Magnetek Elevator Quattro DC User manual

Quattro™ DC
Quattro™ DC Elevator Drive
Technical Manual
To properly use the product, read this manual thoroughly and retain for easy reference, inspection,
and maintenance. Ensure that the end user receives this manual.
TM7337 rev 23
© Magnetek Elevator 2018

WARRANTY Standard products manufactured by the Company are warranted to be free from
defects in workmanship and material for a period of one year from the date of
shipment, and any products which are defective in workmanship or material will be
repaired or replaced, at the Company’s option, at no charge to the Buyer. Final
determination as to whether a product is actually defective rests with the Company.
The obligation of the Company hereunder shall be limited solely to repair or replace,
at the Company’s discretion, products that fall within the foregoing limitations, and
shall be conditioned upon receipt by the Company of written notice of any alleged
defects or deficiency promptly after discovery and within the warranty period, and in
the case of components or units purchased by the Company, the obligation of the
Company shall not exceed the settlement that the Company is able to obtain from the
supplier thereof. No products shall be returned to the Company without its prior
consent. Products which the company consents to have returned shall be shipped
prepaid f.o.b. the Company factory. The Company cannot assume responsibility or
accept invoices for unauthorized repairs to its components, even though defective.
The life of the products the Company depends, to a large extent, upon type of usage
thereof and THE COMPANY MAKES NO WARRANTY AS TO FITNESS OF ITS
PRODUCTS FOR THE SPECIFIC APPLICATIONS BY THE BUYER NOR AS TO
PERIOD OF SERVICE UNLESS THE COMPANY SPECIFICALLY AGREES
OTHERWISE IN WRITING AFTER PROPOSED USAGE HAS BEEN MADE KNOWN
TO IT.
This warranty does not apply to experimental products for which no warranty is made
or given and Buyer waives any claim thereto.
THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, BUT LIMITED TO, ANY
WARRANTY OF MECHANTIBILITY OR OF FITNESS FOR A PARTICULAR
PURPOSE AND BUYER HEREBY WAIVES ANY AND ALL CLAIMS THEREFORE.
LIMITATIONS IN NO EVENT SHALL MAGNETEK BE LIABLE FOR LOSS OF PROFIT,
OF LIABILITY INDIRECT, CONSEQUENTIAL OR INCIDENTAL DAMAGES WHETHER
ARISING OUT OF WARRANTY, BREACH OF CONTRACT OR TORT.
QUATTRO is a trademark of Magnetek, Inc.
All rights reserved. No part of this publication may be reproduced or used in any form or by any means - graphic, electronic, or
mechanical including photocopying, recording, taping, or information storage and retrieval systems - without written permission
of the publisher.
 2018 Magnetek, Inc.

1
Quattro™ Startup guide
1. Prior to applying any voltage to the drive complete the following steps.
2. Record the following motor data;
a. Rated Motor Volts, Amps, Field amps forcing, Field amps running
b. Rated motor RPM, Rated encoder PPR, Elevator speed (ft/min, m/sec, mm/sec)
c. If using a friction wheel, find the ratio between wheel and the surface it is riding on
3. Disconnect the motor armature wires and the field wires from the drive;
a. Using a megger at 500 – 1000V, a good reading is 2Mohms or larger.
i. Armature
1. Check A1 to ground
2. Check A2 to ground
3. If a breakdown is detected this must be addressed before
proceeding.
ii. Field
1. Check F1 to ground
2. Check F2 to ground
3. If a breakdown is detected this must be addressed before
proceeding.
iii. Armature - Field
1. Check A1 /2 to F1 / 2
2. If a breakdown is detected this must be addressed before proceeding.
b. Measure the total field resistance (F1 – F2) with a DVOM, record this number.
c. Measure the resistance of each individual field coil.
d. Perform an AC drop test on the field coils.
i. Apply 120 / 240VAC to F1 and F2, measure the AC voltage on each coil.
