TracXP™ TXP-WTA
Wireless Sensor Transmitter
Instruction Manual

TXP-WTA_Instruction_Manual_(Rev1.3)
REV – 1.3 [34-2900-0207-4 ] 2 |Page
1 Safety Information.................................................................................................................................................... 5
1.1 Read Before Installation and Operation........................................................................................................... 5
1.2 WARNINGS ....................................................................................................................................................... 6
2.1 Introduction...................................................................................................................................................... 7
2.2 Key Features ..................................................................................................................................................... 7
2.3 Ratings and Certifications................................................................................................................................. 7
2.4 Specifications.................................................................................................................................................... 7
2.4.1 Input Power Options ................................................................................................................................ 7
2.4.2 Sensor Input.............................................................................................................................................. 7
2.4.3 Standard Output....................................................................................................................................... 7
2.4.4 Display ...................................................................................................................................................... 7
2.4.5 Ambient temperature............................................................................................................................... 8
2.4.6 Humidity ................................................................................................................................................... 8
2.4.7 Wireless Performance .............................................................................................................................. 8
2.5 Sensor Options ................................................................................................................................................. 9
3 Installation Instructions.......................................................................................................................................... 10
3.1 System Diagrams ............................................................................................................................................10
3.1.1 External system Diagram........................................................................................................................ 11
3.1.2 Transmitter Diagram .............................................................................................................................. 12
4 Product Description................................................................................................................................................13
4.1 LCD Readouts..................................................................................................................................................13
4.1.1 LCD Status Icons ..................................................................................................................................... 13
4.2 RF Broadcast Cycle and Conserving Battery Life ............................................................................................15
4.3 Battery Board..................................................................................................................................................16
4.4 Display / Radio Board ..................................................................................................................................... 16
5 Installation Instructions.......................................................................................................................................... 18
5.1 Ratings and Certifications...............................................................................................................................18
5.2 Sensor Location .............................................................................................................................................. 18
5.3 Mounting the Enclosure ................................................................................................................................. 18
5.3.1 Magnetic Mount Option......................................................................................................................... 19
5.4 Antenna Transmission Range ......................................................................................................................... 20
5.4.1 Antenna Selection & Location ................................................................................................................21
5.4.2 System Grounding ..................................................................................................................................21
6 Operating Instructions............................................................................................................................................22
6.1 Using the Magnetic Keypad............................................................................................................................22
6.2 Cycling Sensor Transmitter Power On / Off ................................................................................................... 22
6.3 Alarm Operation.............................................................................................................................................25
6.3.1 Understanding Fail Alarm Operation...................................................................................................... 25
6.3.2 Low Battery Condition............................................................................................................................ 25
6.4 Smart Sensor Modules ................................................................................................................................... 26
6.4.1 Sensor Separation Kit ............................................................................................................................. 27
7 Setup Menus........................................................................................................................................................... 28
7.1 Menu Structures.............................................................................................................................................28
7.2 Main Menu .....................................................................................................................................................28

