M-Audio code25 User manual

User Guide
English
Manual Version 1.0

2
Table of Contents
Introduction.................................................................................................................................9
Box Contents.........................................................................................................................9
Support ..................................................................................................................................9
Quick Start /Connection Diagram............................................................................................9
Features ....................................................................................................................................10
Code 25 ................................................................................................................................10
Top Panel ........................................................................................................................10
Rear Panel .......................................................................................................................14
Code 49 ................................................................................................................................15
Top Panel ........................................................................................................................15
Rear Panel .......................................................................................................................19
Code 61 ................................................................................................................................20
Top Panel ........................................................................................................................20
Rear Panel .......................................................................................................................24
Operation ..................................................................................................................................25
Basic Concepts ...................................................................................................................25
Presets.............................................................................................................................25
Control Modes.................................................................................................................26
Using the Bank Buttons ..............................................................................................27
Edit Mode ........................................................................................................................28
Overview of Control Assignments................................................................................28
Editing Controls...........................................................................................................28

3
Zones...............................................................................................................................30
Assigning Keys to a Zone ............................................................................................30
Zone Channel..............................................................................................................31
Zone Octave and Transposition...................................................................................32
Zone Program Change ................................................................................................33
Zone Bank Change .....................................................................................................34
Channels..........................................................................................................................35
Control Channel ..........................................................................................................35
Zone Channel..............................................................................................................36
Global Channel............................................................................................................36
Keyboard..............................................................................................................................37
Commands ......................................................................................................................37
Ctrl Assign...................................................................................................................37
Zone Chan ..................................................................................................................37
Chan Assign................................................................................................................38
Prog............................................................................................................................38
Snap Shot ...................................................................................................................38
Bank LSB / Bank MSB................................................................................................38
Memory Dump ............................................................................................................39
Data 1 .........................................................................................................................39
Data 2 .........................................................................................................................39
Data 3 / +/–.................................................................................................................39
MIDI Out / Color ..........................................................................................................39
Store ...........................................................................................................................40
Curve / Mackie®/HUI®..................................................................................................40
Numeric Keys (0–9) .....................................................................................................40
Enter ...........................................................................................................................40
Editing Assignments........................................................................................................41
Channel.......................................................................................................................41
Curve ..........................................................................................................................41
Octaves and Transposition..............................................................................................42

4
Faders ..................................................................................................................................43
Editing Assignments........................................................................................................43
Channel.......................................................................................................................43
Messages....................................................................................................................44
MIDI CCs.................................................................................................................44
Relative Messages...................................................................................................45
Modes..............................................................................................................................46
MIDI Mode ..................................................................................................................46
Mackie Control/HUI Mode ...........................................................................................46
Buttons.................................................................................................................................47
Editing Assignments........................................................................................................47
Channel.......................................................................................................................47
Messages....................................................................................................................48
MIDI CCs.................................................................................................................48
MIDI CC Value Increment/Decrement ......................................................................49
MIDI CC Value Cycle................................................................................................50
Program, Bank LSB, and Bank MSB .......................................................................51
Program Increment/Decrement................................................................................52
Program Cycle.........................................................................................................53
MIDI Notes ..............................................................................................................54
MMC (MIDI Machine Control)...................................................................................55
Keystrokes...............................................................................................................56
Latching ......................................................................................................................57
Colors .........................................................................................................................58
Modes..............................................................................................................................59
MIDI Mode ..................................................................................................................59
Mackie Control/HUI Mode ...........................................................................................59
HID Mode....................................................................................................................59

5
Encoders..............................................................................................................................60
Editing Assignments........................................................................................................60
Channel.......................................................................................................................60
Messages....................................................................................................................61
MIDI CCs.................................................................................................................61
Relative Messages...................................................................................................62
Curve ..........................................................................................................................63
Modes..............................................................................................................................64
MIDI Mode ..................................................................................................................64
Mackie Control/HUI Mode ...........................................................................................64
X-Y Pad ................................................................................................................................65
Editing Assignments........................................................................................................65
Channel.......................................................................................................................65
Messages....................................................................................................................66
MIDI CCs.................................................................................................................66
Relative Messages...................................................................................................67
MIDI Notes ..............................................................................................................68
Curve ..........................................................................................................................69
Modes..............................................................................................................................70
MIDI Mode ..................................................................................................................70
MIDI Note Mode..........................................................................................................70
HID Mode....................................................................................................................70

