CONTENT
I. SAFETY GUIDELINES
II. FEATURES
III. TECHNICAL NAME OF COMPONENTS
IV. INSTALLATION AND OPERATING INSTRUCTION
V. CLEAN AND MAINTAINANCE
VI. MAINTAINANCE GUIDENCE
VII. SPECIFICATION
Security warnings:
This equipment can not be used by children or people with impaired mental facules if it is
not under supervision or who have been instructed in the use of the equipment in a safe
way and understand the dangers in which it can derive a bad use of it. Children should not
play with the equipment. Cleaning and maintenance of the equipment should not be
carried out by children without supervision.
If the power cord is damaged, it can only be replaced by the technical service.
For cleaning or maintenance, the equipment must be disconnected from the electrical
network.
11
13
14
15
18
18
18
MCONFORT V360

11
I. SAFETY GUIDELINES
1. It should be under supervision when the appliance is used by children aged from 8 years
or above, or the persons with reduced physical, sensory or mental capabilies or lack of
experience and knowledge, and make sure their safety and are well acknowledged with the
potenal danger.
2. The product is not suitable for people with reduced physical, sensory or mental
capabilies or lack of experience and knowledge, unless they are under prevision.
3. Children shall not play with the appliance. Children should be guarded when cleaning
and maintaining the product.
Read the instrucons carefully since they give important indicaons concerning safety
during using. In the case of the contents of the familiar icon below to read the product
manual.
- ICON
Warnings Indicate thet may cause injury or death to
people or damage people´s property
Prohibited Indicate that absolutely prohibited
Enforcement Indicate that to perform the mandatory
content
Disassembly
prohibited
Electric
risk
Indicate that disassembly prohibited
Indicaon for electric shock
Do not
touch Indicate that touch prohibited
!
!
DO NOT disassemble
Electric risk
Do not touch

12
- In the event of appliance falling to operate, all repairs
must be undertaken by service center.
- Disassemble, reform will affect product safety.
- Do not touch the power cord with wet hands.
- There is a potenal risk of electrocuon.
DO NOT disassemble Electric risk Do not touch
- Do the scks and other objects into the inlet and
outlet will lead to leakage, short circuit and possible
damage to the product.
- Do not spray pescides or flammable liquids around
the equipment.
- It can cause damage or a short circuit.
Electric riskProhibited Prohibited
- Avoid direcng air flow directly to children for
prolonged periods.
- It can affect the child's health.
- When unplugging the power cord, do not pull on the
cord.
- Will cause the power cord is damaged, leakage and
other dangers.
Prohibited
Prohibited Electric risk
- Make sure the power cord is not scking foreign
objects, and the plug is fully inserted.
- Can cause dangerous leakage.
- Excepon handling.
- When the product is in use unpleasant smell,
abnormal sound, stop using it inmediately and
disconnect the power.
!!
Required
Required Electric risk
MCONFORT V360

13
General
forbidden
- If the power cord is damaged, do not use the
equipment. It may cause short circuits or fire.
- Do not try to replace the damaged cable yourself.
Contact your service representave.
- Do not put heavy objects on the power cord.
- Doing so may cause its breakage and, consequently,
short circuits or fire.
!!
Required RequiredElectric risk
- Do not risend with water body.
- Will lead to leakage, short circuit and possible
damage to the product.
- Do not use the machine around the tub, sprinkler or
the pool.
- Never leave the machine placed directly below a
power outlet using.
- Keep the unit away from the walls, curtains and
other combusble materials when using to avoid fire.
- If go out for a long me or do not use the machine
must be shut down, unplug the power cord from the
outlet.
- when you have cildren, animals or the mobility of
people present lack of self-control and unaended,
you should avoid using the machine.
- DO NOT COVER.
- Do not put anything on the unit.
- Power outlet should meet the requirements of
elegibility by checking. Carrying capacity and the
outlet of not less than 10A / 220V.
- Must ensure that the supply voltage and the voltage
specified on the nameplate is consistent.
- Please confirm the voltage when move to a new
place.
!
Required
Electric risk
Electric risk
II. FEATURES
I. Timing: 1H, 2H, 4H, 8H.
II. Easy control with remote control.
III. Wind speed: Hi/Med/Low.
IV. Wind modes: Normal, Nature, Sleeping.
V. Buon control with LED display.
VI. Horizontally 360� Oscillation, diferent angles for choice (60�,90�,180�,360�)
VII. Manually vertical Oscillation (-10�, 0�,10�, 20�, 30�, 40�, 50�, 60�,70�,80�,90�)
VIII. Power ON/OFF buttons sound alerts. (Power on: Bi Bi; buttons: Bi; Power off: Bi-)

14
Structure.
Control panel Remote control
III. TECHNICAL NAME OF COMPONENTS
1. Decoraon cover 2. Front grill
5. Grill ring 6. Grill ring buckle
3. Blade nut
7. Grill nut
4. Fan blade
8. Back grill
9. Fan body 10. Power code 11. Adjustment Screw 12. Column tube
13. Base 14. Pipe Screw
MCONFORT V360

