Magiboards MCR001 Mounting instructions

What you will need:What you will have:
PACK A:
3x Magnetic Framed Whiteboard Panels A
PACK B:
1x Triangular Base 1 (Small Hole) B
1x Triangular Base 1 (Large Hole) C
1x Circular Base Plate D
PACK C:
22 x M5 Bolts E
1 x Top Centre Pole F
1 x M8 Wing Nut G
1 x Washer H
1 x Bottom Centre Pole I
1 x Nylon Pole Collar J
1 x Allen Key (Small) K
Rotating 3 Sided Magnetic Whiteboard Assembly Instructions Sheet
www.magiboards.com |01952 2 9 2111 |[e-mail] |pg 1
Create,Shape & Communicate
A x 3 B x 1 C x 1
D x 1
G x 1
J x 1
E x 22
H x 1
K x 1
F x 1
I x 1
PACK A
PACK B
PACK C
PACK C
PACK B
PACK C
PACK C
PACK C
PACK B
PACKC
PACK C
Before you use your new whiteboard for the first time make sure you clean all the panels thoroughly.
If you have any further enquiries on how to fit your whiteboard please contact our customer service team.
x2 people
for the job
INST_ROTATE301

www.magiboards.com |01952 2 9 2111 |[e-mail] |pg 2
Create,Shape & Communicate
Place one whiteboard panel (A) on a
clean surface, ensuring that the dry wipe
whiteboard side of the panel is face down
on the surface.
Make sure that
the surface is
clean
Fasten the
middle bolt on
both sides
Align the holes in the triangular base
(B) with the holes at the end of the
whiteboard panel (A) as shown in the
diagram, and secure together with 3 x
M5 bolts (E), making sure they have been
firmly tightened with the allen key (K).
Repeat this process at the other end of the
panel using triangular base (C).
Take another whiteboard panel (A) and
split it in between the triangular bases
(B and C) so that the holes align, again
fasten each side with 3 x M5 bolts (E).
TIP: Fasten the middle bolt on both sides
of the board before fastening the other
4 bolts so that the board is supported
upright whilst you fasten the other bolts.
STEP ONESTEP TWOSTEP THREE
Rotating 3 Sided Magnetic Whiteboard Assembly Instructions Sheet
INST_ROTATE301

First insert the nylon pole collar (J) into
base (C) now take the top centre pole (F)
and slide it through the hole in triangular
base (C), fitting the pole collar (J) at
the top of the pole through the other
triangular base (B).
Place the washer (H) over the nut
protruding from the top and then place
the wing nut (G) over the top of that,
making sure it is securely tight.
Top centre
pole screw
side first
Using the technique outlined in step 3 fit
the third panel onto the triangular bases
as shown.
STEP FIVE STEP FOUR
Repeat
STEP 3
Create,Shape & Communicate
www.magiboards.com |01952 2 9 2111 |[e-mail] |pg 3
Rotating 3 Sided Magnetic Whiteboard Assembly Instructions Sheet
INST_ROTATE301

ATTENTION
The next step requires TWO people,
do not attempt this on your own!
Before you use your new whiteboard for the
first time make sure you clean all the panels
thoroughly.
If you have any further enquiries on how to fit
your whiteboard please contact our customer
service team.
Place the base plate (D) on the floor and
line up the four holes with the holes in the
bottom centre pole (I).
Fasten the two together using the M5 bolts
(E), ensuring that the bolts are fastened
tightly together using allen key (K).
Whilst holding the pole collar in place,
together, lift the assembled board and slot
the top half of the centre pole inside the
bottom half of the centre pole.
Once you have completed this you should
have a fully functional rotating 3 sided
whiteboard.
STEP SIXSTEP SEVENPLEASE NOTE
CAREFULLY
LIFT
Create,Shape & Communicate
www.magiboards.com |01952 2 9 2111 |[e-mail] |pg 4
Rotating 3 Sided Magnetic Whiteboard Assembly Instructions Sheet
Don’t forget to
hold the pole
collar whilst
assembling
INST_ROTATE301
