Magnaflux CSV-15 User manual

CSV-15 Series
© 2015 Magnaflux
Page 1 Magnaflux-SRVC-IG017
Issued: Apr 2015
Rev. 2
CSV-15 Series
Congratulations on the purchase of your new Magnaflux
CSV-10 Magnetic Particle Inspection Machine! This guide
will help you install and set-up your new Magnaflux machine.
If you have any questions, please contact your local
Magnaflux Authorized Service Center or call Magnaflux
Customer Service at 847-657-5300.

CSV-15 Series
© 2015 Magnaflux
Page 2 Magnaflux-SRVC-IG017
Issued: Apr 2015
Rev. 2
1. A minimum of two feet is required at both ends and the rear of the inspection unit to ensure
adequate space for servicing (removing machine panels) and ventilation.
2. A firm, reasonably level floor capable of supporting the inspection unit and the materials
awaiting inspection.
Operating Manual and
Drawings
The manual is shipped with the unit in electronic format wrapped
in a green bubble wrap mailer within the Accessories Box. In the
manual is an extensive step by step process of how to assemble
the enclosure and attach it to the unit.
Getting Started
Right Side of Unit:
(looking from the front)
Set-Up
Incoming Power
Connections
Chassis Ground Connection
(on floor of unit)

CSV-15 Series
© 2015 Magnaflux
Page 3 Magnaflux-SRVC-IG017
Issued: Apr 2015
Rev. 2
Electrical Input:
Input Volts AC Phase
Full Load
(Amps)
Recommended
Line Fuse (Amps)
Recommended
Wire Size (AWG)
208 N/A N/A N/A N/A
230 N/A N/A N/A N/A
380 3360 300 Per NEC Code
415 3340 260 Per NEC Code
460 3300 230 Per NEC Code
575 3240 190 Per NEC Code
Duty Cycle:
At full output: 0.5 seconds “ON” – 20 seconds “OFF”
The equipment can be fused based on less than the maximum amperage draw due to the duty
cycle. Refer to NEC Code Section 630.31 Ampacity of Supply Conductors and Table 630.31
(A) (2) Duty Cycle Multiplication Factors for Resistance Welders (NPFA National Electric Code
2011). Some areas refer to 2 phase instead of 1 phase. The incoming power goes directly to
an isolation transformer so the unit will operate identically on 1 or 2 phase power.
Note: To obtain full rated output the following conditions must be met:
1. No more than 30’ of 1000 MCM cable double 30’ 4/0 cables attached to each of the Output
Lugs on the front of the unit. If Output 2 and/or 3 are not used — No need to hookup ca-
bles to that output.
2. A power source of the proper voltage, frequency and phase (as designated on the Mag-
naflux Data Plate) capable of providing current per the nameplate for the power pack. It is
highly recommended that an electrical fused disconnect be installed either on the wall be-
hind the unit or on a pedestal near the unit.
