Magnum Energy RD-E Series User manual

RD-E Series
Modified Sine Wave
Inverters/Chargers
Owner’s Manual

© 2010 Magnum Energy, Inc.Page i
Disclaimer of Liability
The use of this manual and the conditions or methods of installation, operation, use, and
maintenance of the RD-E Series Inverter/Charger is beyond the control of Magnum Energy Inc.
Therefore, this company assumes no responsibility and expressly disclaims any liability for loss,
damage, or expense whether direct, indirect, consequential, or incidental that may arise out of or
be in anyway connected with such installation, operation, use, or maintenance.
Due to continuous improvements and product updates, the images shown in this manual may not
exactly match the unit purchased.
Restrictions on Use
The RD-E Series Inverter/Charger may only be used in life-support devices or systems with the
express written approval of Magnum Energy. Failure of the RD-E Series Inverter/Charger can
reasonably be expected to cause the failure of that life-support device or system, or to affect the
safety or effectiveness of that device or system. If the RD-E Series Inverter/Charger fails, it is
reasonable to assume that the health of the user or other persons may be endangered.
Copyright Notice
Copyright © 2004, 2010 by Magnum Energy, Inc. All rights reserved. Permission to copy,
distribute, and/or modify this document is prohibited without express written permission by Mag-
num Energy, Inc.
Contact Information
Magnum Energy, Inc.
2211 West Casino Rd.
Everett, WA 98204
Phone: [phone]
Fax: [phone]
Web: www.magnumenergy.com
Magnum Energy® is a registered trademark of Magnum Energy, Inc.
Record the unit’s model and serial number in case you need to provide this
information in the future. It is much easier to record this information now,
instead of trying to gather it after the unit has been installed.
Model: Serial Number:
RD2624E Z1
RD4024E W1

Page ii © 2010 Magnum Energy, Inc.
IMPORTANT SAFETY INSTRUCTIONS
This manual contains important safety instructions that must be followed during the installation
and operation of this product.
All electrical work must be performed in accordance with local, state and federal electrical codes.
Read all instructions and safety information contained in this manual before installing or using
this product.
This product is designed for indoor/compartment installation. It must not be exposed to rain,
snow, moisture, or liquids of any type.
Use insulated tools to reduce the chance of electrical shock or accidental short circuits.
Remove all jewelry such as rings, watches, bracelets, etc., when installing or performing
maintenance on the inverter.
Always disconnect the batteries or energy source prior to installing or performing maintenance
on the inverter.
Live power may be present at more than one point since an inverter utilizes both batteries
and AC.
Always verify proper wiring prior to starting the inverter.
There are no user-serviceable parts contained in this product.
This unit is provided with integral protection against overloads.
The input and output AC and DC circuits are isolated from the inverter chassis. The inverter
system grounding is the responsibility of the installer in accordance with the NEC/CEC and
local codes.
Both AC and DC overcurrent protection must be provided as part of the installation.
Use Class 1 wiring methods for field-wiring connections to terminals of a Class 2 circuit.
Use only copper wires with a minimum temperature rating of 90°C.
Listed or labeled equipment shall be installed and used in accordance with any instructions
included in the listing or labeling.
Safety Symbols
To reduce the risk of electrical shock, fire, or other safety hazard, the following safety symbols have
been placed throughout this manual to indicate dangerous and important safety instructions.
WARNING: This symbol indicates that failure to take a specified action could result in
physical harm to the user.
CAUTION: This symbol indicates that failure to take a specified action could result in
damage to the equipment.
Info: This symbol indicates information that emphasizes or supplements important
points of the main text.
Remedy: This symbol provides possible solutions for related issues.
SAVE THESE INSTRUCTIONS
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

© 2010 Magnum Energy, Inc.Page iii
IMPORTANT BATTERY SAFETY INSTRUCTIONS
Be very careful when working around batteries, they can produce extremely high currents
if short-circuited. Read the battery supplier’s precautions before installing the inverter and
batteries.
Wear eye protection such as safety glasses when working with batteries.
Remove all jewelry such as rings, watches, bracelets, etc., when installing or performing
maintenance on the inverter.
Never work alone. Always have someone near you when working around batteries.
Use proper lifting techniques when working with batteries.
Never use old or untested batteries. Check each battery’s label for age, type, and date code
to ensure all batteries are identical.
Batteries are sensitive to changes in temperature. Always install batteries in a stable
environment.
Install batteries in a well ventilated area. Batteries can produce explosive gases. For
compartment or enclosure installations, always vent batteries to the outside.
Provide at least one inch (2.5 cm) of air space between batteries to provide optimum
cooling.
Never smoke in the vicinity of batteries.
To prevent a spark at the battery and reduce the chance of explosion, always connect the
cables to the batteries first. Then connect the cables to the inverter.
Use insulated tools at all times.
Always verify proper polarity and voltage before connecting the batteries to the inverter.
To reduce the chance of fire or explosion, do not short-circuit the batteries.
In the event of accidental exposure to battery acid, wash thoroughly with soap and water. In
the event of exposure to the eyes, flood them for at least 15 minutes with running water and
seek immediate medical attention.
Recycle old batteries.
SAVE THESE INSTRUCTIONS
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

