Magic Chef MCSGC07W User manual

CONVECTION OVEN
7 Liter Capacity
INSTRUCTION MANUAL
Model: MCSGC07W
THANK YOU FOR PURCHASING THIS MAGIC CHEF PRODUCT
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE USING

2
CONTENTS
IMPORTANT SAFEGUARDS …………………..……………………...…… 4
PARTS AND FEATURES ………………...…………….….…...…….…… 7
BEFORE USE …………………………..…………………………….………… 8
OPERATING INSTRUCTIONS ………………….……….…………..…….… 9
CARE AND MAINTENANCE …….………………………………………….. 10
BENEFITS TO COOKING WITH A HALOGEN OVEN ………...……….. 11
CONVECTION OVEN COOKING GUIDE ………………………...……….. 12
COOKING TIPS …………………….……………..………….……….……… 13
RECIPES …………………………………………..………….……….……… 14
TROUBLESHOOTING …………………………..………….……….……… 26
WARRANTY ……………………………………..………….……….……… 27

3
What you need to know about Safety Instructions
Warnings and Important Safety Instructions appearing in this manual are
not meant to cover all possible conditions and situations that may occur.
Common sense, caution and care must be exercised when installing,
maintaining, or operating any appliance.
Always contact your dealer, distributor, service agent or manufacturer
about problems or conditions you do not understand.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY

4
IMPORTANT SAFEGUARDS
When using any electrical appliance, basic safety precautions should always be followed,
including the following:
1. READ ALL INSRUCTIONS BEFORE USING.
2. Close supervision is necessary when any appliance is used near children.
3. Keep the product out of the reach of children and pets. This product is not intended for
use by children.
4. Household use only. Do not use outdoors.
5. Use only when the voltage indicated on the base of the appliance corresponds to the
voltage at a place you intend to use the product.
6. Always ensure the product is unplugged from the electrical outlet and cool before
assembling, disassembling, relocating, or cleaning.
7. Do not leave the product unattended when in use. Always unplug the product from the
electrical outlet when not in use.
8. To protect against electric shock, keep cord, plug(s), or lid from water or other liquid and
do not immerse cord, plugs, or lid in water or other liquid.
9. Never move the appliance by pulling the cord. Do not put any stress on the power cord
where it connects to the product, as the power cord may fray and break.
10. Do not let the electrical cord hang over the edge of a table or counter or touch hot
surface.
11. Never use accessories which are not recommended by the manufacturer. They could
constitute a danger to the user and risk damage to the appliance.
12. Only operate the appliance on a flat and stable surface.
13. Do not plug or unplug the product into or out from any electrical outlet with a wet hand.
14. Do not place the base, power cord, or plug of this product in or expose the parts to water
or other liquids.
15. Do not plug the appliance into a damaged outlet.
16. Do not turn the power on unless the appliance is properly assembled.
17. Do not touch hot surfaces. Use handles or knobs.
18. Leave 6 to 8 inches of open space all around the exterior of the appliance during use.

5
19. Do not use this appliance as a fryer. Do not attempt to fill with oil or attempt to deep
fry. Such actions may cause fire and injury.
20. Do not cover the appliance while in use.
21. Oversize foods or metal utensils must not be inserted in the appliance as they may create
fire or risk of electric shock. Do not place the appliance near or touch flammable materials
such as curtains, draperies and walls when in operation.
22. Always place the top unit or lid onto the bowl before plugging the power cord and switching
on.
23. Extreme caution must be taken when moving an appliance containing hot liquids.
24. The oven should be operated on a separate electrical circuit from other operating
appliances. If the electric circuit is overloaded with other appliances, this appliance may not
operate properly.
25. Do not move or lift the appliance while the power cord is still connected to the wall outlet.
26. Before removing the lid:
A. Turn off the timer.
B. Disconnect power cord.
C. Lift the top lid by the handle.
27. Do not place the hot underside of the lid directly onto laminated or wood surfaces, paper,
plastic or other flammable surfaces. NOTE: Place lid on heat resistant surfaces only.
28. Never place the lid on an unstable surface while the product is plugged in and operating.
29. Do not clean with metal scouring pads. Pieces broken off the pad can touch electrical parts
involving a risk of electric shock.
30. The included 7 Liter glass bowl container is designed for use only with this appliance. It
must never be used on a range top.
31. Do not set a hot glass bowl container on a cold surface.
32. Do not use a cracked glass bowl container or a glass bowl container having loose or
weakened handles.
33. Allow unit to completely cool and store in a cool dry place.
34. Do not operate the appliance if it has a damaged or cut power cord or plug, if wires are
exposed, malfunctioning, dropped or damaged, or if the heater housing is dropped in or
exposed to water.
35. This product has no user-serviceable parts. Do not attempt to examine or repair this
product yourself. Only qualified service personnel should perform any servicing.
36. Do not use this appliance other than its intended use.

6
CAUTION
It is not recommended to use the plug with an extension cord. If
an extension cord is required, be sure the extension cord is of the
proper power and voltage rating. Do not alter the plug of the
appliance or any extension cord used with this appliance. Do not
attempt to defeat the safety purpose of the 3 prong grounded plug.
WARNING
To protect against electric shock, fire, and injury to person(s), do
not immerse main cord, plug or unit in water or any other liquid.