6
Pads......................................................................................................................................71
Editing Assignments........................................................................................................71
Channel.......................................................................................................................71
Messages....................................................................................................................72
MIDI Notes ..............................................................................................................72
MIDI CCs.................................................................................................................73
MIDI CC Value Increment/Decrement ......................................................................74
MIDI CC Value Cycle................................................................................................75
Program, Bank LSB, and Bank MSB .......................................................................76
Program Increment/Decrement................................................................................77
Program Cycle.........................................................................................................78
MMC (MIDI Machine Control)...................................................................................79
Latching ......................................................................................................................80
Curve ..........................................................................................................................81
Colors .........................................................................................................................82
Octaves and Transposition..............................................................................................83
Wheels..................................................................................................................................84
Editing Assignments........................................................................................................84
Channel.......................................................................................................................84
Messages....................................................................................................................85
MIDI CCs.................................................................................................................85
Sustain Pedal.......................................................................................................................86
Editing Assignments........................................................................................................86
Channel.......................................................................................................................86
Messages....................................................................................................................87
MIDI CCs.................................................................................................................87
MIDI Notes ..............................................................................................................88
MIDI CC Value Increment/Decrement ......................................................................89
Program, Bank LSB, and Bank MSB .......................................................................90
Program Increment/Decrement................................................................................91
MMC (MIDI Machine Control)...................................................................................92
Latching ......................................................................................................................93

7
Volume Pedal.......................................................................................................................94
Editing Assignments........................................................................................................94
Channel.......................................................................................................................94
Messages....................................................................................................................95
MIDI CCs.................................................................................................................95
Mackie Control®and HUI®..................................................................................................96
Using Mackie Control ......................................................................................................96
Using HUI ........................................................................................................................97
MIDI Out...............................................................................................................................98
MIDI Panic ...........................................................................................................................98
Program Changes ...............................................................................................................99
Zone Program Change ....................................................................................................99
Bank Changes ...................................................................................................................100
Zone Bank Change........................................................................................................100
Presets and Memory.........................................................................................................101
Selecting Presets...........................................................................................................101
Storing Presets ..............................................................................................................101
Sending and Restoring SysEx Memory.........................................................................102
Restoring Default Settings.............................................................................................102
Appendix .................................................................................................................................103
Parameter Numbers .........................................................................................................103
Faders, Encoders, X-Y Pad, Wheels, and Volume Pedal..............................................103
Registered Parameter Numbers (RPNs) (000–127) ....................................................103
Non-Registered Parameter Numbers (NRPNs) (128–144)..........................................104
Buttons, Pads, and Sustain Pedal.................................................................................105
Registered Parameter Numbers (RPNs) (000–127) ....................................................105
Non-Registered Parameter Numbers (NRPNs) (128–156)..........................................106

8
Presets ...............................................................................................................................107
Colors.................................................................................................................................108
Buttons ..........................................................................................................................108
Pads...............................................................................................................................108
Velocity Curves .................................................................................................................109
Keyboard (VCrV) ............................................................................................................109
Pads (PCrV) ...................................................................................................................109
Encoders (ECrV) ............................................................................................................110
X-Y Pad (TCrV) ..............................................................................................................110
Technical Specifications ..................................................................................................111
Code 25 .........................................................................................................................111
Code 49 .........................................................................................................................112
Code 61 .........................................................................................................................113
Trademarks and Licenses................................................................................................114

