Magtek EXCELLA STX User manual

3. Ethernet Installation
Connect cables
• Connect Ethernet interface cable, USB to Excella STX (Figure 3).
• Connect round connector from the power supply to Excella.
• Connect the power cord to the socket on the power supply block.
• Connect the three-prong power cord to AC wall outlet.
• Wait until only the middle LED is illuminated with a steady green.
• Connect interface cable to PC.
Ethernet Configuration
• In your web browser, type Excella STX’s default Ethernet IP address as
follows: http://192.168.10.100; Excella STX’s built-in web page will be
displayed.
• In the User Menu, click on Conguration.
• Select the Ethernet tab and congure all parameters shown (Figure 2).
• Click on Save Settings and close the web browser.
• Continue to Step 4, INSTALL INK CARTRIDGE(S).
Figure 2. Ethernet Conguration Screen
1. Start
For USB, go to Step 2 below. For Ethernet, got to Step 3 below.
2. USB Installation
• RUN EXCELLA STX DEMO
• Navigate to and run C:\Program Files (x86)\MagTek\Excella-STX-
ImageSafe\ Excella-STX_Demo.exe
• Click on the Excella Demo icon to run the demo; the main screen will
be displayed (Figure 1).
• In the Select Device pull-down menu, choose Excella.EXC001.
• Click on the Connect button.
Connect cables
• Connect interface USB cable to Excella STX (Figure 3).
• Connect round connector from the power supply to Excella STX.
• Connect the power cord to the socket on the power supply block.
• Connect the three-prong power cord to AC wall outlet.
• Wait until only the middle LED is illuminated with a steady green.
• Connect interface cable to PC.
NOTE: When the device is plugged in and detected by the PC, the USB
drivers will be automatically installed.
Excella STX - USB or Ethernet
Small Document Scanner
Quick Installation Guide
Setup and Installation
MagTek®Inc., 1710 Apollo Court, Seal Beach CA 90740 | p 562-546-6400 | support 651-415-6800 | f 562-546-6301 | www.magtek.com
Figure 3. Cables & Connectors

4. Install Ink Cartridge(s)
• Remove the outer cover by pressing the release buttons on each side and lifting the cover.
• Remove the center cover by pressing the rear/front release buttons and lifting the cover.
• Ensure the printer latch is down and locate the alignment pegs on the Printer/Cartridge and the guide holes in the Printer Base (Figure 4).
• Slide the alignment pegs into the guide holes as indicated.
• Raise the latch so that it touches the Printer/Cartridge.
• Press the latch into the lock position, and move the Cartridge slightly to ensure it is locked.
• If needed, perform steps 1-4 on the Front Printer/Cartridge located inside of the exit path.
Figure 4. Rear Print Cartridge Installation/Removal
MagTek®, MagnePrint®, and MagneSafe® are registered trademarks of MagTek, Inc.
MAGTEK: Registered to ISO 9001:2015 © Copyright 2021 MagTek, Inc. PN D99875344 rev 30 4/21
MagTek®Inc., 1710 Apollo Court, Seal Beach CA 90740 | p 562-546-6400 | support 651-415-6800 | f 562-546-6301 | www.magtek.com
Setup and Installation (Continued)
5. Run Excella STX Demo
• Click on the Excella STX Demo icon to run the demo.
• The Demo’s main screen will be displayed (Figure 5).
• In the “Select Device” window, choose the device you want to connect
(USB or Ethernet).
• Click on the “Connect” button.
• Based on the document you want to read, click on one of these
buttons:
• “Check”, to read and scan checks (the left LED is blinking)
• “Card”, to read and scan ID cards (the right LED is blinking)
• “Check/Card”, the unit will accept either a check or a card (both
LED’s blinking)
• Feed the appropriate document.
• The unit will remain in the Read/Scan mode until the “Stop” button is
clicked.
Figure 5. Excella STX Demo