7
1. Base and handles
2. 7 Liter glass bowl
3. Lid and heating element
4. Handle with safety switch
5. Tongs
6. High rack
7. Low rack
8. Power lamp (Red)
9. Heat lamp (Green)
10. Timer
11. Temperature Control
PARTS AND FEATURES
SPECIFICATIONS:
Voltage Rating: 120V
Power Rating: 750W
Glass Bowl Capacity: 7 Liters

8
BEFORE USE
1. Carefully unpack the convection oven and remove all packaging materials.
2. Select a flat, heat-resistant, and non-flammable surface to place the convection oven.
3. Do not immerse the heating element or lid in water or any other liquid.
4. To remove any dust that may have accumulated on the removable parts during packaging,
clean the surface with a damp cloth and remove any stickers (except for any warning/caution
stickers).
5. Wash the glass bowl container in warm soapy water. Rinse and dry thoroughly.
6. Before first use, heat up the oven, empty, at maximum temperature for five minutes. This will
burn off the brand new scent. A little smoke may occur. This is normal and will soon
disappear during usage.
7. After the timer has turned off and the oven is completely cooled, wipe the inside of the glass
bowl container once more.
THREE-PRONG PLUG
CAUTION: To ensure continued protection against the risk of electric shock, connect to
properly grounded outlets only.
This appliance has a three-prong plug (meaning there are three prongs to fit into a power
outlet).
To reduce the risk of electric shock, this plug is intended to fit into a three-prong electrical outlet
only in one direction. If it does not fit, contact a qualified electrician. Do not attempt to modify
the plug in any way.

9
OPERATING INSTRUCTIONS
WARNING: ALWAYS ASSEMBLE THE PRODUCT COMPLETELY BEFORE PLUGGING IT
INTO AN ELECTRICAL OUTLET.
CAUTION: ALWAYS PLACE A PAN OR BOWL ON TOP OF ONE OF THE INCLUDED
RACKS. DO NOT PLACE A PAN OR BOWL DIRECTLY ONTO THE BOTTOM OF THE
GLASS BOWL CONTAINER.
1. Place the low rack in the glass bowl container before the food is placed. . Keep the food
approximately 1 to 1.25 inch from the glass wall to allow maximum hot air circulation.
NOTE: High rack is used for achieving crispness or browning of the food.
2. Place the top lid securely on the glass bowl container.
NOTE: Make sure that the food does not touch the heating element located on the bottom of
the lid.
3. Insert the power cord firmly into the wall outlet.
4. Use the temperature control knob to set the desired cooking temperature (250 F to 480 F).
5. Set the timer to the desired time (5 to 60 minutes). The power light (red) and heat light
(green) will illuminate.
6. Fold the handle until it snaps into place. The heating element and fan will only activate if the
handle is folded completed down. As a safety feature, the convection oven will switch off
when the handle is lifted up. To turn the unit back on, swing the handle all the way down until
it snaps into place.
7. The timer will switch “off” after the preset time period has passed and a bell will sound
momentarily to alert you that the cooking time is over.
8. Use the tongs to lift the rack (with food) out of the bowl.
9. Unplug the cord from the power outlet before removing the lid.
10. Do not put the oven lid directly on the countertop, table or cooking surface, otherwise, the
cooking surface may stain.
11. Always use wooden, heat proof plastic or nylon utensils while cooking. Metal utensils may
scratch the glass bowl container.
12. Allow the unit to completely cool before moving and/or cleaning.
Defrost Setting
The halogen oven has a defrost setting (low temperature) that should be used to defrost foods.
This setting is indicated on the temperature control knob.

10
CARE AND MAINTENANCE
WARNING: ALWAYS UNPLUG THE UNIT FROM THE ELECTRICAL OUTLET AND ALLOW
ALL PARTS TO COMPLETELY COOL BEFORE DISASSEMBLING IT FOR CLEANING.
NEVER IMMERSE THE HEATING ELEMENT OR LID IN WATER OR ANY OTHER LIQUID.
NOTE: Clean the product after each use.
1. Unplug the oven and let it cool.
2. Wash the glass bowl in hot, soapy water and dry thoroughly. Clean the exterior of the base
by wiping it with a soft, damp cloth.
3. Wipe the lid and fan housing using a damp, clean dish cloth or sponge with a little mild
dishwashing detergent.
Do not clean the glass bowl or lid with steel-wool pads or abrasive materials.
4. Wash the wire racks in mild dishwashing detergent and water.
5. Clean metal parts using a sponge or dish cloth with mild dishwashing detergent, then wipe
clean. If scrubbing is necessary, use a nylon or polyester mesh pad or a brush.
6. Store in a cool, dry area.
The oven has a WASH setting on the temperature control.
1. Remove any food and drain fat away from the base.
2. Pour small amount of water in the bowl and turn the convection oven to WASH.
detergent will rinse the
3. The racks can be left in the bowl at the same time to soften any deposits.
4. You may need to use a washing brush for any stubborn debris before rinsing and wiping
clean.
WASH Setting
The combination of the heat, swirling
motion of water and detergent will rinse the glass bowl.
