Lyon Workspace 8000 Series User manual

UPRIGHT
HEIGHT
84"
96"
120"
NUMBER
OF NUTS & BOLTS
16
18
22
Contact us direct for fast friendly service [phone]
SHEET 1 OF 2
BOLT SIDE SHEETS TO OFFSET ANGLE POSTS
ASSEMBLE SHELF CLIPS TO POSTS
ASSEMBLE TOP AND BOTTOM
SHELVES TO FRAME UNIT.
AS SHOWN. USE NUTS AND BOLTS AT TOP
AND BOTTOM AND MINIMUM OF 12"
SPACING IN BETWEEN.
(SEE CHART BELOW FOR QUANTITY
OF NUTS AND BOLTS REQUIRED)
CLIPS CAN ONLY ASSEMBLE TO INSIDE OF ANGLE
SEE #9306-DA INSTRUCTIONS FOR
ASSEMBLY OF SPLIT BACK

IMPORTANT NOTE:
AFTER A ROW OF
SHELVING HAS BEEN
ASSEMBLED AND
ACCURATELY LOCATED,
CAREFULLY LEVEL AND
PLUMB THE UNITS AS
REQUIRED. DO THIS BY
PLACING ONE OR MORE
FLOOR PLATES/SHIMS
UNDER EACH UPRIGHT
POST WHERE REQUIRED.
Contact us direct for fast friendly service [phone]
SHEET 2 OF 2
ANCHOR POSTS TO FLOOR
LEVEL AND PLUM
FILL IN REMAINDER OF SHELVES IN SECTION
