Magnum MFM-FS Specification sheet

Product instruction manual
Magnum® MFM-FS Folding System
Fixed Speed
Magnum Folders have been designed to be user friendly,
however we strongly recommend you take a few minutes
to read through this manual to ensure correct operation.
Keep this manual safe for future reference.

2
Page 2 - Specications
Page 3 - Introduction
Page 4 - Safety Instructions and environmental requirements
Page 5 - Information before use
Page 6 - Parts
Page 7 - Operation panel and functions
Page 8 - How to use
Page 14 - Warranty and incorrect use
Contents
Paper Size 125 x 176mm (B6) to 297 x 420mm (A3)/5 x 7”to 11 x 17”
Paper Weight up to 220gsm single folding, up to 135gsm multiple folding
Paper Quality Woody paper, high-quality paper, high-quality paper for stencil printing,
medium-quality paper
Fold Type Single, Double parallel, Letter, Gate, Zig-Zag, Fold-out
Paper Feed System Friction roller feed system
Max. Stacking Capacity 500 sheets
Folding Speed 50-200 sheets per minute
Operating Method Digital key input
Power Supply Required 13 Amps
Power Supply 220/240 V / 110-120 V
Rate Input Power 50W
Frequency (Hz) 50-60Hz
Dimensions 610 x 580 x 450mm
Gross Weight 29Kg
Specications

3
Thank you for purchasing the Magnum MFM-FS Folding System.
This system enables users to achieve greater eciency in clerical work by releasing
them from paper-folding work that has manually been performed in the past.
Please read these instructions carefully before starting to use the system to ensure you
get the best results and are competent at operation.
Should you experience any problems please contact your supplier.
Introduction

4
Safety Instructions
• Make sure that the system is electrically grounded. This prevents an electric shock when there is a leak
of electricity.
• Use the system at 110 – 120 VAC, 220 – 240 VAC with a frequency of 50Hz to 60Hz. A re may start or
the system may break down if a higher or lower voltage is used, or if an electric current with a
frequency that is not within the range of frequency stated above.
• Do not place any objects on this system. A re may start or electricity may leak if water or a foreign
object enters the system.
• Handle the power cord with care. A re may start or an electric shock may be caused if the cord is
damaged, broken, or processed, if a heavy object is placed on the cord, or if the cord is bent forcibly.
• Do not pull the power plug out of or put it in the electric outlet using a wet hand.
Otherwise, an electric shock may be caused.
• Do not remove the cover of this system. Otherwise, an electric shock or injury may be caused.
• Do not remodel this system. Otherwise, a re may break out or an electric shock may be caused.
• If the system is used when it is in an abnormal condition, such as generating heat, emitting smoke,
and giving out a strange smell, a re may break out or an electric shock may be caused. Turn o the
power switch immediately and then pull the power plug out of the electric outlet. Afterwards, report
the fault to your supplier.
• If abnormalities such as the power cord generating heat and giving out a strange smell are found,
turn o the power switch immediately and then pull the power plug out of the electric outlet.
Afterwards, report the fault to your supplier.
• If a foreign object enters the system, turn o the power switch rst and then pull the power plug out
of the electric outlet. Afterwards, report the fault to your supplier.
• If thunder approaches, pull the power cord out of the electric outlet to prevent a re or breakdown
caused by the falling of a thunderbolt.
• Do not let hairs, a necktie or necklace hang above the drive of the system.
Doing so may cause an injury.
• Do not put the system on an unstable place such as a shaky stand or a slanted oor. Doing so may
cause the system to drop or fall down, causing an injury.
• Do not put the system in a moist or dusty place. Doing so may start a re or cause an electric shock.
• Be sure to pull out the power cord while holding the plug. If the power plug is pulled out while
holding the cord, a re may break out or an electric shock may be caused.
• Be sure to pull the power plug out of the electric outlet rst when moving this system.
Otherwise, the cord may be damaged, causing a re or an electric shock.
• Be sure to pull the power plug out of the electric outlet for safety purposes when this system is not
used for consecutive holidays or for other reasons.

