MadJax CONVEX MIRROR 03-035 User manual

03-035
convex mirror
installation instructions
included:Tools Needed: (not provided)
1
2
Bracket Hardware Mirror
Find desired location on cart, and mark
with pen.
For E-Z-GO®TXT/RXV®Golf Cart’s,
remove roof and retain factory
hardware.
Drill
#2 Phillips Head Screwdriver
10mm socket
10mm wrench
1/4’’ drill bit
Madjax®recommends professional installation. If you choose to not have this product installed by a professional, we highly
recommend that you exercise caution, care, and patience when installing this product as it involves drilling holes into your
bodywork. The Madjax®Limited Warranty only covers defects in materials and workmanship, and does not cover damage due
to improper installation. If you are having difculty installing this product, contact your Authorized Madjax®Dealer.

3
4
Using quarter inch drill bit, drill holes as
shown.
Using self-tapping attach brackets as
shown.
For Club Car®Precedent® drill holes into
canopy as shown. Use provided nuts
and bolts to attach bracket.
For Club Car® DS®drill holes into canopy
as shown. Use provided nuts and bolts
to attach bracket.
For Yamaha® G-Series®drill holes into
canopy as shown. Use nuts and bolts to
attach bracket.
For Yamaha® Drive®drill holes into
canopy as shown. Use nuts and bolts to
attach bracket.
Club Car® Precedent®
Club Car® DS®
E-Z-GO® TXT/RXV®
Yamaha® Drive®
Yamaha® G-SERIES®

5
7
6
Loosen screws on back of mirror.
Attach mirror to bracket as shown.
Tighten screws on back of mirror.
Reattach roof with hardware attained
from Step 2.
E-Z-GO®, E-Z-Go®TXT®, and E-Z-Go® RXV®are registered trademarks of Textron Innovations, Inc. Club Car®, Club Car®Precedent®, and Club Car® DS®are
registered trademarks of Ingersoll Rand, Inc. Yamaha®, Yamaha®Drive®, G-14®, G-16®, G-19®, and G-22®are registered trademarks of Yamaha Golf-Car Company.
Any reference to Club Car®, E-Z-Go®, or Yamaha®or their associated trademarks, word marks, and products are only for purposes of identifying golf carts with which
this Madjax product is compatible. Madjax products are aftermarket parts and are not original equipment parts. Madjax is not connected to, afliated with, sponsored
by, or endorsed by either Textron Innovations, Inc., Ingersoll Rand, Inc., Yamaha Golf Cart Company, or any of their parent or subsidiary companies.
installation complete
visit www.mymadjax.com
