Mackie Vision Series PA261 User manual

Vision Series
Compact Two-Way Speaker System
PA261

The PA261 is an extremely versatile wide-dispersion,
low-pro le, two-way loudspeaker system offering sub-
stantial power and value for a variety of professional
applications that include primary sound reinforcement
and supplementary  ll for larger systems. Its sub-compact
size makes it ideal for low visibility column, side-wall
or under-balcony mounting. The high-frequency sec-
tion is a constant directivity horn loaded to a 1-inch
titanium diaphragm tweeter for smooth, wide dispersion.
The low-frequency transducers are two 6-inch carbon
 ber woofers suitable for dif cult climatic environments.

The system includes a high-level crossover network
that features markedly lower (than conventional)
induction values in series with the woofer. We call
this innovation LICC (Low Impedance Compensated
Crossover). The bene t is delay reduction, reduced
phase shift and superior transient response. Dynamic
high-frequency driver protection is accomplished with
a fast-response  lament resistor, chosen to comple-
ment the power curve of the driver.

The Mackie PA261 is a part of the VISION family of
loudspeaker products including full-range, cost-effective
two-way loudspeakers and complementary subwoofer
cabinets. These enclosures have a trapezoidal foot-
print for easy array con guration. All enclosures are
constructed using 19 mm void-free, birch plywood
and  nished with a scratch-resistant black coating.
Transducer components are protected from the envi-
ronment by a heavy gauge metal grille. The VISION
products are eminently suited for  xed installation,
ready for suspension via built-in M10 inserts with
metal reinforcement and forged shoulder eyebolt hard-
ware. The PA261 also includes M8 inserts.

This Mackie product is covered by an exclusive, one-
time, NO FAULT repair policy in addition to a  ve year
limited warranty.
Features

Two 6-inch carbon  ber LF transducers

100° x 100° constant directivity horn-loaded 1-inch
titanium dome tweeter

Trapezoidal enclosure for array con gurations

HF driver dynamic protection

LICC (Low Impedance Compensated Crossover) network

19 mm birch plywood construction

Suspension points (M10 and M8) and eyebolt
suspension hardware

Exclusive Mackie — one-time, NO FAULT
repair policy

Five year limited warranty
oF 6 PAGES
1OF 6 PAGES
A P PL I C AT I O NS

Cluster Con gurations

Live Music Reinforcement

High-Level AV Playback

Zone Delay and Fill Systems
SPEAKER
PA261

Compact Two-Way Speaker System
PA261
SPEAKER
PA261
oF 6 PAGES
2OF 6 PAGES
Speci cations
System
System
Freq. Range (–10 dB):
Freq. Range (–10 dB):
45 Hz–16 kHz
45 Hz–16 kHz
Freq. Response (–3 dB):
Freq. Response (–3 dB):
60 Hz–15 kHz
60 Hz–15 kHz
Horz. Coverage Angle (–6 dB):
100° averaged
2 kHz to 16 kHz
2 kHz to 16 kHz
Vert. Coverage Angle (–6 dB):
100° averaged
2 kHz to 16 kHz
2 kHz to 16 kHz
Directivity Factor; Q (DI):
8.0 (9.0) averaged
2 kHz to 16 kHz
2 kHz to 16 kHz
System Sensitivity
System Sensitivity
1
:
:
90 dB, 1W @ 1m
90 dB, 1W @ 1m
Rated Maximum SPL:
Rated Maximum SPL:
119 dB, @ 1m
119 dB, @ 1m
System Nominal Impedance:
System Nominal Impedance:
4
4
Ω
System Input Power Rating
System Input Power Rating
2
:
:
200W rms; 800W Peak
200W rms; 800W Peak
Recommended Ampli er
Recommended Ampli er
3
:
:
300W
300W
HF Protection:
HF Protection:
Dynamic
Dynamic
Crossover:
Crossover:
2.5 kHz, 12 dB/Octave
2.5 kHz, 12 dB/Octave
Transducers
Transducers
Low-Frequency:
Two 6 in/152 mm carbon
 ber woofers
 ber woofers
High-Frequency:
Integrated horn, 1 in/25 mm
titanium diaphragm tweeter
titanium diaphragm tweeter
Physical
Physical
Enclosure:
Trapezoidal, 15° side angles,
19 mm multilayered birch
19 mm multilayered birch
Rigging Inserts:
5 points for M10, 4 points for
M8 threaded hardware
M8 threaded hardware
Color:
Color:
Black, scratch resistant paint
Black, scratch resistant paint
Grille:
Grille:
Custom perforated steel grille
Custom perforated steel grille
Input Connectors:
Input Connectors:
Screw terminals
Screw terminals
Dimensions (HxWxD):
Height:
24.0 in/610 mm
Width:
10.0 in/254 mm
Depth:
Depth:
11.5 in/292 mm
11.5 in/292 mm
Net Weight:
Net Weight:
37.4 lb/17.0 kg
37.4 lb/17.0 kg
Options
Options
PA-A1
Forged shoulder M10 eyebolt hardware
Forged shoulder M10 eyebolt hardware
1
Measured on axis in the far  eld with 1 watt (2.0 V rms, 4
Ω
) input and referenced to 1 meter distance
Ω) input and referenced to 1 meter distance Ω
using the inverse square law. Listed sound pressure represents an average from 300 Hz to 3 kHz.
2
rms using 20 Hz to 20 kHz, PN Spectrum, Peak for 2 hours with +6 dB crest factor.
3
Recommended Ampli er is a power capability value that should be taken as a guide.

