M-Elec PULSE ML-PUL600-5K-S User manual
PULSE
ILLUMINATE VICTORY
AVAILABLE WITH GLARE GUARD
FULLY GASKETED & SECURE LENS
Full screen design with secure locking
tabs and IP66 sealing to protect against
the elements
PULSE
ILLUMINATE VICTORY
INDEPENDENT CONTROL GEAR
IP66 independent driver box, can be
remotely installed or attached to the
(optional) on board brackets for excellent
heat dissipation.
FULL ADJUSTABLE BRACKET
Vertical rotation 0-270°
Horizontal expansion 0-100mm
IP66 RAPID CABLE CONNECTION
Easy and quick wiring of power
supply with fully protected 4-pin
male and female connectors
OPTIMISED HEAT DISSIPATION
Fully integrated die cast aluminium
heat sinks for improved thermal
management
SAA, IP66, IK08, C-TICK
Total Power:
MAX Lumen Output: 65000
IP Rating: IP66
130lm/W
50/60Hz
10mA
Current inrush 2.8A 13.8A
Beam Angle: 60° (30°/90°/120° options)
Temp Range:
Dimmable: 0-10V dimming
Average Life: 50,000 hrs**
IK Rating
LM Rating
LB Rating
SDCM Rating
EPA rating
Dimensions: 690x618x369mm
Weight: 12kg
Control gear weight: 5.5kg
21kg
5 Years*
Data subject to change at any time
For further information about our Warranties please go to:
Commercial applications:
- Large area lighting
- Wharf/harbors
- Airports
DIMMABLE WARRANTYBEAMIK8IP66
•
• 0-270° rotational head
• 0-100mm extendable head
• Fully gasketed lens and control gear to protect against the elements
• Power consumption: 500W
• Average life of 50,000 hours
• Low and high power options available
• 0-10v dimming capability
• 60° beam angle (30°/ 90°/ 120° option available)
• IP66 and IK08 rated
• Five year warranty
IK
60
°
YEAR
5
PULSE 500W
APPLICATIONS
FEATURES
TECHNICAL INFORMATION
COMPLIANCE
SAA, IP66, IK08, C-TICK
Total Power: 600w
MAX Lumen Output: 78000 lm
IP Rating: IP66
130lm/W
50/60Hz
10mA
Current inrush 4.7A 7.7A
Beam Angle: 60° (30°/90°/120° options)
Temp Range:
Dimmable: 0-10V dimming
Average Life: 50,000 hrs**
1.3A
IK Rating
LM Rating
LB Rating
SDCM Rating
EPA rating
Dimensions: 690x618x369mm
Weight: 12kg
Control gear weight: 5.5kg
23kg
5 Years*
Commercial applications:
- Large area lighting
- Wharf/harbors
- Airports
•
• 0-270° rotational head
• 0-100mm extendable head
• Fully gasketed lens and control gear to protect against the elements
• Power consumption: 600W
• Average life of 50,000 hours
• Low and high power options available
• 0-10v dimming capability
• 60° beam angle (30°/ 90°/ 120° option available)
• IP66 and IK08 rated
• Five year warranty
APPLICATIONS
FEATURES COMPLIANCE
PULSE 600W
Data subject to change at any time
For further information about our Warranties please go to:
DIMMABLE WARRANTYBEAMIK8IP66
IK
60
°
YEAR
5
TECHNICAL INFORMATION
PRODUCT DIMENSIONS
498.70
A A
B B
C C
D D
E E
F F
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DRAWN
CHK'D
APPV'D
MFG
Q.A
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
ANGULAR:
FINISH:
DEBURR AND
BREAK SHARP
EDGES
NAME
SIGNATURE
DATE
MATERIAL:
DO NOT SCALE DRAWING
REVISION
TITLE:
DWG NO.
