Magellan MiVue 5 series User manual

User Manual
MiVue 5 Series

508 538

Magellan’s Take-Back Program provides a way for
consumers to recycle certain Magellan equipment.
As part of this program, all Magellan GPS models will
be accepted.
Visit magellanGPS.com for more information.
Magellan Take-Back Program
Connect with us
@MagellanGPS

2
Please check with your state or local law
enforcement for applicable regulations regarding
mounting to the windshield.
The driver should enter data or program the
Magellan receiver only when the vehicle is stopped.
Only a vehicle passenger should enter data or
program the receiver while the vehicle is moving.
It is your responsibility to comply with all traffic
laws.
Every attempt is made to ensure that the database
is accurate. However, roadways, points of interest
(POIs), and business and service locations may
change over time.
Keep the receiver safe from extreme temperature
conditions. For example, do not leave it exposed to
direct sunlight for an extended period of time. The
maximum operating temperature is 140°F (60°C).
Take care when mounting the receiver in your
vehicle, whether using the windshield mount
or other mount or accessories, that it does not
obstruct the driver’s view of the road, interfere with
the operation of the vehicle’s safety devices such
as airbags, or present a hazard to occupants of
the vehicle should the receiver be dislodged while
driving.
You assume the risks associated with damage to
your vehicle or vehicle occupants as the result of
your choices in mounting the receiver.
The battery is rechargeable and should not be
removed. In the event it should need to be replaced,
please contact Magellan Technical Support.
FCC RF Radiation Exposure Statement
1. This Transmitter must not be co-located or
operating in conjunction with any other antenna or
transmitter.
2. This equipment complies with FCC RF radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be installed
and operated with a minimum distance of 20
centimeters between the radiator and your body.
Wi-Fi 5G Band 1 is for indoor use only.
Canada, Industry Canada (IC) Notices
This device complies with Industry Canada licence-
exempt RSS standard(s). Operation is subject to
the following two conditions: (1) this device may not
cause interference, and (2) this device must accept
any interference, including interference that may
cause undesired operation of the device.
Canada, avis d’Industry Canada (IC)
Le présent appareil est conforme aux CNR
d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux
deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le
fonctionnement.
Tested To Comply With
FCC Standards
FOR HOME OR OFFICE USE
Magellan MiVue
508/538/638/658WIFI

3
Getting to know the recorder
1Device mount socket
For the device mount.
2Mini-USB connector
Connects to the charger.
3HD OUT connector*
Connects to an external
device.
4LCD screen
5Buttons
Navigate menu settings
6LED indicator 1
Indicates the system status of
the recorder.
7Power key
8Memory card slot
Data is recorded to a MicroSD
card.
9Speaker
Outputs audio.
10 Camera lens
11
LED indicator 2
Indicates the Parking mode of
the recorder.
12
Microphone
Allows you to record the video
with sounds.
* Available on certain models

4
Power key
Once the vehicle engine is started, the recorder automatically turns on. By default,
the recording will start right after the recorder turns on.
You can do the following using the Power key:
To manually turn the recorder on and off, press and
hold the Power key for 2 seconds.
When the recorder is turned on, press the Power key
to switch the LCD screen on/off.
LED indicators
Status LED 1 LED 2
The power cable is connected and the recorder is
on:
The battery is charging, and
- the recording is in progress.
- the recording stops.
The battery is fully charged, and
- the recording is in progress.
- the recording stops.
Green, Amber /
Blinking
Green / On
Red / Blinking
OFF
OFF
OFF
OFF
OFF
Parking mode is enabled, and the power cable is
disconnected:
The parking recording is in progress.
The parking recording stops.
Red / Blinking
OFF
Red / Blinking
Red / Blinking

5
Using the Function keys
The device provides four function keys to control the corresponding icons displayed at the bottom
of the LCD screen. The key’s function may vary on different screens. For example, the device will
display four icons as shown below while continuous recording is in progress.
Example Button Description
Press to enter the Settings Menu.
Press to manually enable Parking mode.
Press to take a photo.
Press to manually start an event recording.
Icon Description
The REC icon blinks while recording is in
progress.
Displays the current time.
/ Recording with sound is enabled/disabled.
The GPS signal icon indicates the GPS status. *
The Battery icon indicates the remaining
battery power.
* GPS enabled units only

6
Inserting a memory card
You must insert a memory card before you can start recording.
1. Hold the card by the edges and gently insert it into the slot with the label facing
the rear side of the recorder.
2. To remove card, gently push the top edge of the card inwards to release it, and
pull it out of the slot.
CAUTION:
DO NOT apply pressure to the center of the memory card.
Use a Class 10 memory card with at least 8GB capacity. The recorder supports
memory cards with up to 32GB capacity.
Magellan does not guarantee the product’s compatibility with memory cards
from all manufacturers.
Before you start recording, please format the memory card to avoid
malfunction caused by files not created by the recorder.
You can format the card on your computer or on the recorder (by selecting
Settings Menu > Format).
Please turn the device off before removing the memory card.

7
Using your recorder in a vehicle
1. Make sure that your car is parked on a level ground.
2. Follow the instruction below to mount your recorder in a vehicle securely.
3. Connect the car charger to the
vehicle power plug. Route the
cables through the top ceiling
and the A-pillar so that it does
not interfere with driving. Ensure
the cable installation does not
interfere with the vehicle's airbags
or other safety features.

8
4. When adjusting the angle of mounting, make sure that the camera’s view is
parallel with the level ground, and you see the entire road on the screen.
5. When not using the recorder, follow the instruction below to remove the recorder
from the holder.
NOTE:
To ensure the highest quality recordings, you are advised to place the recorder
near the rear view mirror.
Select an appropriate location for mounting the device in a vehicle. Never
place the device where the driver’s field of vision is blocked.
If the car’s windscreen is tinted with a reflective coating, it may be athermic
and impact the GPS reception. In this instance, please mount your device
where there is a “clear area.”
The system will automatically calibrate the impact sensor of the device during
boot up. To avoid impact sensor malfunction, ALWAYS turn the device on after
you mount it in the vehicle properly.