Compact Two-Way Speaker System
PA261
oF 6 PAGES
3OF 6 PAGES
PA261
Vertical Polars
200 Hz
250 Hz
315 Hz
400 Hz
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
–12–36
0°
500 Hz
630 Hz
800 Hz
1 kHz
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
–12–36
0°
1.25 kHz
1.6 kHz
2 kHz
2.5 kHz
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
–12–36
0°
3.15 kHz
4 kHz
5 kHz
6.3 kHz
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
–12–36
0°
8 kHz
10 kHz
12.5 kHz
16 kHz
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
–12–36
0°
Frequency (Hz)
Attenuation (dB)
20 100 1000 10000 20000
–30
–20
–10
0
10
0 deg
–10 deg
–20 deg
–30 deg
–40 deg
PA261 Vertical Off-Axis Frequency Response (UP)
0 deg
Frequency (Hz)
Attenuation (dB)
20 100 1000 10000 20000
–30
–20
–10
0
10
0 deg
–10 deg
–20 deg
–30 deg
–40 deg
PA261 Vertical Off-Axis Frequency Response (DOWN)
0 deg

oF 6 PAGES
4OF 6 PAGES
PA261
Horizontal Polars
200 Hz
250 Hz
315 Hz
400 Hz
60°
30°
0°
330°
300°
270°
240°
210°
180°
150°
120°
–12
–36
90°
500 Hz
630 Hz
800 Hz
1 kHz
60°
30°
0°
330°
300°
270°
240°
210°
180°
150°
120°
–12
–36
90°
1.25 kHz
1.6 kHz
2 kHz
2.5 kHz
60°
30°
0°
330°
300°
270°
240°
210°
180°
150°
120°
–12
–36
90°
3.15 kHz
4 kHz
5 kHz
6.3 kHz
60°
30°
0°
330°
300°
270°
240°
210°
180°
150°
120°
–12
–36
90°
8 kHz
10 kHz
12.5 kHz
16 kHz
60°
30°
0°
330°
300°
270°
240°
210°
180°
150°
120°
–12
–36
90°Frequency (Hz)
Attenuation (dB)
20 100 1000 10000 20000
–30
–20
–10
0
10
0 deg
10 deg
20 deg
30 deg
40 deg
PA261 Horizontal Off-Axis Frequency Response
Compact Two-Way Speaker System
PA261

Compact Two-Way Speaker System
PA261
oF 6 PAGES
5OF 6 PAGES
Directivity Index
Beamwidth vs. Frequency
Frequency Response is measured on-axis at a distance referenced back to
1m at 1-watt drive. Shown as a half space (2π) environment.
Frequency (Hz)
SPL, 1W/1m (dB) Impedance (ohms)
20
60
70
80
90
100
100
316
10
100 1000 10000 20000
Frequency (Hz)
Vert BW
Horz BW
–6 dB Beamwidth (degrees)
Directivity Index (DI), dB
Directivity Factor (Q)
20
60
10
20
0 0
10
100
1
120
180
240
300
360
100 1000 10000 20000
Frequency (Hz)
20 100 1000 10000 20000
24.02" (610mm)
10.04" (254mm)
4.52" (115mm)
3.14" (80mm)
3.77" (96mm)
11.46" (291mm)
9.13" (232mm)
6.70" (170.2mm)
13˚
15˚
5.0" (127mm)
8.95" (227.5mm)
8.95" (227.5mm)
6.29" (160mm)
15.82" (402mm)
2.75" (70mm)
4.33" (110mm)
1.37" (35mm)
11.46" (292mm)
SIDE
REAR
FRONT
TOP
10.04" (255mm)
24.02" (610mm)