1. These numbers should be similar for each coil.
4. Is Quattro configured with the standard field module or the alternate low voltage version?
a. High voltage module generates motor field current from 1 – 40A. This module will
work for all cases and has no additional switches or jumpers to set.
b. Low voltage module is design for to separate ranges; 1- 20A and 20 -40A. The
hardware requires two separate hardware setups to set the range. This module can
be identified by the addition of a transformer plugged in at location J3, for the low
range this must be located in the ‘A’ position and the high range would be the ‘B’. In
addition JP1 jumper must be installed in the ‘A’ location for low and ‘B’ for the high
range.
If using the low voltage supply, this quick check should be completed to verify it will work on
this specific motor;
Calculate both Vbus (DC bus voltage) and Vf (voltage required on the motor field to reach full
field amps).
Vbus = (Vin x SQRT 2) + DC Bus Voltage Boost (A5), where Vin is the three phase AC
voltage applied to the Quattro, if an auto-transformer is used then this would be measured at
the secondary, SQRT 2 = 1.41, DC Bus Voltage Boost (A5) is defaulted to 30 and has the
range of 15 – 75.
Vf = Full FLD Current (A6) x Field resistance, where the Full FLD Current is the maximum DC
current which will be applied to the motor fields, field resistance is obtained by disconnecting
the motor field wires at TB3 – 1 and TB3 -2 and measuring the resistance. A typical number
for this would be 5 – 100 ohms.
These are the two condition which are being tested;

a. Full FLD Current (A6) less than or equal to 20
a. Vbus / 2 must be greater than or equal to (Vf x 1.5)
b. Full FLD Current (A6) greater than 20
a. Vbus / 4 must be greater than or equal to (Vf x 1.5)
If either of these conditions are not true then the standard field module must be used
5. Input voltage requirements.
These are the two equations to calculate to determine the minimum AC voltage applied to the
drive based on the conditions;
‐ Rated drive amps is the current rating of the Quattro
DC drive 125, 150, 200, 250, 300.
‐ Full Load Motor Volts is the required voltage to run at
contract speed up at full load. If this isn’t know use the
motor nameplate volts.
a. V L-L = (((Full Load Motor Voltage X 1.3) – 75) / 1.41)
Equation 1. Nominal Line to Line voltage
b. V L-L = ((Rated motor current X Full Load Motor voltage x 0.92) / rated
drive amps)
Equation 2. Nominal Line to Line voltage
The drive will require the larger of the values from Equation 1 and 2. This determines
minimum voltage required to operate that motor. If the actual voltage is less than this calculation, then
it would be required that the voltage be stepped up. Magnetek has optional Auto transformers
specifically designed for this purpose and will fit within the Quattro drive enclosure. If the actual
voltage applied to the Quattro exceeds 1.5 x rated motor voltage, then it would be recommended that
the voltage be stepped down to closer to 1 to 1.1 times rated motor voltage. The chart shown below
provides a method to select an auto transformer.
6. Open the fuse holders in the drive labeled F1, 2, 3, 4
7. Apply three phase power to the drive, measure the 230V control power on the line side of F1,
F2. This should be between 220 and 240Vac.
8. Turn off the three phase power and close the F1, F2 fuse holders. Re-apply the three phase
power. Locate the LV Power Distribution PCB (A10), verify the low voltage DC levels;

3
a. Check TP1 +5V, TP3 +15V, TP4 -15V, Reference TP2 COM, TP5 +24V, reference
TP6 C_24V.
9. Verify all of the drive parameters are set according to the controller manufacturers
recommendations.
10. Close the F3, F4 fuse holders, and clip the meter leads on those same points. Set the meter
on DC voltage. Push the PCM relay in for about 1s (damage will occur if held in longer!!),
then release, the meter should read the line voltage x 1.41. Dropping slowly is normal, quick
is not a good condition.
