MAGUIRE NOVATEC NDB Series User manual

Page 1 of 2
NDB-15 through NDB-50
DOCUMENT: NDB-15-50 IM 28 FEB 2018
© NOVATEC, Inc. 2018 All Rights Reserved
NDB-25

NDB-15-50 IM 28 FEB 2018 © 2018 NOVATEC, Inc. All Rights Reserved Page 2
NOTES:
Please record the following
information, which is specific to
this piece of equipment, in the
space provided. Our Parts/Service
Department will need these
numbers to properly respond to
any of your requests.
Instruction Manual: NDB-15-50 IM 28 FEB 2018
Model #:___________________________
Serial #____________________________
DISCLAIMER: NOVATEC, Inc. shall not be liable for
errors contained in this Instruction Manual nor for
misinterpretation of information contained herein.
NOVATEC shall not, in any event, be held liable for any
special, indirect or consequential damages in
connection with performance or use of this information.

NDB-15-50 IM 28 FEB 2018 © 2018 NOVATEC, Inc. All Rights Reserved Page 3
Table of Contents
1.0 PRODUCT SPECIFICATIONS..................................................................................................4
2.0 INSTALLATION.........................................................................................................................5
3.0 DESCRIPTION OF OPERATION..............................................................................................5
4.0 INITIAL START- UP PROCEDURE...........................................................................................6
5.0 OPERATING PROCEDURE......................................................................................................6
6.0 MONITORING PLC CYCLE ......................................................................................................7
6.1 8-Hour Sequence of Operation..................................................................................................7
6.2 PLC Counter Settings................................................................................................................7
7.0 TEMPERATURE CONTROLLER..............................................................................................8
7.1 Overview............................................................................................................................................... 8
7.2 Initial Settings....................................................................................................................................... 8
7.3 Parameter Settings ............................................................................................................................. 9
7.4 Excerpt from RKC REX C-100 Operation Manual......................................................................... 9
8.0 TROUBLE SHOOTING GUIDE...............................................................................................10
9.0 MAINTENANCE AND INSPECTION SCHEDULE...................................................................12
10.0 RECOMMENDED SPARE PARTS........................................................................................13
11.0 WARRANTY..........................................................................................................................14

NDB-15-50 IM 28 FEB 2018 © 2018 NOVATEC, Inc. All Rights Reserved Page 4
1.0 PRODUCT SPECIFICATIONS
Model
NDB-15
NDB-25
NDB-50
Supply Voltage
115/1/60
460/1/60
460/3/60
KVA
1.6
2.2
11.2
Total Amperage
13.9
4.8
14.0
Process Heater Amperage
8.7
3.5
10.0
Regen Heater Amperage
(Left Bed)
4.3
1.1
2.2
Regen Heater Amperage
(Right Bed)
4.3
1.1
2.2
Process Heater Wattage
1000
1600
4600
Adsorption CFM
15
25
50
Desiccant per bed (Pounds)
7
10
20
Blower Hp
1/25
1/25
3/4
Additional Specifications: All models:
Outlet Air Temp (Max)… 350° F
Outlet Duct Size… 2”
Cooling coil GPM Req… 1
Inlet Water Temp (max)… 80° F
Outlet Dew Point… -40° F
Cycle time per bed… 4 hrs
Desiccant Type… 13X

