MAcarbon MAA.R8.06 Configuration guide

Audi R8 Carbon Fiber Handbrake Install Instructions
Tools Required
1 Flat Screwdriver
Installation Steps
Step Instructions Photo
1 Undo the rear trim of the handbrake by pushing down
and back as shown in the picture.
2 This picture shows the trim piece undone from the
handbrake. Remove the small retaining clip that is on
the top of the handbrake grip.

3 Pull up on the handbrake.
Insert a screwdriver through the seam in the leather.
There is a hole on the bottom of the handbrake under
the seam. Look at the carbon piece to see where it is
located. Press up firmly. Slide the handbrake off.
Note: By using the screwdriver to press up into the
hole, the metal clip (highlighted in second picture) is
being disengaged from the handbrake rod.
4 Remove the top clip from the OEM handbrake and
transfer it to the carbon fiber handbrake.
5 Slide the carbon fiber handbrake on. Make sure the
top clip stays in place.

6 Secure the rear trim piece back onto the handbrake
by pushing down and then forward.
7 Now you are all finished and you now have a
beautiful carbon fiber handbrake to complement the
other carbon in the car!