Page iv © 2010 Magnum Energy, Inc.
Table of Contents
1.0 Introduction..................................................................................1
1.1 Features and Benefits................................................................................. 2
1.2 How an Inverter/Charger Works................................................................... 5
1.3 What Appliances will run from a Modified Sine Wave Inverter........................... 5
1.4 Appliances and Run Time ............................................................................ 5
2.0 Installation ...................................................................................7
2.1 Pre-Installation.......................................................................................... 7
2.2 Mounting the Inverter ...............................................................................10
2.3 Wiring the Inverter - General Requirements .................................................12
2.4 DC Wiring ................................................................................................13
2.5 AC Wiring ................................................................................................19
2.6 Grounding Inverters..................................................................................24
2.7 Inverter Notification Requirements ..............................................................28
2.8 Final Inspection ........................................................................................28
2.9 Functional Test .........................................................................................29
3.0 Operation....................................................................................30
3.1 Inverter Mode ..........................................................................................30
3.2 Standby Mode ..........................................................................................31
3.3 Battery Charging ......................................................................................31
3.4 Transfer Time ...........................................................................................33
3.5 Battery Temperature Sensor Operation ........................................................33
3.6 Protection Circuitry Operation.....................................................................34
3.7 Inverter Startup .......................................................................................35
3.8 Factory Default Values ...............................................................................36
4.0 Maintenance and Troubleshooting...............................................37
4.1 Recommended Inverter and Battery Care.....................................................37
4.2 Troubleshooting ........................................................................................38
4.3 Resetting the Inverter ...............................................................................39
Appendix A - Specifications and Optional Equipment...........................40
A-1 Inverter/Charger Specifications ..................................................................40
A-2 Optional Equipment and Accessories............................................................41
A-3 Wiring Color Codes for Europe and the U.S./Canada ......................................42
Appendix B - Battery Information .......................................................43
B-1 Battery Location .......................................................................................43
B-2 Battery Types...........................................................................................43
B-3 Battery Temperature .................................................................................43
B-4 Battery Bank Sizing ..................................................................................43
B-5 Battery Bank Sizing Worksheet ...................................................................44
B-6 Battery Wiring Configurations .....................................................................45
Limited Warranty ................................................................................47
How to Receive Repair Service ............................................................47

© 2010 Magnum Energy, Inc.Page v
List of Figures
Figure 1-1, Power Switch, Status LED, and Accessory Connection Ports................................................3
Figure 1-2, Electrical Connection Points ...........................................................................................3
Figure 1-3, Left Side Features ........................................................................................................4
Figure 2-1, Simplified Installation Diagram for Permanent Installations ................................................8
Figure 2-2, Approved Mounting Positions ....................................................................................... 10
Figure 2-3, RD-E Series Dimensions and Side Reference .................................................................. 11
Figure 2-4, DC and Battery Temperature Sensor Wiring ................................................................... 14
Figure 2-5, Battery Hardware Installation ......................................................................................16
Figure 2-6, Inverter DC Hardware Installation ................................................................................ 16
Figure 2-7, Battery Temperature Sensor ........................................................................................ 17
Figure 2-8, RD-E Series Inverter/Charger - AC Wiring ..................................................................... 20
Figure 2-9, RD-E Series Inverter/Charger - AC Wiring (Access Cover) ............................................... 20
Figure 2-10, AC Terminal Block..................................................................................................... 21
Figure 2-11, AC Wiring Input/Output............................................................................................. 23
Figure 2-12, Grounding System for RD-E Series.............................................................................. 24
Figure 2-13, Multiple Connections to DC Ground Rod (Method 1)....................................................... 25
Figure 2-14, Multiple Connections to DC Ground Rod (Method 2)....................................................... 26
Figure 2-15, Single Connection to DC Ground Rod (Method 3) .......................................................... 26
Figure 2-16, Warning Label .......................................................................................................... 28
Figure 2-17, AC Voltage Checks.................................................................................................... 29
Figure 3-1, Power Flow - Inverter Mode .........................................................................................30
Figure 3-2, Power Flow - Standby Mode......................................................................................... 31
Figure 3-3, Automatic 4-Stage Charging Graph............................................................................... 32
Figure 3-4, BTS Temperature to Charge Voltage Change .................................................................. 33
Figure 3-5, Power Switch and Status Indicator................................................................................ 35
Figure 4-1, Performing an Inverter Reset .......................................................................................39
Figure B-1, Series Battery Wiring.................................................................................................. 45
Figure B-2, Parallel Battery Wiring ................................................................................................ 45
Figure B-3, Series-Parallel Battery Wiring....................................................................................... 45
Figure B-4, Battery Bank Wiring Examples (24-volt) ........................................................................ 46
List of Tables
Table 1-1, Typical Appliance Power Consumption...............................................................................6
Table 2-1, Recommended DC Wire/Overcurrent Device for Rated Use ................................................ 15
Table 2-2, DC Wire Size For Increased Distance .............................................................................. 16
Table 2-3, AC Grounding Electrode Conductor Sizing ....................................................................... 25
Table 2-4, Equipment Grounding Conductor Sizing .......................................................................... 27
Table 3-1, Inverter Battery Turn On/Off Levels................................................................................ 34
Table 3-2, Inverter/Charger Default Values .................................................................................... 36
Table 4-1, Basic Troubleshooting................................................................................................... 38
Table A-1, AC Wiring Color Codes.................................................................................................. 42
Table A-2, DC Wiring Color Codes ................................................................................................. 42