NDB-15-50 IM 28 FEB 2018 © 2018 NOVATEC, Inc. All Rights Reserved Page 5
2.0 INSTALLATION
NDB Dryers can be mounted directly to the processing machine. Secure with bracing as required
to stabilize the unit. Convenient lugs are located at the end and on the valve box for this purpose.
Others may be used if necessary.
The NDB can also be mounted on a floor stand next to the dryer. The floor stand (P/N SCR-FS-
004) is supplied with a Vacuum Takeoff Box, a 1.5” probe and 5” casters. Dried material can be
transferred to the process machine with a Machine Mount Loader.
Connect power to the dryer according to the nameplate, which is located on the frame or
control box of the dryer.
Connect the required electrical power according to plant, local and state electrical
codes and regulations. Electrical installation should only be performed by a qualified
electrician.
3.0 DESCRIPTION OF OPERATION
NDB dryers are designed to be a simple, compact and easy to use for drying of plastics in
cases where the throughput is 50 lb./hr. or less.
Moist air is drawn from the drying hopper by the blower assembly and it
is directed through the valve assembly and into one of the desiccant beds. Moisture is
adsorbed by the desiccant and the dry, low dew point air is blown across the process heater,
heated to the desired temperature, and discharged from the dryer. A small portion of this air is
diverted back through the second desiccant bed instead of traveling through the process
heater. This air is heated by the regeneration heater, which is buried in the desiccant bed. The
hot air regenerates the desiccant and carries away the moisture through the regeneration air
exhaust port.
At the end of the regeneration heating cycle, the regeneration heater is shut down but the dry
purge air continues to flow. This helps to carry some of the excess heat of regeneration away
from the desiccant bed, allowing it to cool in preparation for the adsorption cycle.
At the end of the timed 4-hour adsorption period a simple shift of the solenoid valve causes the
diverter valve to change position. The freshly regenerated bed now begins adsorbing moisture
and the other bed is regenerated. Just one blower (the process blower) is required for both the
process and regeneration functions and it runs continuously when the dryer is on.

NDB-15-50 IM 28 FEB 2018 © 2018 NOVATEC, Inc. All Rights Reserved Page 6
4.0 INITIAL START- UP PROCEDURE
Fill the hopper completely with material and adjust the temperature
controller to 60º F. Push the on/off switch to the “ON” position and check the blower for proper
rotation by observing the rotation of the motor at the end facing the control box. The proper
rotation is indicated by an arrow on the blower housing.
Allow the unit to dry-cycle for 24 hours with the hopper filled with material before operating. This
will allow the moisture adsorbed by the desiccant during transit or inactivity to be discharged.
Failure to dry cycle the unit may cause drying problems with the material. It is necessaryto have
material in the hopper in order for the regeneration cycle to function properly.
5.0 OPERATING PROCEDURE
After the initial start-up period, adjust the temperature controller to the drying temperature
necessary for the material to be dried. Dry the plastic pellets for the required residence period,
which is generally two to six hours depending on the material.
After the residence period is complete, the material is dry and ready for processing. As dry
material is withdrawn from the bottom, additional material should be added to the hopper at the
same rate. (NOTE: It is extremely important to keep the hopper as full as possible for proper
drying.)

NDB-15-50 IM 28 FEB 2018 © 2018 NOVATEC, Inc. All Rights Reserved Page 7
6.0 MONITORING PLC CYCLE
•Press ESC button on the Mini PLC
•Press the ⇓arrow to the Set Param line.
•Press OK button. Main counter B1 should display with Cnt value at bottom of the screen
•Cnt value represents current count in minutes for the total cycle. If counter B1 fails to display,
press ⇓or ⇑arrows until B1 displays with Cnt value.
•To fast cycle advance counter B1 connect the 115V hot wire to PLC input I2.
•Check schematic diagram for wires numbers to jump for fast cycle advance. Each
1 minute count becomes 1 second in the fast advance mode.
•On initial start fast advance B1 counter to 0 or 1 counter value. Reference the chart below for
sequence of operation.
6.1 8- Hour Sequence of Operation
Time
Counter, B1
8 Hour Cycle
0 Hour, 0 Minute
0
Bed shift, left bed drying, overtemp alarm inactive.
0 Hour, 1 Minute
1
Right bed regen heater on.
0 Hour, 20 Minute
20
Overtemp alarm active.
1 Hour, 37 Minute
97
Right bed regen cooling, regen heater off.
4 Hour, 0 Minute
240
Bed shift, right bed drying, overtemp alarm inactive
4 Hour, 1 Minute
241
Left bed regen heater on.
4 Hour, 20 Minute
260
Overtemp alarm active.
5 Hour, 37 Minute
337
Left bed regen cooling, regen heater off.
8 Hour, 0 Minute
480
Bed shift, left bed drying.
6.2 PLC Counter Settings
Counter
ON Value
OFF Value
Description
B1
480
0
Cycle reset
B3
0
240
Bed shift
B4
241
337
Left bed regen heater
B5
1
97
Right bed regen heater
B7
240
260
Right bed drying alarm delay
B8
0
20
Left bed drying alarm delay