TXP-WTA_Instruction_Manual_(Rev1.3)
REV – 1.3 [34-2900-0207-4 ] 3 |Page
8 Channel Setup Menus.............................................................................................................................................30
8.1 Channel Enable / Inactive............................................................................................................................... 30
8.2 Configure Readout.......................................................................................................................................... 30
8.2.1 Measurement Name...............................................................................................................................31
8.2.2 EUnit .......................................................................................................................................................31
8.2.3 Zero (0%)................................................................................................................................................. 31
8.2.4 SPAN (100%) ........................................................................................................................................... 31
8.2.5 Decimal Points ........................................................................................................................................31
8.2.6 CAL Span Val ........................................................................................................................................... 31
8.2.7 Readout Dead Band................................................................................................................................ 31
8.2.8 Track Negative........................................................................................................................................ 31
8.2.9 Backup Config ......................................................................................................................................... 31
8.2.10 Restore Config ........................................................................................................................................ 31
8.2.11 Load Defaults..........................................................................................................................................31
8.3 Alarm Settings ................................................................................................................................................32
8.3.1 Set Point .................................................................................................................................................32
8.3.2 Dead Band ..............................................................................................................................................32
8.3.3 Low Trip .................................................................................................................................................. 32
8.4 Sensor Information.........................................................................................................................................33
8.5 Technicians Only............................................................................................................................................. 33
8.5.1 Set Gain to Unity (TECHNICIANS ONLY!) ................................................................................................ 34
8.5.2 PreAMP Gain Adjust (PGA) (TECHNICIANS ONLY!)................................................................................. 34
8.5.3 ZERO CAL VALUE (TECHNICIANS ONLY!).................................................................................................35
8.5.4 RAW MIN / MAX COUNTS (TECHNICIANS ONLY!) .................................................................................. 35
8.5.5 RF LINK TEST (TECHNICIANS ONLY!).......................................................................................................35
8.5.6 Sensor Comp Table (TECHNICIANS ONLY!)............................................................................................. 35
8.6 Packet Count................................................................................................................................................... 36
8.7 Sensor Temp Reading..................................................................................................................................... 36
9 TXP-WTA Device Setup Menus............................................................................................................................... 37
9.1 RF Link Setup .................................................................................................................................................. 37
9.1.1 Network ID..............................................................................................................................................37
9.1.2 RMT ID (Remote ID)................................................................................................................................ 38
9.1.3 *Wakeup Timer ...................................................................................................................................... 38
9.1.4 *TX Retries..............................................................................................................................................38
9.1.5 *TX Config Time...................................................................................................................................... 39
9.1.6 RF Link Status.......................................................................................................................................... 39
9.1.7 *RF HANDSHAKING (900 MHz MODELS ONLY) ......................................................................................39
9.1.8 *RF LINK.................................................................................................................................................. 40
9.1.9 *TX POWER (900 MHz MODELS ONLY) .................................................................................................. 40
9.1.10 TX CNT (TRANSMIT COUNTER) ...............................................................................................................40
9.2 Clock, Warm up and CAL Purge Delays...........................................................................................................40
9.2.1 Warm Up Timer ......................................................................................................................................41
9.2.2 CAL Purge Timer ..................................................................................................................................... 41
9.3 System Security ..............................................................................................................................................41

TXP-WTA_Instruction_Manual_(Rev1.3)
REV – 1.3 [34-2900-0207-4 ] 4 |Page
9.4 LCD Contrast Adjust........................................................................................................................................42
9.5 Turn Power Off ...............................................................................................................................................42
9.6 Reset Range Icon ............................................................................................................................................ 42
10 TracXP Antenna Selection ..................................................................................................................................44
10.1 Antenna Selection ..........................................................................................................................................44
10.1.1 Dipole and Collinear Antennas ...............................................................................................................44
10.1.2 Yagi Antennas ......................................................................................................................................... 45
10.1.3 Mounting Near Other Antennas............................................................................................................. 46
10.1.4 Coax Cables.............................................................................................................................................46
10.2 Surge Protection & Grounding .......................................................................................................................46
10.2.1 Antenna Grounding ................................................................................................................................47
10.2.2 Connection to Other Equipment ............................................................................................................ 47
11 TXP-WTA Legacy Mode....................................................................................................................................... 48
12 Optional Add-ons................................................................................................................................................ 49
13 Appendix A – Table of Figures ............................................................................................................................ 50
14 Macurco Gas Detection Product limited warranty............................................................................................. 52
Technical Support Contact Information...................................................................................................................... 52
General Contact Information ...................................................................................................................................... 52