9
Introduction
Box Contents
Code Series Keyboard Quickstart Guide
USB Cable User Guide
(download)
Software Download Cards Safety & Warranty Manual
Support
For the latest information about this product (system requirements, compatibility information,
etc.) and product registration, visit m-audio.com.
For additional product support, visit m-audio.com/support.
Quick Start /Connection Diagram
Remember to select Code 25, Code 49, or Code 61 as the controller in the Preferences,
Device Setup, or Options of your digital audio workstation (DAW).
Items not listed in Introduction > Box Contents are sold separately.
MIDI
PIANO
ORGAN
GUITAR/BASS
BRASS/ORCH
SYNTH/PAD
RHYTHM
SPECIAL FX
PATCH
PERFORM
RHYTHM
GM
External MIDI Sound Module
(optional)
Sustain Pedal
(optional)
Computer
Power
(optional)
Expression Pedal
(optional)
External MIDI Sequencer
(optional)

10
Features
Code 25
Top Panel
1
46
23
5
Important: For more complete explanations of how to use all of these controls, please see the
Operation chapter.
1. Keyboard: This 25-note keyboard is velocity-sensitive with aftertouch and, in conjunction
with the Key Octave –/+buttons, can access the full range of 127 available MIDI notes (10
octaves).
2. Pitch-Bend Wheel: Move this wheel to send MIDI pitch bend information.
You can also change this wheel’s MIDI assignment. See Operation > Wheels > Editing
Assigments to learn how to do this.
3. Modulation Wheel: Move this wheel to send continuous controller data—MIDI CC #01
(modulation), by default.
You can also change this wheel’s MIDI assignment. See Operation > Wheels > Editing
Assigments to learn how to do this.
4. Key Octave –/+: Press one of these buttons to move the keyboard up or down an octave.
Press and hold Transpose and press one of the buttons to move the keyboard down or
up a semitone.
5. Pads: Use these pads to trigger drum hits or other samples in your software or external MIDI
sound module. The pads are velocity-sensitive, which makes them very responsive and
intuitive to play.
You can also change these pads’ MIDI assignments. See Operation > Pads > Editing
Assigments to learn how to do this.
6. Pad Octave –/+: Press one of these buttons to move the pads up or down an octave.
Press and hold Transpose and press one of the buttons to move the pads down or up a
semitone.

11
7
8
11
10 13
12
9
7. Faders (F1–F5):Use these faders to send MIDI CC or Mackie Control®/HUI®messages to your
software or external MIDI device. Use the Fader Mode button to change their current mode.
You can also change these faders’ MIDI assignments. See Operation > Faders > Editing
Assigments to learn how to do this.
8. Fader Mode: Press this button to switch the Faders (F1–F5) between their two modes,
distinguishable by this button’s color:
Red: MIDI Mode (the default)
Green: Mackie Control®/HUI®Mode
Learn more about these modes in Operation > Faders > Modes.
9. Buttons (B1–B5):Use these buttons to send MIDI CC, Mackie Contro/HUI, or HID
messages to your software or external MIDI device. They can function as momentary or
toggle (latching) buttons. Use the Button Mode button to change their current mode.
You can also change these buttons’ MIDI assignments. See Operation > Buttons >
Editing Assigments to learn how to do this.
10. Button Mode: Press this button to cycle the Buttons (B1–B5) through their three modes,
distinguishable by this button’s color:
Red: MIDI Mode (the default)
Green: Mackie Control/HUI Mode
Yellow: HID Mode
Learn more about these modes in Operation > Buttons > Modes.
11. Bank Right/Left: Press one of these buttons to move to the next or previous bank of
assignable controls (Faders, Buttons, and Encoders). This will affect only the assignable
controls that are in the same mode as the Bank Right/Left buttons, distinguishable by this
button’s color:
Red: MIDI Mode
Green: Mackie Control/HUI Mode
Yellow: HID Mode
White: Global (the default; this affects all assignable controls regardless of their current
modes)
Learn more about these modes in Operation > Basic Concepts > Control Modes >
Using the Bank Buttons.
12. Encoders (E1–E4):Use these 360º knobs to send MIDI CC or Mackie Contro/HUI
messages to your software or external MIDI device. You can also change these encoders’
MIDI assignments.
You can also change these encoders’ MIDI assignments. See Operation > Encoders >
Editing Assigments to learn how to do this.
13. Encoder Mode: Press this button to switch the Encoders (E1–E4) between their two
modes, distinguishable by this button’s color:
Red: MIDI Mode (the default)
Green: Mackie Control/HUI Mode
Learn more about these modes in Operation > Encoders > Modes.

