Macsense Connectivity MPC110 User manual
User Manual
ii
Table of Contents
1. Introduction................................................................................................................1
1.1. About the Product ...........................................................................................1
1.2. Features...........................................................................................................1
1.3. Notice..............................................................................................................2
1.4. Check List.......................................................................................................2
2. Playing System...........................................................................................................4
2.1. Install Battery in the Remote Control.............................................................4
2.2. To Plug in and Switch on................................................................................4
2.3. To Insert Cards................................................................................................4
2.4. Remote controller pad Instruction ..................................................................5
2.5 Appearance.......................................................................................................6
2.6. Operations for Media Player playback (** means default value)...................6
2.7 To Take out the cards .....................................................................................13
3. Troubleshooting .......................................................................................................13
3.1 Known Issues.................................................................................................15
Get user manuals: See SafeManuals.com
User Manual
1
1. Introduction
1.1. About the Product
The new 6-in-1 media player enhances your media presentation or advertising to be
more convenient and brings the immediate enjoyment and entertainment to your life.
The compact, dual slot design allows Compact Flash*1or IBM Micro drive to work
concurrently with the Smart Media, Memory Stick, and Multimedia Card/Secure
Digital card.
1.2. Features
Media player feature:
zCredit Card Style Remote Controller:
zPlayable Format: MPEG1/2/4, JPEG, MP3
Type Support Format
Picture JPEG
Baseline JPEG: maximum resolution is 5120*3840
Progressive JPEG: maximum resolution is 2048*1536
MPEG1-Audio-Layer1
MPEG1-Audio-Layer2
Audio
MPEG1-Audio-Layer3 (MP3)
Video MPEG1 (*.mpg, *.dat)
1The Compact Flash card must be Removable Type.
MPC110 MPC200
Get user manuals: See SafeManuals.com
User Manual
2
MPEG2 (*.vob, *.mpg)
Support Format
Video Data rate 1.0-10.0 Mbit/sec
VGA*2(MPC200 only) 640*480 60Hz
NTSC 720*480 or 704*480；29.97fps interlaced
PAL 720*576 or 704*576；25fps interlaced
Audio MPEG1-Audio-Layer1
MPEG1-Audio-Layer2
MPEG1-Audio-Layer3 (MP3)
Note : The AC3/AAC-audio support is optional. When it is not
enabled, this media player will only play video (no sounds) of the DVD
(*.vob) or MPEG2 file contains AC3/AAC-audio. Besides, We strongly
suggest you use CF card as media storage when playback MPEG2
video.
MPEG4
DivX3.11/4.x/5.x (*.avi) Xvid MPEG4 MS MPEG4 V2/V3(*.avi)
Note:We attached “How to get codec Information” in manual CD for your reference.
zStorage Capacity: Compact Flash card, IBM Micro Drive, SM/ MMC/ SD/ MS card
zPlayback Functions: Play, Stop, Pause, Repeat, Previous/Next Track, Mute, Rotate,
Interval Time, Play List and Media Classification
zAudio: Stereo output 2W
zEnvironmental: Operating temperature: 0 C to 50 C; Relative humidity: 5%-95%,
non-condensing
1.3. Notice
zDo not use abrasive cleaners, waxes or solvents for cleaning, use only a dry or damp,
soft cloth.
zUse only with a high quality, safety-approved,AC/DC power adapter.
1.4. Check List
Before using this media player, please make sure that all the items listed below are present in
your package
Accessory Quantity
Media Player unit 1
DC Adapter 1
AV-RCA Cable 1
S-Video Cable 1
Audio Cable 1
Remote Control with 3V battery 1
2You can switch between Video and VGA output by pressing the latch switch next to VGA connector.
Note that you must reboot the MPC device after output switch.
Get user manuals: See SafeManuals.com
User Manual
4
2. Playing System
2.1. Install Battery in the Remote Control
Insert the battery and match the (+) and (-) on battery to the marks inside the battery
compartment.
First-time use:
Remember to remove the insulating mylar piece form the battery.
