,press [UNIT] key to move the flash
digit to right,
Press [ZERO] key to increase the flash digit, press [HOLD] key to confirm the
selection ( the calibration weight should be more than 2/3 of full capacity). Press
[HOLD] key again to enter the next menu, the display will show DIV,
Press [UNIT] key to select division, press [HOLD] key to confirm the selection.
Press [HOLD] key again to enter the next menu, the display will show ADC,
press [UNIT] key to select 20, press [HOLD] key to confirm the selection..
Press [PRINT] key, the display will show CAL, then AD value, press [UNIT] key
when the stable indicator to be displayed, the display will show flash calibration
weight, place the shown weight on the platform, press [UNIT] key when the
stable indicator to be displayed, the display will show -----, AD value. Turn off the
scale. Now calibration is finished and you can remove the weights.
Turn on the scale, place tested weight to check whether it is correct, if not,
please repeat above steps.
Calibration
Calibration has been done in factory already. Do not recalibrate it unless it is extremely
inaccurate. If you have any problems about calibration, please contact with the dealer
who will provide you professional guidance.
Press and hold [ZERO] key then press [ON/OFF] key, the display will show
CAPU=, press [UNIT] key to select full capacity unit kg or lb.
Press [HOLD] key to confirm the selection. press [HOLD] key again to enter the
next menu, the display will show CAP,

Rev.2 01.30.2023 11
Baud rate： 9600
Data Bit：8
Parity Bit：NONE
Stop Bit：1
Data Format：ASCII
3.Transmission Information Format： 20 Byte ，blank=20H
HOLD FUNCTION
Place the item on the scale platform.
Wait for the stable weights to be displayed.
Press the [HOLD] key. The “.” hold indicator will turn-on.
Remove the item from the scale platform. The item’s weight reading will remain on the
display. Now you can also select unit (i.e. to Pounds or Kilograms) by pressing [UNIT]
key.
Remove the item from the scale platform. The item’s weight reading will remain on the
display. Now you can also select unit (i.e. to Pounds or Kilograms) by pressing [UNIT]
key.
Interface
1：battery socket：
AC/DC 9V―――――― external positive, inner negative
2：RS232 interface：DB9
RS232 TRANSMIT FUNCTION
1. RS232 interface：DB9
SCALE PC
TXD 3 2 RXD
GND 5 5 GND
2.RS232 Transmission Agreement
Mode Simplex Asynchronous Serial

Rev.2 01.30.2023 12
Maintenance & Service
For maintenance-work, the balance must be disconnected from the power supply
(remove power adapter plug from socket). Also ensure that the balance cannot be
connected to the power supply during the work by a third party.
Make sure that no liquid spills into the scale while performing maintenance work. If
liquid is spilled on the scale, it must be inspected by a service technician.
Regularly perform maintenance to the weighing pan and the weighing pan holder by
removing any dirt or dust from under the weighing pan and on the weighing scale
housing. Use a soft brush or a soft, lint-free cloth, moistened with a mild soap solution.
Never use solvents, acids, alkalis, paint thinners, scouring powders or other aggressive
or corrosive chemicals for cleaning; these substances can cause damage to the
surfaces of the scale housing.
Transportation & Storage
Your weighing machine is a precision instrument, treat it carefully. Avoid shaking,
severe impacts and vibration during the transportation. Make sure that there are no
marked temperature fluctuations during the transportation and that the weighing
machine does not become damp (condensation).
If you would like to take the weighing machine out of service for an extended period,
disconnect it from the electricity supply, clean it thoroughly (refer to Maintenance &
Service) and store it in a place which meets the following conditions:
No violent shaking, no vibrations
Minimum temperature fluctuations
No direct solar radiation
Minimum moisture

Rev.2 01.30.2023 13
Warranty
LW Measurements products are under warranty against factory defects for a period of
two (2) years from the date of shipment for Customers in the continental United States.
LW Measurements will pay for freight both ways within the first 30 days of purchase if
technical support is required. (Determined by our certified Technical Support Team) In
the event technical support is needed the customer is responsible for shipping the
product back to us after the 30 day period has expired. Once the product is received,
the technical support team will inspect and as necessary repair or replace the scale. LW
Measurements will ship the product back to the customer at our expense.
Any new scales returned for warranty must be properly packaged in the original box. If
they are not properly packed in the original box, the customer is responsible for the
shipping cost. If we determine there is a factory defect, we will provide a replacement
and accept responsibility for shipping back to customer. If we determine that it is not a
factory defect, the customer will be responsible for shipping fees incurred.
For Customers outside the lower 48 States, including Mexico, Canada, Puerto Rico,
Hawaii, Alaska and all other countries are responsible for all shipping fees incurred.
Our warranty does not cover misuse or neglect including but not limited to battery or
water damage, overloading, and chewed or cut wires, keypad damage (punctures),
scratched platforms, dented platforms unless caused by shipping (Must report/return
within 30 days). If the product is found to have been misused or damaged by the
customer, LW measurements is not responsible for the cost of return.
For warranty claims please call your customer service representative.