11. Once, the drive has passed all of the steps, the drive is ready to run the auto tune. To start
the process, go to the selection ‘A4 AUTO TUNE MOTOR’. If it completes with no faults, then
go into the A4 menu and select the gain selection method ‘Use self-tune’, the drive is ready to
run the elevator.
12. Next, the field current can be adjusted.
a. In the A6 menu, there is forcing current, running current and standing current. The
forcing current may be on the motor N.P. or perhaps the field voltage is available (FFA
= FFV / Field R). After that step is complete, run the elevator from bottom to top at
100% contract speed, adjust the weak field amps until the armature volts measure
nameplate. Standing field can be set to 10 – 25% of the forcing current.
13. At balanced load run the elevator from bottom to top, then top to bottom. Look in the D1 menu
and locate the Estimated Inertia, enter this as the new inertia in the A1 menu.

Table of Contents
Introduction ............................................................................................................. 16
Drive Ratings and Specifications ....................................................................................................... 16
Software Operating Features ............................................................................................................. 17
Drive Model Numbers ........................................................................................................................ 17
Part Number Definition ........................................................................................... 18
QDC AAA-1BCD-EE ................................................................................................ 18
Quattro startup guide ............................................................................................. 19
Initial Inspection ................................................................................................................................. 19
Advanced output filter ........................................................................................................................ 21
Grounding considerations .................................................................................................................. 21
Initial adjustments after power up ...................................................................................................... 22
Interconnections ..................................................................................................... 24
Drive Sequencing .................................................................................................... 31
NORMAL operating sequence ........................................................................................................... 31
ABNORMAL operating sequence ...................................................................................................... 32
Quattro Pre-Charge ........................................................................................................................... 32
Drive Operation and Feature Overview ................................................................. 33
Analog Velocity Follower ................................................................................................................... 33
Preset Speed & Profile Generator ..................................................................................................... 33
Serial Link Follower ............................................................................................................................ 33
Pre-Torque ......................................................................................................................................... 33
Torque Feed Forward ........................................................................................................................ 33
Torque/Current Ramp-Down ............................................................................................................. 33
Motor Field Current Control and Field weakening ............................................................................. 33
DSPR ................................................................................................................................................. 34
Over-Speed Test ................................................................................................................................ 34