12
15
16 17 18 19
20
14
21
14. Transport Controls: These six buttons are dedicated buttons for sending conventional
Mackie Control/HUI transport control commands: Rewind (), Fast-Forward (), Stop
(), Play (), and Record ().
15. Display: Use this screen to view parameter values, settings, and messages relevant to
Code 25’s current operation. The various messages shown here are described throughout
this User Guide.
16. Preset Down/Up ():Use these buttons to move to the previous or next preset.
You can also use these buttons to cycle through the editable parameters shown in the
display, set the global MIDI channel, or set the MIDI channel of a zone of the keyboard.
17. Shift: Press and hold this button to access the secondary functions of certain buttons and
keys. Press this button in Zone Edit Mode to access additional zone editing functions.
18. Channel: Press this button to enter or exit Channel Mode. In Channel Mode, use the
Preset Down/Up () buttons to change Code 25’s global MIDI channel. See Operation
> Basic Concepts > Channels > Global Channel to learn more about this mode.
19. Edit: Press this button to enter or exit Edit Mode. In Edit Mode:
•Use the Preset Down/Up () buttons to change the value or setting of the
parameter shown in the display.
•Use the keyboard’s keys to access additional functions or commands (printed above
the keys).
Learn more about this mode in Operation > Basic Concepts > Edit Mode.
20. Zone, 1–4: Press the Zone button to enter Zone Mode, which lets you use 4 different
overlapping or non-overlapping ranges of keys on different MIDI channels. This is useful
for sending notes to 4 virtual instruments or 4 external synthesizers from the same
keyboard, for example.
Press any of the 1–4buttons simultaneously or separately (when the Zone Button is
active/lit) to activate or deactivate those zones of the keyboard. When a zone is active, its
corresponding button will be lit.
Press and hold the Zone Button for 1 second to enter or exit Zone Edit Mode. You can
press any of the flashing 1–4buttons to edit that zone.
Learn more about zones in Operation > Basic Concepts > Zones.
21. Transpose: Press and hold this button and press one of the Pad Octave –/+or Key
Octave –/+buttons to move the pads or keys (respectively) down or up a semitone.

13
22
24
23
24
23
22. X/Y Pad: This touch-sensitive pad lets you control two parameters simultaneously in a
two-dimensional way (rather than a traditional one-dimensional modulation wheel). You
can assign the parameter and range of each axis, X(horizontal) and Y(vertical). This pad
can be in one of three modes as determined by the X-Mode and Y-Mode buttons.
You can also change each axis’s MIDI assignment. See Operation > X-Y Pad > Editing
Assigments to learn how to do this.
23. X/Y Buttons: Press one of these buttons to send the maximum value for the parameter
assigned to that axis.
In Edit Mode, press one of these buttons when assigning a parameter to assign it to that
axis: X(horizontal) or Y(vertical).
In HID Mode, use the Xor Ybutton as a left-click or right-click mouse command
(respectively).
24. X-Mode /Y-Mode: Press one of these buttons to cycle through the available modes for
that axis of the X/Y Pad, distinguishable by the button’s color:
Red: MIDI CC Mode (the axis is assigned to a MIDI CC number)
Pink: In MIDI Note Mode (the axis is assigned a range of MIDI notes)
Yellow: HID Mode (the axis lets you use the X/Y Pad as a mouse/track pad)
Learn more about these modes in Operation > X-Y Pad > Modes.

