Magic Chef MCL3LDFRT User manual

1
PLEASE READ THIS MANUAL CAREFULLY BEFORE USING YOUR DEEP
FRYER AND KEEP IT FOR FUTURE REFERENCE.
Model MCL3LDFRT
Deep Fryer
User’s Manual

2
PRODUCT REGISTRATION
Thank you for purchasing a Magic Chef®product. The first step to protect your new product is to complete the product
registration on our website: www.mcappliance.com/register. The benefits of registering your product include the following:
1. Registering your product will allow us to contact you regarding a safety notification or product update.
2. Registering your product will allow for more efficient warranty service processing when warranty service is required.
3. Registering your product could act as your proof of purchase in the event of insurance loss.
Once again, thank you for purchasing a Magic Chef product.

3
CONTENTS
PRODUCT REGISTRATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
PARTS AND FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
BEFORE USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
CARE AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4
IMPORTANT SAFETY INSTRUCTIONS
This manual contains Safety Instructions, Installation and Operating Instructions, and Troubleshooting Tips. Please
carefully read this manual before using your deep fryer for instructions on how to use and maintain the product
properly. Be sure to follow the safety instructions to avoid injury or damage to the product.
Keep this manual. When passing on/selling the device to a third party, the manual must be handed over along
with the device.
Before calling for service, please make sure unit is installed and being used correctly, and read the troubleshooting
section.
WARNING: When using your appliance, follow the precautions listed below:
NOTE: Specifications may change at any time without notice.
1. Read all instructions.
2. This appliance is for household use only. It is not intended for outdoor or commercial applications. DO NOT
use appliance for other than intended use.
3. Before using, check that the voltage of wall outlet corresponds to the rating plate.
4. To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other).
This plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet,
reverse the plug. If it still does not fit, try a different outlet or contact a qualified electrician. DO NOT
attempt to modify the plug in any way.
5. DO NOT turn the deep fryer on unless it is full of oil. ALWAYS ensure that it is filled with oil between the
minimum and maximum level marks on the inside of the Bowl.
6. WARNING: Avoid using the appliance for long periods, as this can result in the oil overheating, causing a
fire.
7. CAUTION: DO NOT add water to the oil. This is extremely dangerous and may cause the oil to splatter
out of the bowl.
8. CAUTION: DO NOT touch the hot oil.
9. DO NOT leave the appliance unattended while it is in use.
10. Close supervision is necessary when any appliance is used by or near children.
11. Some Parts of the appliance get very hot when in operation. DO NOT touch hot surfaces. Use caution when
unit is in use, and ALWAYS use handles or knobs.
12. ALWAYS set the temperature control to the lowest possible temperature, and unplug the fryer as soon as
you have finished cooking the food.
13. ALWAYS turn off and unplug from the outlet when not in use and before cleaning. Allow unit to cool down
before putting on or taking off parts, and before cleaning the appliance.
14. To protect against electrical shock do not immerse cord, plugs, or the whole unit in water or other liquid.
15. DO NOT operate the unit or handle the plug with wet hands.
16. Only use the appliance in a dry and well ventilated room.
17. This appliance should not be operated by anyone with reduced physical, sensory or mental capabilities or
does not have experience with this type of equipment, unless under supervision.
18. This appliance is not intended to be operated by means of an external timer or separate remote-control
system.

5
19. ALWAYS place unit on a level, stable, heat resistant surface. DO NOT use on carpet, vinyl, cloth, etc. and DO
NOT move during operation.
20. DO NOT use near or below curtains or other combustible materials.
21. DO NOT cover the appliance.
22. DO NOT let the cord hang over edge of table or counter or touch hot surfaces.
23. DO NOT place on or near a hot gas or electric burner, or in a heated oven.
24. DO NOT operate any appliance with a damaged cord or plug; or after the appliance malfunctions or is
damaged in any manner. Contact customer service for assistance.
25. DO NOT modify or repair the unit by yourself.
26. A short power-supply cord (or detachable power-supply cord) should be used to reduce the risks resulting
from becoming entangled in or tripping over a longer cord. Extension cords may be used if care is exercised
in their use and:
a. The marked electrical rating of the extension cord should be at least as great as the electrical rating
of the appliance.
b. The longer cord should be arranged so that it will not drape over the countertop or table top where it
can be pulled on by children or tripped over.
27. DO NOT unplug your appliance by pulling on the power cord. ALWAYS grasp the plug firmly and pull it
straight out from the outlet.
28. DO NOT roll the cord up or wind it around the appliance.
29. CAUTION: If a fire starts in the fryer, DO NOT try to put it out with water. Close the lid and try to
smother the flames with a damp cloth or wet towel.
30. The use of accessories not recommended by the appliance manufacturer may cause injuries.
31. DO NOT use outdoors.
32. Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.
33. Always attach plug to appliance first, then plug cord into the wall outlet. To disconnect, turn any control to
“off”, then remove plug from wall outlet.
34. Be sure handle is properly assembled to basket and locked in place. See detailed assembly instructions.
READ AND FOLLOW THIS
SAFETY INFORMATION CAREFULLY
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY

