made for movement NF-Walker 2 User manual

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 1 of 56
User´s manual
Orthopedic standing and walking
brace system

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 2 of 56
User’s manual for NF-Walker 2
Content:
1. Introduction ................................................................................................................................4
2. Intended use ...............................................................................................................................4
2.1 Contraindications................................................................................................................4
3. Symbols used in the user manual ...............................................................................................4
4. Warnings .........................................................................................................................5
5. Technical description ..................................................................................................................7
5.1 Undercarriage (chassis):......................................................................................................8
5.2 Brace: ................................................................................................................................10
5.3 Adjustment range .............................................................................................................12
5.4 Guide straps/elastics.........................................................................................................13
6. Adjustment to a user ................................................................................................................14
6.1 Fitting the NF-Walker 2 to the user: .................................................................................15
7. How to adjust............................................................................................................................16
7.1 Damper..............................................................................................................................16
7.2 Height of column...............................................................................................................17
8. Using NF-Walker 2 ....................................................................................................................18
8.1. Duration of use .................................................................................................................18
8.2. Getting the user into NF-Walker 2....................................................................................18
8.3. Shoes.................................................................................................................................18
8.4. Preparatory steps..............................................................................................................18
8.5. Getting the user into the NF-Walker 2 (without lifting straps).........................................19
8.6. Getting the user into the NF-Walker 2 (with lifting straps) ..............................................22
8.7. How to transfer the user out of the NF-Walker 2.............................................................23
a. Without lifting straps ........................................................................................................24
b. With lifting straps..............................................................................................................24
8.8. Release the user from the brace.......................................................................................25
8.9. Transfer the user into the NF-Walker 2 –with a seat.......................................................26
8.10. Transfer the user out of the NF-Walker 2 –With a seat...................................................28
9. Individual adjustments and aftercare.......................................................................................30
9.1. Individual adjusting...........................................................................................................30
10. Transport...................................................................................................................................31
10.1. Assembling........................................................................................................................34
11. Technical information ...............................................................................................................35

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 3 of 56
11.1 Data and dimensions for the NF-Walker 2........................................................................35
12. Extra equipment .......................................................................................................................36
12.1 Knee anti-overstretch .......................................................................................................36
12.2 Lifting straps......................................................................................................................37
12.3 Ring clamps .......................................................................................................................38
12.4 Abduction joint..................................................................................................................39
12.5 Dynamic knee stretcher ....................................................................................................40
12.6 Brace rotation system.......................................................................................................41
12.7 Head-support ....................................................................................................................42
12.8 Side bars............................................................................................................................43
12.9 Guide bars 70 and 90 cm ..................................................................................................44
12.10 Seat ...................................................................................................................................45
12.11 Steering .............................................................................................................................46
12.12 Table..................................................................................................................................47
12.13 Removable handle and table bracket ...............................................................................48
12.14 Escort handle.....................................................................................................................49
12.15 Support handle..................................................................................................................50
13. Tests and approvals for NF-Walker 2........................................................................................51
14. Waste disposal ..........................................................................................................................51
15. Cleaning and maintenance .......................................................................................................51
a. Cleaning.............................................................................................................................51
b. Maintenance .....................................................................................................................52
16. Reuse.........................................................................................................................................53
17. Warranty ...................................................................................................................................53
18. Declaration of conformity.........................................................................................................54

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 4 of 56
1. Introduction
Congratulations on choosing the NF-Walker 2 aid. Every human has the right to movement. At
Made for Movement, we make it our mission to offer opportunities for movement to people with
restricted movement or who are only able to move on their own to a limited extent. NF-Walker 2
offers users with limited ability to stand or walk independently the opportunity of dynamic standing,
walking and movement. NF-Walker 2 can be adjusted to suit the needs of most users. These
instructions provide an introduction to the use of the NF-Walker 2.
2. Intended use
NF-Walker 2 is a helping aid intended to allow dynamic standing, walking and movement. NF-Walker
2 comes in two sizes: XS (extra small) and S (small). Please refer to chapter 5 for more information
about the different sizes.
2.1 Contraindications
The user’s therapist, doctor or the person prescribing NF-Walker 2 is in all cases responsible
for evaluating any risks and benefits associated with using the product.
The following should be observed in order to assess possible contraindications:
Fixed contractures
Instable bone structure
Open wounds on the skin in areas of the body that come into contact with parts of
NF-Walker 2
Circulatory disorders
Respiratory disorders
Heart complaints
Epilepsy
Osteoporosis
3. Symbols used in the user manual
This symbol means that the following text should be read careful
This symbol indicates that the following text contains useful tips

