Magicfx FX-SWITCHPACK MFX3211 Operating manual
FX-
SWITCHPACK.
®
USER AND INSTALLATION MANUAL
CONTROL GEAR PART01245
rev 01-01
ENGLISH
2 MAGICFX® —User and Installation Manual
Read this manual carefully before installing and/or using this
product. Failure to read the manual and to follow the printed
instructions may lead to personal injury and/or damage to the
product.
© 2019 MAGICFX®
All rights reserved.
Nothing from this publication may be copied, reproduced and/or published by
means of printing, photocopying or by any other means, without the prior written
approval of MAGIC FX.
MAGIC FX reserves the right to modify specications stated in this manual.
Any brand names mentioned in this manual are registered trademarks of their
respective owners.
MAGIC FX accepts no liability for claims from third parties arising from unauthorised
use, use other than that stated in this manual, and use other than in accordance with
the General Conditions registered at the Chamber of Commerce.
We further refer to the General Conditions. These are available on request, free of
charge.
Although considerable care has been taken to ensure a correct and comprehensive
description of all relevant components, the manual may nonetheless contain errors
and inaccuracies.
Should you detect any errors or inaccuracies in the manual, we would be grateful if
you would inform us. This helps us to further improve our documentation.
MAGICFX® —User and Installation Manual 3
Disclaimer 2
Trademarks 2
Liability 2
Foreword 4
Language 4
Revision table 4
1 Meet the MAGICFX®
17
4 MAGICFX® —User and Installation Manual
Congratulations! You have bought a great new product from MAGIC FX.
This manual contains all information required for the intended use of the equipment.
Deviation from the described intended use can result in a hazardous situation and/or
property damage.
This manual includes notes and warnings on safe operation of the equipment. These
notes and warnings are accompanied by the following icons. Read them attentively!
Indicates a hazardous situation that, if not avoided, will result in
death or serious injury. This signal word is to be limited to the most
extreme situations.
Indicates a hazardous situation that, if not avoided, could result
in death or serious injury.
Indicates a hazardous situation that, if not avoided, could result
in minor or moderate injury.
Indicates information considered important, but not hazard-
related (e.g. messages relating to property damage).
This document contains the original instructions in English. In case you require other
languages please contact MAGIC FX.
Date
PART01245 01-00 14-11-2017 Initail release MBO TVA
PART01245 01-01 01-08-2019 A4 to A5 format TFR TVA
MAGICFX® —User and Installation Manual
1 ®
The MAGICFX® FX-SWITCHPACK is a DMX switch for safely switching on and o multiple
electronic special eects machines.
The MAGICFX®FX-SWITCHPACK is designed with unique safety features, including a
DMX safety channel which keeps all other channels disabled untill you set it to a
specic value.
1.1
4 LED OUTPUT INDICATORS
4 RESETTABLE OUTPUT
FUSES (5 A)
SAFETY EYE
DISPLAY AND BUTTONS
LEFT SIDE
DMX INPUT
& OUTPUT
(5-POLE)
FX LED INDICATOR
POWER INPUT
& OUTPUT
(100 250 Vac
)
4 SWITCHABLE POWER OUTPUTS
(100 250 Vac)
Main parts
® —User and Installation Manual
1.2
Product Name MAGICFX®FX-SWITCHPACK
Product Code MFX3211
Product Type CONTROL GEAR
Main
Length 140 mm 5.5 in
Width 305 mm 12 in
Height 133 mm 5.2 in
Weight 2.9 kg 6.4 lb
Length 400 mm 15.7 in
Width 260 mm 10.2 in
Height 250 mm 9.8 in
Packaged weight 4.2 kg 9.3 lb
Minimum Temperature -10 °C 14 °F
Maximum Temperature 50 °C 122 °F
Voltage Input 100– 250 Vac
Voltage Frequency 50 – 60 Hz
Power Consumption 15 W
Power Connector Neutrik®powerCON TRUE1 (in & out)
Power Output MAX 5 A per output with resettable
output fuse (max. 16 A in total)
Control Options DMX
Control Protocols DMX512-A (ANSI E1.11)
RDM (ANSI E1.20)
Control Connectors Neutrik®5 pole male / female XLR
Congure Options On Device & RDM
Technical data
1.3
Type plate
MAGICFX® —User and Installation Manual
1.4
MFX0311 Neutrik® powerCON TRUE1 - Male to Female - Link cable 10 m
MFX0312 Neutrik® powerCON TRUE1 - Male to Female - Link cable 20 m
MFX0322 Neutrik® powerCON TRUE1 - Male to Female - Link cable 0.5 m
MFX0323 Neutrik® powerCON TRUE1 - Male to Female - Link cable 1.5 m
MFX0324 Neutrik® powerCON TRUE1 - Male to Female - Link cable 3 m
MFX0325 Neutrik® powerCON TRUE1 - Male to Female - Link cable 5 m
MFX0326 Neutrik® powerCON TRUE1 - Male to Female - Link cable 15 m
MFX0313 Schuko to Neutrik® powerCON TRUE1 - cable 1.5 m X
MFX3103 M10 twenty clamp for truss mounting
Accessories
Please contact MAGIC FX for additional possibilities.