© 2010 Magnum Energy, IncPage 1
Introduction
1.0 Introduction
Congratulations on your purchase of the RD-E Series inverter/charger from Magnum Energy. The
RD-E Series is a modified sine wave inverter designed especially for renewable energy systems.
Powerful, yet simple to operate, this inverter/charger will provide you with the years of trouble-
free performance you have come to expect from Magnum Energy, all backed by our limited 2 year
warranty.
Installation is easy. Simply connect the inverter’s output to your distribution circuits or electrical
panel, connect your utility or AC generator power to the inverter’s easy-to-reach terminal block,
connect the batteries, and then switch it on for power.
Use the optional accessories listed below to control and monitor many other Magnum devices.
The RD-E Series inverter/charger includes:
2600 or 4000 watt models in a small footprint – less weight and area needed for installation
(shelf, bulkhead, or upside-down mounting)
Modified Sine Wave output
Automatic Power Factor Corrected (PFC) multi-stage battery charging
RS485 standard communication protocol
Remote and Network ports (easy connection for optional accessories)
ON/OFF inverter-mounted switch with LED indicator
30 Amp per leg/input
Large AC access and terminal block [wire size: 10 to 6 AWG (5.3 to 13.3 mm2) CU]
DC terminal covers with 360 degree connection
Field-serviceable for qualified personnel – tested repair kits available
Automatic battery temperature compensation (using battery temperature sensor) – for
optimum charging even during extreme temperature changes
Overcurrent, over-temperature, and high/low battery voltage protection
The following accessories are also available for use with the RD-E Series inverter/charger:
ME-RC50 (Basic Remote Control) - easy to read LCD display panel that enables standard
inverter and accessories set up, control, and troubleshooting.
ME-ARC50 (Advanced Remote Control) - easy to read LCD display panel that enables advance
inverter and accessories set up, control, and troubleshooting.
ME-AGS-N (Automatic Generator Start Module - Network version) - automatically starts/stops
your generator.
ME-BMK(Battery Monitor Kit - with Shunt) - provides precise DC voltage/current measurements
and provides information on your battery’s State of Charge (SOC) condition.
MPX-CB (Conduit Box) - provides several knockouts for connecting AC and DC conduit runs
to the inverter.
ME-SBC (Smart Battery Combiner) - monitors and keeps a second battery charged using a
portion of the current that is charging a main battery.
MMP (Mini Magnum Panel) - combines all of the major components required for a renewable
energy system into a single, easy to install pre-wired enclosure.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

Page 2
© 2010 Magnum Energy, Inc.
Introduction
1.1 Features and Benefits
The RD-E Series inverter/charger is designed to allow easy access to wiring, circuit breakers, and
controls. Its die cast baseplate with one-piece aluminum cover ensures maximum durability with
minimum weight, as well as cooler more efficient operation.
The front of the RD-E Series is equipped with the following features (see Figures 1-1 and 1-2):
1Power ON/OFF Switch - a momentary pushbutton switch that alternately turns the inverter
On or Off.
2Status LED Indicator - this green LED illuminates to provide information on the inverter
or charger operation.
3Stack/Accessories Connection Port (red label) - a RJ11 port that accepts the optional
Remote Switch Adapters (RSAs) which enable remote on/off switch operation.
Info: The stacking feature is NOT available with the RD-E Series.
4Network Connection Port (green label) - a RJ11 port that accepts optional network
capable accessories (e.g., Auto Gen Start or Battery Monitor).
5Remote Connection Port (blue label) - a RJ11 port that allows the optional remote
controls (ME-RC50 or ME-ARC50) to be connected.
6BTS Connection Port (yellow label) - RJ11 port that accepts the remote Battery
Temperature Sensor (BTS) accessory.
7DC Equipment Ground Terminal - this connection is used to tie the exposed chassis of
the inverter to the DC grounding system. This terminal accepts CU/AL conductors from
#14 to #2 AWG (2.1 to 33.6 mm2).
8AC Input/Output Connections - two 3/4” knockouts provided with cable-clamp strain
reliefs to allow and hold the AC input and output field wiring.
9Intake Air Vents -ventilation openings to pull in air to help keep the inverter cool for
peak performance.
10 Positive DC Terminal - provides 360 degree connection point for the positive (+) cable
from the battery bank; provided with a Kep or Flange nut on a 5/16-18 bolt (5/8” usable
length) to hold the battery cable to the DC terminal.
11 Negative DC Terminal - provides 360 degree connection point for the negative (-) cable
from the battery bank; provided with a Kep or Flange nut on a 5/16-18 bolt (5/8” usable
length) to hold the battery cable to the DC terminal.
12 Mounting Flange - used to secure the inverter to a shelf or wall.