14
Rear Panel
1
2
34
5
678
1. Power Input: If you do not want to use a computer in your setup (i.e., if you are using
Code 25 to control an external MIDI module), connect Code 25’s power input to a power
outlet using an optional power adapter (9 VDC, 1 A, center-positive, sold separately).
Alternatively, you can connect Code 25’s USB Port to a power outlet using a standard
USB charger (sold separately).
2. Power Switch: Press this button to power Code 25 on. Press and hold this button for 1
second and then release it to power Code 25 off.
3. USB Port: Use a standard USB cable to connect this USB port to your computer. The
computer’s USB port provides ample power to Code 25. This connection is also used to
send and receive MIDI data to and from your computer.
This connection is also relevant to Code 25’s MIDI Out and MIDI In:
•If an external device is connected to the MIDI Out, your computer can send MIDI
messages out along this path: computer Code 25 external device.
•If an external device is connected to the MIDI In, the external device sends MIDI
messages in along this path: external device Code 25 computer. MIDI
messages can then be sent to an external device via the MIDI Out, but it must pass
through the computer first.
4. Sustain In: Connect an optional 1/4” (6.35 mm) TS sustain pedal to this input.
You can also change this input’s MIDI assignment. See Operation > Sustain Pedal >
Editing Assigments to learn how to do this.
5. Volume In: Connect an optional 1/4” (6.35 mm) TRS expression pedal to this input.
You can also change this input’s MIDI assignment. See Operation > Volume Pedal >
Editing Assigments to learn how to do this.
6. MIDI In: Use a standard five-pin MIDI cable to connect this MIDI In to the MIDI Out of an
external MIDI device (e.g., another MIDI controller). The MIDI messages sent to this MIDI In
will be sent to your computer via the USB port.
7. MIDI Out: Use a standard five-pin MIDI cable to connect this MIDI Out to the MIDI In of an
external MIDI device (e.g., a synthesizer, sequencer, drum machine, etc.).
8. Kensington®Lock Slot: You can use this slot to secure your Code 25 to a table or other
surface.

15
Code 49
Top Panel
F6 F7 F8 F9
1
23
46
5
Important: For more complete explanations of how to use all of these controls, please see the
Operation chapter.
1. Keyboard: This 49-note keyboard is velocity-sensitive with aftertouch and, in conjunction
with the Key Octave –/+buttons, can access the full range of 127 available MIDI notes (10
octaves).
2. Pitch-Bend Wheel: Move this wheel to send MIDI pitch bend information.
You can also change this wheel’s MIDI assignment. See Operation > Wheels > Editing
Assigments to learn how to do this.
3. Modulation Wheel: Move this wheel to send continuous controller data—MIDI CC 01
(modulation), by default.
You can also change this wheel’s MIDI assignment. See Operation > Wheels > Editing
Assigments to learn how to do this.
4. Key Octave –/+: Press one of these buttons to move the keyboard up or down an octave.
Press and hold Transpose and press one of the buttons to move the keyboard down or
up a semitone.
5. Pads: Use these pads to trigger drum hits or other samples in your software or external
MIDI sound module. The pads are velocity-sensitive, which makes them very responsive
and intuitive to play.
You can also change these pads’ MIDI assignments. See Operation > Pads > Editing
Assigments to learn how to do this.
6. Pad Octave –/+: Press one of these buttons to move the pads up or down an octave.
Press and hold Transpose and press one of the buttons to move the pads down or up a
semitone.