MAIN MENU
DMX/RDM SETTINGS
BACK PREV NEXT
SELECT
Display panel
The display panel is located on the backside of the MAGICFX®FX-SWITCHPACK.
Check the following menu structure for all options in the menu. Use the buttons for
navigation and selection. The le-hand LED blinks red when DMX is active. The right-
hand LED continuously lights red when an error is present.
® —User and Installation Manual
Idle Display
Main Menu
DMX Start Address (1–511)
DMX Safety Address (1–512)
Unique ID
Bootloader CRC
Build Date
Lock/Unlock Controller
(press and hold for 5 seconds)
Reset Errors
DMX/RDM Settings
Error History
Configuration
Information
DMX Footprint
RDM (ON/OFF)
Soware Version
Soware CRC
Display Dimmer (ON/OFF)
(dims aer 30 seconds of button inactivity)
Control Mode
(Sequence/Merged)
Display Flip (On/Off)
Factory Defaults (YES/NO)
Menu structure
In merged mode, the ouputs are controlled together as one.
In merged mode the MAGICFX®FX-SWITCHPACK works with 1 safety address and 1
operational address. The Safety address cannot be the same as one of the
operational addresses.
MAGICFX® —User and Installation Manual
Operating the addresses in merged mode results in the following:
Safety address
0 99 Device disbaled
100 155 Device enabled
156 255 Device disabled
Start address 0 199 All outputs disabled
200 255 All outputs enabled
Operation of the DMX addresses in merged mode
Make sure the outputs are deactivated before activating the
safety address. The safety address cannot be activated when
one or more outputs are activated.
When you link multiple machines with DMX, we advise you to use the same Safety
address for all machines.
Always plug in a DMX Terminator into the DMX output of the nal
unit in the control sequence. Using a DMX Terminator improves
signal reliability.
In sequence mode, the ouputs are controlled individually.
In sequence mode the MAGICFX®FX-SWITCHPACK works with 1 safety address and 4
sequential addresses. The Safety address cannot be the same as one of the
sequential addresses.
Operating the addresses in sequence mode results in the following:
Safety address
0 99 Device disbaled
100 155 Device enabled
156 255 Device disabled
Start address 0 199 Output 1 disabled
200 255 Output 1 enabled
Start address + 1 0 199 Output 2 disabled
200 255 Output 2 enabled
Start address + 2 0 199 Output 3 disabled
200 255 Output 3 enabled
Start address + 3 0 199 Output 4 disabled
200 255 Output 4 enabled
Operation of the DMX addresses in sequence mode
® —User and Installation Manual
Make sure the outputs are deactivated before activating the
safety address. The safety address cannot be activated when
one or more outputs are activated.
When you link multiple machines with DMX, we advise you to use the same Safety
address for all machines.
Always plug in a DMX Terminator into the DMX output of the nal
unit in the control sequence. Using a DMX Terminator improves
signal reliability.