Fault & Alarm Reset ........................................................................................................................... 34
Electronic Motor Over-Load ............................................................................................................... 34
Armature Voltage Feedback .............................................................................................................. 34
EN81-1 Single Contactor .................................................................................................................. 35
Parameters .............................................................................................................. 36
Parameter Introduction ...................................................................................................................... 36
Menu Navigation ................................................................................................................................ 37
Parameter Tree .................................................................................................................................. 39
Adjust A0 menu ....................................................................................................... 41
Drive A1 submenu ............................................................................................................................. 41
S-Curves A2 submenu ....................................................................................................................... 51
Multistep Ref A3 submenu ................................................................................................................. 53
Motor Side Power Convert A4 submenu ........................................................................................... 55
Line Side Power Converter A5 submenu........................................................................................... 57

5
Motor Parameters A6 submenu ......................................................................................................... 59
Configure C0 menu ................................................................................................. 64
User Switches C1 submenu .............................................................................................................. 64
Logic Inputs C2 submenu .................................................................................................................. 78
Logic Outputs C3 submenu ............................................................................................................... 81
Analog Outputs C4 submenu ............................................................................................................. 83
Display D0 menu ..................................................................................................... 84
Elevator Data D1 submenu ................................................................................................................ 84
MS Power Data D2 submenu ............................................................................................................ 87
LS Power Data D3 submenu ............................................................................................................. 88
Utility U0 menu ........................................................................................................ 89
Fault F0 menu .......................................................................................................... 95
Maintenance ............................................................................................................ 97
Maintenance Overview ...................................................................................................................... 97
Drive Servicing ................................................................................................................................... 97
Troubleshooting ...................................................................................................... 98
Appendix ................................................................................................................ 122
Auto Tune Procedure ....................................................................................................................... 122
................................................................................................................................ 122
