M-TI OSIT-1001 Manual

Instruction Guide | OSIT Table
U.S. & Canada [phone] |International [phone] |www.mti.net
WARNING/AVERTISSEMENT
Read this manual before installation and use.
Lisez ce manuel avant l’installation et l’utilisation.
Required Tools
none
This manual is for the following part numbers:
PART NUMBER DESCRIPTION
7000010-XXX OSIT-1000 Instrument Table w/o Tray, Laminate Top
7000011-XXX OSIT-1001 Instrument Table w/Tray, Laminate Top
7000066-XXX OSIT-2000 Instrument Table w/o Tray, Solid Surface
7000067-XXX OSIT-2001 Instrument Table w/Tray, Solid Surface Top
REVISION HISTORY TABLE
DAT E REVISION CO#/ECO# DETAILS
5/3/2016 A CO-0066/EC-0310 Initial release

2 Instruction Guide | OSIT Table
OPERATION
Raising and Lowering the Table
Loosen the handles on each side of the table located
on the posts by twisting counter clockwise. Raise or
lower the table to the desired height. Tighten the
knob on both sides. (Figure 1) To move the knob out of
the way, press the button while twisting the knob and
release in desired position.
Figure 1
Locking and Unlocking Casters
To lock the casters, press down on the lever on each
caster. To unlock the caster, lift up on the lever on each
caster. (Figure 2)
Lock
Unlock
Figure 2
Positioning the Table
The table rolls over the foot/seat of most chairs.
(Figure 3). However, the OSIT table does not fit over any
chair with a “Low-Boy” Mobile Base. On a 440 Mobile
Stretcher Bed, the OSIT casters and the bed casters
should be parallel to each other. Unlock one side of the
440 Stretcher bed and push the OSIT Table over the
chair. (Figure 4)
Figure 3
Figure 4

Instruction Guide | OSIT Table 3
EXPLODED VIEWS
PART NUMBER QTY DESCRIPTION
032101 6PHP SCREW, 1/4-20 x 1 ZINC
037007 2HANDLE, ADJ CLAMP, 3/8-16X2.48,3-1/6" HANDLE
043142 2THRUST BEARING, 3/8 ID x .812 OD x .078 THK
045032 4SAE WASHER, 3/8 ZINC
045148 6LOCK WASHER, 1/4, ZINC
055007 4PLUG, 2 X 2 UNIVERSAL END CAP
056024 4CASTER, 3" BLACK SOFTECH W/BRAKE
7009010 1LEG WLD, OSIT RH
7009011 1TOP WLD, OSIT
7009018 1LEG WLD, OSIT LH
7009070-XXX 1COUNTER TOP ASSY, OSIT LAM
0431422X
7009018
7009010
032101 6X
045148 6X
045032 4X
037007 2X
7009011
056024 4X 0550074X
7009070-XXX
-XXX OSIT- INSTRUMENT TABLE W/O TRAY, LAMINATE TOP

4 Instruction Guide | OSIT Table
PART NUMBER QTYDESCRIPTION
032050 6PHP SCREW, 8-32 x 1/4 ZINC
032054 8PHP SCREW, 8-32 x 1/2 ZINC
032101 6PHP SCREW, 1/4-20 x 1 ZINC
037007 2HANDLE, ADJ CLAMP, 3/8-16X2.48,3-1/6" HANDLE
043142 2THRUST BEARING, 3/8 ID x .812 OD x .078 THK
044004 1SLIDE, OSIT PULL OUT TRAY
045032 4SAE WASHER, 3/8 ZINC
045148 6LOCK WASHER, 1/4, ZINC
055007 4PLUG, 2 X 2 UNIVERSAL END CAP
056024 4CASTER, 3" BLACK SOFTECH W/BRAKE
7001071 1TRAY, OSIT
7009010 1LEG WLD, OSIT RH
7009011 1TOP WLD, OSIT
7009018 1LEG WLD, OSIT LH
7009070-XXX 1COUNTER TOP ASSY, OSIT LAM
0431422X
7009018
7009010
032101 6X
045148 6X
045032 6X
037007 6X
7009011
056024 6X
0550072X
7009070-XXX
0320506X
044004
7001071
0320548X
-XXX OSIT- INSTRUMENT TABLE W/TRAY, LAMINATE TOP