5
Check accessories immediately after unpacking. Should an item be missing, contact your supplier.
Also, check if the warranty has the dealer’s signature and the date of purchase is mentioned.
Accessory Quantity
Table 1 1
Table 2 1
Power Cable 1
System cover 1
Instruction Manual 1
Information Before Use
1. Precautions on Installation
Do not install it in an unstable place such as on a faltering bench or an inclined place.
It may fall down or drop and cause an injury.
Do not install it in a dusty place or a place of high humidity.
It may cause a re, or an electric shock.
Do not install it in a place exposed to direct sunlight.
Avoid a location near a window.
It should be used at an ambient temperature of 5 to 35°C.
Do not install it in a location close to heating equipment.
Do not install it in a place exposed to a direct wind.
2. Checking Accessories
i

6
Parts
Number Name Number Name
(1) Roller cover (10) Table 1
(2) Left hand side cover (11) Control panel
(3) Paper feed roller (12) Paper feed table
(4) Paper guide (13) Table 2
(5) Feed table (14) Right hand side cover
(6) Paper ejection roller (15) Paper feed table lever
(7) Paper stacking table (16) Power switch
(8) Stopper plate (17) Power cable socket
(9) Fold position micro adjustment (18) Circuit breaker

7
Operation Panel and Functions
No. Designation/Indication Function
(1) Test key Test folds two sheets without counting.
(2) Start/Stop key Starts and stops the system.
(3) Clear/Reset key Clears counter indication resets error.
(4) Numerical key Inputs the desired number of sheets to be folded.
(5) Counter Shows the number of sheets.
(6) Check lamp Lights when paper stock runs short, or indicates the location where
paper feed jam occurs.
(5) (6)
(4) (3) (1) (2)

8
How to Use
1. Preparation
(1) Setting table 1 and 2
Fit (a) and (b) of table 1 and (c) and (d) of table 2 on the studs (a), (b), (c)
and (d) at the left and right sides of the side plate.
When setting Table 1, be sure to put the stopper plate in the centre. If table 1 and 2 are not properly set,
the system may not be able to fold paper correctly.
(2) Setting paper
Pull the paper stacking table out and set it while lifting the
feed table.
Raise the paper feed table lever.
Set the paper guide at the required size
of paper stock being used.
Place the paper on the feed table
with its printed side facing up.
Ensure that the paper is loaded neatly and with its leading
edge ush with the front plate of the feed tray.
Ensure that both Table 1 and 2 aren’t warped and properly tted on the studs (a) (b) (c) and (d). If they are
improperly set, it may cause incorrect folding or injury.
CAUTION

9
Place the paper printed side down in case of fold-out.
Place the paper on the feed table so that it touches the paper guide and then tighten the paper guide
setscrews.
Lower the paper feed table lever and set the paper.
If the paper does not come in contact with the paper feed roller, it may be fed incorrectly. In such case,
the leading edge of the paper may touch the guide plate in the front and prevent the paper from being
fed. Reset it by pulling it backwards.
If the paper is curled or wrinkled it might cause the sheets to misfeed. Correct it before use.
In the case of printed paper, use it only after the ink is dry, otherwise the paper feed rubber roller, paper
separator, fold roller and other parts of the unit will be stained with ink and may get ink on subsequent
sheets.
Do not use ruled paper as the paper folding may deteriorate.
2. Operation Procedure
(1) Switch the power on.
Insert the plug into the power socket and switch the power on. Be sure to remove the power plug from
the socket after use.
(2) Setting Paper Fold Position
Pull the fold adjustment lever to move the stopper plate to the desired position on Table 1 and 2,
matching the stopper plate mark (?) with the position and leave the half-nut lever there. The stopper
plate automatically locks at the position where the half-nut lever remains.
* Incase of single fold only, all size paper should be set at the position of ‘All Sizes’. Should wrinkles or
irregular folding occur in single fold, move the stopper plate until halting by the stopper adjustment
knob.
(3) Setting paper ejection roller
Set the paper ejection roller at the indication for the size of paper
stock used. If the roller is set at a wrong position, it may cause prob-
lems with stacking of folded sheets.
The paper folding length may be altered depending on the fold
type and paper curl may be caused by changes of temperature and
humidity. Therefore, whenever a paperjam occurs at the stage of
ejection, reset to adjust the paper eject roller to the best position.
(4) Setting paper stacking table
Pull out the paper stacking table and set it so that the ejected
sheets ows out smoothly.

10
(3) Test Folding
Press the test key to feed 2 sheets of paper. Check if
the paper has been folded correctly by examining the
second of the 2 folded sheets.
* When the fold position is not correct, refer to
‘Adjusting Paper Fold Position’.
Never put your hand in any driving part such as a roller. Keep ties, necklaces, hair etc away from the
system as this can cause injury.
CAUTION
(4) Adjusting Paper Fold Position
When the fold position is incorrect, refer to the following chart.
* The illustration represents the folded paper seen from the operator. ( ) shows the length of folding and
L stands for paper length.

