Magiboards BGG104 Mounting instructions

Finished Product:What you will have:
Glass Board with Hidden Rail Assembly Instructions Sheet
www.magiboards.com |01952 292111 |[e-mail] |pg 1
Create,Shape & Communicate
A x 10 B x 10 C x 2 D x 2
Before you use your new glass board for the first time make sure you clean all the panels thoroughly.
If you have any further enquiries on how to fit your glass board please contact our customer service team.
Please Note: Our glass boards are heavy and will require 2 people to assemble and install the boards
INST_GLASSHR
10 x Wall plugs*1
2 x Long rails for C
portrait orientation*2
landscape orientation
10 x Screws*1
2 x Short rails for
A
B
D
Remove fixing rails from packaging x1
(120 x 90cm)
Remove fixing rails from packaging x2
(150 x 120cm)
Remove fixing rails from packaging x4
(240 x 120cm and 180 x 120cm)
2 x long rails are for fixing the glass board
in landscape position
2 x short rails are for fixing the glass board
in portrait position
STEP ONE
*1 The 120 x 90cm board is supplied with only 4 screws and wall
plugs, because it only has one rail to fix to the wall.
*2 The 240 x 120cm and 180 x 120cm boards are supplied with 2
long rails for landscape orientation and 2 short rails for portrait
orientation. The 150 x 120cm board is supplied with 2 rails only,
which can be used for landscape or portrait orientation.
Supplied screws to be
used in these holes
Supplied screws to be
used in these holes
Landscape Orientation
Portrait
Orientation

www.magiboards.com |01952 292111 |[e-mail] | pg 2
Create,Shape & Communicate
(240 x 120cm and 180 x 120cm ONLY) If you
are not assembling a 240 x 120cm or 180 x 120cm
board, please skip to step 3.
Once orientation is decided, 2 of the 4
rails provided can be put aside as they won’t
be required.
Fit the top rail to the wall at the required height,
ensuring the rail is level with the use of a spirit
level. Evenly space and drill 5 screws through
the holes on the rail to fit the rail to the wall.
Please Note: Remeber to measure the distance
from the rail to the top of glass board to ensure
you install you board at the correct height.
STEP TWOSTEP THREE
Repeat step three with the bottom rail, ensuring
it is spaced correctly with the top rail.
STEP FOUR
INST_GLASSHR
Glass Board with Hidden Rail Assembly Instructions Sheet
Next, install the glass board on to the rails,
Fixing clasp on the rear
of the glass board
allowing the upper and lower clasps on the
rear of the glass board to full engage and
latch onto the rail.
STEP FIVE
Please ensure that the centre piece of the rail is flat
against the wall, with the extended lips protruding
for your glass board clasps to latch on to.
Wall
Afor landscape orientation
Bfor portrait orientation