Compact Two-Way Speaker System
PA261
oF 6 PAGES
6OF 6 PAGES
Architects’ and Engineers’ Speci cations
The two-way loudspeaker system shall be self-contained
and consist of the following components: (1) two 6-inch, low-
frequency drivers; (2) a high-frequency section consisting of
a 1-inch titanium dome tweeter; (3) a two-way crossover
network; (4) a vented enclosure.
The two low-frequency transducers shall be cone type loud-
speakers having cone diameters of at least 6 inches/152 mm.
They shall have voice coils of at least 3 inches/76 mm in
diameter and carbon  ber diaphragms. Together they shall
present a nominal impedance load of 4 ohms. Sensitivity
shall be at least 90 dB when measured at 1 m with an input
of 1 watt and the power rating shall be at least 200 watts
(AES), 800 watts peak.
The high-frequency section shall have a compression
driver with a titanium diaphragm of at least 1 inch/25 mm in
diameter. It shall present a constant-impedance load of 8 ohms.
It shall have a nominal coverage pattern of 100° horizontal by
100° vertical.
The system shall be crossed over by an internal, high-
level, passive network having a response of 12 dB/octave.
The nominal crossover frequency shall be 2.5 kHz. The low-
pass section of the network shall have minimum inductance
in series with the low-frequency drivers. A switch shall be
provided to disconnect the crossover network, but not the
high-frequency protection circuit, from the drivers to allow
bi-amp operation.
The enclosure shall be a vented design with an internal
volume of at least 0.83 cubic feet. The vent shall be tuned to
60 Hz. It shall be constructed using 0.75 inch/19 mm, void-
free birch plywood and  nished with black, scratch-resistant
paint. It shall be trapezoidal shaped with 15° angled sides. A
full size, detachable, perforated steel grille,  nished in black
scratch-resistant paint shall be provided. At least 9 reinforced
threaded metal sockets (M10, M8) for attaching mounting
hardware and three eye bolts shall also be provided. The
overall dimensions of the enclosure shall not exceed 24.0 in/
610 mm x 10.0 in/254 mm x 11.5 in/292 mm. Connections
to the loudspeaker shall be screw terminal connectors.
The performance of the two-way loudspeaker system shall
be as follows: long-term power handling, at least 200 watts
rms; peak power handling, at least 800 watts; frequency
response, 60 Hz–15 kHz at –3 dB; maximum SPL, 119 dB
(anechoic–1m); sensitivity, 90 dB SPL (1W/1m anechoic);
–6 dB coverage, measured average 2 kHz–16 kHz, 100°
horizontal by 100° vertical. The two-way loudspeaker system
shall be a model PA261 manufactured by Mackie Designs.
Electronic  les for this product available at:
www.mackie.com
Electronic  les for this product available at:
www.mackie.com
Electronic  les for this product available at:
This Speci cation Sheet
This Speci cation Sheet
PA261.PDF
PA261.PDF
part no. 910-149-10 Rev. C
(continued Architects’ & Engineers’ Specs)
SPEAKER
PA261
www.mackie.com
16220 Wood-Red Road. NE, Woodinville, WA 98072 USA
888.337.7404, fax [phone], [e-mail]
UK
+44.1268.571.212, fax [phone], [e-mail]
UK +44.1268.571.212, fax [phone], [e-mail]
ITALY
+39.0522.354.111, fax [phone], [e-mail]
FRANCE
+33.3.85.46.91.60, fax [phone], [e-mail]
GERMANY
+49.2572.96042.0, fax [phone], [e-mail]
GERMANY +49.2572.96042.0, fax [phone], [e-mail]
Mackie Designs continually engages in research related to product improvement. New material,
production methods, and design re nements are introduced into existing products without notice as a
routine expression of that philosophy. For this reason, any current Mackie product may differ in some
respect from its published description, but will always equal or exceed the original design speci cations
unless otherwise stated. ©2002 Mackie Designs Inc. All rights Reserved. Mackie and the "Running Man"
 gure are registered trademarks of Mackie Designs Inc.
