mainnav MG-950d User manual

MG-950d Sport GPS

1
Table of content
A. Quick Use ---------------------------------------------------------------------------- 2-5
B. Introduction ---------------------------------------------------------------------------- 5
C. Feature ---------------------------------------------------------------------------------- 6
D. Specification -------------------------------------------------------------------------- 6
Physical Dimension------------------------------------------------------------------------ 6
Environmental Characteristics---------------------------------------------------------- 6
GPS-------------------------------------------------------------------------------------------- 6
LED Status ---------------------------------------------------------------------------------- 7
Bluetooth ------------------------------------------------------------------------------------ 7
Position accuracy -------------------------------------------------------------------------- 7
Interfaces------------------------------------------------------------------------------------- 7
Connector------------------------------------------------------------------------------------ 7
Battery---------------------------------------------------------------------------------------- 7
Accessory ----------------------------------------------------------------------------------- 8
Certification: -------------------------------------------------------------------------------- 8
Warranty ------------------------------------------------------------------------------------- 8
E. Operational characteristics-------------------------------------------------------- 8
F. Safety Statement----------------------------------------------------------------------- 9
G. Earth Datums &output setting --------------------------------------------------- 10-12
H. GMT Time Zone setting --------------------------------------------------------- 13-16
I . Bike mounting installs -------------------------------------------------------------
17-18

2
A.Quick use
1.Standard package
Rechargeable battery, 850mAh
Car charger: Mini USB , IP:12~24V, OP:5V 500mA
Software
Bike mounting
USB cable
Warranty card
Travel charger
2. 8 hours full charge is required before using (recommendation)
Fully charge the battery for at least 8 hours before using can last for 8 hours continuously
operation facilitating the low power consumption design at 66 mA .
3. GPS Start to get GPS signal --- when power on , the unit will automatically search GPS
signal . About 42 seconds , the GPS fixed the signal
4.Found a shortcut automatically in Bluetooth Manager window
When unit is on, the Bluetooth is on too.
The system will automatically set up quick connect device, Mainnav in Bluetooth Manager.
Further step, click the device to connect Bluetooth receiver.
5.Check the Serial Port in Bluetooth Setting and Set up correct Serial Port in your
map software
Click Serial Port to confirm the COM port after pairing with the receiver. Using PDA / PC to
pair the receiver. Start your map function and choose the right serial port and select
“Outbound COM port “. The pass word for paring is “0000”.
6. GPS data logger
Turn on the MG-950d and press Power button then enter data logger recorded system, start
to record your journey. Stop the data logger function, press “Power” button, it will turn off.
Check the GPS data—Using USB cable connect MG-950d to your PC (please install
Mainnav software application), then you could view recorded data on Google Maps. For
detail instruction , please check CD ( software instruction)

3
7 . Others
Car charger --
Make sure use Mainnav car charge or it could not transmit GPS data in car
When charge the device , the unit could not turn on ( protect circuit )
8. LCD display
Current Speed/Elevation Speed/time Speed/total mileage Speed/ trip time
Speed/moved distance Speed/average Speed Speed/ Maximum speed Clear the data
GPS signal Bluetooth on Data logger on Memory full backlight on Power

4
9.Button intro
10. Function switch
Operation display Definition
Press Power button around 3 seconds Power on Stay on –GPS and Bluetooth
is on too
When you see this mark , that means GPS is fixed GPS fixed
When Power on , press power button 3
seconds------ the data logger is on , you will see the
flag on the top of screen
Press power button3 seconds again-----the data
logger will off.
Data logger is on
Data logger is off (no flag
mark)
Press back-lighted button 3 seconds ---
Back-lighted is on
Press 3 second again---- Back-lighted is off
Back-lighted is on
Back-lighted is off
When unit on ,press back-lighted button 12 Clear all data (except time)
Power
Back- lighted
Touch Pad
USB Port