16
F6 F7 F8 F9
7
9
8
10
11
12
13
7. Faders (F1–F9):Use these faders to send MIDI CC or Mackie Control®/HUI®messages to your
software or external MIDI device. Use the Fader Mode button to change their current mode.
You can also change these faders’ MIDI assignments. See Operation > Faders > Editing
Assigments to learn how to do this.
8. Fader Mode: Press this button to switch the Faders (F1–F9) between their two modes,
distinguishable by this button’s color:
Red: MIDI Mode (the default)
Green: Mackie Control®/HUI®Mode.
Learn more about these modes in Operation > Faders > Modes.
9. Buttons (B1–B9):Use these buttons to send MIDI CC, Mackie Control/HUI, or HID
messages to your software or external MIDI device. They can function as momentary or
toggle (latching) buttons. Use the Button Mode button to change their current mode.
You can also change these buttons’ MIDI assignments. Please see Operation > Buttons
> Editing Assigments to learn how to do this.
10. Button Mode: Press this button to cycle the Buttons (B1–B9) through their three modes,
distinguishable by this button’s color:
Red: MIDI Mode (the default)
Green: Mackie Control/HUI Mode
Yellow: HID Mode
Learn more about these modes in Operation > Buttons > Modes.
11. Bank Right/Left ():Press one of these buttons to move to the next or previous bank of
assignable controls (Faders, Buttons, and Encoders). This will affect only the assignable
controls that are in the same mode as the Bank Right/Left () buttons, distinguishable
by this button’s color:
Red: MIDI Mode
Green: Mackie Control/HUI Mode
Yellow: HID Mode
White: Global (the default; this affects all assignable controls regardless of their current
modes)
Learn more about these modes in Operation > Basic Concepts > Control Modes >
Using the Bank Buttons.
12. Encoders (E1–E8):Use these 360º knobs to send MIDI CC or Mackie Control/HUI
messages to your software or external MIDI device. You can also change these encoders’
MIDI assignments. Please see Operation > Encoders > Editing Assigments to learn how
to do this.
13. Encoder Mode: Press this button to switch the Encoders (E1–E8) between their two
modes, distinguishable by this button’s color:
Red: MIDI Mode (the default)
Green: Mackie Control/HUI Mode
Learn more about these modes in Operation > Encoders > Modes.

17
15
16 17 18 19
20
14
21
14. Transport Controls: These six buttons are dedicated buttons for sending conventional
Mackie Control/HUI transport control commands: Rewind (), Fast-Forward (), Stop
(), Play (), and Record ().
15. Display: Use this screen to view parameter values, settings, and messages relevant to
Code 49’s current operation. The various messages shown here are described throughout
this User Guide.
16. Preset Down/Up ():Use these buttons to move to the previous or next preset.
You can also use these buttons to cycle through the editable parameters shown in the
display, set the global MIDI channel, or set the MIDI channel of a zone of the keyboard.
17. Shift: Press and hold this button to access the secondary functions of certain buttons and
keys. Press this button in Zone Edit Mode to access additional zone editing functions.
18. Channel: Press this button to enter or exit Channel Mode. In Channel Mode, use the
Preset Down/Up () buttons to change Code 49’s global MIDI channel. See Operation
> Basic Concepts > Channels > Global Channel to learn more about this mode.
19. Edit: Press this button to enter or exit Edit Mode. In Edit Mode:
•Use the Preset Down/Up () buttons to change the value or setting of the
parameter shown in the display.
•Use the keyboard’s keys to access additional functions or commands (printed above
the keys).
Learn more about this mode in Operation > Basic Concepts > Edit Mode.
20. Zone, 1–4: Press the Zone button to enter Zone Mode, which lets you use 4 different
overlapping or non-overlapping ranges of keys on different MIDI channels. This is useful
for sending notes to 4 virtual instruments or 4 external synthesizers from the same
keyboard, for example.
Press any of the 1–4buttons simultaneously or separately (when the Zone Button is
active/lit) to activate or deactivate those zones of the keyboard. When a zone is active, its
corresponding button will be lit.
Press and hold the Zone Button for 1 second to enter or exit Zone Edit Mode. You can
press any of the flashing 1–4buttons to edit that zone.
Learn more about zones in Operation > Basic Concepts > Zones.
21. Transpose: Press and hold this button and press one of the Pad Octave –/+or Key
Octave –/+buttons to move the pads or keys (respectively) down or up a semitone.
Press and hold Shift and press this button to send a “MIDI Panic” message. This means
all MIDI notes will stop and all controls will stop sending their messages.

18
22
24
23
24
23
22. X-Y Pad: This touch-sensitive pad lets you control two parameters simultaneously in a
two-dimensional way (rather than a traditional one-dimensional modulation wheel). You
can assign the parameter and range of each axis, X(horizontal) and Y(vertical). This pad
can be in one of three modes as determined by the X-Mode and Y-Mode buttons.
You can also change each axis’s MIDI assignment. See Operation > X-Y Pad > Editing
Assigments to learn how to do this.
23. X-Y Buttons: Press one of these buttons to send the maximum value for the parameter
assigned to that axis.
In Edit Mode, press one of these buttons when assigning a parameter to assign it to that
axis: X(horizontal) or Y(vertical).
In HID Mode, use the Xor Ybutton as a left-click or right-click mouse command
(respectively).
24. X-Mode /Y-Mode: Press one of these buttons to cycle through the available modes for
that axis of the X-Y pad, distinguishable by the button’s color:
Red: MIDI CC Mode (the axis is assigned to a MIDI CC number)
Pink: In MIDI Note Mode (the axis is assigned a range of MIDI notes)
Yellow: HID Mode (the axis lets you use the X-Y pad as a mouse/trackpad)
Learn more about these modes in Operation > X-Y Pad > Modes.