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 5 of 56
4. Warnings
NF-Walker 2 must only be used when the user is under the supervision of an adult,
responsible person
NF-Walker 2 is a personal helping aid and must not be used by persons for whom it has not
been specially adjusted for
NF-Walker 2 must not be adjusted by persons not qualified to do so
NF-Walker 2 must not be used without regular follow-ups by Made for Movement or its
representatives
NF-Walker 2 must only be used with shoes compatible with the shoe-clips belonging to NF-
Walker 2’s brace
NF-Walker 2 must be stored in such a way that children or unauthorised persons cannot use
it as a toy or tamper with the settings
NF-Walker 2 may only be used and stored in dry environments. Not in wet rooms as
showers, washing areas, moist environments etc.
During transport, the NF-Walker 2 must be appropriately secured to avoid transport damage
or damage to the interior of the vehicle or persons in the car
Belts, straps, paddings and upholsters are flammable!
Control the surface-temperature of the NF-Walker 2 before use. NF-Walker 2 may be
affected in temperature by heaters, direct sunlight etc.
There are squeeze hazards for fingers around the joints of the brace during handling and
use. Please be careful and aware of where the user is placing his/hers hands and where you
as an assistant are holding on to the NF-Walker’s brace.

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 6 of 56
Warnings –continued
NF-Walker 2 is certified for both indoor and outdoor use
No modification of this equipment is allowed. Modifications may lead to dangerous
situations and product breakdown
Do not fit other accessories to the product than what is described in this user’s
manual chapter 12. This will lead to non-compliance of the certification
belonging to the NF-Walker 2
Make sure that there is always a piece of clothing between the user’s skin and places
on the body that are in contact with the product. This is important to minimise the
risk of allergic reactions and to prevent blisters during use.

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 7 of 56
5. Technical description
Picture no. 1 Complete NF-Walker 2 size XS with small kit Picture no. 2 Complete NF-Walker 2 size S
The NF-Walker 2 is delivered in two sizes:
XS extra small user size 70* –110cm, max 30 kg
S small user size 100 –140**cm, max 40 kg
* For the smallest users, a small kit with smaller wheels is necessary.
** Subject for individual evaluation
The NF-Walker 2 consist of two main parts: the undercarriage and the brace-system
The NF-Walker 2 is an individual adapted helping aid. Before delivery of the product, the actual user
will have to be measured and the measures sent to Made for Movement for initial adjustment. This
initial adjustment will adapt the NF-Walker 2 to roughly fit the actual user. A consultant from Made
for Movement or its representatives, will make the last adjustments relative to the user and make
sure she/he is having the best possible fitting of the product.
Serial number:
Each NF-Walker 2 is having its own unique serial number. This number is located at the back, under
the rear frame.

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 8 of 56
5.1 Undercarriage (chassis):
Picture no. 3 NF-Walker 2 undercarriage (chassis) (this picture shows the undercarriage of NF-Walker 2 size S)
The undercarriage has an H-shape. The front axle (12) and rear axle (18) are connected by the main
frame (10). When a user is using the NF-Walker 2, she/he will have one leg at each side of the main
frame (10), between the front axle (12) and the rear axle (18). Having the main frame (10) between
the user’s legs will prevent the user of crossing hers/his legs while using the NF-Walker 2.
The undercarriage has four wheels (8 and 16) with 185mm diameter. The rear wheels (8) are fixed in
direction, and a brake (7) can be activated to prevent the undercarriage from rolling. The front
wheels (16) can freely rotate 360° or be locked in forward direction using the direction lock (15). The
rear wheels (8) are assembled to the rear axle (18) which is having a fixed width. The front wheels
(16) are connected to the front axle (12) which is fixed in width.
1 Fix plate
2 Column
3 U-tube
4 Roller
6 Damper
7 Brake
17 Trailing arm
8 Rear wheel
9 U-tube clamp
5 Height setting
screw
13 Front axle frame part
12 Front axle
11 Front roller
14 Wall guard
16 Front wheel
18 Rear axle
10 Main frame
15 Direction
lock