© 2010 Magnum Energy, IncPage 3
Introduction
Figure 1-1, Power Switch, Status LED, and Accessory Connection Ports
Figure 1-2, Electrical Connection Points
POWER ON/OFF SWITCH
STATUS (CHARGING/INVERTING) LED
STACK/ACCESSORIES PORT
(RED LABEL - RJ11 CONNECTION)
NETWORK PORT
(GREEN LABEL - RJ11 CONNECTION)
REMOTE PORT
(BLUE LABEL - RJ11 CONNECTION)
BATTERY TEMPERATURE SENSOR PORT
(YELLOW LABEL - RJ11 CONNECTION)
INTAKE AIR VENTS
(AND ON RIGHT SIDE)
AC INPUT/
OUTPUT
CONNECTIONS
DC EQUIPMENT
GROUND
TERMINAL
POSITIVE (+) DC
TERMINAL
(UNDER COVER)
NEGATIVE (-) DC
TERMINAL
(UNDER COVER)
MOUNTING
FLANGE
6
5
4
3
2
1
11
10
12
7
8
9

Page 4
© 2010 Magnum Energy, Inc.
Introduction
Figure 1-3, Left Side Features
The left side of the RD-E Series is equipped with the following features (see Figure 1-3):
13 Exhaust Air Vent - ventilation openings that allow heated air to be removed by the
internal cooling fan.
14 Model/Serial Number Label -includes model/serial number information, date of
manufacture, and inverter and charger specifications. See the RD-E Specifications in
Appendix A for more information and the different models that are available.
15 AC Access Cover - provides access to the internal AC wiring terminal block. This terminal
block is used to hardwire all inverter AC input and output wiring connections. Remove the
two screws to access the AC wiring terminal block.
16 Input Circuit Breaker - this circuit breaker protects the unit’s internal charger wiring
and pass-thru relay while in Standby mode. This circuit breaker will pop out when it
opens. Press in to reset. This input circuit breaker is not branch-circuit rated, therefore,
branch-circuit rated breakers must be installed in the inverter’s input wiring.
CAUTION: The inverter’s internal AC transfer relay is rated for 30 amps per leg. The
pass-thru current must be no greater than 30 amps per leg or damage to the relays
may occur.
MODEL/SERIAL
NUMBER LABEL
AC ACCESS
COVER
EXHAUST
AIR VENTS
INPUT CIRCUIT BREAKER
13
16
15
14

© 2010 Magnum Energy, IncPage 5
Introduction
1.2 How an Inverter/Charger Works
An inverter takes direct current (DC) from your batteries and turns it into alternating current (AC).
It also takes alternating current (when connected to a generator or to utility power) and transforms
it into direct current to charge your batteries. These two modes of operation associated with this
inverter/charger are referred to in this document as:
Inverter Mode:
When the inverter is properly connected to batteries and turned on, the direct current
(DC) from the batteries is transformed into a modified sine wave alternating current (AC).
This AC is similar to the voltage provided by a utility for your home, and is used to power
the AC electrical appliances (i.e., AC loads) connected to the inverter’s output.
Standby Mode:
When an external source of AC power (e.g., utility power or generator) is connected and
qualified on the inverter’s AC input, it operates in the Standby mode. In the Standby
mode, the unit operates as a battery charger to convert the incoming AC power into DC
power to recharge the batteries; and at the same time, automatically closes an internal AC
transfer relay to pass the incoming AC power directly to the inverter’s output to continue
powering the connected electrical appliances.
1.2.1 Inverter Applications for Permanent Installations
An inverter can be used for backup power in a permanent location that normally uses utility
power, such as a home or office. When the utility power is available, the inverter keeps the
batteries charged. When the utility power fails, the inverter comes on automatically to supply
AC power to your home or office during the power failure. For a home or business, reliable
backup power is needed to prevent lost computer data, or to maintain ligts and keep food fresh
in the refrigerator/freezer.
In some areas where utility power is not available, the inverter can be used in a standalone
renewable power system. The inverter enables AC electrical appliances to be run from the storage
battery bank. When the battery bank becomes discharged, either renewable DC sources (solar,
wind, or hydropower) can be used to recharge the batteries, or a generator can be connected to
the inverter to power the system while the batteries recharge.
1.3 What Appliances will run from a Modified Sine Wave Inverter
Today’s inverters come in two basic output waveforms: modified sine wave (which is actually a
modified square wave) and pure sine wave. Modified sine wave inverters approximate a pure sine
waveform and will run most appliances and electronics without any problems. These inverters are
less expensive, and therefore, offer a viable alternative to more expensive pure sine inverters.
The output of a modified sine wave inverter will run most electronic and household items, including
but not limited to: TV, VCR, satellite dish receiver, computers, and printers. Some devices such as
rechargeable power supplies for phones, drills, and other like items may not run, and could even
be at risk for damage from modified sine wave inverters.
1.4 Appliances and Run Time
The RD-E Series inverter/charger can power a wide range of household appliances including small
motors, hair dryers, clocks, and other electrical devices. As with any appliance using batteries
for power, there is a certain length of time that it can run – this is called “run time.” Actual run
time depends on several variables, including: the size and type of appliance, the type of batteries
installed in your application, as well as the battery’s capacity and age. Other factors such as the
battery’s state of charge (SOC) and temperature can also affect the length of time your appliances
can run.
•
•