Inertia Calculations .......................................................................................................................... 124
Anti-Rollback .................................................................................................................................... 125
EMC Compliance ............................................................................................................................. 128
Encoder Cable Clamps .................................................................................................................... 128
Testpoints (Main Control Board – Power Supplies) ......................................................................... 129
Testpoints (Product Interface Board – Power Supplies) .................................................................. 130
Testpoints (Product Interface Board – Other) .................................................................................. 131
Testpoints (Product Interface Board - LED definitions) ................................................................... 132
Testpoints (Power Distribution Board – Power Supplies) ................................................................ 133
Testpoints (Gate Drive Board – LED definitions) ............................................................................. 134
Testpoints (Customer Interface Board – Power Supplies) .............................................................. 136
Testpoints (Customer Interface Board – Other) .............................................................................. 137
Control Power Consumption ............................................................................................................ 138
Watts Loss ....................................................................................................................................... 138
Input / Output Ratings ...................................................................................................................... 138
Wire Terminal Specs ........................................................................................................................ 139
Note: Additional ground terminal lugs are located at the top of the drive on right side of the chassis.
These lugs will accommodate ground wires in the range of #6-350MCM (10-175mm^2) .............. 139
Dimensions / Weights Standard ...................................................................................................... 141
Dimensions / Weights with Top Hat ................................................................................................. 142
Component Locations ...................................................................................................................... 149
Low Voltage Field Module ............................................................................................................... 154
Input Voltage Requirements ............................................................................................................ 156
Spare Parts Quattro DC Drive ......................................................................................................... 160
Index ....................................................................................................................... 171

6
Sub
menu Parameter Units Range Default Site
Setting
A1 Drive A1 Submenu – See Drive A1 submenu on page 41.
A1 CONTRACT CAR SPD fpm 0.0 – 1500.0 100.0
m/s 0.000 – 8.000 2.000
A1 CONTRACT MTR SPD RPM 30.0 – 3000.0 50.0
A1 RESPONSE rad/sec 1.0 – 20.0 5.0
A1 INERTIA sec 0.25 – 10.00 2.00
A1 INNER LOOP XOVER rad/sec 0.1 – 20.0 2.0
A1 CURRENT LIMIT % 0.0 – 300.0 250.0
A1 GAIN REDUCE MULT % 10 – 100 100
A1 GAIN CHNG LEVEL % of rated spd 0.0 – 100.0 100.0
A1 TACH FILTER BW rad/sec 1 – 100 100
A1 TACH RATE GAIN none 0.0 – 30.0 0.0
A1 SPD PHASE MARGIN degrees 45 – 90 80
A1 RAMPED STOP TIME sec 0.00 – 2.50 0.20
A1 CONTACT FLT TIME sec 0.10 – 5.00 0.50
A1 BRAKE PICK TIME sec 0.00 – 5.00 1.00
A1 BRAKE HOLD TIME sec 0.00 – 5.00 0.50
A1 OVERSPEED LEVEL % of contract spd 90.0 – 150.0 115.0
A1 OVERSPEED TIME sec 0.00 – 9.99 0.10
A1 OVERSPEED MULT % 100.0 – 150.0 125.0
A1 ENCODER PULSES PPR 600 – 20000 5000
A1 ENC RATIO MULT none 0.001 – 32.000 1.000
A1 SPD DEV LO LEVEL % of contract spd 0.1 – 20.0 10.0
A1 SPD DEV TIME sec 0.00 – 9.99 0.50
A1 SPD DEV HI LEVEL % of contract spd 0.0 – 99.9 10.0
A1 SPD COMMAND BIAS volts -6.00 – +6.00 0.00
A1 SPD COMMAND MULT none 0.90 – 5.00 1.00