6
SPECIFICATIONS
Dimensions (W x H x D) 8.6” x 8.9” x 16.2” (218 mm x 226 mm x 411 mm)
Power Supply 120V ~ 60Hz
Rated Power 1650W
Figure 1
8.9”
(226 mm)
8.6”
(218 mm)
16.2” (411 mm)

7
PARTS AND FEATURES
a. Housing
b. Housing carrying handle
c. Power indicator
d. Heat Indicator
e. Control panel with power cord
f. Temperature control
g. Heating element
h. Lid handle
i. Lid
j. Viewing Window
k. Bowl
l. Basket
Figure 2
l
k
de f g
hj
ba
c
i

8
BEFORE USE
• Read the safety instructions carefully.
• Remove all packaging from the appliance and place it on a flat, stable surface, e.g. a kitchen counter, at a
safe distance from flammable objects.
• Clean the lid, bowl, and basket in warm, soapy water. Rinse thoroughly and dry completely. Wipe the
housing using a soft, damp cloth or sponge.
• NOTE: The bowl and basket may be washed in a dishwasher.
• Attach the heating element and control panel assembly to the housing by sliding the rails on the inside
of the control panel into the grooves on the back of the housing. Make sure that the heating element is
pushed all the way to the bottom of the bowl.
• NOTE: There is a safety switch on the control panel unit that will only be pushed in when it is fully slid
into place. If it is not installed correctly, the unit will not heat.
Figure 3
• The handle is stored folded into
the basket. Unfold the handle so
that it is in the correct position
and locked firmly in place.

9
OPERATING INSTRUCTIONS
DEEP FRYING
1. ALWAYS make sure the deep fryer is turned off when starting.
2. Pour the oil into the bowl so that the fill level falls between the “Min” and Max” marks.
NOTE: It is recommended to use liquid oil. Lard or solid fats can be used, but must be melted prior
to using by placing small pieces of it into the bowl and warming it on the lowest setting. Once it is fully
melted, you can set the control to the required cooking temperature.
3. Place the lid on the bowl.
4. Attach the magnetic cord and plug the fryer in; the red power indicator will light.
5. Set the desired temperature by turning the temperature control knob. The green heat indicator will light
and remain lit while the fryer is heating up. Once the unit reaches the set temperature, the green heat
indicator light will turn off.
NOTE: The heat indicator will turn on and off while the fryer is in use, as needed to maintain the
selected temperature.
6. DO NOT add food until the required temperature is reached.
7. Remove the lid and carefully lower the basket with the food into the bowl. Make sure the oil level does not
rise to the top of the bowl.
NOTE: ALWAYS hold the basket handle firmly when fitting or removing the lid.
CAUTION: When putting food into or removing it from the fryer, hot oil may splatter. Take care when
removing the lid, as hot steam may be released.
There is a non-auto resetting thermostat built in the product. If the deep fryer has been in use for a prolonged
time, the built-in thermostat will activate and cut off the current to protect the appliance from overheating.
Reset the thermostat by pushing the indicated button on the back of the control panel, after the heating element
has cooled down, to enable the deep fryer to function normally again.
AFTER COOKING
1. Carefully lift the basket out of the oil and use the clips to hang it on the front edge of the bowl.
CAUTION: Handle may be hot after extended use.
2. Allow the oil to drip from the food before removing from the basket.
3. Set the temperature control knob to the lowest setting and unplug from the outlet.
4. Allow the fryer to cool for at least 1-2 hours before emptying the oil, moving, or cleaning.
CAUTION: DO NOT attempt to move the deep fryer while it is hot.
FOOD PREPARATION TIPS
• ALWAYS make sure that the food is dry before lowering it into the hot oil.
• Ensure that the food is roughly the same size so that it cooks evenly. Avoid very thick pieces.
• Some types of food should be breaded before being cooked in the deep fat fryer.
• Make sure you remove as much ice as possible from frozen food. However, it does not need to be defrosted
before cooking.
• DO NOT fill the basket above the max mark on the metal plate under the handle.