NDB-15-50 IM 28 FEB 2018 © 2018 NOVATEC, Inc. All Rights Reserved Page 8
7.0 TEMPERATURE CONTROLLER
RKC Brand, Model: RF-100, NOVATEC Part Number: 02275 (Replaces RKC Rex C-100)
7.1 Overview
7.2 Initial Settings
•To enter Engineering mode: Press RUN/STOP key for more than 2 seconds to change from
RUN to STOP, STOP lamp turns on.
•Press & hold SET & RUN/STOP simultaneously until F00 displays.
•Continue to press SET until MODE displays. Change MODE setting to 0128, this allows
access to engineering parameters above F09.
•Press SET until F00 displays, press UP/DOWN arrow keys until Function Block to be
accessed appears.
•Press SET to scroll through parameters of each function block.
•Press UP/DOWN arrow keys to change values than return to Function Block.
•Press UP/DOWN Arrow keys to move to next Function Block.
•After parameters have been changed, return to F00 change MODE setting back to 0.
•Exit Engineering mode the same way it was entered.
•Press RUN/STOP key for more than 2 seconds to change from STOP to RUN, STOP lamp
turns off.

NDB-15-50 IM 28 FEB 2018 © 2018 NOVATEC, Inc. All Rights Reserved Page 9
7.3 Parameter Settings
To access the parameter setting mode...Press the SET key for more than five seconds; (AL1)
will display. Scroll through the parameters with the SET key. Exit parameter set mode the
same way it was entered.
7.4 Excerpt from RKC REX C-100 Operation Manual

NDB-15-50 IM 28 FEB 2018 © 2018 NOVATEC, Inc. All Rights Reserved Page 10
8.0 TROUBLE SHOOTING GUIDE
Most drying problems are the result of dirty filter(s), air leaks, desiccant contamination and
malfunctioning regeneration heaters. It is seldom that other components fail.
PROBLEM INVESTIGATE
Machine won’t start A, B, C
Inadequate or no E, F, G, H, I
Regeneration heat
Inadequate or no D, F, H, I, J
Process heat
Inadequate or no A, E, H, I
Adsorption air flow
Inadequate Dew point E, F, G, H, I, K, L, M
Changeover Temp. too high E, H, I

NDB-15-50 IM 28 FEB 2018 © 2018 NOVATEC, Inc. All Rights Reserved Page 11
CHECK CONDITIONS SOLUTIONS
A. Power supply A. No voltage A. Check field installed
or voltage incorrect disconnect and incoming
power supply.
B. Transformer B. No voltage on primary B. See A
1. No voltage on 1. Check fuse; of ok
secondary. Replace transformer.
C. Stop/Start Switch C. No voltage through C. Replace switch
Switch.
D. Adsorption Motor D. Voltage at motor, D. Replace motor.
amperage incorrect.
E. Mini PLC E. Voltage at PLC E. Check that PLC is in
but no outputs. Start mode & Input I1 is on.
F. Heater Amperage F. Voltage correct F. Replace heater
Reading
1. Voltage incorrect 1. Correct voltage
supply
G. Valve solenoid G. No voltage at solenoid G. See E.
1. Voltage at solenoid
Valves move freely 1. Replace valve
by hand solenoid
H. Filter H. Filter dirty H. replace element
I. Air Duct I. Obstructed I. Remove obstruction
J. Process Heater J. Adjustment incorrect J. adjust
Temperature
Controller 1. No voltage across 1. Replace controller
Switch.
K. Leaks in system K. Air leaks in or out K. Replace gaskets repair
of system. leaks as necessary
L. Desiccant L. Contaminated L. Replace desiccant
1. Saturated 1. Dry cycle for 24 hours.

NDB-15-50 IM 28 FEB 2018 © 2018 NOVATEC, Inc. All Rights Reserved Page 12
9.0 MAINTENANCE AND INSPECTION SCHEDULE
It is recommendedthatmaintenanceand inspectionbedone on a scheduled basis,Maintenance
requirements will naturallyvarywidelyfor each installation and specific operating conditions. Itis
suggestedthata completeinspectionbe performed withnecessarymaintenanceattheend of the
first month, the first three months, and the first six months. These inspections will be indicative of
how often future maintenance will be necessary.
Every Month
A. Inspect air filters. Clean or replace as required. Replace if cartridge is broken. The time
interval for inspection should be shortened if experience indicates unusual dust loading.
B. Check system for air leaks or flow obstructions and correct as required.
Every 3 Months
A. Check heater amperage (see Specification Sheet.)
B. Check Motor amperage (see Specification Sheet.)
C. Checkallelectricalconnections to make sure thattheyhavenotbecomeloose,especially
those connections at contactors, motor starters, and heater elements.
Once Every Year
Check Solenoid valve operation and operation of valve.
Every 2 Years or as needed
Remove top cover of dryerand replace desiccant.Use high temperature silicon caulking to reseal
the cover. (See specification page for the amount of desiccant.)