A1 EXT TORQUE BIAS volts -6.00 – +6.00 0.00
A1 EXT TORQUE MULT none -10.00 – +10.00 1.00
A1 PRE TORQUE TIME sec 0.00 –10.00 0.00
A1 ZERO SPEED LEVEL % of contract spd 0.00 – 99.99 1.00
A1 ZERO SPEED TIME sec 0.00 – 9.99 0.10
A1 UP/DWN THRESHOLD % of contract spd 0.00 – 9.99 1.00
A1 ANA 1 OUT OFFSET % -99.9 – +99.9 0.0
A1 ANA 2 OUT OFFSET % -99.9 – +99.9 0.0
A1 ANA 1 OUT GAIN none 0.0 – 10.0 1.0
A1 ANA 2 OUT GAIN none 0.0 – 10.0 1.0
A1 FLT RESET DELAY sec 0 – 120 5
A1 FLT RESETS/HOUR faults 0 – 10 3
A1 UP TO SPD. LEVEL % of contract spd 0.00 – 110.00 90.00
A1 RUN DELAY TIMER sec 0.00 – 0.99 0.00
A1 AB ZERO SPD LEV % 0.00 – 2.00 1.00
A1 AB OFF DELAY sec 0.00 – 9.99 0.00
A1 CONTACTOR DO DLY sec 0.00 – 5.00 0.00
A1 TRQ LIM MSG DLY sec 0.00 – 10.00 0.50
A1 ARB MODE none 0 - 2 0
A1 ARB BANDWIDTH RAD 1.00 – 15.00 6.00
A1 ARB DAMPING none 0.01 – 20.00 2.00
A1 ARB SPEED
THRESHOLD none 0.00 – 10.00 0.00
A1 NOTCH FILTER FRQ Hz 5 – 60 20
A1 NOTCH FILT DEPTH % 0 – 100 0
A1 STNDBY FLD TIME sec 0 – 999 5

Quattro DC Quick Parameter Reference
7
Sub
menu Parameter Units Range Default Site Setting
A1 DSPR TIME min 0 – 546 10
A1 FULL FIELD FLT TIME min 0 – 99 1
A1 SER2 INSP SPD ft/s2 0 – 100 30
m/s2 0
–
0.500 0.150
A1 SER2 RS CRP SPD ft/s2 0 – 300 10
m/s2 0 – 1.540 0.050
A1 SER2 RES CRP TIME Sec 0 – 200.0 180
A1 SER2 FLT TOL Sec 0 – 2.00 0.5
A2 S-Curves A2 Submenu – See S-Curves A2 submenu on page 51.
A2 ACCEL RATE 0 ft/s2 0.00 – 7.99 7.99
m/s2 0.000 – 3.999 2.000
A2 DECEL RATE 0 ft/s2 0.00 – 7.99 7.99
m/s2 0.000 – 3.999 2.000
A2 ACCEL JERK IN 0 ft/s3 0.0 – 29.9 0.0
m/s3 0.00 – 9.99 0.00
A2 ACCEL JERK OUT 0 ft/s3 0.0 – 29.9 0.0
m/s3 0.00 – 9.99 0.00
A2 DECEL JERK IN 0 ft/s3 0.0 – 29.9 0.0
m/s3 0.00 – 9.99 0.00
A2 DECEL JERK OUT 0 ft/s3 0.0 – 29.9 0.0
m/s3 0.00 – 9.99 0.00
A2 ACCEL RATE 1 ft/s2 0.00 – 7.99 7.00
m/s2 0.000 – 3.999 0.090
A2 DECEL RATE 1 ft/s2 0.00 – 7.99 3.00
m/s2 0.000 – 3.999 0.090
A2 ACCEL JERK IN 1 ft/s3 0.0 – 29.9 8.0
m/s3 0.00 – 9.99 2.40
A2 ACCEL JERK OUT 1 ft/s3 0.0 – 29.9 8.0
m/s3 0.00 – 9.99 2.40
A2 DECEL JERK IN 1 ft/s3 0.0 – 29.9 8.0
m/s3 0.00 – 9.99 2.40
A2 DECEL JERK OUT 1 ft/s3 0.0 – 29.9 8.0
m/s3 0.00 – 9.99 2.40
A2 ACCEL RATE 2 ft/s2 0.00 – 7.99 3.00
m/s2 0.000 – 3.999 0.090
A2 DECEL RATE 2 ft/s2 0.00 – 7.99 3.00
m/s2 0.000 – 3.999 0.090
A2 ACCEL JERK IN 2 ft/s3 0.0 – 29.9 8.0
m/s3 0.00 – 9.99 2.40
A2 ACCEL JERK OUT 2 ft/s3 0.0 – 29.9 8.0
m/s3 0.00 – 9.99 2.40
A2 DECEL JERK IN 2 ft/s3 0.0 – 29.9 8.0
m/s3 0.00 – 9.99 2.40
A2 DECEL JERK OUT 2 ft/s3 0.0 – 29.9 8.0
m/s3 0.00 – 9.99 2.40
A2 ACCEL RATE 3 ft/s2 0.00 – 7.99 3.00
m/s2 0.000 – 3.999 0.090
A2 DECEL RATE 3 ft/s2 0.00 – 7.99 3.00
m/s2 0.000 – 3.999 0.090
A2 ACCEL JERK IN 3 ft/s3 0.0 – 29.9 8.0
m/s3 0.00 – 9.99 2.40
A2 ACCEL JERK OUT 3 ft/s3 0.0 – 29.9 8.0
m/s3 0.00 – 9.99 2.40
A2 DECEL JERK IN 3
ft/s3 0.0 – 29.9 8.0
m/s3 0.00 – 9.99 2.40

Quattro DC Quick Parameter Reference
8
Sub
menu Parameter Units Range Default Site Setting
A2 DECEL JERK OUT 3 ft/s3 0.0 – 29.9 8.0
m/s3 0.00 – 9.99 2.40
A2 ACCEL RATE 4 ft/s3 0.0 – 7.99 5
m/s3 0.000 – 3.999 1.52
A2 DECEL RATE 4 ft/s3 0.0 – 7.99 5
m/s3 0.000 – 3.999 1.52
A2 ACCEL JERK IN 4 ft/s3 0.0 – 29.9 0
m/s3 0.00 – 9.99 0
A2 ACCEL JERK OUT 4 ft/s3 0.0 – 29.9 0
m/s3 0.00 – 9.99 0
A2 DECEL JERK IN 4 ft/s3 0.0 – 29.9 0
m/s3 0.00 – 9.99 0
A2 DECEL JERK OUT 4 ft/s3 0.0 – 29.9 0
m/s3 0.00 – 9.99 0
A3 Multistep Ref A3 Submenu – See Multistep Ref A3 submenu on page 53.
A3 SPEED COMMAND 1 ft/min -3000.0 – +3000.0 0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 2 ft/min -3000.0 – +3000.0 0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 3 ft/min -3000.0 – +3000.0 0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 4 ft/min -3000.0 – +3000.0 0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 5 ft/min -3000.0 – +3000.0 0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 6 ft/min -3000.0 – +3000.0 0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 7 ft/min -3000.0 – +3000.0 0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 8 ft/min -3000.0 – +3000.0 0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 9 ft/min -3000.0 – +3000.0 0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 10 ft/min -3000.0 – +3000.0 0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 11 ft/min -3000.0 – +3000.0 0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 12 ft/min -3000.0 – +3000.0 0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 13 ft/min -3000.0 – +3000.0 0.0
m/sec -16.000 – +16.000 0.000
A3 ft/min -3000.0 – +3000.0 0.0