SCALE:1:10
SHEET 1 OF 1
A3
WEIGHT:
001
M-ELEC PTY. LTD.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPRIETARY OF
M-ELEC PTY. LTD. ANY REPRODUCTION
IN PART AS A WHOLE WITHOUT THE
WRITTEN PERMISSION OF
M-ELEC PTY. LTD. IS PROHIBITED
498.7
FRONT VIEW
BOTTOM VIEW
SIDE VIEW
PLEASE NOTE
• Read instructions carefully before attempting to install the fitting. Retain this guide for future reference
• Disconnect power before installing or servicing
• This fitting is for outdoor use and should not be used in areas with limited ventilation or high ambient temperatures
• Do not extend low voltage cables from the output of power supply
• All components must not be mechanically stressed
•
• 000)
•
under warranty
• Damage by corrosion will not be honoured as a material defect claim. It is the user’s responsibility to provide suitable protection against
corrosive agents such as moisture, condensation and other harmful elements
Data subject to change at any time
For further information about our Warranties please go to:
SAA, IP66, IK08, C-TICK
•
• 0-270° rotational head
• 0-100mm extendable head
• Fully gasketed lens and control gear to protect against the elements
• Power consumption: 1000W
• Average life of 50,000 hours
• Low and high power options available
• 0-10v dimming capability
• 60° beam angle (30°/ 90°/ 120° option available)
• IP66 and IK08 rated
• Five year warranty
FEATURES COMPLIANCE
PULSE 1000W
Commercial applications:
- Large area lighting
- Wharf/harbors
- Airports
APPLICATIONS
DIMMABLE WARRANTYBEAMIK8IP66
IK
60
°
YEAR
5
Total Power: 1000W
MAX Lumen Output: 130000 lm
IP Rating: IP66
130lm/W
50/60Hz
10mA
Current inrush 5.6A 27.6A
Beam Angle: 60° (30°/90°/120° options)
Temp Range:
Dimmable: 0-10V dimming
Average Life: 50,000 hrs**
2.2A
IK Rating
LM Rating
LB Rating
SDCM Rating
EPA rating
Dimensions: 780x618x621mm
Weight: 19.5kg
Control gear weight: 7.8kg
32kg
5 Years*
TECHNICAL INFORMATION
Data subject to change at any time
For further information about our Warranties please go to:
Data subject to change at any time
SAA, IP66, IK08, C-TICK
•
• 0-270° rotational head
• 0-100mm extendable head
• Fully gasketed lens and control gear to protect against the elements
• Power consumption: 1200W
• Average life of 50,000 hours
• Low and high power options available
• 0-10v dimming capability
• 60° beam angle (30°/ 90°/ 120° option available)
• IP66 and IK08 rated
• Five year warranty
FEATURES COMPLIANCE
For further information about our Warranties please go to:
PULSE 1200W
Commercial applications:
- Large area lighting
- Wharf/harbors
- Airports
DIMMABLE WARRANTYBEAMIK8IP66
IK
60
°
YEAR
5
APPLICATIONS
Total Power: 1200w
MAX Lumen Output: 156000 lm
IP Rating: IP66
130lm/W
50/60Hz
10mA
Current inrush 9.4A 15.5A
Beam Angle: 60° (30°/90°/120° options)
Temp Range:
Dimmable: 0-10V dimming
Average Life: 50,000 hrs**
2.6A
IK Rating
LM Rating
LB Rating
SDCM Rating
EPA rating
Dimensions: 780x618x621mm
Weight: 19.5kg
Control gear weight: 7.8kg
34kg
5 Years*
TECHNICAL INFORMATION
Data subject to change at any time
SAA, IP66, IK08, C-TICK
•
• 0-270° rotational head
• 0-100mm extendable head
• Fully gasketed lens and control gear to protect against the elements
• Power consumption: 1500W
• Average life of 50,000 hours
• Low and high power options availble
• 0-10v dimming capability
• 60° beam angle (30°/ 90°/ 120° option available)
• IP66 and IK08 rated
• Five year warranty
FEATURES COMPLIANCE
For further information about our Warranties please go to:
PULSE 1500W
Commercial applications:
- Large area lighting
- Wharf/harbors
- Airports
APPLICATIONS
DIMMABLE WARRANTYBEAMIK8IP66
IK
60
°
YEAR
5
Total Power: 1500w
MAX Lumen Output: 195000 lm
IP Rating: IP66
130lm/W
50/60Hz
10mA
Current inrush 8.4A 41.4A
Beam Angle: 60° (30°/90°/120° options)
Temp Range:
Dimmable: 0-10V dimming
Average Life: 50,000 hrs**
3.3A
IK Rating
LM Rating
LB Rating
SDCM Rating
Dimensions: 964x571x280mm
Weight: 27kg
Control gear weight: 11.8kg
41kg
5 Years*
TECHNICAL INFORMATION
PRODUCT DIMENSIONS
591.68
A A
B B
C C
D D
E E
F F
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DRAWN
CHK'D
APPV'D
MFG
Q.A
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
ANGULAR:
FINISH:
DEBURR AND
BREAK SHARP
EDGES
NAME
SIGNATURE
DATE
MATERIAL:
DO NOT SCALE DRAWING
REVISION
TITLE:
DWG NO.