Page 6
© 2010 Magnum Energy, Inc.
Introduction
Depending on your inverter capacity, electrical appliances that use larger loads such as coffee
pots and hair dryers can be used for short durations. However, loads that are used for longer
periods (stoves, water heaters, etc.) can quickly drain your batteries and are not recommended
for inverter applications.
All electrical appliances are rated by the amount of power they consume (see Table 1-1). The rating
is printed on the product’s nameplate label, usually located on its chassis near the AC power cord.
Even though it is difficult to calculate exactly how long an inverter will run a particular appliance, the
best advice is trial and error. Your RD-E Series inverter has a built-in safeguard that automatically
protects your batteries from over-discharge.
Info: For optimum performance, a minimum battery bank of 200 AH is recommended
for moderate loads (<1000W) and greater than 400 AH for heavy loads (≥1000W).
Table 1-1, Typical Appliance Power Consumption
Device Load Device Load
Blender 400W Coffee Maker 1200W
Computer 300W Color TV 150W
VCR 40W Hair Dryer 1000W
Hot Plate 1800W Iron 1000W
Light (Flo) 10W Light (Inc) 100W
Microwave 1000W Refrigerator 500W

© 2010 Magnum Energy, IncPage 7
Installation
2.0 Installation
WARNING: Installations should be performed by qualified personnel, such as a licensed
or certified electrician. It is the installer’s responsibility to determine which safety
codes apply and to ensure that all applicable installation requirements are followed.
Applicable installation codes vary depending on the specific location and application of
the installation.
CAUTION: Review the “Important Product Safety Information” on page ii, and the
“Important Battery Safety Instructions” on page iii before any installation.
CAUTION: The inverter is heavy. Use proper lifting techniques during installation to
prevent personal injury.
The simplified system diagram shown in Figure 2-1 should be reviewed to assist you in planning
and designing your installation. This drawing is not intended to override or restrict any national
or local electrical codes. This drawing should not be the determining factor as to whether the
installation is compliant, that is the responsibility of the electrician and the onsite inspector.
2.1 Pre-Installation
Before installing the inverter, read the entire installation section to determine how you are going
to install your RD-E inverter/charger. The more thorough you plan in the beginning, the better
your inverter needs will be met.
2.1.1 Unpacking and Inspection
Carefully remove the RD-E Series inverter/charger from its shipping container and inspect all
contents. Verify the following items are included:
The RD-E inverter/charger
Red and black DC terminal covers with Phillips screws
AC access cover with two Phillips screws
Two 5/16” Kep or Flange nuts (installed on the DC terminals)
Battery Temperature Sensor
Warning label
RD-E Series Owner’s Manual
If items appear to be missing or damaged, contact your authorized Magnum Energy dealer or
Magnum Energy. If at all possible, keep your shipping box. It will help protect your inverter from
damage if it ever needs to be returned for service. Save your proof-of-purchase as a record of
your ownership; it will also be needed if the unit should require in-warranty service.
Record the unit’s model and serial number in the front of this manual in case you need to provide
this information in the future. It is much easier to record this information now, instead of trying
to gather it after the unit has been installed.
2.1.2 Required Tools and Materials
Hardware/Materials
Conduit, strain-reliefs, and appropriate fittings• Mounting bolts and lock washers•
Electrical tape• Wire ties•
Tools
Miscellaneous screwdrivers• Pliers• Wire strippers•
Drill and drill bits• Pencil or marker• Multimeter•
Level• 1/2” wrench•
•
•
•
•
•
•
•