10
BASIC DEEP FRYING GUIDE
Temperature Time
Breaded Chicken Fillets 350° F (175° C) 12-15 minutes
Onion Rings 350°F (175° C) 3 minutes
Breaded Fish Fillets 350°F (175° C) 5-6 minutes
Large Prawns 350°F (175° C) 3-5 minutes
French Fries 350°F (175° C) 5-6 minutes
Battered Broccoli 365° F (185° C) 2-3 minutes
NOTE: ALWAYS check internal temperature of meats to make sure they are fully cooked.

11
CARE AND MAINTENANCE
CLEANING THE DEEP FRYER
• Once the oil has cooled, pour it into an appropriate storage container and wipe out the bowl with a paper
towel.
• Clean the Housing, Bowl, Lid and basket using hot soapy water. The Bowl and Basket may be cleaned in a
dishwasher if desired.
• DO NOT use of strong or abrasive cleaners on the deep dryer or its accessories. NEVER use a steel wool or
scrubbing brush to clean the appliance, as this may damage the finish.
• DO NOT immerse the heating element or control panel in water or any liquid. Remove the control panel
and heating element before cleaning the appliance. Wipe these parts clean with a soft damp cloth or
sponge.
CAUTION: DO NOT attempt to move, drain, or clean the deep fryer with hot oil in it. ALWAYS allow the oil to
cool completely before handling.
HANDLING AND STORING OIL
• ALWAYS make sure all oil is completely cool before handling.
• Remove any food residue from the oil after use.
• Filter the oil regularly. Filters for deep frying oil are available, or pour through cheesecloth to filter.
• The oil should be changed once it has been used approximately 10 times. All the oil should be changed at
the same time; DO NOT mix old and new oil. The old oil should be disposed of as per local regulations.
• Store the oil in an airtight container in a dry, cool and dark place. (It is not necessary to refrigerate).
STORING THE DEEP FRYER
• Ensure the fryer is completely cooled down before storing.
• NEVER store it while it is hot or wet.
• Thoroughly clean and dry all parts before storing.
• Store appliance in a clean, dry place.

12
TROUBLESHOOTING
Problem Possible Cause Solution
Unpleasant odor Oil is old Change oil after about 10 uses or if it darkens
in color
Oil overflows the bowl Too much oil added to the bowl Reduce the amount of oil
Too much food in the basket Reduce the amount of food being fried
Food is not crispy Cooking time is too short Adjust the cooking time
Too much food in the basket Only fill basket to about 2/3 full
Unit will not power on Safety shut off switch has been activated Press the reset button.

13
LIMITED WARRANTY
MC Appliance Corporation warrants each new Deep Fryer to be free from defects in material and workmanship, and agrees to
remedy any such defect or to furnish a new part(s), at the company’s option, for any part(s) of the unit that has failed during the
warranty period. Parts and labor expenses are covered on this unit for a period of one year from the date of purchase. A copy of
the dated sales receipt/invoice is required to receive warranty service, replacement or refund.
This warranty covers appliances in use within the contiguous United States, Alaska, Hawaii and Puerto Rico. This warranty does not
cover the following:
• Damages due to shipping damage or improper installation.
• Damages due to misuse or abuse.
• Content losses due to failure of the unit.
• Repairs performed by unauthorized service agents.
• Service calls that do not involve defects in material and workmanship such as instructions on proper use of the
product or improper installation.
• Replacement or resetting of house fuses or circuit breakers.
• Failure of this product if used for other purposes than its intended purpose.
• Disposal costs for any failed unit not returned to our factory.
• Any delivery/installation costs incurred as the result of a unit that fails to perform as specified.
• Expenses for travel and transportation for product service if your appliance is located in a remote area where
service by an authorized service technician is not available.
• The removal and reinstallation of your appliance if it is installed in an inaccessible location or is not installed in
accordance with published installation instructions.
• Refunds for non repairable products are limited to the price paid for the unit per the sales receipt.
• This warranty is non transferable. This warranty applies only to the original purchaser and does not extend to any
subsequent owner(s).
Limitations of Remedies and Exclusions:
Product repair in accordance with the terms herein, is your sole and exclusive remedy under this limited warranty. Any and all
implied warranties including merchantability and fitness for a particular purpose are hereby limited to one year or the shortest
period allowed by law. MC Appliance Corporation is not liable for incidental or consequential damages and no representative or
person is authorized to assume for us any other liability in connection with the sale of this product. Under no circumstances is
the consumer permitted to return this unit to the factory without the prior written consent of MC Appliance Corporation.
Some states prohibit the exclusion or limitation of incidental or consequential damages, or limitations on implied warranties.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Model Parts Labor Type of Service
MCL3LDFRT One Year One Year Carry In
For Service or Assistance please call 888-775-0202 or visit us on the web at www.mcappliance.com to request warranty service
or order parts.