Remote Device Management Protocol (RDM) is an enhancement of the DMX512
communication protocol. RDM can be used for conguration and status monitoring
while DMX512 takes care of the default controlling.
For RDM you will need a RDM compatible controller. The following RDM parameters
are supported by the MAGICFX®FX-SWITCHPACK.
DISC_UNIQUE_BRANCH X
DISC_MUTE X
DISC_UN_MUTE X
DEVICE_INFO X
SUPPORTED_PARAMETERS X
SOFTWARE_VERSION_LABEL X
DEVICE_MODEL_DESCRIPTION X
MANUFACTURER_LABEL X
SLOT_DESCRIPTION X
DMX_PERSONALITY_DESCRIPTION X
DMX_START_ADDRESS X X
IDENTIFY_DEVICE X X
DEVICE_LABEL X X
FACTORY_DEFAULTS X X
DMX_PERSONALITY X X
DISPLAY_INVERT X X
RESET_DEVICE X
RDM parameters
RDM parameters are subject of change due to soware updates. Contact MAGIC FX
for the latest information and updates.
MAGICFX® —User and Installation Manual 11
2
The MAGICFX®FX-SWITCHPACK has been designed and constructed in such a
manner that it can be used safely. This applies to the use, the circumstances and the
regulations as described in this documentation. Reading this documentation and
following the instructions are therefore necessary for everyone who is authorised to
work with the MAGICFX®FX-SWITCHPACK.
The MAGICFX®FX-SWITCHPACK must be used in surroundings that:
• Have a stable temperature of between -10 and 50 °C.
• Have a relative humidity degree between 20% and 90 % (non condensing).
• Are free of dust, corrosive gases and high concentrations of organic vapours.
• Are not situated in the vicinity of a source of vibration.
2.1
• Only authorised persons may carry out work with the MAGICFX®FX-
SWITCHPACK.
• Do not use the MAGICFX®FX-SWITCHPACK if there are people or animals in the
direct output.
• Make sure that children, unauthorised people and animals do not obtain
access to the MAGICFX®FX-SWITCHPACK.
• Make sure there are no freestanding objects or objects that can be damaged
by the connected machines within the output distance.
• Do not remove any safeguards, safety caps and safety symbols.
• All required safety devices must be in good condition and function properly.
• Ensure sucient lighting of the surroundings.
• Keep the workplace clean.
• Refer to the manual(s) of the connected machine(s) for safety instructions
concerning the use of those machines.
2.2
Please follow the European and national guidelines for safe rigging and trussing.
2.3
The voltage and frequency connected to the power input of the MAGICFX®FX-
SWITCHPACK are also the voltage and frequency of the switchable power outputs.
With a maximum electric current per switchable output (see Chapter 1.2 Technical
Data), a deviant input voltage or frequency may cause connected FX-machines to
not work properly. The switchable output cannot deliver the power the FX-machine
might require.
12 MAGICFX® —User and Installation Manual
2.4
Using a damaged or an improper installed switch can lead to
death, serious injury or property damage. Always inspect the
switch thoroughly before operation.
Unauthorized operation of the switch can lead to death, serious
injury or property damage. Never leave the switch unattended
when the machine is ready for use.
3
3.1
Place the switch in a suitable area.
This may either be on a stable surface or on a truss.
To mount the switch on a truss follow the instructions below:
1 Screw two clamps into the holes.
Use two M10 twenty clamps for truss mounting (product code MFX3103).
MAGICFX® —User and Installation Manual 13
2 Mount the clamps rmly on a truss.
3 Secure the switch onto the truss with use of the safety eye.
4 Inspect if the switch is mounted rmly and secured correctly.
14 MAGICFX® —User and Installation Manual
3.2
Do not connect FX-machines to the switchable power output(s)
when the output cannot deliver sucient power to the FX-
machine. See Chapter 1.
1 Connect the PowerCon TRUE1 power cable to the switch.
Connect the other end to a power outlet.