Page 8
© 2010 Magnum Energy, Inc.
Installation
Figure 2-1, Simplified Installation Diagram for Permanent Installations
Battery Bank
230VAC
powerto
inverter
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
230
VAC
DC
Overcurrent
protection
(Breaker or
Fuse/switch)
RD-E
Series
Inverter/
Charger
Main Panel Sub-panel
230 VAC Inverter power
(or230 VAC pass-thru power)
to Sub-panel
ME-BMK
Battery Monitor with
shunt
(Magnum Accessory )
DC
Shunt
AC
Transfer
Switch
Generator Power
230 VAC Output
Utility Power
230 VAC Output
Flu x
Capa cito r Gene ra tor
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
BTS
ON
OFF
ON
OFF
30 A
30A
ME-SBC
Smart Battery
Combiner
(Magnum Accessory )
ME-AGS-N
Auto Gen Start
Controller
(Magnum Accessory )
SELECT
TECHAG S M ETER SETUPSHO REINVERTER
CHARG ER
INV
CHG
FA U LT
PWR
ON/ OFF
ON/ OFF
Remote Controls (Magnum Accessories )
ME-RC50 ME-ARC50

© 2010 Magnum Energy, IncPage 9
Installation
2.1.3 Locating the Inverter
Only install the inverter in a location that meets the following requirements:
Clean and Dry - The inverter should not be installed in an area that allows dust, fumes, insects, or
rodents to enter or block the inverter’s ventilation openings. This area also must be free from any
risk of condensation, water, or any other liquid that can enter or fall on the inverter. The inverter
uses stainless steel fasteners, plated copper busbars, and a power-coated aluminum base. The
internal circuit boards are conformal coated. All of this is done to help fight the harmful effects
of corrosive environments. However, the inverter’s life is uncertain if used in the above types of
environments, and inverter failure under these conditions is not covered under warranty.
Info: If the inverter is installed in an area where moisture may occur, we
recommend putting silicone dielectric grease compound into the electrical ports
(see Figure 1-1, Items 3-6). Before installing the cables, or if leaving any ports open,
squirt a liberal amount into each port. Silicone dielectric makes an effective moisture
and corrosive barrier to help protect and prevent corrosion to the RJ11 connections.
Cool - The inverter should be protected from direct sun exposure or equipment that produces
extreme heat. The ambient temperature around the inverter must not exceed 77°F (25°C) to
meet power specifications.
Ventilation - In order for the inverter to provide full output power and avoid over-temperature
fault conditions; do not cover or block the inverter’s ventilation openings, or install this inverter in
an area with limited airflow. The inverter uses two fans to provide forced-air cooling. These fans
pull in air through the intake vents (see Figure 1-2, Item 9) and blow out air through the exhaust
vents (see Figure 1-3, Item 13). Allow at the minimum an airspace clearance of 6” (15.2 cm) at
the intake and exhaust vents, and 3” (7.6 cm) everywhere else to provide adequate ventilation.
If installed in an enclosure, a fresh-air intake opening must be provided directly to the front side
(intake vents) of the inverter, and an exhaust opening on the back side (exhaust vents) of the
inverter. This allows cool air from the outside to flow into the inverter, and heated air to exit the
inverter and the enclosure. When mounted in an enclosed compartment, airflow must be ≥100
cfm in order to maintain no more than a 68°F (20°C) rise in compartment temperature.
CAUTION: Do not mount this inverter in a zero clearance compartment, nor cover or
obstruct the ventilation openings – overheating may result.
Safe - Keep any flammable/combustible material (e.g., paper, cloth, plastic, etc.) that may be
ignited by heat, sparks, or flames at a minimum distance of 2 feet (61 cm) away from the inverter.
Do not install this inverter in any area that contains extremely flammable liquids like gasoline or
propane, or in locations that require ignition-protected devices.
Close to the battery bank - As with any inverter, it should be located as close to the batteries as
possible. Long DC wires tend to loose efficiency and reduce the overall performance of an inverter.
However, the unit should NOT be installed in the same compartment as the batteries, or mounted
where it will be exposed to gases produced by the batteries. These gases are corrosive and will
damage the inverter; also, if these gases are not ventilated and allowed to collect, they could ignite
and cause an explosion.
Info: The battery bank should be installed in a clean, dry, ventilated environment where
they are protected from high and low temperatures. The batteries must be mounted
upright (if using liquid batteries) and securely fastened. The location must be fully
accessible and protected from exposure to heat producing devices, and away from any
fuel tanks.