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 9 of 56
The front axle (12) is equipped with horizontal wheels (14) that will function as wall guards if the
undercarriage is colliding into furniture or walls.
The rear axle (18) is connected to a trailing arm (17) which is suspended by a damper (6). The
damper (6) is adjustable in length and stiffness. The damper (6) can be delivered with four different
configurations:
soft
medium soft
medium hard
hard
The front axle (12) is connected to the front axle frame part (13) which is clamped in place in the
main frame (10). Underneath the front axle (12), there is two rollers (11) for guidance of the guide
straps/elastics. The front axle of the NF-Walker 2 can be delivered in two widths. The front axle
frame part (13) is adjustable in length totally 110mm. The main frame (10) is the connection point
for all forces picked up by the undercarriage and is connecting the different parts of the
undercarriage together.
A column (2) with a fix plate (1) is placed vertically in the main frame (10). The fix plate (1) is the
fixation point for the brace-system. The column (2) is height adjustable. A height setting screw (5) is
securing the height of the column (2) together with the clamping done by the main frame (10). The
column (2) has a U-tube clamp (9) placed between the height setting screw (5) and the fix plate (1).
The U-tube clamp (9) secures the position of the U-tube (3).
The U-tube (3) is fitted with two rollers (4) for guide straps/elastics.

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 10 of 56
5.2 Brace:
Picture no. 4 NF-Walker 2 brace
The brace has contact with the user’s body at the chest belt (1), hip belt (10), calf bows (7) and at
both of the user’s shoes. The brace system has a chest belt (1), securing the upper body of the user.
This belt is possible to adjust in width. The position of the user’s upper body relative to the Thorax
steel (2) can also be adjusted with the chest belt (1).
The Thorax steels (2) are suspending the fixation point for the chest belt (1) and are adjustable in
height. The Thorax steels (2) are fixed to the hip bows (4).
The Hip bows (4) are connected to a hip plate (3) and are adjustable in width. There are 2 different
sizes of the hip bows (4) to choose among in order to fit the brace to the user.
The hip plate (3) has upholstery in the front where it can come in contact with the user. At the back
there are clamps that allows adjustment of the width of the hip bows (4) and are making a steady
fixation point for the hip bows (4). The hip plate (3) is equipped with a tongue (14) that can be
connected to the undercarriages fix plate (please refer to chapter 5.1, pos. no. 1).
1 Chest belt
3 Hip plate
4 Hip bow
5 Hip joint
6 Ring
7 Calf bow
8 Ankle joint
9 Shoe-clip
2 Thorax steel
10 Hip belt
11 Brace
12 Knee joint
13 Ring
17 Wing nut
15 Snap hook
14 Tongue
16 Foot steel

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 11 of 56
The hip bows (4) are the fixation point for the hip belt (10) that is adjustable in width and depth. The
hip belt (10) will secure the user’s pelvic and will also place the user correct in the brace relative to
the hip joints (5) turning point.
Hip joints (5) are placed at the outer of the hip bows (4), carrying each of the leg bracings. Each leg is
built up of one hip joint (5), one knee joint (12) and one ankle joint (8).
The braces (11) connecting the joints allows telescopic adjustment of the length of the brace.
At each leg of the bracing, there are two rings (6 and 13). There is one at the knee joint (12) and one
at the ankle joint (8). These are the connection point for the snap hook (15) of the guide strap/elastic
that will run over the rollers at the front and back of the undercarriage. The height of these ring
clamps (6 and 13) can be adjusted by moving the rings to the next free hole.
Underneath the knee joint (12), there is a calf bow (7) for fixation of the user’s calf. The calf bows (7)
are equipped with straps, securing the user’s calf and are upholstered for comfort.
At each of the ankle joints (8), there is a foot steel (16). This foot steel is the bracket for assembling
the user’s shoe to the brace.
Shoe-clips (9) for fixation of the user’s shoes are attached to the foot steel (16). A wing nut (17) is
securing this shoe-clips (9) position. There are several different shoe-clips (9) to choose among. The
shoe-clip that fits to the shoes the user will prefer, will be assembled onto the shoe. The shoe-clip
will ensure that the shoe is held in the correct position while the user is standing in the NF-Walker 2
and provide an easy way of getting the feet out of the brace-system when the use of NF-Walker 2
comes to an end.