15
Installaon.
1. Open the package and take out the products , make sure all components are
included, IM, remote control, etc.
2.Install the fan according to below instrucons.
a-.Put the column tube through the hole of base and fix them ghtly by
pipe screw (Figure 1).
b-.Put the fan body on to the column tube, and fix by the adjustment
screw (Figure2).
c-. Amount the rear grill to the front cover of motor, and align the 3
posioning point to the holes on grill, finally fix by grill nut.(Figure 3)
d-. Fit the fan blade on the motor axel, ghtly fixing by blade screw in
crosswise (Figure4).
e-. Assemble front grill and grill ring to the rear grid. Fix the grill with the
crew on grill buckle. (Figure5)
f-.Put the fan stand up aer assembled and plug in, use according to the
instrucon manual.(Figure6)
IV. INSTALLATION AND OPERATING INSTRUCTION
Fig.1 Fig.2
Fig.4 Fig.5
Fig.3
Fig.6

16
Operaon instrucon.
All funcons can be operated by ckling the buons on the control panel.
1. When first plug in, the fan with “Bi Bi” sound alerts, then the fan will under
standby status, in which no buon works except “ON/OFF”.
2. ON/ OFF:
a. No buon works except “ON/OFF” when the fan under standby status. It starts
to work aer pressed “ON/OFF”. The fan starts with Med speed, and turns to Low
speed in three seconds, the Led lights on correspondingly. The fan works in normal
speed, no me seng and oscillaon funcon.
b. Press “ ON/ OFF” when the fan is working, the fan will turn to standby aer
“BI---” sound.
c.Aer turning on under standby state, the fan keeps the same working state as
before turning off, besides the me seng and wind modes. (When the fan is in Hi
or Low speed before turning off, it will start with Med speed when turn on again,
and shi to the memoried speed aer 3s)
2.SPEED
Press “SPEED” buon to set the wind speed at the rule of --L--M--H--L… and led
light changes accordingly.
4.SWING
a. Manually Vercal oscillaon: -8°, 0°, 10°, 20°, 30°, 40°, 50°, 60°, 70°, 80°, 90°
adjust according to users.
b. Horizontal oscillaon can be any angle in 0-360° by hand;
c. Automacally horizontal oscillaon, press “SWING” buon to set the oscillaon
as the rule of 0(stop horizontal oscillaon), 60°, 90°, 180°, 360°, 0(stop
oscillaon)…, and led light changes accordingly
5.MODE
The fan is inially set at normal mode when turning on. Press MODE buon, it will
change as the rule of normal→nature→sleeping→normal…, and the display will
show accordingly.
1. Normal wind
High wind speed high -----
Medium wind speed medium ----
Low wind speed low ----
2.Natural wind
Natural wind includes three wind mode, high, med, low.
MCONFORT V360

17
3.Sleeping wind：
High:30 minutes’ high natural wind—30 minutes’ medium natural
wind-low natural wind(keeping)
Medium:30 minutes’ medium natural wind—low natural wind(keeping)
The speed led display do not change as the wind speed at natural and sleeping mode,
6.TIMER
Aer turned on, there is no me seng by default and no TIMER led display. Press
the TIMER buon, you can set the running me for this fan, Time seng as: 1H,
2H, 4H, 8H,no me seng,1H,circulang as this, and the led light changed
according. Aer the me seng, the system enters into the countdown and works
unl the unit turns off.
7. FUNCTION CONSERVATION
When in standby mode, wind speed and oscillaon will all be conserved. (Timing &
sleeping mode will not be conserved)
8. LED LIGHT
The LED light has dimming funcon if no operaons on buons in 1 minutes (33%
darkening than original brightness). If press the buon again, the light will
brighten.
Usage for remote control
1. Open the baery box on the back of remote control, and install One buon
baery (CR2032 3V).
2. Allign to the remote control receiver. The RC will not work when blocked. Well
keep the remote controler, do not throw it to the floor. Put it in the handle.
3. Replace the baery aer power off. Please note the posive & negave of the
baery.

18
V. CLEAN AND MAINTAINANCE
VI. MAINTAINANCE GUIDANCE
VI. SPECIFICATION
MODEL V360
RATED VOLTAGE 220 - 240V
RATED FREQUENCY 50 / 60 Hz
RATED POWER 65W
STANDBY POWER CONSUMPTION ≤ 0.5W
SIZE (LxWxH) 45x40x138 cm
NOISE ≤ 60dB
WEIGHT 7,8 Kg
MAX. FLOW 4000 m³/h
REMOTE CONTROL YES
- If there is too much dust or dirt on the back grid cover of the fan, it will affect the
performance of air-out, so we suggest clean the fan
once per month at least
Should be cleaned at least by every other mont
1. Always unplug the fan before cleaning.
2. Wipe all parts with a so cloth. Do not use any of the following as a cleaner:
gasoline, thinner, benzine.
- Unit surface cleaning
1.Do not allow water and steam to drip on .
2. Do not use corrosive detergent or solvent cleaning
3. Always unplug the fan before cleaning.
- Product storage:
1. Unplugged and packed to prevent dust from entering the body if not use for a
long me.
2. Placed in a dry well venlated place aer packed.
When the fan does not rotate, and abnormal smell, immediately turn off the power, sent
noce to the company service center for repair.
MCONFORT V360

This seal indicates that this product should not be disposed of together with other
household waste in the EU. In order to prevent environmental damage or health problems
due to poor disposal, recycle it responsibly. To return your used equipment, contact
whoever sold the equipment. They can take care of him responsibly.