Service life of battery:
1. The battery normally last for about one year although this depends on how often and for
what operations the remote control is used.
2. If the remote control unit fails to work even then it’s operated near the player, please
replace the battery.
3. Use a 3V lithium battery.
2.2. To Plug in and Switch on
1. Connect the power cord to the AC adapter.
2. Plug the power connector into the DC IN jack on the rear of the Media Player.
3. Plug the other end of the power cord into a wall power outlet.
zThe suppliedAD adapter is compatible with 100~240VAC power so that it can be
used almost anywhere in the world (thought you may need a plug adapter).
4. You can press on the remote control to put the Media Player into standby. Pressing
again can switch back on.
5. Please connect this Media Player to power and connect it to outer equipments.
Note: If connect it to outer equipment:
Press on the power button of the TV set, and select “video” or “S-video” as the TV input.
Press on the power button of the stereo system if the Media Player has been connected
to a stereo system.
Push the AV/S-video out/in slide switch to AV/S-video out.
2.3. To Insert Cards
Push the card slide into Media Player connector.
This Media Player supports 6 types of flash memory card:
Get user manuals: See SafeManuals.com
User Manual
5
zCompact Flash Card (CF) zSecure Digital Card (SD)
zSmart Media Card (SM) zMulti-Media Card (MMC)
zMemory Stick (MS) zIBM Micro Drive
Make sure that the card clicks into card slot properly. If the card has one or more kinds of data
recorded on it, a menu screen will appear on the screen.
2.4. Remote controller pad Instruction
1 POWER ON/OFF To switch on/off
2 MEDIAPLAYER SETUP To enter media player setup menu
3 ROTATE To rotate the photo
4 INFORMATION/
FOLDER MENU
To view information of the Photo/Music/Video
To call folder menu (under file library page)
5 START SLIDE SHOW
WITH MUSIC
To play the video frame one at a time (when pausing video)
To start photo slide show with music (under photo page)
6 MOVE UP To move upward in media player menu
7 MOVE LEFT To move leftward in media player menu
8 PLAY/SELECT To start playback or confirm selection in media player menu
9 REPEAT To repeat playback
10 MOVE DOWN To move downward in media player menu
11 F.BWD To reverse the playback
12 F.FWD To advance the playback
13 MUTE To mute while playback
14 MENU To select the media player menu options
15 VOL. UP To increase the volume
16 ZOOM IN Press to zoom in the Photo
17 VOL. DOWN To decrease the volume
18 DISPLAY TRANSITION Press to change interval special-effect of photo slide show
19 INTERVAL TIME To set interval time between Photos
20 MOVE RIGHT To move rightward in media player menu
21 PAUSE/RE-START To pause/re-start the playback
22 STOP To stop the playback
23 NEXT PLAYBACK To skip to next Photo/Music/Video
24 PREVIOUS PLAYBACK To skip to previous Photo/Music/Video
Get user manuals: See SafeManuals.com
User Manual
6
2.5 Appearance
Background of start-up
If no media files are stored in the memory card or no memory card is inserted, the background
of media player will appear to be solid black.
Note:
The start-up screen can be customized upon customer’s request.
2.6. Operations for Media Player playback (** means default value)
2.6.1.Setup
Press to enter SETUP MENU – MAIN PAGE screen.
Photo setup:
Press to select PHOTO SETUP and press to enter SETUP MENU – PHOTO
screen.
THUMBNAIL
DIGEST press and to select
thumbnail digest acceleration
function and then press to
implement. This function will
accelerate but decrease resolution
of thumbnail digest.
zON ** is to implement thumbnail
digest acceleration function
zOFF is to turn off thumbnail
digest acceleration function.
TRANSITION
MODE press and to select
transition mode and then press
to implement. This function
will change transition effect speed
zFAST ** is to implement
transition effect in fast speed.
zSLOW is to implement transition
effect in low speed.
ORIENTATION press and to select
orientation function and then
press to implement. This
function will automatically rotate
the pictures based on the
orientation information in the Exif
header(data in JPEG file).
zDEFAULT ** is to implement
orientation function.
zIGNORE is not to rotate the
picture.
