MagicBox UNNATI 4 User manual

USER MANUAL - MAGIC BOX - UNNATI 4
BOX CONTENTS
Precautions
Protection against Power surge: Unplug the equipment when not in use. Use Surge protecting Power strips.
Protection against Water: Keep device in dry locations and avoid water contact.
Protection against Virus: Use secured Wi-Fi. Use Google Play store only, to download Applications. Use two
Applications provided on device, periodically- LINE Anti-virus and Auto RAM cleaner.
Disclaimer
Some Apps might stall the box because of compatibility Issues. In such cases restart the Magic Box. The company
does not take any responsibility for any content (Software/ Apps/ games) downloaded by the user.
Magic Box may not be compatible with certain High end TV models (Ultra HD and above). Replacement warranty
policy available, within 48 hrs of sale.
SETTING UP OF MAGIC BOX
Connect the Magic Box to your TV via HDMI cable.
Select same HDMI port, using Source / Input button in your TV Remote control unit.
Insert two AAA size batteries, in the Remote-Control Unit.
Connect the Power Adapter to Magic Box and plug into secure power source.
Turn on the supply and wait for Magic Box to display its Home screen.
Unnati 4
If your TV screen does not display Magic Box Home screen or is flickering then, Go to Settings, using
Magic Box Remote control unit  Go to Display  Select HDMI  Then choose lower resolution
from drop list. until the display becomes visible / stable.
Magic Box Unnati 4 HDMI Cable Power Adapter Remote Control User Manual
Android TVBOX
User Manual
Android
TVBOX
MAGIC BOX CONNECTOR INFORMATION
1. Audio-Video OUT (Sound Connector)
2. LAN connector (Ethernet)
3. HDMI connector (TV connection)
4. Power Adaptor connector (5V, 2A)
5. USB 2.0 connector * 2
1 2 345

 Click on the Settings Button
 Click on More Settings  In wireless Network Click on Wi-Fi  Turn ON the Wi-Fi button
 It will show the available
Wi-Fi networks in range
 Click on the Wi-Fi in your
Office / Home and Enter
password
 Once the connection is
established, Magic Box
will be connected to Wi-Fi
Configuring the Magic Box
Connect to Wi-Fi (U4)
 Go to Home Screen  Click on Menu button

Sign in with Google account
To Access Google Applications such as Play store, YouTube, Google drive etc. user has to login to his
Gmail ID.
To sign-in a google account, user can go to the Google Play store and Sign-in.
Fill your Gmail account user ID
After this type your Password for your Gmail ID
Press Accept and Your Gmail Account is Configured and Signed-in
Installing applications from Play Store

Please Note that some Applications are not available on Play store as they are not
compatible /optimized for TV format
 Wait for the Application to download. . .
Click on Open, to start the Application
 Click on Install
First Step is to go to Play store by clicking on the icon
Installing an application from Play Store
In the Play store, type the name of the Application, you want to install

The Applications are categorized as
The Magic Box comes with a variety of Applications installed on the device.
Once in the Menu screen, user can see the newly
installed Application icon. Just select the Application
icon with your Remote and press OK. Refer adjacent
snapshot.
Once inside the folder, user can again click on the desired Application and start using it.
Once the New application is installed,
Go to Home screen and click on Menu button.
Opening pre-installed applications
from Play Store
In the Menu screen, user can see many folders of
different Domains. User can select any of the
Folder by selecting the folder icon with Remote
and press OK. Refer adjacent snapshot.
Applications in Magic Box
Also, Magic Box has the Play store application, from which user can download application of choice.
Entertainment Education Social
Fitness / Covid-19 Music Play Store APP
Opening new application,
installed from Play Store

Remote functions UNNATI 4
Installing Batteries
Insert two AAA size Batteries as per + and – terminals.
Important Note:
If for any reason the Magic Box is not responding then press the Home button of remote to come to home page.
Change to cursor OFF mode, to access Applications on next / previous page, scroll using navigation buttons to
the extreme end of Application screen.
For closing multiple active Applications, long press the home button and close the apps while in Remote cursor
OFF mode.
1. Power Button: Pressing once the Magic Box turns ON / Sleep mode. Long pressing for 3 seconds gives option
of Power OFF.
2. Menu button: Non-Functional.
3. Navigation Button: Navigate through App Menu, Keyboard. Active both in Mouse ON/OFF mode.
4. Back Button: To get back to previous screen.
5. Volume button: Increases / Decrease Volume.
6. Home Button: Return to Home Screen.
7. OK button: Functions as Enter button. Where ever the remote cursor is pointing, the corresponding command
is executed.
8. Remote cursor ON/OFF:
In ON mode, the remote cursor is visible on the screen which enables selected function / key.
In OFF mode, the remote cursor is disabled. Necessary to scroll through Apps and documents.
1
2
3
4
5
6
7
8

Customer support
Warranty terms
1. Free Replacement / Refund, if TV compatibility issue reported, within 48 hrs of sale.
o Replacement will be done only if the packaging is in-tact. Option to replace Magic Box which is
compatible with TV set, by paying according to the MRP of new product, if available in stock.
o Refund will be provided if stock not available.
2. Free Repair, within 12 months from date of installation.
Warranty covers defects arising under normal circumstances and does not include malfunctions / failures
arising from Physical damage, Exposure to water, Power brown out, Power fluctuations, Virus induced from
unauthenticated content download or Acts of nature.
o Any modifications or tampering in Magic Box will void the warranty. Magic Box team, will analyze and
declare final cause of defect. This declaration will define warranty applicability.
Copy of Invoice.
Magic Box with QR code sticker, on rear side.
Non-functional Magic Box unit, to be sent to Repair center, at listed address.
o In warranty units, will be repaired and sent back via courier.
o Out of warranty units will not be repaired.
Warranty requirements
Customer support is available at Toll free number: 18002678466
Monday to Saturday from 10 am to 7 pm.
The Customer support is for warranty related only and not for technical support Issues.
Help Videos for Application installation related procedure is available on our web site. To be referred for any
Application related Issues.