NDB-15-50 IM 28 FEB 2018 © 2018 NOVATEC, Inc. All Rights Reserved Page 13
10.0 RECOMMENDED SPARE PARTS
The following parts are common to all NDB Series dryers and it is recommended that spares
be kept on hand.
ITEM PART NUMBER RECOMMENDED QUANITY
Temperature Controller 02275 1
Solenoid 00767 1
Logo PLC 09029 1
Solid State Relay, 50A 09007 1
Filter Element 00813 1
Additional Recommended Spares:
ITEM DRYER PART NUMBER QTY
Desiccant NDB-15-T 00246 7 lb.
Desiccant NDB-25-T 00246 20 lb.
Desiccant NDB-50-T 00246 40 lb.
Fuse, 2A, Slo-Blow 460/3/60 VAC 00812 3
Thermocouple 00984 (2.5 ft.) 1
Process Htr. Element
NDB-15-T (115V) 00781
NDB-25-T (460V) 00833 1
NDB-50-T (460V) 00933
Regen. Htr. Element
NDB-15-T (115V) 00779
NDB-25-T (460V) 00832 2
NDB-50-T (460V) 00832 4

NDB-15-50 IM 28 FEB 2018 © 2018 NOVATEC, Inc. All Rights Reserved Page 14
11.0 WARRANTY
WARRANTY – NOVATEC, INC. - Effective Date 19 FEB 2018
NOVATEC, INC.offersCOMPREHENSIVE PRODUCTWARRANTIESonallof
ourplasticsauxiliaryequipment. Wewarrant eachNOVATEC manufacturedproduct
to be free from defects in materials and workmanship, under normal use and
service for the periods listed under “Warranty Periods”. The obligation of
Novatec, under this warranty, is limited to repairing or furnishing, without
charge, a similar part to replace any part which fails under normal use
due to a material or workmanship defect, within its respective warranty
period. It is the purchaser’s responsibility to provide Novatec with
immediate written notice of any such suspected defect. Warranted
replacement parts are billed and shipped freight pre-paid. The purchaser
must return the suspect defective part, freight prepaid and with identifying
documentation to receive full credit for the part returned. Novatec shall not be
held liable for damages or delay caused by defects. No allowance will be
made for repairs or alterations without the written consent or approval of
Novatec.
The provisions in equipment specifications are descriptive, unless
expressly stated as warranties. The liability of Novatec to the
purchaser, except as to title, arising out of the supplying of the said
equipment, orits use, whether basedupon warranty, contract or negligence,
shall not in any case exceed the cost of correcting defects in the
equipment as herein provided. All such liability shall terminate upon
the expiration of said warranty periods. Novatec shall not in anyeventbe
held liable for any special, indirect or consequential damages.
Commodities not manufactured byNovatec are warrantedandguaranteed
to Novatec by the original manufacturer and then only to the extent that
Novatec is able to enforce such warranty or guaranty. Novatec, Inc.
has not authorized anyone to make any warranty or representation
other than the warranty contained here. Non-payment of invoice beyond 90
days will invalidate the warranty. A renewed warranty can be purchased directly
fromNovatec.
Please note that we always strive to satisfy our customers in
whatever manner is deemed most expedient to overcome any
issues in connection with our equipment.
Warranty Periods:
Note: All warranty periods commence with the shipment of the
equipment to the customer.
Please note that we always strive to satisfy our customers in whatever manner is deemed most expedient to overcome any issues in
connection with our equipment.
Warranty Periods:
Note: All warranty periods commence with the shipment of the equipment to the customer.
5-Year (Except 1-Year on Non-Novatec Buy-Out Items)
Resin Drying to Include
NovaWheel™ Dryers *
Dual Bed Dryers
NovaDrier *
NDM-5 Membrane Dryer
Gas-Fired Process Heaters
Gas-Fired Regeneration Heaters
Drying Hoppers
Central Drying Hopper Assemblies
Heater/Blower Units and Hot-Air Dryer
Silo Dehumidifiers
NovaVac Dryers *