TXP-WTA_Instruction_Manual_(Rev1.3)
REV – 1.3 [34-2900-0207-4 ] 5 |Page
1Safety Information
1.1 Read Before Installation and Operation
IMPORTANT
AVERTISSEMENT: Lire attentivement les instructions avant de metre en marche.
CAUTION: FOR SAFETY REASONS THIS EQUIPMENT MUST BE OPERATED AND SERVICED BY QUALIFIED PERSONNEL
ONLY. READ AND UNDERSTAND INSTRUCTION MANUAL COMPLETELY BEFORE OPERATING OR SERVICING.
ATTENTION: POUR DES RAISONS DE SÉCURITÉ, CET ÉQUIPEMENT DOIT ÊTRE UTILISÉ, ENTRETENU ET RÉPARÉ
UNIQUEMENT PAR UN PERSONNEL QUALIFIÉ. ÉTUDIER LE MANUE D’INSTRUCTIONS EN ENTIER AVANT D’UTILISER,
D’ENTRETENIR OU DE RÉPARER L’ÉQUIPEMENT.
CAUTION: KEEP EXPLOSION PROOF COVER TIGHT WHILE CIRCUITS ARE ALIVE.
ATTENTION: GARDEZ LE COUVERCLE ANTI-EXPLOSION SERRÉ PENDANT QUE LES CIRCUITS SONT VIVANTS.
CAUTION: USE SUPPLY WIRES SUITABLE FOR 40°C ABOVE SURROUNDING AMBIENT.
ATTENTION: UTILISER DES FILS D'ALIMENTATION QUI CONVIENNENT A UNE TEMPERATURE DE 40°C AU-DESSUS DE
LA TEMPERATURE AMBIANTE.
WARNING - EXPLOSION HAZARD
SUBSTITUTION OF COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS I, DIVISION 2
BATTERIES MUST ONLY BE CHANGED IN AN AREA KNOWN TO BE NON-HAZARDOUS.
AVERTISSEMENT - RISQUE D'EXPLOSION
LA SUBSTITUTION DES COMPOSANTS PEUT PROVOQUER UNE ADAPTATION À LA CLASSE I, DIVISION 2.
LES BATTERIES NE DOIVENT ÊTRE CHANGÉES QUE DANS UNE ZONE QUI N'EST PAS DANGEREUSE.
WARNING- EXPLOSION HAZARD
DO NOT CONNECT OR DISCONNECT WHEN ENERGIZED UNLESS THE AREA IS KNOWN TO BE NON-HAZARDOUS.
AVERTISSEMENT - RISQUE D'EXPLOSION
NE PAS BRANCHER OU DÉBRANCHER LORSQU'IL EST SOUS TENSION, SAUF SI LA ZONE EST CONNUE POUR ÊTRE NON
HASARDEUX.

TXP-WTA_Instruction_Manual_(Rev1.3)
REV – 1.3 [34-2900-0207-4 ] 6 |Page
1.2 WARNINGS
•Calibrate TXP-WTA Sensor Transmitters that communicate to the TracXP wireless monitoring system with a
known concentration of gas at start-up. Check calibration on a regular schedule (at least every 90 days).
More frequent inspections are encouraged to spot problems such as dirt, oil, paint, grease or other foreign
materials on the sensor filter.
•Do not paint any part of the TXP-WTA Sensor Transmitter or corresponding components.
•Do not use the TXP-WTA Sensor Transmitter if any enclosure is damaged or cracked or has missing
components.
•Make sure covers, internal boards, and antenna connections are securely in place before operation.
•Use only approved Smart Sensor Modules that are compatible with the TXP-WTA Sensor Transmitter.
•Periodically test for correct operation of the system’s alarm events by exposing the TXP-WTA Sensor
Transmitter to a known concentration of gas above the High Alarm set-point.
•Do not expose TracXP devices to electrical shock or continuous severe mechanical shock.
•Protect TracXP devices from dripping liquids and high-power sprays.
•Use only for applications described within this manual.

TXP-WTA_Instruction_Manual_(Rev1.3)
REV – 1.3 [34-2900-0207-4 ] 7 |Page
2Product Overview
2.1 Introduction
The TracXP Wireless TXP-WTA Sensor Transmitter is available with 900 MHz or 2.4GHz frequency to meet your
communication requirements. The TXP-WTA Sensor Transmitter can be configured in single or dual sensor
configurations to allow redundant readings for critical operations or monitoring combination gases. The TXP-WTA
Sensor Transmitter’s smart sensors allow users to easily change sensor types. The TXP-WTA Sensor Transmitter also
supports integral and remote sensor options. Intuitive non-intrusive magnetic interface makes set up and
programming quick and easy. Power options include standard 3.6V disposable Lithium battery for portability or a 12-
24V DC power option for longer term or permanent installations.
2.2 Key Features
•900 MHz or 2.4 GHz Radios
•Operates on one “D” size Lithium Battery (Standard)
•Optional 12-24V DC Power Board
•4-20 mA Input option
•Dual Sensor Capable w/ Integral & Remote Sensor Options
•Magnetic Mount Option
•Hazardous Location Rating
•3 Alarm Levels, 1 Fault, 1 Comm Status
•Two Password Levels for Security
•Multiple Antenna Options
2.3 Ratings and Certifications
•FCC 15.247 & Industry Canada (IC),
•CSA Certified for Class 1, Division 2
2.4 Specifications
The following section provides detailed information regarding specifications of the TXP-WTA Sensor Transmitter.
2.4.1 Input Power Options
•Disposable, Internal D-Cell Lithium Battery (Standard)
•Optional 12 - 24V DC Board
2.4.2 Sensor Input
•Single or Dual Electrochemical or Infrared
•4-20 mA Input Option
2.4.3 Standard Output
•Frequency-Hopping Spread Spectrum (FHSS) Wireless Modem w/ Data Encryption
•900MHz Power Adjustable From 10mW to 1.0 watt/0-30dBm
•2.4GHz Output Set At 125mW/21dB
2.4.4 Display
•64 x 128 Pixel LCD w/ One-Hour Trend
•Bar Graph & Engineering Units Display