No Media Detected
Get user manuals: See SafeManuals.com
User Manual
7
DIGEST STYLE press and to select
thumbnail matrix type and then
press to implement.
z2X2 Matrix is to show thumbnail
in 2x2 matrixes.
z3X3 Matrix ** is to show
thumbnail in 3x3 matrixes.
z4X4 Matrix is to show thumbnail
in 4x4 matrixes.
z5X5 Matrix is to show thumbnail
in 5x5 matrixes.
** Default value
Press and select MAIN PAGE, and then press to back to SETUP MENU – MAIN
PAGE or press to turn off SETUP MENU screen.
Music setup:
Press to select MUSIC SETUP and press to enter SETUP MENU – MUSIC
screen.
REPEAT MODE press and to
select music repeat mode
and then press to
implement.
zONE is repeat one song
zALL ** is to repeat whole
songs
zOFF is to turn off repeat.
** Default value
Press and select MAIN PAGE, and then press to back to SETUP MENU – MAIN
PAGE or press to turn off SETUP MENU screen.
Movie setup:
Press to select MOVIE SETUP and press to enter SETUP MENU – MOVIE
screen. Then press to select preferred function.
REPEAT MODE press and to select video repeat
mode and then press to implement.
zSINGLE is to repeat one.
zONE LOOP is to repeat
one loop.
zCONTINUOUS ** is to
repeat continuously whole
videos.
DIGEST STYLE press and to select thumbnail
matrix type and then press to implement.
(optional function)
z2X2 Matrix is to show
thumbnail in 2x2 matrixes.
z3X3 Matrix ** is to show
thumbnail in 3x3 matrixes.
z4X4 Matrix is to show
thumbnail in 4x4 matrixes.
Get user manuals: See SafeManuals.com
User Manual
8
z5X5 Matrix is to show
thumbnail in 5x5 matrixes.
** Default value
Press and select MAIN PAGE, and then press to back to SETUP MENU –
MAIN PAGE or press to turn off SETUP MENU screen.
Slide show setup:
Press to select SLIDE SHOW SETUP and press to enter SETUP MENU –
SLIDE SHOW screen. Then press to select preferred function.
SLIDE SHOW MODE press and to
select slide show mode of
photo and then press to
implement:
zMANUAL is to display next
photo by pressing
or
zAUTO ** is to display next
photo automatically.
FOLDER REPEAT press and to
select folder repeat mode
and then press to
implement.
zON ** is to repeat photos
of whole folder
zOFF is to turn off repeat.
INTERVAL TIME press and to
select interval time between
photos and then press
to implement.
zThere are four modes to
select: 1/3/5/10 seconds.
zDefault is 3 seconds
TRANSITION press and to
select special effect of photo
transition and then press
to implement.
zThere are 13 modes to
select.*1
zDefault is Cross Fade
AUTO START press and to
select slide show auto start
and then press to
implement.
zON ** is to start slide show
automatically after turning
on power.
zOFF is to turn off slide
show auto start.
** Default value
Note:
Play list is complied by the sequence of the file names in the memory card (types of file do not
influence the sequence). Please modify the file names to the sequence to meet you need. A
sample play list as below table:
Get user manuals: See SafeManuals.com
User Manual
9
Auto Play
Sequence of
Memory Card
CF / Micro Drive
SD / MMC / MS SM
Files in Memory
Card
01_XXXXX
02_XXXXX
03_XXXXX
01_XXXXX
02_XXXXX
03_XXXXX
01_XXXXX
02_XXXXX
03_XXXXX
Press and select MAIN PAGE, and then press to back to SETUP MENU –
MAIN PAGE or press to turn off SETUP MENU screen.
1Available transition mode:
FULL SCREEN TOP -> BOTTOM T/B -> CENTER CENTER -> T/B
BLIND: T -> B LEFT -> RIGHT RIGHT -> LEFT L/R -> CENTER
IMPLODE BLIND: L -> R CROSS FADE RANDOM
Preferences setup:
Press the stop the playback and press to back to menu OSD. Enter the FILE
folder, then press and press to select PREFERENCES and press to
enter --PREFERENCES PAGE-- screen. Then press to select preferred function.
