Mail Boss DROP BOX User manual

Use Phillips Head screwdriver to remove handle
from inside of bin door and use provided screws
to attach handle to outside of bin door.
1
1
Have a question?... Need a part ASAP?...1-800-589-7990
Copyright © 2019 Epoch Design™ All rights reserved
We strongly recommend that you WRITE DOWN YOUR KEY NUMBER and keep it in a safe place.
Without a key number we will not be able to provide replacement keys, you will have to purchase a new
lock and keys set. For security purposes, we reserve the right to deny key replacement without proof of
purchase. Additional keys can be purchased at Mailboss.com
The Wall Mount Bin Style Locking Drop box is designed for your security and convenience.
This drop box is constructed of heavy duty galvanized steel and is designed to be installed on a
vertical wall where items may be delivered.
Below you will find a list of hardware parts and detailed installation instructions.
Please take the time to carefully sort the hardware and familiarize yourself with the function of
each piece for ease of installation. Typical installation hardware has also been provided for your
convenience. Since concrete is a hard surface, take proper care when installing this hardware
into hard surfaces, making sure not to break the drill bit or screws provided. An electric drill may
be required for hard surface installation.
If you require assistance with assembly, part replacement, or any other matter, contact the
toll-free Epoch Design Service Center from anywhere in the Continental United States,
Monday through Friday, 9 AM - 5 PM Pacific Standard Time at 1-800-589-7990. You may also
email your request or comments to [email protected] and a service representative will respond.
You will also find helpful hints and tips on our website: www.mailboss.com.
®
DROP BOXDROP BOX
Thank you.
1/2
Parts and Hardware List
4Mounting screws
Connect drop box to any wall
Drop Box mailbox
Locking security mailbox
1
TORX (T25) Drive Bit
Used to drive screw into hole.
1
Security keys
Used to lock and unlock
your Drop box
3
4 mm drill bit
For drilling holes into
concrete, brick,
mortar or wood
1
Please note that it is not the responsibility of mail carriers to open mailboxes that are locked, accept keys for this purpose or lock mailboxes after delivery.
4Rubber Grommets
Already inserted in the box.
Steel Washers
Used with mounting screws.
4
01-May-2019
LOCKING SECURITY MAILBOXES
MAIL BOSS®
Rain Guard
weather shield
1

Carefully place the box on the wall at about 130 cm to 165
cm above the floor, or according to your preference, make
sure it’s level, then mark the center of all four holes.
130 cm to 165 cm
LEVEL
2
2
6.5”
(165.1 mm)
9.6”
(230.19 mm)
Using the 4 mm drill bit provided, create four pilot holes at
least 10 mm deeper than screws provided, or about 40 mm
deep. If the material is unusually hard you may need to use
a rotary impact drill rather than a standard drill to make the
holes. Call a handy man if needed. Put a small amount of
caulk or silicone into each hole.
Place one steel washer onto each of the four screws provided.
Attach the correct socket bit for the screw onto a hand driver or
an electric drill. Now carefully tighten the screws all the way into
the wall. Do not over-tighten or over-torque the screws or you
may break off the screws or strip out the holes.
40 mm
CARE AND MAINTENANCE: Your new Mail Boss mailbox is designed to withstand the elements,
to help preserve the UV and weather coating apply a clear or light colored car wax to the exterior of
the box 2-3 times per year. If your mailbox finish is damaged exposing the metal, we recommend prompt
application of a matching protective paint such as Rust-Oleum to prevent rusting. To preserve your lock
we recommend the application of “Tri-Flow” lubricant to the interior of the lock twice a year. If you live in
an area where dust, debris or salt spray is prevalent, you may consider purchasing a lock dust cover
from mailboss.com for added protection.
3
OPTIONAL: If you’re installing this box in a location without
overhead weather protection, you may wish to install the rain
guard weather shield on the top of your box for added
moisture protection. Simply remove the adhesive backing
from the rain guard and install upon the front of the upper
ledge of the box, with the lip overhanging the upper door.
5
3
4
4
Have a question?... Need a part ASAP?...1-800-589-7990
Copyright © 2019 Epoch Design™ All rights reserved
®
DROP BOXDROP BOX
2/2 01-May-2019
LOCKING SECURITY MAILBOXES
MAIL BOSS®