POWER IN POWER OUT
PowerCon TRUE1 female
POWER
Always plug in a DMX Terminator into the DMX output. Using a
DMX Terminator improves signal reliability.
MAGICFX® —User and Installation Manual
2 Connect the female connector of a 5-pole DMX cable to the DMX input on the
switch.
Connect the other end to your DMX controller.
DMX IN DMX OUT
5-pole female
DMX
3 Make sure the resettable output fuses are in position ‘1’.
® —User and Installation Manual
4 Check the LED output indicators to see if the outputs are activated.
If not: Connect the male connector of the PowerCon TRUE1 link cable(s) to your
FX-machine(s).
Connect the other end(s) to the switched output(s) on the switch.
POWER
PowerCon TRUE1 male
Use the display and buttons to set the machine into SEQUENCE or MERGED
mode and to assign DMX addresses, see chapter 1.
3.3
1. Before switching, refer to the manual(s) of your connected FX-machine(s) for
safety instructions.
2. Make sure all outputs are deactivated.
3. Activate the Safety address. The FX LED indicator on the FX-SWITCHPACK lights
up.
4. When it’s time to switch, activate the necessary operational channel(s), see
Chapter 1.
When you are done with switching, deactivate the operational addresses.
Deactivate the Safety address.
MAGICFX® —User and Installation Manual
3.4
1. Make sure the Safety address is deactivated.
2. First disconnect the power cable from the FX-SWITCHPACK. Then disconnect
the link cables and the DMX cable.
3. Remove the machine.
4
To achieve the maximum service life of the MAGICFX®FX-SWITCHPACK you must
regularly clean the MAGICFX®FX-SWITCHPACK and test if it is functioning correctly.
Contact MAGIC FX if the MAGICFX®FX-SWITCHPACK is not functioning correctly.
Do not replace parts yourself; always consult MAGIC FX.
Always contact MAGIC FX if any malfunctions or errors occur that cannot be solved
with the instructions as described in this manual.
This symbol on the product and / or accompanying documents
means that used electrical and electronic products should not be
mixed with general household waste. For proper treatment,
recovery and recycling, please take this product to designated
collection points where it will be accepted free of charge.
Alternatively, in some countries you may be able to return your
products to your local retailer upon purchase of an equivalent new
product.
Disposing of this product correctly will help save valuable resources and prevent any
potential negative eects on human health and the environment, which could
otherwise arise from inappropriate waste handling.
Please contact your local authority for further details of your nearest designated
collection point.
Penalties may be applicable for incorrect disposal of this waste, in accordance with
your national legislation.
® —User and Installation Manual
According to Annex III A Low Voltage Directive 2014/35/EU
MAGIC FX B.V. declares as manufacturer and composer of the technical construction file that the
product with the following specifications:
Name machine : FX-SWITCHPACK
Type : MFX3211
Voltage : 100-250Vac 50-60Hz
Serial number : on product
Year of construction : on product
Is in conformity with the minimal safety regulations as stated in the following directive(s):
•EMC (2014/30/EC) ElectroMagnetic Compatibility
•RoHS (2011/65/EU) Restriction of the use of certain Hazardous Substances
•WEEE (2012/19/EU) Waste Electrical & Electronic Equipment
The following harmonized standards were applied:
•NEN-EN-ISO 12100:2010, Safety of machinery - General principles for design - Risk
assessment and risk reduction.
•NEN-EN-IEC 60204:2010, Safety of machinery - Electrical equipment of machines - Part 1:
General requirements.
•NEN-EN-IEC 61000-6-3:2007/A1:2011, Electromagnetic compatibility (EMC) - Part 6-3:
Generic standards - Emission standard for residential, commercial and light-industrial
environments.
Original declaration of conformity
Translation of the original declaration of conformity
Name manufacturer : MAGIC FX BV
Address : Schouwrooij 27, 5281 RE BOXTEL
Country : The Netherlands
CEO : B. Veroude
Date : 6-10-2017
Signature :
WWW.MAGICFX.EU
Table of contents
Other Magicfx Switch manuals