Instruction Guide | OSIT Table 5
-XXX OSIT- INSTRUMENT TABLE W/O TRAY, SOLID SURFACE
PART
NUMBER QTY DESCRIPTION
032101 6PHP SCREW, 1/4-20 x 1 ZINC
037007 2HANDLE, ADJ CLAMP, 3/8-16X2.48,3-1/6" HANDLE
043142 2THRUST BEARING, 3/8 ID x .812 OD x .078 THK
045032 4SAE WASHER, 3/8 ZINC
045148 6LOCK WASHER, 1/4, ZINC
055007 4PLUG, 2 X 2 UNIVERSAL END CAP
056024 4CASTER, 3" BLACK SOFTECH W/BRAKE
7009010 1LEG WLD, OSIT RH
7009011 1TOP WLD, OSIT
7009018 1LEG WLD, OSIT LH
7009072-XXX 1COUNTER TOP ASSY, OSIT SOLID SURF
0431422X
7009018
7009010
032101 6X
045148 6X
045032 4X
037007 2X
7009011
056024 4X
0550074X
7009072-XXX

6 Instruction Guide | OSIT Table
PART
NUMBER QTYDESCRIPTION
032050 6PHP SCREW, 8-32 x 1/4 ZINC
032054 8PHP SCREW, 8-32 x 1/2 ZINC
032101 6PHP SCREW, 1/4-20 x 1 ZINC
037007 2HANDLE, ADJ CLAMP, 3/8-16X2.48,3-1/6" HANDLE
043142 2THRUST BEARING, 3/8 ID x .812 OD x .078 THK
044004 1SLIDE, OSIT PULL OUT TRAY
045032 4SAE WASHER, 3/8 ZINC
045148 6LOCK WASHER, 1/4, ZINC
055007 4PLUG, 2 X 2 UNIVERSAL END CAP
056024 4CASTER, 3" BLACK SOFTECH W/BRAKE
7001071 1TRAY, OSIT
7009010 1LEG WLD, OSIT RH
7009011 1TOP WLD, OSIT
7009018 1LEG WLD, OSIT LH
7009072-XXX 1COUNTER TOP ASSY, OSIT SOLID SURF
0431422X
7009018 7009010
032101 6X
045148 6X
045032 4X
0370076X
7009011
056024 4X
0550074X
7009072-XXX
0320506X
044004
7001071
0320548X
-XXX OSIT- INSTRUMENT TABLE W/TRAY, SOLID SURFACE TOP

Instruction Guide | OSIT Table 7
WARNING/AVERTISSEMENT
No modification of this equipment is allowed.
Aucune modification de cet équipement est autorisé.
WARNING/AVERTISSEMENT
Assure equipment, patient, and other objects are in safe
condition before operating the equipment.
Assurer l’appareil, patient, et d’autre objets sont dans un
état sûr avant d’utiliser l’appareil.
CAUTION/PRÉCAUTION
Acidic or abrasive cleaners can damage laminate surfaces.
Do not use them.
Nettoyants abrasifs ou acides peuvent endommager le
stratifié. Ne les utilisez pas.
CAUTION/PRÉCAUTION
Do not leave any moisture on any part of the table for an
extended period of time.
Ne laissez pas l’humidité sur toute partie de la table pour
une période de temps prolongée.
CAUTION/PRÉCAUTION
When working with betadine, neosynephrine, hydrogen
peroxide, silver nitrate, or any other type of harsh chemicals,
do not allow it to get on the cabinet surface. If it does get
on the cabinet, wipe it up immediately or staining will occur.
Lorsque vous travaillez avec de la bétadine, néosynéphrine,
le peroxyde d’hydrogène, le nitrate d’argent, ou tout autre
type de produits chimiques agressifs, ne lui permet pas
de monter sur la surface du meuble. Si elle ne obtient sur
le meuble essuyez-le immédiatement ou coloration se
produira.
SPECIFICATIONS
DESCRIPTION SPECIFICATION
Cabinet Size/Type: OSIT 1000 OSIT 1001 OSIT 2000 OSIT 2001
Overall Height (Counter-top to floor) 30..5” (77.5cm) - 48.0” (121.9 cm) 31.0” (78.7cm) - 48.5” (123.2 cm)
Overall Width 39.0” (99.1 cm) 40” (101.6 cm)
Overall Depth 23.75” (60.3 cm) 24.75” (62.9 cm)
Shipping Weight (product weight will vary) 85 lbs. (39 kg) 92 lbs (42 kg) 108 lbs. (49 kg) 114 lbs (52 kg)
LIST OF ACCESSORIES
DESCRIPTION USE RESTRICTIONS
IV Rod and Mount Provides an IV Rod that mounts to a leg of the
table.
Counter Top Edge Guard Provides a raised trim to prevent instruments
from rolling o the edge of the table.
High Volume Evacuation Tip
Holder
Provides a holder for up to 3 instrument tips to
hang on the side of the table.
Special Color Counter top Customer chosen counter top color Contact MTI for quote on availability
and additional costs.