Page 10
© 2010 Magnum Energy, Inc.
Installation
Accessible -Do not block access to the inverter’s remote control and accessory ports, as well
as the inverter’s controls and status indicator. Also allow enough room to access the AC and DC
wiring terminals and connections, as they will need to be checked and tightened periodically. See
Figure 2-3 for the RD-E Series’ inverter/charger dimensions.
Away from sensitive electronic equipment - High-powered inverters can generate levels of RFI
(Radio Frequency Interference). Locate any electronic equipment susceptible to radio frequency
and electromagnetic interference as far away from the inverter as possible.
2.2 Mounting the Inverter
The inverter base can reach a temperature up to 90°C (194°F) and it is recommended that it should
be mounted on a non-combustible surface*. This surface and the mounting hardware must also be
capable of supporting at least twice the weight of the inverter. To meet regulatory requirements,
the RD-E Series must be mounted in one of the following positions, as shown in Figure 2-2:
above or under a horizontal surface (shelf or table)
or, on a vertical surface (wall) with the DC terminals to the right
or, on a vertical surface (wall) with DC terminals toward the bottom, MP-HOOD (inverter hood)
installed on the top, and either the ME-CB (Conduit Box), MPX-CB (Conduit Box), or the MMP
Series (single inverter) enclosure installed on the inverter’s bottom.
Info: The ME-CB and MPX-CB conduit boxes prevent material from falling out the bottom
in the event of an internal fire. The MP-HOOD inverter hood helps prevent items from
falling inside, causing damage to the inverter.
After determining the mounting position, refer to the physical dimensions as shown in Figure 2-3,
or use the base of the inverter as a template to mark your mounting screw locations.
* Non-combustible surface - A surface made of material that will not ignite, burn, support combustion, or
release flammable vapors when subjected to fire or heat as per the ASTM E136 standard. For the most part,
these are materials that are largely comprised of inorganic matter such as stone, steel, iron, brick, tile,
concrete, slate, and glass. Avoid common building materials such as gypsum board, painted surfaces, wall
coverings, and any type of wood.
•
•
•
Figure 2-2, Approved Mounting Positions
30
30
SHELF OR TABLE
MOUNTED
(RIGHT SIDE UP)
SHELF OR TABLE MOUNTED
(UP SIDE DOWN)
WALL MOUNTED
(DC TERMINALS TO THE RIGHT)
WALL MOUNTED
(DC TERMINALS
ON THE BOTTOM*)
*WHEN THE INVERTER
IS MOUNTED IN THIS
POSITION, THE MP-
HOOD (ON TOP) AND
EITHER THE ME-CB
CONDUIT BOX, MPX-CB
CONDUIT BOX, OR MMP
SERIES ENCLOSURE
MUST BE USED.

© 2010 Magnum Energy, IncPage 11
Installation
Figure 2-3, RD-E Series Dimensions and Side Reference
12 5/8" (32.1 cm)
12" (30.5 cm)
4 7/8"
(12.4 cm)
2"
(5.1 cm)
4 7/8"
(12.4 cm)
Keyhole slots
(x4) and
mounting holes
(x4) accept
up to 9/32"
(7 mm)
screw/bolt
13 3/4"
(34.9 cm)
8"
(20.3 cm)
6 5/8"
(16.8 cm)
BOTTOM
SIDE
RIGHT
SIDE
BACK
SIDE
RIGHT
SIDE
LEFT
SIDE
TOP
SIDE
LEFT
SIDE TOP
SIDE
FRONT
SIDE

Page 12
© 2010 Magnum Energy, Inc.
Installation
2.3 Wiring the Inverter - General Requirements
This section describes the requirements and recommendations for wiring the RD-E Series inverter/
charger. Before wiring the inverter/charger, read all instructions.
All wiring should meet all local codes and industry standards, and be performed by
qualified personnel such as a licensed electrician.
Info: This document uses the term “ground”, or “grounding”; the European equivalent is
“earth”, or “earthing”. Refer to Appendix A-3 for equivalent AC/DC wiring terminology.
Inverter/charger systems involve power from multiple sources (e.g., inverter, generator, utility
power, batteries, etc.) which makes the wiring more hazardous and challenging.
The input and output AC and DC circuits are isolated from the inverter chassis. The inverter
system grounding is the responsibility of the installer in accordance with local codes and safety
practices.
WARNING: Ensure the sources of DC power (i.e., batteries, solar, wind, or hydro)
and AC power (utility power or AC generator) are de-energized (i.e., breakers opened,
fuses removed) before proceeding – to prevent accidental shock.
2.3.1 Protecting Wire - Conduit Box
The AC and DC wires into and out of the inverter must be protected. This can be done by using
jacketed wires or by feeding wires through a conduit. Magnum offers for purchase a conduit box
(ME-CB) that allows both the AC and DC conduit to be connected to the inverter.
Info: If using the ME-CB conduit box, and the AC wires are individual conductors (i.e.,
not jacketed), the strain reliefs can be removed and replaced with 3/4” grommets.
2.3.2 Wiring Requirements
All conductors that are at risk for physical damage must be protected by tape, or placed
in a raceway.
Always check for existing electrical, plumbing, or other areas of potential damage prior to
making cuts in structural surfaces or walls.
Do not mix AC and DC wiring in the same panel unless specifically approved/designed for
both AC and DC wiring. Where DC wiring must cross AC or vice-versa, try to make the
wires 90° to one another at the crossing point.
Both AC and DC overcurrent protection must be provided as part of the installation.
The inverter requires a reliable negative and ground return path directly to the battery.
Use only copper wires with a minimum temperature rating of 90°C.
2.3.3 Wire Routing
Before connecting any wires, determine all wire routes to and from the inverter. Conductors passing
through walls or other structural members must be protected to minimize insulation damage, such
as chafing. During installation, always avoid placing conductors near sources of chafing caused by
vibration or constant rubbing. Typical routing scenarios include:
AC input wiring from the main AC panel to the inverter
AC input wiring from a generator (optional) to the inverter
DC input wiring from the batteries to the inverter
AC output wiring from the inverter to the AC main panel or to dedicated circuits
Battery Temperature Sensor cable from the inverter to the batteries
Remote control cable (optional) to the inverter
Ground wiring to and from the inverter
•
•
•
•
•
•
•
•
•
•
•
•
•