5
seconds
Press back-lighted button 12 seconds----Total
mileage turns zero
Power on
Total mileage turns
Zero(ODO)
When Power on, press two buttons together -----
switch to metric and imperial(mph)/(kph)
Adjust time Zone
When Power off , press 2 buttons together
3seconds ---- Adjust time zone by Power button,
setting by backlight button.
Adjust time Zone
Touch pad–Touch , it could scan to each function Touch –Move to next page
and show different data
Press this button 5 seconds Auto scan for each page
When power is low, the battery will be flash. This
mean battery still have one hour left
Flashing --One hour left
Bluetooth – When pairing your device, the top of
screen will show BT mark.
When Unit is on, BT is on ,
too.
Log time—when move the logger, it records tracks
in every 1 second. If did not move, the tracks will
be record in every 1 minute.
Move – logging every 1
second
moveless—logging every 1
min
When see this mark , the memory is full
B. Introduction
MG-950d is marvelous Sport GPS with data logger. The chip designed based on SiRF Star
III LP which provides the high sensitivity for personal navigation and the wireless Bluetooth
transmission in the world.
This new gadget with LCD monitor is ideal for biking, driving and long journey. User could
easy to view the screen while workout such as total mileage/kilometer, moved time,
elevation and speed. This new device is compact and easy to carry.
MG-950d is a small, robust unit that records NMEA position data from a GPS. It is really

6
convenient, economical alternative to using a laptop computer especially on long road.
Simply connect the logger to a GPS during your trip then download the track data to a PC.
Also, our photo map part is one of brilliant function, User could match photo in certain
waypoint by their own which show on Google earth.
C. Feature
Store up to 260,000 waypoints
LCD display and Touch pad
Automatically change to next page
Absolutely cycle computer upgrading
SiRF Star III Hot start 6 sec, warm start 38sec, cold start 42 sec
Calculates precise speed and distance while you biking
Record track-logs of vehicle movement
User can select among Google earth, Satellite or Hybrid to show the track
Built-in GPS application software, could save as KMZ, CSV, GPX and NMEA
Integrated Photo with Mainnav Software
Transmission data via USB and Bluetooth
Weather Proof IPX6
Bluetooth—pair PDA or smart phone for navigation.
Replay the recorded routes/ time/ speed... point by point
Lightweight and compact --suitable for biking, hiking and traveling.
D. Specification
PhysicalDimension
Size: 73(L)X49(W)x21 (H) (mm)
LCM: 33(mm)X 33(mm)
Weight:70g
Environmental Characteristics
1. Working temperature: -20oC to +75oC (internal temperature).
2. storage temperature: -55oC to +90oC.
3. input voltage: 5.5 ± 0.5VDC
4. Backup power: 3.7V Rechargeable Li-ion Battery 850mAh,
GPS
1) Acquisition:20 channel parallel
2) Tracking: up to 12 satellites
3) Update rate: 1 second
4) Acquisition time

7
Reacquisition 0.1 sec, averaged
Snap start 3 sec, averaged
Hot start 6 sec, averaged
Warm start 38 sec, averaged
Cold start 42 sec, averaged
Bluetooth
1) Transmits up to 10 meters.
2) Version V2.0
Position accuracy:
1.Non DGPS (Differential GPS)
Position: <10 M at 2D RMS
Velocity :0.1 meters/second, with SA off
Time:1 microsecond synchronized GPS time
2. DGPS (Differential GPS) or WAAS / EGNOS ON (Built by demand)
Position: 1 ~ 5 meter, typical
Velocity: 0.05 meters/second, typical
3. Dynamic Conditions:
Altitude: 18,000 meters (60,000 feet) max
Velocity: 515 meters / second (1000 knots) max
Jerk: 20 meters/second, max
Acceleration: 4 G, max
Interfaces
1) USB 2.0 Bluetooth 2.0
2) NMEA 0183 Version 2.2 ASCII output (GPGGA, GPGLL, GPGSA, GPGSV, GPRMC,
GPVTG).
3) Real-time Differential Correction input (RTCM SC-104 message types 1, 5 and 9).
(Optional model)
SiRF protocol. (optional)
Baud rate 9600
Connector
Battery recharging connector: Mini USB
Battery

8
Capacity: 850mAh.
Type: Li-ion rechargeable
Normal use: 12 hours
Accessory
1. Rechargeable battery, 850mAh
2. Car charger: Mini USB , IP:12~24V, OP:5V 500mA
3. Software
4. bike mounting
5. USB cable
6. Warranty card
7.Travel charger
Certification:
RoHs
CE&FCC
§Federal Communications Commission (FCC) Statement
15.21
You are cautioned that changes or modifications not expressly approved by the part responsible for
compliance could void the user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:

9
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
Operation is subject to the following two conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference that may cause undesired
operation of the device.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specific operating instructions for satisfying RF exposure
compliance. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Warranty
All of our GPS products have the one-year warranty and repair policy from the day of
purchase.
The MG-950d is warranted to be free from defects in material and function for one year from
the date of purchase. Any fault product within this period under normal conditions will be
replaced without any charge.
E. Operational characteristics
Initialization
Once the initial self-test is complete, MG-950d start the process of satellite acquisition and
tracking automatically. MG-950D takes about 45 seconds to achieve a position fix in normal
circumstances. After a position fix has been calculated, valid position, velocity and time is
transmitted over the output channel.
Also, our MG-950d records NMEA position data from a GPS. It is really convenient,
economical alternative to using a laptop computer, especially on long road. Simply connect
the logger to a GPS during your trip then download the track data to a PC.
Data logger
1. LCD screen which shows speed altitude/latitude

10
2. Reads NMEA data from GPS
3. Compact size and lightweight
4. Store up to 260,000 waypoints
5. User friendly Windows based Mainnav software
6. Whether proof IPX6
7. With user friendly Windows based Google earth software
8. Replay the recorded routes/ time/ speed... point by point
Navigation
With the acquisition process is completed, the MG-950d sends valid navigation information
over output channels. The data include:
1) Velocity
2) Error estimates
3) Date/time
4) Latitude/longitude/altitude
5) Satellite and receiver status F. Safety Statement
R&TTE / CE
This device complies with ETSI EN 300 328-1, ETSI EN 301 489-1 / 17, EN60950.
FCC
This device complies with Part 15C, Part 15B and ID Application of the FCC rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may
cause undesired operation.
RoHS G. Earth Datums &output setting

11
NMEA Transmitted Messages Output Messages NMEA Sentence
GPGGA: Global positioning system fixed data
GPGLL: Geographic position latitude \ longitude
GPGSA: GNSS DOP and active satellites
GPGSV: GNSS satellites in view.
GPRMC: Recommended minimum specific GNSS data
GPVTG: Course over ground and ground speed
Global Positioning System Fix Data
$GPGGA,161229.487,3723.2475,N,12158.3416,W,1,07,1.0,9.0,M, , ,0000*18
Name Example Units Description
Message ID $GPGGA GGA protocol header
UTC Time 161229.487 Hhmmss.sss
Latitude 3723.2475
ddmm.mmmm
N/S Indicator N N=north or S=south
Longitude 12158.3416 dddmm.mmmm
E/W Indicator W E=east or W=west
Position Fix
Indicator 1 See Table 5-3
Satellites Used 07 Range 0 to 12
HDOP 1.0 Horizontal Dilution of Precision
MSLAltitude 9.0 Meters
Units M Meters
GeoidSeparation Meters
Units M Meters
A
ge of Diff. Corr. second Null fields when DGPS is not used
Diff.Ref.StationID 0000
Checksum *18
<CR> <LF> End of message termination
Position Fix Indicator

12
Value Description
0 Fix not available or invalid
1 GPS SPS Mode, fix valid
2 Differential GPS,SPS mode, Fix valid
3 GPS PPS Mode, Fix valid
GNSS Satellites in View
(GSV)$GPGSV,2,1,07,07,79,048,42,02,51,062,43,26,36,256,42,27,27,138,42*71
$GPGSV,2,2,07,09,23,313,42,04,19,159,41,15,12,041,42*41
Name Example Units Description
Message ID $GPGSV GSV protocol header
Number of
Messages 2 Range 1 to 3
Message Number 1 Range 1 to 3
Satellites in View 07 Range 1 to 12
Satellite ID 07 Channel 1 (Range 1 to 32)
Elevation 79
degrees Channel 1 (Maximum 90)
Azimuth 048
degrees Channel 1 (True, Range 0 to 359)
SNR (C/No) 42 dBHz Range 0 to 99, null when not tracking
Satellite ID 27 Channel 4 (Range 1 to 32)
Elevation 27
degrees Channel 4 (Maximum 90)
Azimuth 138
degrees Channel 4 (True, Range 0 to 359)
SNR (C/No) 42 dBHz Range 0 to 99, null when not tracking
Checksum *71
<CR> <LF> End of message termination
Recommended Minimum Specific GNSS Data (RMC)
$GPRMC, 161229.487,A,3723.2475,N,12158.3416,W,0.13,309.62,120598, ,*10
Name Example Unit Description
Message ID $GPRMC RMC protocol header
UTC Time 161229.487 hhmmss.sss
Status A A=data valid or V=data not valid
Latitude 3723.2475 ddmm.mmmm
N/S Indicator N N=north or S=south
Longitude 12158.3416 dddmm.mmmm