SCALE:1:10
SHEET 1 OF 1
A3
WEIGHT:
001
M-ELEC PTY. LTD.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPRIETARY OF
M-ELEC PTY. LTD. ANY REPRODUCTION
IN PART AS A WHOLE WITHOUT THE
WRITTEN PERMISSION OF
M-ELEC PTY. LTD. IS PROHIBITED
591.68
FRONT VIEW
BOTTOM VIEW
SIDE VIEW
PLEASE NOTE
Data subject to change at any time
For further information about our Warranties please go to:
• Read instructions carefully before attempting to install the fitting. Retain this guide for future reference
• Disconnect power before installing or servicing
• This fitting is for outdoor use and should not be used in areas with limited ventilation or high ambient temperatures
• Do not extend low voltage cables from the output of power supply
• All components must not be mechanically stressed
•
• 000)
•
under warranty
• Damage by corrosion will not be honoured as a material defect claim. It is the user’s responsibility to provide suitable protection against
corrosive agents such as moisture, condensation and other harmful elements
INSTALLATION GUIDE
1. Do not remove any part of the fitting.
2. Install fitting using correct equipment and components
(e.g.. Expansion bolts for masonry)
L
G
N
Data subject to change at any time
For further information about our Warranties please go to:
Align the glare guard with the mounting holes on the
Fix the glare guard in place with the included M4X-
16mm screws
Depending on the type of bracket provided with the
the bracket in place with M20 screws
Detach the blue rubber cover of the adjustable arm
and loosen the M16 hex head screw, adjust the lumi-
naire to the desired angle (0-180°). Tighten the screws
Detach the blue rubber cover of the adjustable arm
and, adjust the luminaire to the depth (0-100mm).
cover
Plug the driver cable connector to the one on the
luminaire, and wire the outcoming lead of the driver
to the corresponding wires of the line (refer to above
wiring diagram)
All wiring
has been
assembled
inside of the
control gear
PRODUCT DIMENSIONS
Data subject to change at any time
For further information about our Warranties please go to:
100
448.50
190
157
372
397.81
130
105
A A
B B
C C
D D
E E
F F
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DRAWN
CHK'D
APPV'D
MFG
Q.A
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
ANGULAR:
FINISH:
DEBURR AND
BREAK SHARP
EDGES
NAME
SIGNATURE
DATE
MATERIAL:
DO NOT SCALE DRAWING
REVISION
TITLE:
DWG NO.
SCALE:1:10
SHEET 1 OF 1
A3
WEIGHT:
001
M-ELEC PTY. LTD.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPRIETARY OF
M-ELEC PTY. LTD. ANY REPRODUCTION
IN PART AS A WHOLE WITHOUT THE
WRITTEN PERMISSION OF
M-ELEC PTY. LTD. IS PROHIBITED
500W-600W CONTROL GEAR
200
448.50
382
0
280.16
242
135
110
A A
B B
C C
D D
E E
F F
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DRAWN
CHK'D
APPV'D
MFG
Q.A
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
ANGULAR:
FINISH:
DEBURR AND
BREAK SHARP
EDGES
NAME
SIGNATURE
DATE
MATERIAL:
DO NOT SCALE DRAWING
REVISION
TITLE:
DWG NO.
SCALE:1:10
SHEET 1 OF 1
A3
WEIGHT:
001
M-ELEC PTY. LTD.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPRIETARY OF
M-ELEC PTY. LTD. ANY REPRODUCTION
IN PART AS A WHOLE WITHOUT THE
WRITTEN PERMISSION OF
M-ELEC PTY. LTD. IS PROHIBITED
1000W-1500W CONTROL GEAR
DIMMING CONNECTIONS
Please note: Do not connect anything
other than a 0-10V dimmer or control
system or the warranty will be void.