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 12 of 56
5.3 Adjustment range
NF-Walker 2
These are typical measures of a user of the NF-Walker 2:
Size Micro
Distance 70cm user 85cm user
Ankle - knee 14cm 22cm
Knee - hip 13cm 22cm
Ground - hip 35cm 45,5cm
Hip width 15cm 23cm
Size XS (extra small)
Distance 80cm user 110cm user
Ankle - knee 16cm 26cm
Knee - hip 16cm 26cm
Ground - hip 40cm 55cm
Hip width 15cm 23cm
Size S (small)
Distance 100cm user 140cm user
Ankle –knee 21cm 34cm
Knee –hip 21cm 34cm
Ground –hip 51cm 70cm
Hip width 18cm 29cm
Ground - hip
Picture no. 5 NF-Walker 2 brace side view
Picture no. 6 NF-Walker 2 brace hip width
Hip width

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 13 of 56
5.4 Guide straps/elastics
There are two guide straps/elastics connecting the brace to the undercarriage. One guide
strap/elastic is connected to the ring (6 (chapter 5.2)) near the knee joints (12 (chapter 5.2)) and is
running over the rollers at the U-tube (3 (chapter 5.1)). The other guide strap/elastic is connected to
the rings (13 (chapter 5.2)) at the ankle joints (9 (chapter 5.2)) and is running over the rollers at the
front axle (11 and 12 (chapter 5.1)). The guide straps/elastics can be slacked or tightened according
to each user’s need.
The guide straps/elastics are having a number of functions:
Stretching out the user
Guiding the walking pattern
Placing the legs under the user’s body
Ensuring weight-bearing trough the user’s body
Pulling of the undercarriage while walking
It’s possible to use either guide straps or guide elastics - or a combination of these. This will have to
be assessed for the actual user of the product.
Elastics will give the user more freedom in movement and less correcting of the gait pattern, while
the guide straps will decrease the freedom and increase the correction of the gait pattern.
Some users are using guide elastics for walking and guide straps for stretching in a standing position.
This gives the NF-Walker 2 a possibility to be both a walking aid and a dynamic standing frame.

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 14 of 56
6. Adjustment to a user
When a NF-Walker 2 is ordered to a new user, measures needs to be taken of the user in order to
decide the correct size of the product, make initial adjustments and for choosing the correct
components for the NF-Walker 2. The user’s physio/ergo-therapist is normally responsible for taking
these measures, and will, together with a consultant from Made for Movement or its
representatives, agree about the need for extra equipment.
Picture no. 7 Measuring form

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 15 of 56
6.1 Fitting the NF-Walker 2 to the user:
The fitting of the NF-Walker 2 will be done by the consultant from Made for Movement or its
representatives where the user is sited: school, kinder garden, at home, training center or other.
Brace: The consultant will take accurate measures of the user’s legs and adjust one leg (hip-
knee-ankle) of the brace to fit the user. If there is no difference in leg-length, the measures
are copied to the opposite brace-leg. Accurate measures of the hip width will be taken and
the distance between the hip bows will be adjusted according to this. The hip strap will be
adjusted, ensuring correct position of the user in the brace. The height of the chest belt will
be adjusted to fit the actual user. The shoes with shoe-clips assembled on to them, will be
put onto the brace.
Undercarriage: The brace will be put onto the undercarriage and the height of the column
will be adjusted. When the height is adjusted correctly, the shoes shall almost touch the
floor. The length of the undercarriage will be controlled and if needed, adjusted by
extending the front axle frame part out of the frame. A tip for correct adjustment of the
front axle, is that the ankle joint of the brace should not be allowed to touch the front axle.
This is important for the stability of the NF-Walker 2 and security of the user. Small
adjustments to the length of the damper may be done to compensate the change of angle
caused by extending the front axle. The guide straps/elastics are put on the brace and
adjusted in length so the brace is approximately in a vertical in position when connected to
the frame
Try out: The brace can now be put on to the user. Follow the description in chapter 8.5 –
8.8.
The user is now in the NF-Walker 2. The spring force of the damper can be adjusted so the
user will be given the best possible dynamic and movement. The user is now having weight
bearing in the shoes, but the pressure from the shoes against the floor may be adjusted by
increasing or decreasing the height of the column and/or the force of the damper. The
degree of stretching of the user while she/he is walking, can be adjusted by correcting the
length of the guide straps/elastics. For stretching only, without walking, guide straps can be
adjusted to a length where the user is standing in a vertical position, stretched out in the
degree that is needed for her/him.
Important: NF-Walker 2 must not be adjusted by persons not qualified to do so.