14
CNA International, Inc. d/b/a MC Appliance Corporation. All rights reserved.
Magic Chef®logo is a registered trademark of CNA International, Inc.
www.mcappliance.com Printed in China

15
POR FAVOR LEA ATENTAMENTE ESTE MANUAL ANTES DE USAR SU
FREIDORA DE INMERSIÓN Y CONSÉRVELO PARA FUTURAS REFERENCIAS.
Modelo MCL3LDFRT
Freidora de inmersión
Manual del usuario

16
REGISTRO DEL PRODUCTO
Gracias por comprar un producto Magic Chef®. El primer paso para proteger su nuevo producto es completar el registro del
producto en nuestro sitio web: www.mcappliance.com/register. Entre los beneficios de registrar su producto se incluyen los
siguientes:
1. Registrar su producto nos permitirá contactarlo en relación con cualquier aviso de seguridad o actualización del
producto.
2. Registrar su producto permitirá un proceso de servicio de garantía más eficiente, cuando se requiera el servicio de
garantía.
3. Registrar su producto podría servir como su prueba de compra en el caso de que usted sufra una pérdida que esté
cubierta por el seguro.
Una vez más, gracias por comprar un producto Magic Chef.

17
ÍNDICE
REGISTRO DEL PRODUCTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
INSTRUCCIONES DE SEGURIDAD IMPORTANTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
ESPECIFICACIONES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
PIEZAS Y FUNCIONES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
ANTES DE SU USO. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
INSTRUCCIONES DE FUNCIONAMIENTO. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
CUIDADO Y MANTENIMIENTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
SOLUCIÓN DE PROBLEMAS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
GARANTÍA LIMITADA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

18
INSTRUCCIONES DE SEGURIDAD IMPORTANTES
Este manual contiene instrucciones de seguridad, instrucciones de instalación y funcionamiento, y consejos de
solución de problemas. Por favor, lea atentamente este manual antes de utilizar su freidora de inmersión para
conocer las instrucciones sobre cómo utilizar y mantener el producto adecuadamente. Asegúrese de seguir las
instrucciones de seguridad para evitar lesiones o daños al producto.
Guarde este manual. Al transferir/vender el dispositivo a un tercero, el manual debe entregarse junto con el
dispositivo.
Antes de contactar al servicio técnico, por favor cerciórese de que la unidad esté instalada y se esté usando de
manera correcta, y lea la sección de solución de problemas.
ADVERTENCIA: Siga las precauciones que se indican a continuación al utilizar su aparato.
NOTA: Las especificaciones pueden cambiar en cualquier momento y sin aviso previo.
1. Lee todas las instrucciones.
2. Este aparato es solo para uso doméstico. No está diseñado para el uso al aire libre ni comercial. NO use el
electrodoméstico de una manera que no sea la prevista.
3. Antes de usar el aparato, compruebe que el voltaje de la toma de corriente corresponde con el voltaje
nominal indicado en la placa de características.
4. Para reducir el riesgo de descarga eléctrica, este aparato tiene una clavija polarizada (un contacto es más
ancho que el otro). Este enchufe está diseñado para encajar en un tomacorriente polarizado de una sola
manera. Si el enchufe no encaja completamente en el tomacorriente, invierta el enchufe. Si aún no encaja,
intente en un tomacorriente distinto o comuníquese con un electricista calificado. NO intente alterar el
tomacorriente de ningún modo.
5. NO encienda la freidora de inmersión a menos que esté llena de aceite. Asegúrese SIEMPRE de que contenga
aceite entre las marcas de los niveles mínimo y máximo del interior del recipiente.
6. ADVERTENCIA: Evite usar el aparato por periodos prolongados pues el aceite puede sobrecalentarse y
causar un incendio.
7. PRECAUCIÓN: NO agregue agua en el aceite. Esto es sumamente peligroso y puede causar que el aceite
salpique fuera del recipiente.
8. PRECAUCIÓN: NO toque el aceite caliente.
9. NO deje el aparato desatendido mientras lo esté usando.
10. Se requiere supervisión de cerca cuando niños utilicen cualquier aparato o cuando se use cerca de ellos.
11. Algunas piezas del aparato se calientan mucho durante su funcionamiento. NO toque las superficies
calientes. Tenga precaución al utilizar la unidad y SIEMPRE utilice manijas o perillas.
12. Gradúe el control de temperatura SIEMPRE a la temperatura más baja posible y desenchufe la freidora
apenas haya terminado de cocinar.
13. SIEMPRE apague y desconecte la clavija del tomacorriente cuando no lo use y antes de limpiarlo. Deje que
la unidad se enfríe antes de poner o quitar las piezas y antes de limpiar el aparato.
14. Para protegerse contra descargas eléctricas, no sumerja el cable, los enchufes o la unidad entera en agua u
otro líquido.
15. NO opere la unidad ni manipule la clavija con las manos húmedas.
16. Use el aparato solo en un espacio seco y bien ventilado.
17. Las personas con facultades físicas, sensoriales o mentales reducidas o que no tengan experiencia con este
tipo de equipos, no deben operar este aparato a menos que sea bajo supervisión.