19
Rear Panel
1
2
34
5
678
1. Power Input: If you do not want to use a computer in your setup (i.e., if you are using
Code 49 to control an external MIDI module), connect Code 49’s power input to a power
outlet using an optional power adapter (9 VDC, 1 A, center-positive, sold separately).
Alternatively, you can connect Code 49’s USB Port to a power outlet using a standard
USB charger (sold separately).
2. Power Switch: Press this button to power Code 49 on. Press and hold this button for 1
second and then release it to power Code 49 off.
3. USB Port: Use a standard USB cable to connect this USB port to your computer. The
computer’s USB port provides ample power to Code 49. This connection is also used to
send and receive MIDI data to and from your computer.
This connection is also relevant to Code 49’s MIDI Out and MIDI In:
•If an external device is connected to the MIDI Out, your computer can send MIDI
messages out along this path: computer Code 49 external device.
•If an external device is connected to the MIDI In, the external device sends MIDI
messages in along this path: external device Code 49 computer. MIDI
messages can then be sent to an external device via the MIDI Out, but it must pass
through the computer first.
4. Sustain In: Connect an optional 1/4” (6.35 mm) TS sustain pedal to this input.
You can also change this input’s MIDI assignment. See Operation > Sustain Pedal >
Editing Assigments to learn how to do this.
5. Volume In: Connect an optional 1/4” (6.35 mm) TRS expression pedal to this input.
You can also change this input’s MIDI assignment. See Operation > Volume Pedal >
Editing Assigments to learn how to do this.
6. MIDI In: Use a standard five-pin MIDI cable to connect this MIDI In to the MIDI Out of an
external MIDI device (e.g., another MIDI controller). The MIDI messages sent to this MIDI In
will be sent to your computer via the USB port.
7. MIDI Out: Use a standard five-pin MIDI cable to connect this MIDI Out to the MIDI In of an
external MIDI device (e.g., a synthesizer, sequencer, drum machine, etc.).
8. Kensington®Lock Slot: You can use this slot to secure your Code 49 to a table or other
surface.

20
Code 61
Top Panel
F6 F7 F8 F9
1
23
46
5
Important: For more complete explanations of how to use all of these controls, please see the
Operation chapter.
1. Keyboard: This 61-note keyboard is velocity-sensitive with aftertouch and, in conjunction
with the Key Octave –/+buttons, can access the full range of 127 available MIDI notes (10
octaves).
2. Pitch-Bend Wheel: Move this wheel to send MIDI pitch bend information.
You can also change this wheel’s MIDI assignment. See Operation > Wheels > Editing
Assigments to learn how to do this.
3. Modulation Wheel: Move this wheel to send continuous controller data—MIDI CC 01
(modulation), by default.
You can also change this wheel’s MIDI assignment. See Operation > Wheels > Editing
Assigments to learn how to do this.
4. Key Octave –/+: Press one of these buttons to move the keyboard up or down an octave.
Press and hold Transpose and press one of the buttons to move the keyboard down or
up a semitone.
5. Pads: Use these pads to trigger drum hits or other samples in your software or external
MIDI sound module. The pads are velocity-sensitive, which makes them very responsive
and intuitive to play.
You can also change these pads’ MIDI assignments. See Operation > Pads > Editing
Assigments to learn how to do this.
6. Pad Octave –/+: Press one of these buttons to move the pads up or down an octave.
Press and hold Transpose and press one of the buttons to move the pads down or up a
semitone.