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 16 of 56
7. How to adjust
7.1 Damper
Height of damper: Loosen the two screws at the top (1), using a 4mm Umbraco key. Lift the
frame up to the wanted height and tighten both screws securely.
Stiffness of damper: Loosen, by hand, the lock nut (3) a couple of turns. If you want the
damper to be harder, turn the spring adjustment nut (2) clockwise. Anti-clockwise will give a
softer suspension. Tighten the lock nut (3) against the spring adjustment nut (2) after
adjustment.
Picture 8 Damper on NF-Walker 2
1 height
adjustment screw
2 spring adjustment
nut
3 lock nut

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 17 of 56
7.2 Height of column
Loosen the screws (2) at both sides of the frame (6 screws in total). Loosen the height
setting screw (3). Adjust the height of the column (1) and tighten all of the screws securely.
Adjustment range: The column can be adjusted within a range of approximately 130mm.
Important: Make sure that the column is at least 105mm down in the main frame. Less
intervention between the main frame and column will cause instability in the undercarriage.
Important: NF-Walker 2 must not be adjusted by persons not qualified to do so.
Important: After adjusting the height of the column, please make sure that the column is not
touching the floor when the suspension is fully compressed.
Picture no. 9 Adjustment of the NF-Walker 2’s column
Important: After adjusting the height of the column, make sure that the guide strap/elastic
are rolling freely over the roller at the U-tube. If not, correct the height of the U-tube by
adjusting the height of the U-tube clamp.
Min 105mm
2 Screw
1 Column
3 Height
setting screw

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 18 of 56
8. Using NF-Walker 2
8.1. Duration of use
The amount of time the user should use the NF-Walker 2, must be assessed on the basis of
physical condition and state of health. The user’s therapist/doctor is responsible for
assessing usage on a regular basis.
8.2. Getting the user into NF-Walker 2
The following section presupposes that NF-Walker 2 has been adjusted for the user by a
consultant from Made for Movement or its representatives. The user’s assistant should also
have undergone the necessary training in using the product and read and understood this
user’s manual. The information below describes a number of methods for getting the user
into and out of NF-Walker 2.
8.3. Shoes
NF-Walker 2 must only be used with shoes compatible with the shoe-clips supplied
by Made for Movement or its representatives. Check regularly to ensure that the
shoes/sandals are having a good fit to the user’s feet. Ensure to tighten the
laces/Velcro so that the shoes fit well.
If you are in doubt if the user is having the appropriate type of shoe or shoe-
size, please contact Made for Movement or its representative.
8.4. Preparatory steps
Remove the brace from the undercarriage and place it on a mat or a firm
surface
Ensure that all the buckles are open before placing the user in the brace
Activate the brake at the rear axle of the undercarriage
Make sure the lock at the column is in open position
Picture no. 10 Open the lock at the column
Lock in open position

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 19 of 56
8.5. Getting the user into the NF-Walker 2 (without lifting straps)
1. Remove the brace from the undercarriage and place it
on a mat or a bench. Open all the buckles. Lift the user into the
brace.
Picture no. 11 Remove the brace, open the buckles, lift the user into the brace
2. Bend the users knee and support the users heel
towards the bench or mat. Bend the brace at the knee joint and
attach the shoe to the brace.
Picture no. 12 Fasten shoes
3. Attach the calf bow. Avoid folding the trousers at the
front of the leg before fastening the calf bow, to prevent
pressure points.
If the assistant may put in one finger between the calf
bow and the user’s calf while she/he is in standing position, the
strap is perfectly tightened.
Picture no. 13 Attach calf bow
4. Close the chest belt. If an upholster is used, position
this underneath the chest belt before closing the buckle.
Picture no. 14 Close the chest belt

Version: User’s manual EN NF-Walker 2 ver. 2.0
Date for this version: 09.02.2017 Page 20 of 56
5. Make sure that the pelvic is horizontal according to
the hip joint before closing the hip-belt.
Picture no. 15 Close the hip belt
6. Roll the user to the side close to the body of the
helper. Hold on to the brace with one hand on the hip bow
and one hand on the thorax steel.
Picture no. 16 Lift the user
7. Transfer the user into the undercarriage and close
the lock at the column after the brace is attached.
Picture no. 17 Transfer the user into the undercarriage
8. Close the lock at the column!
Picture no. 18 Close the lock at the column