© 2010 Magnum Energy, IncPage 13
Installation
2.3.4 Torque Requirements
Torque all AC wiring connections to 16 in lbf (1.8 N-m). Torque DC cable connections from
10 to 12 ft lbf (13.6 to 16.3 N-m).
2.4 DC Wiring
This section describes the inverter’s required DC wire sizes, the recommended disconnect/overcurrent
protection, and how to make the DC connections to the inverter and the battery bank.
Refer to Figure 2-4 when connecting the DC wires.
WARNING: Even though DC voltage is “low voltage”, significant hazards may be
present, particularly from short circuits of the battery system.
CAUTION: The inverter is NOT reverse polarity protected, which means that if the
negative and positive battery voltage is connected backwards to the inverter, the
inverter will likely be damaged. You should verify the correct voltage polarity using a
voltmeter BEFORE connecting the DC wires.
CAUTION: Before wiring the DC cables, review the safety information at the beginning
of this manual and the instructions below to ensure a safe and long-lived system.
Info: DO NOT connect the battery cables to the inverter until all wiring is complete.
When the inverter is installed in a Photovoltaic System, standard safety practices require that
the DC circuit conductors and overcurrent devices to the inverter be sized to carry not less
than 125% of the inverter’s maximum current rating.
The DC positive and negative cables connected to the inverter from the battery bank should
be tied together with wire ties or electrical tape approximately every 6 inches (153mm). This
helps improve the surge capability and reduces the effects of inductance, which improves the
inverter waveform and reduces the wear of the inverter’s filter capacitors.
Use crimped and sealed copper ring terminal lugs to connect the DC wires to the inverter’s DC
terminals. (We use 5/16” terminal lugs in U.S., determine the European equivalent.)
The battery bank voltage must match the DC voltage required by the inverter (i.e., 24-volt
battery bank for a 24-volt inverter), or the inverter may be damaged.
To ensure the maximum performance from the inverter, all connections from the battery bank
to the inverter should be minimized. The exceptions are the DC overcurrent disconnect in the
positive line, and a shunt in the negative line. Any other additional connection will contribute
to additional voltage drops and these extra connection points may loosen during use.
All wiring to the battery terminals should be checked periodically (once a month) for proper
tightness. The torque requirement for the DC terminals is between 10 to 12 ft lbf (13.6
to 16.3 N-m). If you don’t have a torque wrench, ensure all DC terminals are tight and
cannot move.
Be aware that overtightening or misthreading the nuts on the DC terminals can cause the
bolts to strip and snap/break off.
Make sure cables have a smooth bend radius and do not become kinked. Place long cable runs
in conduit and follow existing wire runs where possible.
A brief spark or arc may occur when connecting the battery cables to the inverter DC terminals;
this is normal and due to the inverter’s internal capacitors being charged.
Color code the DC cables/wires with colored tape or heat shrink tubing: BROWN for positive (+),
BLUE for negative (-), and GREEN (or GREEN w/YELLOW stripe) for DC ground to avoid polarity
problems. Refer to Table A-2 for a list of equivalent wiring color codes for Europe and North
America.
•
•
•
•
•
•
•
•
•
•
•

Page 14
© 2010 Magnum Energy, Inc.
Installation
Figure 2-4, DC and Battery Temperature Sensor Wiring
DC System Grounding point
[Electrode Conductor
(i.e., ground rod)]
RD-E Series
Inverter/Charger
front view
Battery Temp Sensor Cable
Inverter’s DC Negative Connection
Inverter’s DC Positive Connection
Inverter’s Equipment Ground Wire
BTS
BTS
Battery Bank
Battery Bank’s Equipment Ground Wire
Battery Bank’s Negative Cable
Battery Bank’s Positive Cable
MMP enclosure – forsingle inverter installations
(includes DC disconnect breaker, DC shunt for
battery monitor, and inverter DC busbars).