Resin Blending and Feeding to Include
WSB Blenders, MaxiBatch & Feeders *
Gaylord Sweeper Systems
Downstream Extrusion Equipment to Include
C and NC Bessemer Series Cutters
NPS Bessemer Series Pullers
NPC Mini Puller/Cutter
All NS Series Servo Saws
All Cooling and Vacuum Tanks Manufactured by Novatec
Nitrogen NovaDriers (Nitro)
DryTemp Plus
Central System Controls to Include
FlexTouch™ Series Controls
FlexXpand™ Series Controls
OptiFlex™ Series Controls
PLC Communications Modules
Greenboard Communications Modules
LOGO! Mini PLC
MCS-600 Series Controls – (Distributed I/O)
MCS-400 Series Controls
CL Silo Manager
Moisture Measurement Equipment to Include
MoistureMaster®
PET Resin Crystallizers
Resin Conveying and Systems Components to Include
GSL Series Vacuum Loaders
GlassVu Loaders, Receivers and Hoppers
VL/VLP Series Loaders
VRH, VR, VR-FL & VRP Series Receivers
Compressed Air Loaders
AL-B Barrel Loader
Cyclone Dust Collectors
Conveying System Accessories
Surge Bins
Valves and Accessories
Electronic Metal Separators
Quick Select Manifolds
Tilt Tables
Filter Dust Collectors
Drawer Magnets
Velocity Control Valves
3-Year
Resin Conveying System Components to Include
** VPDB Vacuum Positive Displacement Pumps
** SVP Vacuum Pumps
** MVP Vacuum Pumps
** Railcar Unloading Systems
**5-Year Extended Warranty- When a MachineSense® data plan is activated for products with **, Novatec automatically extends the warranty to 5
years. The data plan must be activated within 60 days after product shipment, and remain active through the warranty period to maintain extended warranty
eligibility. The first 6-months of data plan usage is free from Novatec.
1-Year
Infrared Dryers
UltraVac Vacuum Pumps
Vacuum Regenerative Blower Pumps
Custom Equipment of any kind unless otherwise specified

Exclusions:
Routine maintenance/replacement parts are excluded from the warranty. These include, but are not limited to: hoses, desiccant, filters, filter
elements, wiper seals, gaskets, dew point sensors, infrared lamps, motors, internal solenoids, fuses and motor brushes. Use with abrasive
materials will void the warranty of any standard product. Wear resistant options may be available to extend usable service life with abrasive
materials. Novatec reserves the right to limit the warranty if the customer installs replacement parts that do not meet the specifications of the
original parts supplied byNovatec.
*Specific Exclusions:
1. NovaDrier™ and NITROdry™ warranty is void if coalescing filters are not replaced on a 6-month or yearly basis (per
instruction manual) and/or membrane has been exposed to ozone.
2. NovaVac Dryer -The ability of the canisters to hold vacuum will be compromised if the vacuum seal edge is damaged
from mishandling. We do not warrantycanisters damaged from improper handling. We do, however, warranty the seals.
3. LOAD CELLS on our WSB’s are covered by Novatec standard warranty as long as they have not been damaged from
improper handling.
4. Desiccant Wheel Warrantywill be void if the wheel has been exposed to plasticizer, dust or other contaminants as a result
of negligence on the part of the processor.
5. DryTemp+ - We assume no responsibility from equipment failures resulting from untreated or improperly treated water.
This warranty shall not apply to equipment:
1. Repaired or altered without written approval of NOVATEC unlesssuchrepairoralteration
was, in our judgment, not responsible for the failure
2. Which has been subject to misuse, negligence, accident or incorrect wiring by others
3. Warranty is void if processing rates exceed manufacturer-recommended levels or if damage is caused by
ineffective power isolation and/or power spikes/sags or incorrect installation.
NOTE: All conditions and content of this warranty are subject to changes without notice.