Note:
You may only modify the setting of Preferences when a memory card is not inserted in the card
slot.
TV TYPE zpress and to select television
type and then press to implement.
This Media player supports NTSC, PAL
and MULTI.** SYSTEM.
VIDEO OUTPUT zpress and to select television
output mode and then press to
implement. This Media player supports
S-Video**, YPBPR and RGB.
OSD LANG zpress and to select preferred
language and then press to
implement. This Media Player supports
English** and Traditional Chinese.
OSD MESSAGE zpress and to select OSD
message on or off** while playback and
then press to implement.
Get user manuals: See SafeManuals.com
User Manual
10
SETUP VALUES zYou may re-set the previous settings in
custom setup to the default setting. Press
and to reset all custom
preferences*.
** Default value
2Media Type along with its firmware version
Press and select MAIN PAGE, and then press to back to SETUP MENU –
MAIN PAGE or press to turn off SETUP MENU screen.
Exit setup:
Press to select EXIT SETUP and press or press to turn off SETUP MENU
screen.
2.6.2.MenuSelect
Press and menu screen will appear.
Press to select card if multi cards inserted.
Press to select PHOTO/MUSIC/VIDEO/FILE page and press to enter.
Note:
No matter on what kind of screen, press will stop playback and return to the root
menu screen.
If no card inserted, the display will appear “NO MEDIADETECTED”.
When appears while a button is being operated, it means that correspond operation
is prohibited by the Media Player.
2.6.3. Playback
On PHOTO/MUSIC/VIDEO/FILE page, press to select preferred data and then
press to start playback.
Note:
is defined as enter key.
zOn PHOTO page, press will start playback of photo with music if MP3 data contented in
card.
Media Type Current Firmware
version
Box only (MPEG1/2/4) DEFAULT VCxx
x
means version
Get user manuals: See SafeManuals.com
User Manual
11
zWhen playing video, press will play the video frame one at a time.(optional function)
zAdjust the volume: using the remote control or OSD board button -/+.
This Media player supports only JPEG-PHOTO, MP3-MUSIC and MPEG1, 2, 4–VIDEO
format.
2.6.4.Pause
Press once during playback to pause the slide show/music/video. To return to normal
playback just need to press .
Note: Pause key is defined as Play/ Pause key which toggle between those two functions.
2.6.5.Stop
Press to stop playback.
Note:
When slide show playing, press and the Media player will bookmark this stopping
point of these photos contented in the card. Press will start playback from the
last stopping point.
2.6.6.MutetheMediaPlayer
Press button during playback.
When “MUTE” appears on the screen, this Media player is mute. To resume the sound, press
the mute button until “MUTE OFF” appears on the screen.
2.6.7.NextorPrevious
On PHOTO/MUSIC/VIDEO/FILE page, press /for switch to next/previous page.
When playing photo slide show/music/video, press or will switch to next item and press
or will switch to previous item.
2.6.8. Rapid Advance or Reverse
Press or during playback.
Press or to resume normal playback.
2.6.9.Information
Under PHOTO/MUSIC/VIDEO page, press to display the information of the playback.
Photo information: file name, file size, resolution and date
Music information: elapsed time, file name, artist, total time, format of music type and
equalizer.
Video information: elapsed time, file name, file size, total time, file created date.
Get user manuals: See SafeManuals.com
User Manual
12
2.6.10.FileModification
Under FILE page, press and a dialog with modification will pop up on the screen.
COPY
DELETE
RENAME
NEW FOLDER
PROPERTIES
CANCEL
COPY Press to select COPY and then press to enter COPY
MODE.
Press to select media file and press to confirm copy.
(Pressing can move target right to memory card column and press
to change objective memory card or sub-folder.)
Press to exit COPY MODE.
DELETE Press to select DELETE and then press .
Select YES and press to confirm delete.
RENAME Press to select DELETE and then press to enter VIRTUAL
KEYBOARD.