13
E/W Indicator W E=east or W=west
Speed Over Ground 0.13 Knots
Course Over
Ground 309.62 Degrees True
Date 120598 ddmmyy
Magnetic Variation (1) Degrees E=east or W=west
Checksum *10
<CR> <LF> End of message termination
H. World GMT Time zone setting
MG-950d time zone setting is from 1~24 hour but in GMT time zone is from +1~+12
and -1~-12. For Mainnav device, time zone from -1~-12 will be deducted from 24
hours. Example : USA –New York GMT is -4，on MG-950d need to set 20. After setting
time zone, the GPS will record correct time.
North America
Country Time zone GMT
Newfoundland(NST) -3:30
(St. Johns) -2:30
UTC-4 AST -4
(Goose Bay) -3
EST -5
Toronto -4
CST -6
Winnipeg -5
MST -7
Calgary -6
PST -8
Canada
Vancouver -7
Nicaragua -6
Guatemala -6
Honduras -6
EST -5
U.S.A. New York -4

14
CST -6
Chicago -5
MST -7
Salt Lake City -6
PST -8
Los Angeles -7
AKST -9
Anchorage -8
HST -10
Honolulu -9
Costa Rica -6
El Salvador -6
Oceania Area
Country Time zone GMT time zone
12
New Zealand 13 ( October ~ March is
daylight saving time )
AEST 10
10
Sydney 11(from Apr to Oct , from Oct
to March is daylight saving
time
ACST +9:30
Adelaide +10:30
WST 8
(Australia)
Perth 9
Guam 10

15
European Country Country GMT time zone
1
(Denmark) 2(Mar to Sep is daylight saving
1
Belgium) 2(Mar to Sep is daylight saving)
(Iceland) 0
1
(Hungary 2(Mar to Sep is daylight saving)
1
(Spain 2(Mar to Sep is daylight saving)
1
Greece 2(Mar to Sep is daylight saving)
1
Poland 2(Mar to Sep is daylight saving)
1
France 2(Mar to Sep is daylight saving)
2
Finland 3(Apr to Oct is daylight saving)
0
Great Britain
GMT 1 (Mar to Oct is daylight saving time )
1
Norway 2 (Mar to Sep is daylight saving time )
1
Czech 2(Mar to Sep is daylight saving time)
1
Vatican 2(3-9 is daylight saving time)
1
Netherlands 2(3-9 is daylight saving time)
1
Slovak 2(3-9 is daylight saving time)
Austria 1

16
2(3-9 is daylight saving time)
1
Switzerland 2(3-9 is daylight saving time)
1
Sweden 2(3-9 is daylight saving time)
1
Italy 2(3-9 is daylight saving time)
1
Germany 2(3-9 is daylight saving time)
1
Monaco 2(3-9 is daylight saving time)
1
Luxembourg 2(3-9 is daylight saving time)
Asia Area
Country GMT time zone
2
Turkey 3 (5-10 is daylight saving time)
China 8
Japan 9
Nepal +5:45
Indonesia 8
Thailand 7
Malaysia 8
Philippines 8
Singapore 8
Africa
Country GMT Time zone
South Africa 2
Egypt 2

17
Attachment for Bike mount
1 find a position to fix on Handle bar
2 Using screw Combine these two together
3.Fix the rubber under the holder
4. put string through the holder

18
5.Fix on the handle bar – circle on the handle bar
6. tight on the handle bar and cut the over string part
7.Put the device on bike mount and finish attachment