1. Open the back of the control gear.
2.
your 0-10V dimming system.
3.
the latches are properly locked and
ensure that the seals are secure.
Water penetration from a failure to
seal the fitting properly will not be
covered under warranty.
0-10V Dimming
Notes:
1. The dimmer can also be replaced by an active 0-10V voltage source signal or passive components like zener.
Implementation 1: DC input
GLARE GUARD
ML-PUL-GG
DRIVER STENTS 1M METAL CABLE PROTECTION
ML-PUL-CAB
ACCESSORIES
PLEASE NOTE
• Read instructions carefully before attempting to install the fitting. Retain this guide for future reference
• Disconnect power before installing or servicing
• This fitting is for outdoor use and should not be used in areas with limited ventilation or high ambient temperatures
• Do not extend low voltage cables from the output of power supply
• All components must not be mechanically stressed
•
• 000)
•
under warranty
• Damage by corrosion will not be honoured as a material defect claim. It is the user’s responsibility to provide suitable protection against
corrosive agents such as moisture, condensation and other harmful elements
Data subject to change at any time
For further information about our Warranties please go to:
ACCESSORY INSTALLATION
A B
PULSE
Compatible with:
•
•
•
•
•
ML-PUL-GG
Data subject to change at any time
For further information about our Warranties please go to:
Compatible with:
•
•
•
•
•
DRIVER STENTS
ACCESSORY INSTALLATION
A B
C D
E F
PULSE
A A
D D
DRAWN
A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DRAWN
CHK'D
APPV'D
MFG
Q.A
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
ANGULAR:
FINISH:
DEBURR AND
BREAK SHARP
EDGES
NAME
SIGNATURE
DATE
MATERIAL:
DO NOT SCALE DRAWING
REVISION
TITLE:
DWG NO.
SCALE:1:5
SHEET 1 OF 1
A1
WEIGHT:
T04-2__-LEDiL__
A A
D D
DRAWN
A A
D D
DRAWN
A A
D D
DRAWN
A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DRAWN
CHK'D
APPV'D
MFG
Q.A
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
ANGULAR:
FINISH:
DEBURR AND
BREAK SHARP
EDGES
NAME
SIGNATURE
DATE
MATERIAL:
DO NOT SCALE DRAWING
REVISION
TITLE:
DWG NO.
SCALE:1:5
SHEET 1 OF 1
A1
WEIGHT:
T04-2__-LEDiL__
Data subject to change at any time
For further information about our Warranties please go to:
Cable size: 4x1.0mm
Temperature rating -30°C - +60°C
ACCESSORY INSTALLATION
A
PULSE
Compatible with:
•
•
•
•
•
ML-PUL-CAB
LN
G
Data subject to change at any time
For further information about our Warranties please go to:
ONSITE WARRANTY
EXCLUSIVE TO
MEMBERS ONLY
FREE
Version 10
This manual suits for next models
1
Table of contents
Other M-Elec Floodlight manuals
Popular Floodlight manuals by other brands
Chauvet
Chauvet Bubble King user manual
BELL lighting
BELL lighting Skyline Elite Series installation instructions
Chauvet
Chauvet EZpar T6 USB Quick reference guide
YORKVILLE
YORKVILLE LP-LED2 Service manual
Mr. Beams
Mr. Beams MB12983 user manual
LI-TIAN LIGHTING
LI-TIAN LIGHTING LT-ALP-20W-MA installation instructions
NVC
NVC ODESSA V2 instructions
Red Arrow
Red Arrow FLSMD50Y-1 installation instructions
ETC
ETC CE Source FourPAR user manual
BARRON
BARRON TRACE-LITE FXA Series installation instructions
IB LIGHTING SUPPLY
IB LIGHTING SUPPLY FL50W-C quick start guide
Francis Searchlights
Francis Searchlights FB230 User instruction & installation manual
RAB Lighting
RAB Lighting ANGSHARK quick start guide
ACR Electronics
ACR Electronics RCL-600 SEARCHLIGHT Product support manual
Acuity Brands
Acuity Brands Lithonia Lighting HomeGuard LED HGX LED 2RH 40K 120... installation instructions
Rego
Rego SF Series user guide
Chauvet
Chauvet Nexus user manual
Chauvet
Chauvet LEDRAIN 64C user manual