Press and to key-in preferred file name.
Select OK and press to finish rename.
VIRTUAL KEY BOARD
0 1 2 3 4 5 6 7 8 9
_ - # A B C D E F
G H I J K L M N O P
Q R S T U V W X Y Z
OK ERASE CANCEL
NEW FOLDER Press to select NEW FOLDER and then press to enter
VIRTUAL KEYBOARD.
Press and to key-in preferred folder name.
Select OK and press to finish naming new folder.
Get user manuals: See SafeManuals.com
User Manual
13
PROPERTIES
(Details of
media file)
Press to select PROPERTIES and then press to show
details of this media file.
Press to exit PROPERTIES.
2.6.11.Rotate
When playing playback of photo, press once to rotate the photo 90 degree clockwise.
2.6.12.IntervalTime
When playing playback of photo, press once to set interval time between photos.
The time of display interval (1, 3, 5, 10 sec.) changes with each press on the button.
2.6.13.RepeatViewing
Press to repeat during playback.
Press once: REPEAT ON
Press twice: REPEAT OFF (repeat cancelled)
Note:
You can select repeat mode in SETUP MENU—SLIDE SHOW/ MUSIC/ VIDEO
2.7 To Take out the cards
1. If the playback is playing, press to stop it.
2. Take out the card.
3. Troubleshooting
Before requesting service for this Media Player, check the chart below for a possible cause of
the problem you are experiencing. Some simple checkups or a minor adjustment on your
part may eliminate the problem and restore proper operation.
Mute, Volume control, Fast Forward
under FILE menu
zFile menu is for previewing only; therefore,
all control functions, such as volume and
mute, will not work unless enter key is
pressed to get into a play mode.
No power
zInsert the power plug securely into the
power outlet.
zCheck if the on/off button on the right of the
Media Player is set to on.
zCheck if no power at theAC outlet by
plugging in another appliance for a test.
The Media Player does not start playback
when play is pressed
zCondensation has formed: wait about 1 to
2 hours to allow the Media Player to dry
Get user manuals: See SafeManuals.com
User Manual
14
out. Check if the Media Player is
defective by trying another card.
The Media Player starts playback but
stops immediately
zThe card may be dirty and may require
cleaning.
zEnsure that the card is installed with proper
situation position.
No picture zEnsure that the equipment is connected
properly.
zCheck if outer equipment is on.
No sound zEnsure that the equipment is connected
properly.
zIf using a hi-fi amplifier, try another sound
source.
zCheck the volume adjustment.
zCheck the audio format,AAC and AC3
audio codec are not supported.
Distorted sound zEnsure that the input settings for stereo
system are proper.
zNo sound is heard during still picture
(pause).
No audio at digital output zCheck the digital connections.
zCheck if the audio format of the selected
audio language matches your receiver
capabilities.
Picture is distorted during rapid advance
or rapid reverse
zThe picture will be somewhat distorted at
times: this is normal.
No rapid advance (or rapid reversed)
playback
zSome video may have sections that
prohibit rapid advance (or rapid reverse).
No operations perform with the remote
control
zCheck the battery is installed with the
correct polarities (+and-).
zThe battery is depleted: replace them with
new ones.
zPoint the remote control unit at the remote
control signal sensor and operate.
Operate the remote control unit at a
distance but no more than 7 meters from
the remote control signal sensor.
zRemove the obstacles between the remote
Get user manuals: See SafeManuals.com
User Manual
15
control unit and remote control signal
sensor.
No key operation (by the Media Player AC
power and / or the remote control) is
effective
zTurn the unit off and then back to on.
Alternatively, turn off the unit,
disconnect the cord and then
re-connect it. (The player may not be
operating properly due to lightning,
static electricity or some other external
factor.)
3.1 Known Issues
Issue 1: When a movie is playing and press fast forward, the following movie will play at the
normal speed but without sound.
Issue 2: Under MUSIC selection menu the Next/Back chapter key becomes stop key.
Get user manuals: See SafeManuals.com
This manual suits for next models
1
Table of contents