TXP-WTA_Instruction_Manual_(Rev1.3)
REV – 1.3 [34-2900-0207-4 ] 8 |Page
2.4.5 Ambient temperature
•-40°F to 131°F (-40°C to +55°C)
•*See Smart Sensor Specifications
2.4.6 Humidity
•0-95% RH Non-Condensing
2.4.7 Wireless Performance
•2.4GHz freq. range: 2400 - 2483.5 MHz w/ 42 hops
•2.4GHz indoor range: Up to 1500 feet w/ 7dBi collinear antenna
•2.4GHz outdoor RF LOS (Line of Site) range: Up to 2 miles with high-gain antenna
•900MHz frequency range: 902 - 928 MHz w/ 50 hops
•900MHz indoor/urban range: Up to 3000 feet w/ 2dBi dipole antenna
•900MHz outdoor RF LOS range: Up to 2-3 miles w/ high-gain antenna
2.4.7.1 Power Consumption (900 MHz Models)
2mA during “sleep” mode, 40mA while receiving beacon, up to 1 amp during 1 watt “transmit” mode. Transmit
power may be set from 10mW to 1 watt (see Section 8.1.9)
NOTE: 1-watt operation is not recommended or necessary for most applications as it can cause an unnecessary load
on the battery thereby significantly reducing battery life.
Power Consumption (2.4 GHz Models)
2mA during “sleep” mode, 170mA during 125mW broadcasts.
2.4.7.2 Maximum Transmit (TX) Power (900 MHz Models (EIRP based on a 2dBi gain antenna))
30dBm at highest 1W power setting. Transmit power may be set from 10mW, 200mW, 400mW and 1 watt (see
Section 8.1.9)
NOTE: 1-watt operation is not recommended or necessary for most applications as it can cause an unnecessary load
on the battery thereby significantly reducing battery life.
2.4.7.3 Maximum Transmit (TX) Power (2.4 GHz Models (Conducted; no antenna))
Transmit power is fixed at 125mW (21dBm)
2.4.7.4 Receive (TX) Sensitivity (900 MHz Models)
100 dBm
2.4.7.5 Receive (TX) Sensitivity (2.4 GHz Models)
95 dBm
2.4.7.6 Radio Frequency (900 MHz Models)
Hopping occurs between 902 – 928 MHz
2.4.7.7 Radio Frequency (2.4 GHz Models)
Hopping occurs between 2400 – 2483.5 MHz
2.4.7.8 Memory
Non-volatile memory retains configuration values in the event of power outages.

TXP-WTA_Instruction_Manual_(Rev1.3)
REV – 1.3 [34-2900-0207-4 ] 9 |Page
2.5 Sensor Options
Gas
Range
Ammonia
NH
3
Arsine
AsH
3
Carbon Dioxide
CO
2
(IR)
Carbon Monoxide
CO
Chlorine
CI
2
Combustibles
(IR)
Ethylene Oxide
C
2
H
4
O
Formaldehyde
CH2O
Hydrogen
H
2
Hydrogen Chloride
HCI
Hydrogen Cyanide
HCn
Hydrogen Fluoride
HF
Hydrogen Sulfide
H
2
S
Nitric Oxide
NO
Nitrogen Dioxide
NO
2
Oxygen
O
2
Ozone
O
3
Phosphine
PH3
Sulfer Dioxide
SO
2
Vinyl Chloride
C
2
H
3
CI
4-20 mA input option
--
--
*For additional gas / sensor options, please contact your TracXP representative

TXP-WTA_Instruction_Manual_(Rev1.3)
REV – 1.3 [34-2900-0207-4 ] 10 |Page
3Installation Instructions
3.1 System Diagrams
Refer to the following diagrams for identification of system components that may be referred to in this manual.
Figure 3-1 – Complete Transmitter (Single Sensor, Dual Sensor & Poly Versions)