8 Instruction Guide | OSIT Table
073157 Rev A
3655 W Ninigret Drive, Salt Lake City, Utah, 84104-6572
[phone] • [phone] • Fax [phone]
www.mti.net
© MTI, Inc. All rights reserved.
MTI reserves the right to make any
product changes without notice.
Strength in patient care.™
WARNING/AVERTISSEMENT
This product contains chemicals known to the State of
California to cause cancer and/or birth defects or other
reproductive harm. See http://www.mti.net/FAQs.aspx for
details on California Proposition 65.
Ce produit contient des produits chimiques reconnus
par l’État de Californie pour causer le cancer et / ou
des anomalies congénitales ou d’autres problèmes de
reproduction. Voir http://www.mti.net/FAQs.aspx pour plus de
détails sur la California Proposition 65.
Cleaning and Disinfection
See “MTI Cleaning Solution Recommendation Letter” for
more details on disinfecting solutions which have been
tested on MTI’s products. It is available for download at
http://www.mti.net/downloads.aspx in the Product Support
Bulletins folder, found under the Resources tab on our
website. In the U.S. & Canada, call [phone], or
International, call [phone] to request a copy.
Painted and Plastic Surfaces
All painted metal parts have been electrostatically painted
and the paint is baked on for durability. Weekly, those
surfaces should be wiped down with a quality grade
cleaner and a soft cloth or a damp cloth with mild soap.
Plastic Laminate
A quality grade of plastic/vinyl cleaner like SD-20 or a
mild detergent in warm water with a soft cloth should be
used to clean all the laminate surfaces. For a disinfectant,
use a combination of 10% household bleach and 90%
water. Make sure to dry with a soft cloth.
Calls for Service
[phone] | International [phone]
[email protected] | www.mti.net
LIMITED WARRANTY
Medical Technology Industries, Inc. (hereinafter referred to as MTI), shall
repair or replace products of its manufacture, which prove to be defective
in material and/or workmanship for a period of twelve (12) months from
the date of shipment to the customer (the “Warranty Period”). MTI will,
at its option, provide parts to the customer or repair the defective part
at MTI’s factory or authorized repair facility. Except as it may otherwise
specifically agree in writing, MTI shall not be liable for transportation
or labor charges for repairs or adjustments or other work done on any
of its products by MTI’s authorized dealers or service organizations.
Customer shall notify MTI of any alleged claim or defect within
fourteen (14) days from the date customer discovers, or upon
reasonable inspection should have discovered, such alleged claim or
defect (but in any event before the expiration of the Warranty Period).
All repair parts are warranted for Ninety (90) calendar days from
the date of shipment to the customer. Warranty is non-cumulative.
This warranty does not apply to any part or product which upon examination
by MTI or its authorized agents indicates the product has been repaired or
altered in any way by persons other than MTI or its authorized agents, has
been misused, abused or used in a manner contrary to any instructions
issued by MTI. Any parts or products claimed under this warranty must
be properly packaged by customer and returned to MTI’s factory with no
liability to MTI for the parts, products or transportation charges thereon.
In no event, shall MTI have any liability for consequential, indirect,
incidental, special, exemplary, punitive or enhanced damages, lost prots
or diminution in value arising out of or relating to a product defect or
the repair or replacement of any products manufactured or sold by it.
THE FOREGOING LIMITED WARRANTY IS MADE IN LIEU OF ALL
WARRANTIES EXPRESSED OR IMPLIED, AND MTI MAKES NO OTHER
WARRANTY WHATSOEVER WITH RESPECT TO THE PRODUCTS
INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OR
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
