M-SURE Digital Caliper User Manual
Part No: MS-200 Series
Doc V: 1.0
M-SURE Digital Calipers
• Before using the Digital Caliper for the fi rst time, wipe the Caliper with a clean cloth ideally soaked with cleaning oil.
• The Caliper is a precision measuring instrument. Avoid using excessive force and treat with care.
• The fi tted battery is intended for the factory test procedure and therefore may not meet the specifi ed battery life.
• Avoid exposure to all liquids, excessive humidity or temperature.
• Avoid exposure to bright sunlight.
• Never apply voltage on any part of this Digital Caliper or electric engrave
the Caliper.
• Remove the battery if the Caliper is not being used for a long period of time.
• Never use solvents to clean the Caliper, only use a soft cloth with cleaning oil.
Precautions
a. Check the measuring surface is clean, switch on Caliper.
b. Ensure the locking screw is loose and close Caliper. If the display is not
reading zero, press zero button.
c. Choose the display units as required (mm or inch).
d. Close Caliper on workpiece to take desired measurement. Do not use
excessive force.
External Internal
Step Depth
Internal
measurement
on long length
Calipers.
Use preset function
when available.
1. Internal Jaw
2. Display
3. Locking Screw
4. Beam
5. Depth Bar
6. Thumb Wheel
7. Battery Cover
8. Function Buttons
9. External Jaw
10. Step Measurement
1. Insert the key into the battery cover.
2. Twist to unlock. DO NOT use
excessive force.
3. Lift out the battery cover. 4. Remove the battery. (A magnet tip tool can
be used)
5. Locate the side spring battery contact.
6. Insert the replacement battery with
its edge against the side battery contact.
7. Press down on the opposite edge.
8. Locate the two lugs on the battery
cover with the two slots on the Caliper.
Insert the battery cover.
9. Twist to lock. DO NOT use excessive
force.
1
2
6
7
8
9
3
4
5
Battery Replacement
1234
5
9
87
6
10

m-sure.co.uk
www.m-sure.co.uk - Allendale Group Ltd, Pindar Road, Hoddesdon, Hertfordshire. EN11 0BZ.
Images & Content ©2020 Allendale Group Limited. E&OE - Specifi cations subject to change without prior notice.
M-SURE Digital Caliper User Manual
Trouble Shooting
Metric/Inch Conversion
25.40mm
in/mm

Press in/mm to convert from
inch to metric display.
1.000
The display will indicate
which units are being
displayed.
in/mm

in
Calipers with a Preset Value Function (MS-222 Series only)
0.00mm
ZERO/SET

In ‘INC’ mode only; Press and
hold the ZERO/SET button
until SET fl ashes.
20.00mm
PRE+/PRE-

Press PRE+ or PRE- to
increase or decrease
the value.

SETSET 20.00mm
ZERO/SET

Once the desired value is
achieved, press the ZERO/
SET button.

SET 20.00mm
ZERO/SET

To recall the entered Preset
value press the ZERO/SET
button, IN ‘INC’ MODE ONLY.

SET
How to Zero Calipers
0.00mm
ZERO

Press ZERO to clear.
Problem Possible Cause Solution
Flashing display Low voltage
Poor contact
Replace battery
Clean contact
No display Dead or weak battery
Poor contact
Replace battery
Clean contact
Erratic or frozen display Contamination between beam & head
low voltage
Wipe Caliper clean
Replace battery
Erroneous reading Low voltage
Contamination between beam & head
Too much operating force
Low ambient temperature
Replace battery
Wipe Caliper clean
Use pressure device
Store Caliper at normal room temperature
Caliper with ABS Function
0.00mm
ZERO

Close Caliper. Press ZERO
button.
10.00mm
Measure workpiece, for
example 10mm.
5.00mm
ABS

Press the ABS button once to
change between ABS mode
and INC mode. (Not displayed)
15.00 ABS

Press ABS to switch back to
Absolute display.
mm
ABS