19
18. Este aparato no está diseñado para ser utilizado con un temporizador externo ni un sistema a control
remoto aparte.
19. SIEMPRE coloque la unidad sobre una superficie plana, estable y resistente al calor. NO la utilice sobre
alfombras, vinilos, telas, etc. y NO la mueva mientras se encuentre funcionando.
20. NO la utilice cerca de cortinas u otros materiales inflamables ni debajo de los mismos.
21. No cubra el aparato.
22. NO deje que el cable quede colgando del borde de mesas o tocar superficies calientes. SIEMPRE mantenga
el cable alejado de superficies u objetos calientes.
23. NO lo coloque encima ni cerca de una hornilla caliente ni cualquier otra fuente de calor, ni dentro de un
horno caliente.
24. NO opere este aparato si tiene dañado el cable o la clavija, o si la unidad está defectuosa o funciona mal de
alguna manera. Póngase en contacto con Atención al Cliente o con un técnico de servicio.
25. NO altere ni repare la unidad usted mismo.
26. Se debe utilizar un cable de alimentación corto (o extraíble) para reducir el riesgo de enredo o disparo con
un cable más largo. Pueden utilizarse cables de alimentación más largos y extraíbles si se ejerce cuidado en
su uso y:
a. La capacidad eléctrica del cable de extensión debe ser al menos tan alta como la capacidad eléctrica
del aparato.
b. Si el aparato es del tipo con conexión a tierra, el cable de extensión debe ser un cable de 3 hilos con
conexión a tierra. El cable más largo se debe colocar de tal manera que no salga de la superficie de la
mesa o el mostrador donde puede ser tirado por los niños o tropezó.
27. NO desenchufe su aparato halando el cable de alimentación. SIEMPRE sujete la clavija firmemente y sáquela
derecha desde el tomacorriente.
28. NO enrolle el cable ni le dé vueltas alrededor del aparato.
29. PRECAUCIÓN: Si la freidora comienza a incendiarse NO intente apagarla con agua. Cierre la tapa y trate
de cubrir las llamas con un trapo húmedo o una toalla mojada.
30. El uso de accesorios no recomendados por el fabricante del aparato puede causar lesiones.
31. NO lo utilice fuera.
32. Tenga mucho cuidado al mover un aparato que contenga aceite caliente u otros líquidos calientes.
33. Siempre conecte primero el enchufe al aparato y, a continuación, conecte el cable a la toma de corriente.
Para desconectar, gire cualquier control a "apagado", luego retire el enchufe de la toma de corriente.
34. Asegúrese de que el mango está correctamente bloqueado en la cesta. Consulte " ANTES DE SU USO " para
obtener instrucciones.
LEA ESTA INFORMACIÓN DE
SEGURIDAD Y SÍGALA CUIDADOSAMENTE
GUARDE ESTAS INSTRUCCIONES
USO DOMÉSTICO SOLAMENTE

20
ESPECIFICACIONES
Dimensiones (AxLxP) 8.6” x 8.9” x 16.2” (218 mm x 226 mm x 411 mm)
Fuente de alimentación 120V ~ 60Hz
Potencia de entrada 1650W
Figura 1
8.9”
(226 mm)
8.6”
(218 mm)
16.2” (411 mm)