11
(5) Square Fold Adjustment
Turn the adjustment wheel to the right if the lower side of the
folded paper slants to the right. Turn the wheel to the left of the
lower side slants to the left.
* In other cases than single fold, place the folded paper with its
face down on Table 1 and make the adjustment.
(6) To Start Folding
Press the Start/Stop key. The system starts to fold the sheets continuously.
Press the Start/Stop again while the system is in operation, to stop.
* The counter continues to add up the number of sheets folded.
If the desired number of sheets only is to be fed, set that number by pressing 1000, 100, 10 keys.
Then the reduction mode lamp will be on.
Under the following conditions, the system will automatically stop feeding;
• When the start/stop key is pressed while there is no stock
• When the start/stop key is pressed while the paper feed lever is at the lower position.
• When the stock runs out
• When paper feed slip occurs
• When paper jam occurs at Table 1 and Table 2
• When paper stack table is full
• When a paper jam occurs at the paper ejecting unit
Press the clear/reset key to reset after the error is corrected.
(7) To Stop Paper Feed
Press the stop key to halt paper feed while the system is in operation.
(8) Correction of Paper Jam
Should paper jams occur, switch the power o immediately and remove the jammed sheets.
When the jammed paper is stuck around the folder roller or other parts, it can easily be removed by
detaching Table 1 and 2 from the unit. When the roller cover is opened, the system will stop the operation
in an instant.

12
3. Maintenance
(1) Before cleaning the system, be sure to switch the power o and pull the power plug from the outlet.
(2) When the unit is not in use, put its cover in place to prevent dust, paper dust etc accumulating on the
paper fold rollers.
(3) If paper dust or ink etc have accumulated on the paper fold rollers, it may cause wrinkles or improper
feeding. To prevent this clean them periodically as follows;
• Remove Table 1 and 2
• Clean the surface of the fold rollers using the cleaning kit to remove stains or dust
(4) If paper dust or ink etc are accumulated on the paper feed rubber roller and the paper separator
the paper feed performance deteriorates and the system becomes liable to paper jams or slipping.
To prevent this, clean them periodically as follows
• Clean the surface of the paper feed rubber fold rollers using the cleaning kit to remove stains or dust
• Move the paper feed shaft towards you in the order as shown in the gure then clean the paper feed
shaft
(5) Consumable products
• Paper feed rubber roller, rubber brake, paper feed separator used for the unit are consumable
products
• Fold rollers are guaranteed for 6 months

13
4. Troubleshooting
Trouble Possible Cause Solution
The paper is not feeding correctly
Paper stuck just after its printed Loosen the paper suciently or
feed the paper after its dry
Stains on the paper separator Clean the paper feed separator
using the unit cleaner
Stains on the paper feed rubber
roller
Clean the paper chips or ink on
the paper feed roller with the unit
cleaner
The paper separator is worn out Replace the paper separator with
a new one
The volume of paper loaded
on the paper feed table is not
enough
If the volume on the paper feed
table is not enough, it does not
feed since the paper detection
lever is installed. Load 20 sheets
or more.
The system does not operate even
after the start/stop key is pressed Paper jam inside the unit Detach table 1 and 2 and remove the paper in the unit
Paper creasing
Paper stuck just after its printed Loosen the paper suciently or
feed the paper after it is dry
Stains on the paper separator Clean the paper separator using
the unit cleaner
Stains on the paper feed roller
Clean the paper chips or ink on
the paper feed roller with the unit
cleaner
Stains on four paper fold rollers Clean the stain on four fold rollers
using the unit cleaner
Table 1 and 2 are not properly set Reset properly
Paper jam in table 1 and 2 Detach table 1 and 2 and remove
the jammed paper
Improper fold position The total length of the paper is
not standard size
Measure the total length of the
paper and adjust using the ne
adjustment knob
Drawing paper (125gsm
or lighter) cannot be folded
The surface of four fold rollers are
stained with paper chips or ink
(slippery situation)
Clean away the stain on four fold
rollers using the unit cleaner
Low room temperature
The paper gets sti and hard to
fold at the low room temperature
in winter. Perform folding after
leaving the paper as it is for 3 to 4
hours at the temperature of 20-
25°C

Warranty & Incorrect Use
IMPORTANT INFORMATION
Your Magnum Folding Machine should reach you in perfect condition, however please retain all of the original packaging once
you have unpacked your Folding Machine in case you need to return it for repair. If your machine arrives damaged or faulty in
anyway, this must be reported to your supplier immediately. If the Folding machine is sent back for repair under warranty and
is damaged in transit due to faulty packaging your warranty may be void.
The Folding Machine you have purchased includes a 1 year warranty on defective parts and general wear and tear. It does not
cover any jams or misfeeds caused by operator error and you could be liable for the repair costs (including delivery charges) if
damage is caused by operator error.
E&O.E
